CMOSTEK CMT216 Series User manual

Copyright © By HOPERF
Rev 0.6 | 1/32
www.hoperf.com
Overview
CMOSTEK CMT216x offline writer (hereinafter referred to as Burner or Writer) is a high efficiency production
tool which copy the user program and configuration parameters to the NextGenRFTM CMT216x chip storage.
CMOSTEK CMT216x offline writer supports for single machine manual recording and automatic batch
recording.
This document introduces basic function, using process as well as using notice of the recorder.
Table 1. Part number covered in this document
Part Number
Single
ended PA
Differential
PA
12-Bit
ADC
Operational
Amplifier
Low Frequency
Wake up
External
32.768 kHz
Package
CMT2160A
4-ch
SOP14
CMT2163A
9-ch 
TSSOP28
CMT2168A 
12-
ch
QFN32
CMT2189D
 8-ch
QFN20
CMT2189BE
 4-ch
SOP14
CMT216x Offline Writer Operating Guide
AN279

AN279
Rev 0.7 | 2/32
www.hoperf.com
Table of Contents
1Offline Writer Kit Content............................................................................................................................................ 3
2Hardware Introduction ................................................................................................................................................ 4
2.1 Offline Writer Host Panel.......................................................................................................................................4
2.1.1 Description of the front view of each component on the offline writer panel............................................4
2.1.2 Interface description of the offline writer back view.................................................................................6
2.2 LCD Display Information .......................................................................................................................................7
2.2.1 Offline burner startup initialization display information............................................................................7
2.2.2 Offline writer display information.............................................................................................................7
2.3 Indicator and Beeper status description................................................................................................................8
2.4 Description of burning control interface and connection mode............................................................................10
3Offline burning operation and description.............................................................................................................. 13
3.1 Basic operation ...................................................................................................................................................13
3.2 Use WriterConfig for program and configuration download.................................................................................13
3.2.1 Burning option description.....................................................................................................................14
3.2.2 User-defined serial number (SN) increment function and settings........................................................15
3.2.3 EEPROM initial burning value inside chip.............................................................................................16
3.2.4 WriterConfig Interface Description ........................................................................................................18
4Online Burning Operating Mode .............................................................................................................................. 21
5Firmware Upgrade and Degrade Function .............................................................................................................. 24
5.1 Firmware Upgrade ..............................................................................................................................................24
5.2 Firmware Degrade ..............................................................................................................................................25
5.3 Error Upgrade Handling ...................................................................................................................................... 26
6Using Notice............................................................................................................................................................... 28
7FAQ ............................................................................................................................................................................. 29
8Revise Record............................................................................................................................................................ 31
9Contacts..................................................................................................................................................................... 32

AN279
Rev 0.7 | 3/32
www.hoperf.com
1 Offline Writer Kit Content
Offline writer kit is comprising of the following hardware and software.
Table 2. Hardware and Software of the Offline Writer
Type
Name
Function Description
Hardware
Host machine Fast and efficient offline burning
DC power adapter
Specification is：
Input: AC 100 ~ 240 V 50/60 Hz 0.6 A
Output: DC 9 V 1 A
USB wire USB A type interface->USB B type interface，1.5 m.
They are used to connect the writer to the computer
and induces the chip configuration parameters.
Writer connecting
cable 1 IDC 10P cable，using for connecting the writer
with the chip burn-in socket. (pins)
Software
CMOSTEK
CMT216x
WriterConfig
Operating on the computer and introduces the *.hex
document of chip procedure to the writer.

AN279
Rev 0.7 | 4/32
www.hoperf.com
2 Hardware Introduction
2.1 Offline Writer Host Panel
2.1.1 Description of the front view of each component on the offline writer panel
1
2
3
4
56789
Figure 1. Front View of the Host Panel
Table 3. Description of Components on the Host Panel
Number Name Function
1 Fail（Red Light）Red light indicates programming failed.
2 Busy（Yellow
Light）
Yellow light indicates busy with the following two situations：
1. In burning mode: indicates that the target chip model has been identified
and programming;
2. In USB mode: Information is exchanged between the USB and computer.
3 OK（Green
Light）Green light indicates OK and it will keep light up even after removing the
chip.
4 LCD Display Display information of configuration and programming.

AN279
Rev 0.7 | 5/32
www.hoperf.com
5 Save Key Press this key to manually save the programming counts to Flash
6 - 8 Key of K1 – K3 Reserve keys for subsequent function expansion
9 Start Key Press the key to start programming

AN279
Rev 0.7 | 6/32
www.hoperf.com
2.1.2 Interface description of the offline writer back view
1 2 3 4
Figure 3. Back View of the Host Machine
Table 4. Interface Description of the Host Machine Back View
Number Name Function
1 Burn Connect to the burning chip
2 Comm Connect the automatic machine to control burning. Automatic machine refers to the 3rd party automatic production equipment, which can be connected with the burner
to achieve batch burning.
3 USB Used to connect to the computer, import the burning user procedures and
configuration data
4
Power
Supply 9 V/1
Burner power supply, connected to 9 V/1 A DC power adapter

AN279
Rev 0.7 | 7/32
www.hoperf.com
2.2 LCD Display Information
2.2.1 Offline burner startup initialization display information
The information displayed within 5 seconds after startup are shown in the following figure and table：
1 2 3
Figure 4. LCD display at startup initialization
Table 5. LCD display description at startup initialization
No.
LCD display
character
Description
1 CMT216x Represents CMT216x series chip burner
2 Writer V3.2 Represents the burner hardware version number
3 FV505
Represents the burner firmware version number
2.2.2 Offline writer display information
The offline writer information is displayed as follows.
123
Figure 5. Offline writer display information

AN279
Rev 0.7 | 8/32
www.hoperf.com
Table 6. Burning information display description
2.3 Indicator and Beeper status description
Offline writer uses indicator light and buzzer state to represent the state information in the process of using the
writer. For the indicator state, please refer to the table of components on the panel of the burner host, and the
buzzer state description that shown in the table below
Table 7. Beeper status description
Warning
tone
Tip state Description
“Beep”
once
The burner is ready or
already successfully
burned.
1.
After startup: beep, it means that the recording machine is
ready for USB configuration or chip burning starts.
2. Burning process: beep indicates that burning is successful,
and the green light lights up.
No.
LCD display
character
Description
1
0
（SN setting
disable）
Indicates that the already burned consecutive chip numbers, the values are
based on decimal integer.
Each burn was automatically added to one with a maximum number of
4294967295, and recounted from 0 after exceeding the maximum value.
When WriterConfig downloads the user program and configuration data again,
the count will be cleared to zero.
FFFF0123456789B5
（SN setting enable）When SN Settings Enable，it will display the current SN number to be burned.
2 CMT216xA Series number, covering the applicable chip model: CMT2168A、
CMT2163A、CMT2160A、CMT2189BE、CMT2189D
3 7_0 The corresponding value for burn options (tick)
18AB Represents the checksum of the contents of the burn program.

AN279
Rev 0.7 | 9/32
www.hoperf.com
“Beep”
twice
Burning failed After the recording is completed, “beep” twice, and the LCD screen prompts recording failed and red lights on, it indicates that the
burning has failed.
The identification model
does not match
If the chip is identified while the model is not consistent with the
configured parameter, the system beeps twice and displays a
message on the LCD screen, it indicates that the model does not
match.
Verification error while
burning programs or
configuring data
When the burning program or configuration data source verification
error, “beep” twice, and LCD screen information prompts
verification error, please reload user program and configuration
data.

AN279
Rev 0.7 | 10/32
www.hoperf.com
2.4 Description of burning control interface and connection mode
The burning control interface includes two parts: burning and automation control. For manual control burning,
it only needs to connect the chip by pressing the start button. For batch burning, the chip and automaton
control are connected as follows:
1. Burning interface
The burning interfaces are shown in the following figure and table:
Figure 6. Burning interface
Table 8. Burning interface description
Pin No. Pin name Description Connect to chip pin
1 CSB Selected signal
B2 / S3S_CSB
CSB
2 GND Ground
GND
GND
3 - -
-
-
4 VDD Chip power supply
VDD
VDD
5 CLK RF serial clock signal
B3 / S3S_CLK
SCL
6 - -
-
--
7 DIO RF serial port data signal
B4 / S3S_DIO
SDA
8 - -
-
-
9 - -
-
-
10 VPP Voltage output regulating
B1 / VPP
-
Note
：
Due to the high speed of the burning port signal, connecting line between the recorder and chip needs to
use the same length of flat cable or Dupont line to ensure that the signal timing is correct.

AN279
Rev 0.7 | 11/32
www.hoperf.com
2. Automatic control interface
Connect the burner automatic control interface with the automatic machine through wire, and the automatic
machine sends out the start signal to trigger the burning, and detect the OK, BUSY, FAIL status signal sent by
the burner to control the operation of the machine, and then carry out automatic batch burning. The
connection mode of the burner automatic control interface and the automatic machine is shown in the figure
and table below:
Figure 7. Automatic control interface（Comm interface）
Table 9. Description of the automatic control interface
Pin No. Pin name IO Description
Connect to host
machine
1 FAIL O
Indicates output is failed and low level
is valid.
Fail
2 GND GND Ground GND
3 BUSY O
Indicates that the burner is busy and
low level is effective.
Busy
4 - - - -
5 OK O
Indicates burning successfully and low
level effective.
Ok
6 - - - -
7 START I
Burning trigger signal, low level
effective. Low level duration should be
greater than 30 ms and less than 50
ms
Start
8 - - - -
9 3.3 V O 3.3 V power supply output -
10 - - - -
START
OK
FAIL
200ms
400ms
400ms
Waiting time
Figure 8. Burning automatic control sequence diagram

AN279
Rev 0.7 | 12/32
www.hoperf.com

AN279
Rev 0.7 | 13/32
www.hoperf.com
3 Offline burning operation and description
3.1 Basic operation
The basic burning steps are as follows：
1. Connect the burner to the computer through the USB cable and load the user program data file *.hex in
WriterConfig, and then configure and download to the burner. (More information, see chapter 3.2
“WriterConfig” configuration download description.)
2. Insert the "burning connection flat cable" into the burning interface, connect the burner and the chip
module, and connect to power supply. Or connect the burner control interface to the automaton table in
mass production, and connect the power supply (See Chapter 2.4 "The burner control interface
description and connection mode" for details).
3. Recording by manually pressing the start button or the start signal from the automatic machine.
3.2 Use WriterConfig for program and configuration download
Figure 9. CMT216x Writer Config Master Interface
Steps for downloading the burning target Hex to offline burner:
1. Select the “OTP”, which means the operation burning target is the import Hex file in OTP.
2. Click “Add File…”, import the target burning Hex file；
3. Click “Setting…”, choose the required burning option；
4. Click“Download to Writer”, download the target Hex and burning options to the offline writer, after

AN279
Rev 0.7 | 14/32
www.hoperf.com
which the offline writer can carry out the offline mass production burn mode
3.2.1 Burning option description
Click “Setting…” the interface of burning option and the descriptions are shown as followed.
Figure 10. CMT216xA MCU Setting Interface（Burning option part）
Table 10. CMT216x MCU Setting Description
No. Option Description
1 Encrypt
Code The enabling user code encryption option. It is not recommended temporarily.
2 NoXoMode
Disable external crystal (26MHz) mode. This will save cost for situations of no require of
high frequency transmission.
It should be noted that CMT216x chip needs to be
connected to the external 26MHz crystal during the initial power-on self-test by default.
Otherwise, the user program will not operate if self-test fails.
3 User User mode option. If this option is selected, the chip will be burned to User mode. For
details of the User mode feature, see the AN290 CMT216xA User manual
4 Exe User
Boot
User code execution option. If this option is selected, the user code will be automatically
executed after being loaded. If unchecked, user code is only loaded into PRAM, but not
executed.
5 Run Run mode option If this option is selected, the chip will be burned into Run mode (that is, finished chip mode). For details about Run mode features, see the AN290CMT216xA
user manual
6 FTP Disable FTP protection switch option. If it is selected under the Run mode, the FTP protection
mechanism takes effect in Re-test mode and FTP access is prohibited. For details about
the protection mechanism and Re-test mode, see AN290 CMT216xA user manual.

AN279
Rev 0.7 | 15/32
www.hoperf.com
No.
Option
Description
7 OTP
Disable
The OTP protection switch option. If the item is selected in Run mode, the protection
mechanism remains active in the Re-
test mode, and the OTP forbids access. For
protection mechanisms and Re-test mode features, see the
AN290 CMT216xA User
Manual.
8 S3S Disable
S3S Bus Switch Options. If the item is selected in Run mode, the S3S bus and 1-wire
debugging interface are disabled and the chip has been encrypted and cannot enter re-
test mode at the same time. If this parameter is not selected, S3S and 1-wire can be
opened in a special mode and enters Re-test mode. More details about Re-test mode,
see AN290 CMT216xA user manual
9 por_cal_dis
Disable the calibration option when the chip is powered on for the first time. After the
check, the chip will be banned for the first time on internal calibration processing, which
can shorten the time of the first power on to the user program execution (equivalent
power on reset time). Since the cancellation of calibration will affect the part function
modules, it is suggested to operate under the guidance of professionals.
10 Max Count It is used to limit the maximum times of burning in chip configuration.
3.2.2 User-defined serial number (SN) increment function and settings
Figure 11. CMT216xA MCU Setting Interface（SN setting part）
SN Settings Enable, select whether to synchronize the ID self-add function. When SN Settings in CMT216xA
MCU Setting is selected, related configuration items is shown in the following table.
Table 11. SN Settings in CMT216xA MCU Setting
No. Option Description
1 Start Addr (Hex) The start addresses of SyncID storing, with up to 8 bytes serial number
storing. The serial number is burned to specified address of OTP.

AN279
Rev 0.7 | 16/32
www.hoperf.com
No. Option Description
2 End Addr (Hex) The ending address of SyncID storing
3 Step Size After each chip is burned, the next ID will change incrementally according
to Step Size setting rule
4 Current SN(Hex)
1. SN changes according to the Current SN value when the chip is
continuously burned；
2. Both of the interface and Writer displayed ID value are hexadecimal
number；
3. SN最大支持范围为8字节。
5 Repeat Count The numbers of chips that are burned repeatedly until changing the ID.
6 Max Count Used to limit the maximum burning times of the chip
3.2.3 EEPROM initial burning value inside chip
Figure 12. CMT216xA MCU Setting Interface（Burn EEPROM part）
CMT216xA series chip has a 64-byte EEPROM internally, which can be saved by users as important
information on power failure. The default value of this part of memory is 0. When users burn the target
program, they can specify an initial value for the 64-byte EEPROM at the same time. Users just need to edit
the specify initial value into TXT text format as shown below. After that, select Burn EEPROM and loading the
file via Add File...

AN279
Rev 0.7 | 17/32
www.hoperf.com
Figure 13. Example for specific EEPROM initial value
Note；
1. All the edit content is in hexadecimal (0-9, A-F, case unlimited)；
2. Use the byte unit, and insert spaces between each byte；
3. Users can define its content according to all 64 bytes or part of them, noted that the burner address is
written from 0x00, and the first 64 bytes are treated as valid content (ignored the exceed part and filled the
vacancy with 0, the chip default value).
4. EEPROM initial value burning function only supports edited content, and does not support self-increasing
burning of SN serial

AN279
Rev 0.7 | 18/32
www.hoperf.com
3.2.4 WriterConfig Interface Description
The following figure shows the WriterConfig page and version information and they are marked as 9 and 10.
However, Num 9 indicates the Writer hardware and Firmware version. Below, the hardware version is V3.2,
and the Firmware version is 505.bet.app, Num 10 indicates the CMT216x WriterConfig software version which
is V5.0.5 below.

AN279
Rev 0.7 | 19/32
www.hoperf.com
WriterConfig Software version
Writer Ha rdware Firmw are version
Part Number
Writer Config pop up page
Add the user
writer
program
Download to
offline wri ter
Confirm the
writer
config
setting
Default
configure
information
of the
offline
reading
writer
1
Information
Parameters
2
4
7
6
8
10
9
3
5
Figure 14. CMT216x Writer Config main page and pop-up page

AN279
Rev 0.7 | 20/32
www.hoperf.com
Table 12. User program and configuration download steps description
Num Name Description
1 Add File… Adding the hex document to be burned
2 Settings…
CMT216x MCU Setting
，
CMT216x chip burning option. Details see at
the following table “CMT216x MCU Setting” description. The dialog
box will be displayed automatically after the file is imported. Click the
"OK" button to save the settings.
3 OK（popup window）Click the OK button to confirm the burning configuration.
4 Download to Writer
Click the button
，
Download burning configuration parameters and user
program to the offline writer.
5 Read Settings
Click the button
，
read the original MCU configuration and display in
the current MCU config window，users can modify the configuration as
required.
6 SoC PartNumber Automatically display as CMT216x
7 Parameters
The imported file and chip Flash size are used to check whether the
downloaded data is correct, including the file name, file size, and chip
Flash size.
8 Information
Import the file Checksum (in hexadecimal). The Checksum displayed
on the LCD of the burner must be the same as the Checksum
displayed here. If not, the LCD displays an error message of CFG CHK
ERR1. In this case, you need to download the Checksum again.
