TOTAL NETWORK SOLUTIONS
PRO200WL 10/100MBPS N-WAY PCI BUS ADAPTER W/ WAKE-ON-LAN
www.cnetusa.com
The PRO200WL is a 100/10Mbps Fast Ethernet PCI-Bus Adapter equipped with Wake-On-LAN technology. A cutting
edge technology, Wake-On-LAN allows workstations to accept "Magic Packets", Microsoft Wake-Up Frames, or Link
Change that can power "On" a workstation from a remote location. This ability is useful for many tasks, including
deploying operating systems or applications, transferring files, running programs on client workstations, and much
more.
Key Features
•=Single chip PCI Bus 100BASE-TX Fast
Ethernet Adapter.
•=Fully complies with IEEE 802.3u and IEEE
802.3 standards.
•=Full-Duplex available in both modes for up to
200Mbps throughput.
•=Optimal line-speed set automatically via Auto-
Negotiation function.
•=Shielded RJ-45 connector provides unified
100BASE-TX and 10BASE-T network media
interface.
•=Complies with PCI specification 2.1, 2.2, ACPI
1.0, and PCI Bus Power Management 1.1.
•=3.3V main power supply for LAN Controller.
•=Device drivers compliant with Microsoft PC99,
RedHat 6.0, and Novell certification.
•=EMI and EMC compliance with FCC Class B
and CE mark emission standards.
•=Complies with UL and CUL product safety
requirements.
Product Name Fast Ethernet PCI-Bus Adapter
DRIVERS
Netware 3.x, 4.x, 5.x
Windows 95/98 and OSR2
Windows NT, Windows 2000
Windows ME
Windows for Workgroups
LAN Manager
SCO UNIX
NCSA
PC/TCP
Sun PC-NFS
DEC Pathworks
Banyan Vines
Client 32
DOS ODI
Linux
STANDARDS IEEE 802.3u 100BASE-TX
IEEE 802.. 10-BASE-T
BUS TYPE PCI Bus specification revision 2.1, 2.2.
NETWORK INTERFACE One (1) shielded RJ-45 phone-type jack
NETWORK MODES 100BASE-TX (Category 5 TP cable required)
10BASE-T (Category 3, 4, and 5 TP supported)
Full-Duplex available in both modes
LED ACT/LINK (Green)
100M (Green)
ENVIRONMENT Operating Temp.: 0° ~ 55° C (32° ~ 131° F)
Storage Temp.: -20° ~ +70° C (-4° ~ 158° F)
Humidity: 10% ~ 90% non-condensing

Specifications are subject to change without notice Trademarks & Trade Names belong to their owners
DIMENSIONS 120 x 42 mm (4.78 x 1.65in.)
ORDERING INFORMATION
CNet Model# Description
CNPRO200WL (D) 10/100Mbps N-Way PCI Bus Adapter w/ Wake-On-LAN
