CO/Tech J1x-JF2-210 User manual

Important!
Read the entire instruction manual carefully
and make sure that you fully understand
it before you use the equipment. Keep the
manual for future reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den innan
du använder utrustningen och spara den för
framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre deg
om at du forstår dem før du bruker enheten
og oppbevar dem for senere bruk.
Tärkeätä tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin alat
käyttää laitetta. Säilytä ohjeet myöhempää
tarvetta varten.
Kap & Geringssåg
Kapp- & Gjæresag
Katkaisu- ja jiirisaha
Art.no. Model
18-3027 J1x-JF2-210/20-UK
30-9012 J1x-JF2-210/20
ENGLISHSUOMI
Compound
Mitre Saw
Ver. 200810

3
ENGLISH
Please note:
• Workingwithwoodmaybedangerousifnotperformedproperly.
• Ifyouusethesawwithcareandcaution,youwillsignicantlyreducetherisk
ofpersonalinjury.
• Protectiveequipmentsuchascovers,supports,clamps,protectiveeyeglasses,
dustlters,andearplugscannotcompensateforpoorjudgment,carelessness,
orlackofattention.
• Remember:Youareresponsibleforyourownsafety.Thesawhasbeen
designedforspecictasks.Westronglyrecommendthatyoudonotmodifythe
saworuseitforanythingotherthanthetasksitisintendedfor.
• DONOTUSETHESAWifyouareuncertainifitcanorshouldbeusedforthe
purposeyouhaveintended.
Always unplug the main electric cord before service
and adjustment of the product.
Compound Mitre Saw (sliding)
Art.no.: 18-3027 Model: J1x-JF2-210/20-UK
30-9012 J1x-JF2-210/20
Pleasereadtheentireinstructionmanualbeforeusingandsaveitforfutureuse.
Weapologiseforanytextorphotoerrorsandanychangesoftechnicaldata.
Ifyouhaveanyquestionsconcerningtechnicalproblemspleasecontactour
CustomerServices(seeaddressonreverse).

4
ENGLISH
General safety rules for your protection
and the protection of others
Portable Power Tools
Caution:Whenusingelectrictools,thefollowingsafetyrulesshouldalwaysbe
adheredtoinordertoavoidtheriskofre,electricshock,andpersonalinjury.
1. Keep the work area clean.
Clutteredsurfacesandtablesinviteaccidents.
2. Do not use the machine in a hazardous environment.
Electricdevicesshouldnotbeusedondamp,wetsurfacesorinrain.Assure
thatthelightingissufcientintheworkarea.Assurethereisgoodventilation
whenengagingindustytasks.Neveruseelectricmachines/toolswherethey
maycausereorexplosion.
3. Avoid electric shock.
Avoidphysicalcontactwithgroundeditemssuchaswaterlines,radiators,
kitchenstoves,etc.whileusingelectricmachines/tools.
4. Keep away from children and visitors.
Allchildrenandvisitorsshouldbeatasafedistancefromelectricmachines/
toolsorelectriccablesintheworkarea.
5. Store the machine out of the reach of children. 
Storeelectricmachines/toolslockeduporoutofreachofchildrenwhilenotinuse.
6. Do not force the machine.
Itwilldothejobbetterandsaferattheintendedfeedingspeed.
7. Use the appropriate tools.
Donotforceatooloranattachmenttoperformataskitisnotintendedfor.
8. Wear appropriate clothing.
Noloosettingclothes,mittens,necklaces,rings,bracelets,orother
jewellerythatmaybecomeentangledinrotatingparts.Non-slipshoesare
recommended.Wearahairnetorsimilarifyourhairislong.
9. Always wear protective eyeglasses.
Alwayswearprotectiveeyeglasses,regulareyeglassesareinsufcient.Also
usedustltersoraprotectivemaskswhenperformingdustytasks.
10.Use dust extractors.
Usesuctionequipmenttoremoveandcollectsawdustandwoodshavings,
ifthemachineisintendedforthispurpose,andassurethattheequipmentis
usedcorrectlyandemptiedasneeded.Caution:Sawdustandshavingsfrom
certainkindsofwoodandwoodproductsmaybeharmfultoyourhealthafter
onlyashortperiodofexposure.
11.Do not misuse the power cord.
Nevercarrythemachineinitscord.Donotpullthecord;insteadunplugthe
devicewhenturningoffthepower.Assurethatthecorddoesnotcomein
contactwithheat,oil,orsharpedges.

5
ENGLISH
12.Fasten the workpiece securely.
Useclampsorscrewclampswherepossibletoallowyoutohandletheworkpiece
withbothhands.Thisissaferthanholdingtheworkpiecewithonehand.
13.Do not overreach.
Makesureyoualwaysstandrmlyandwell-balanced.
14.Maintain the tools.
Assuretheyarecleanandthatthebladesaresharptoachievetheoptimaleffect
andasaferesult.Followtherecommendationsinthemanualpertainingtogreasing
andreplacementofparts.Checkthepowercordregularly,andifitisdamagedit
shouldbereplacedbyaqualiedservicetechnician.Checkallextensioncords
regularlytomakesuretheyarenotdamaged.Makesurethehandlesofthe
machine/toolandleversareclean,dry,andcompletelyfreeofoil,grease,etc.
15.Turn off the power.
Unplugthedeviceandpushtheemergencybrake,ifthereisone,beforeservice
andwhenreplacingpartssuchasplaningirons,drillbits,sandingbelts,orblades.
16. Remove all keys and service tools.
Makeitahabittoverifythatallspannersandservicetoolsareremovedfrom
themachinebeforeturningonthepower.
17.Avoid unintentional start.
Donotcarryatoolwithyourngeronthepowerswitchifitispluggedin.
AssurethepowerswitchisOFFwhenplugginginthedevice.
18. Use the correct extension cords.
Ifusingextensioncordsoutdoors,useonlythoseintendedforoutdooruse.
Useextensioncordswithsufcientrange,unrolltheentirecord.
19.Use common sense and caution.
Thinkthrougheachtaskbeforeperformingit,sothatitisperformedinasafe
manner.Neverusethemachine/toolwhenyouaretired,undertheinuenceof
medication,etc.
20.Make sure that all parts are undamaged. Before starting the tool, make
sure that:
• allcoversandadditionalpartsareundamagedandoperatecorrectly
• thatmovablepartscanrotatefreelyandareaimedintherightdirection
• thatnomoveablepartscangetcaught,thatnodefecthasoccurred,and
othercircumstancesthatmayaffecttheoperationofthetask.
 Adamagedcoverorotherpartshouldberepairedbyaqualiedtechnicianor
replaced.Damagedpowercordsandpowerswitchesmustalwaysbereplaced
byaqualiedtechnician.Neverusethetoolifyouareunabletoswitchitoffor
startitinasafemanner.
21.Use recommended attachments.
Theuseofnotrecommendedattachmentsmaycauseaccidentsorpersonalinjury.
22.Repair by a qualied technician.
Thetoolcomplieswithallsafetyregulations.Repairsofthetoolmustalways
beperformedbyaqualiedprofessional,usingoriginalparts,orthetoolmay
causeaccidentsorpersonalinjury.

6
ENGLISH
6
Special safety rules for the compound mitre saw
Caution: Unplug the power cord before service or when replacing a blade.
Assurethatallpartsoperateappropriatelyandthatthesafetyfeaturesprotectas
intendedbeforestartingthesaw.
1. Caution: Useonlycuttingblades.Makesurethattungstencarbideblades
havenegativeteeth.Donotusebladeswithdeepspacesbetweentheteeth
assuchcanbendandcomeincontactwiththebladeguard.Adamagedsaw
blademustimmediatelybereplaced.
2. Donotusethesawuntilitiscompletelyandaccuratelyassembledaccording
tothisoperationsmanual.Verifytherotationdirectionofthemotorandthe
blade(seetherotationarrowonthebladeguard.)Makecertainthatthesaw
bladedoesnottouchtherotationtableinanysetting.Unplugthepowercord
andleanthesawblademanuallyat45°and90°.Adjustifneeded.
3. Unlessyouunderstandhowthesawistobeused,youshouldaska
knowledgeablepersonforadvice.
4. Neversawfreehanded.Fastentheworkpiecesecurelyagainstthefenceinan
appropriatemannerbeforebeginningtosaw.Iftheworkpieceyouaresawing
requiresthatyoukeepyourhandascloseas10cmfromtheblade,youshould
alwayslocktheworkpieceinplacewithaclamporsimilarbeforesawing.
5. Caution: Keepyourhandsclearofthesawblade.Neversawsmallpieces.
Usesupports.
6. Ascertainthatthebladeiswellcentred,sharp,andrunsfreelywithoutvibrating.
7. Letthemotorpickupspeedbeforebeginningtosaw.
8. Keeptheventilationopeningsofthemotorcleanandfreeofsawdust.
9. Alwaysmakesurethatallclampscrewsaretightbeforebeginningtosaw,
evenifthetableisxedatarmangle.
10.Makesurethatthebladeandtheangesarecleanandthatthespindlenutis
tight,useonlythebladeangesthatbelongtoyourparticularsaw.
11.Useonlyblades210mmindiameterandtherightspeedclassication
(atleast6000RPM).
12.Useanappropriateextrasupportwhensawinglongworkpieces.
13.Beforesawing,alwaysmakesurethatthebladeisnotcrackedordamaged.
Suchabladeshouldimmediatelybereplaced.
14.Donotusethesawifanycomponentofthesawismissing,damaged,or
faulty,unplugthepowercordtothesawifitstartsmakingastrangenoise
orvibrating.Letaprofessionalreplacethemissingordamagedcomponent
beforeyouusethesawagain.
15.Neverusethesawifthecoversarenotinplaceordonotworkproperly.
15.Neverreacharoundorbehindthebladewhileitrotates.Standrmlysothat
youcanalwayskeepyourbalance.

7
ENGLISH
17.Assurethatthebladecanrotatefreely(especiallyaftertransportand/orblade
replacement)beforeplugginginthesawandstartingit.
18.NeverlocktheswitchintheONposition.
19.Caution: Whenyouhavecutclearthroughtheworkpiece,releasethepower
switchandwaituntilthebladehasstoppedrotatingbeforeliftingupthesawhead.
20.Releasethepowerswitchandwaituntilthebladehasstoppedbeforemoving
theworkpieceorchangingsettings.
21.Donotremovestuckorcut-offpiecesuntilthebladehasstopped.
22.Neversawthroughferrousmetalsorthroughbrickormortar.
23.Neverusethesawintheproximityofhighlyinammablegasesorliquids.
24.Nevercleantheplasticpartsofthesawwithasolvent.Solventsmaymeltthe
plasticordamagethematerialinotherways.Onlycleanwithasoft,dampcloth.
25.Unplugthepowercordandcleanthesawbeforeleavingit.Assurethatthe
workspaceiscleanwhennishingthework.
26.Savethisoperationsmanual.Readthroughitoftenanduseittoinstruct
others.Makesurethatallpersonsusingthesawreadtheseinstructions.
27.Donotexposethesawtorainanddonotuseitindampenvironments.
28.Arrangeforgoodlightingintheworkarea.
29.Usesuitableworkclothes.Loosehangingclothingorjewellerymaygetcaught
intherotatingparts.
30.Ausershouldbeatleast18yearsofage.Usersbelowtheageof16should
besupervisedbyaninstructorwhileusingthesaw.Keepchildrenawayfrom
thesawwhileitisconnectedtoapowersource.
31.Keepyourworkplaceorderlyanddonotallowdebrisorothergarbagetobe
presentunnecessarily.Assurethatthewastecanberemovedfromthesaw
blade,oritmaybedispersedbythesawblade.
32.Donotdistractpeopleoperatingthesaw.
33.Donotattempttostopthebladebypushingsomethingagainstthesideofthe
bladeafteryouhaveturnedoffthepowertothesaw.
34.Neverusesawbladesthatdonotcorrespondtothespecicationsinthemanual.
35.Itisimportanttocheckthatallbladeguardscoveringthesawbladeare
functioningwell.
36.Neverlocktheprotectivecoverinanopenpositionandneverdisassemblethe
coverofthemachineanddonotchangeitsfunction.Neveruseadamagedor
faultysafetydevice,butreplaceitimmediately.
37.Besuretoplaceyourhandssafely,sothattheydonotslipinunderthesaw
bladeofyouloseyourbalance.Neversawthroughworkpiecessosmallthat
theycannotsafelybeheld.
38.Useatable,rollerstand,etc.assupportwhenworkingwithlongworkpieces,
sothatthemachinedoesnottipover.

8
ENGLISH
39.Clamproundworkpieceswithappropriatedevices,sothattheycannotrotate.
40.Neversawthroughworkpiecescontainingnailsorotherforeignobjects.
41.Alwaysstandatthesideofthesawbladewhilethemachineisinuse,sothat
thebladedoesnotstrikeyouifitshouldbrake.
42.Alwayspresstheworkpieceagainstthetableandthefasteningdevicesothat
itcannotturnormoveduringthesawing.
43.Neversawthroughseveralworkpiecessimultaneously.
44.Nevertrytoremovedust,akes,orwoodthathasattacheditselfwhilethe
bladeisrotating.Ifyoumustadjustthemachineorremovedebris,alwaysrst
turnthemachineoffandunplugit.
45.Alwaysturnthemachineoffandunplugitbeforechanging,adjusting,or
cleaningthemachine,ormeasuringtheworkpiecetobesawed.
46.Turnthemachineoffandunplugitbeforeleavingtheworkplace.
47.Electricinstallation,repairs,andmaintenanceshouldonlybeperformedby
aprofessional.
48.Allcoversandsafetydevicesmustberestoredimmediatelyafterrepair
ormaintenance.
49.Itisimportanttoadheretothesafety,use,andmaintenanceinstructionsofthe
manufacturer,aswellastoadheretothedimensioninstructionsindicatedin
“technicaldata.”
50.ItisnecessarytoadheretotherulesoftheLabourProtectionBoardaswellas
othergeneralsafetyrules.
51.Onlyusethemachinewithdustsuctioninaclosedroom,iftheroomhas
inowingair,toavoidcreatingavacuumintheroom.
52.Thesawshouldonlybeconnectedtosocketswith230Vsecuredwithatleast
a10Afuse.
53.Damagedsafetydevicesandpartsmustbereplacedorrepairedbya
professionalatanauthorizedservicefacility.
54.Thismachinecomplieswithallrelevantsafetyregulation.Themachinemust
onlyberepairedbyaprofessionalatanauthorizedservicefacilityusing
originalspareparts.Unlessyouadheretothisrule,itmayleadtoaccidents
andexposetheusertodanger.

9
ENGLISH
Product labelling with safety symbols on the machine
1. Read the entire operations manual.
Readtheentireoperationsmanualandattempttounderstandhow
themachineworks.
2. Use ear plugs.
Thereisariskofhearingloss.Alwaysuseearplugswhenoperating
themachine.
3. Use protective eyeglasses.
Protectyoureyesfromyingdebrisanduseprotectiveeyeglasses
oravisor.
4. Use protective shoes.
Useprotectiveshoeswithasteeltoethatprotectagainstfallingobjects.
5. Keep visitors away from the proximity of the machine.
Keepchildren,pets,andvisitorsaminimumof5metresawayfrom
theriskzoneofthemachine.
6. Caution: Be attentive, keep your hands away from the proximity
of the saw blade.
Thereisariskofinjuryduringcontactwithrotatingsawblade,alsoat
alowspeed.
7. Do not use the help of assistants, unless necessary.
Itisprohibitedforpeopleotherthanthemachineoperatortobe
presentintheriskzoneofthemachine.
8. Turn off the machine and unplug it from the power source before
cleaning and service.
Read this manual thoroughly and think through the information provided.
Use the manual to acquaint yourself with the machine, its use and safety rules.
Even if the machine is used completely according to the directions, it is
impossible to eliminate all potential risks. The construction and use of the
machine may be the cause of the following risks when the saw is in use:
• Contactwiththesawbladewherethecoverdoesnotreach.
• Contactwitharotatingsawblade(cutinjury).
• Theworkpiecebeingsawedorpartsthereofbeingthrownbackwardstowardthe
user(kickback).
• Fracturesinthesawblade.
• TheT.C.tipsmaycomelooseandbethrownout.
• Hearinglossmayoccurifnoearplugsareused.
• Harmfuldustmaycauseinjuryinpoorlyventilatedareas.
!
!
!
!
!
!
!
!

10
ENGLISH
6
7
8
1112
15
1821 22
24
26
23
10
Description
1. Releaselever
2. Handle
3. Powerswitch
4. Sawhead
5. Sawblade
6. Bladeguard,sliding
7. Fence
8. Mitreplate
9. Bottomplate
10.Lockingwheel
11.Indexmark
12.Scale
13.Lockinglever
14.Lockingwheelforslide

11
ENGLISH
1
2 3 4
5
9 14
17
19
20 25 13
16
15.Scale
16.Stop
17.Spindlelock
18.Lidstocarbonbrushes
19.Clamp
20.Support
21.Screw
22.Rotationmarking
23.Dustbag
24.Adjustmentscrew0˚
25.Adjustmentscrew45˚
26.Stop

12
ENGLISH
Technical data
Motor    230VAC,50Hz
Outputpower:   1800W
No-loadspeed:   4800rpm
TCT sawblade  Ø210xØ30x2.6mm
Numberofteeth:   30
Adjustablebladetilt:  0°-45°totheleft
Adjustablemitresawing:  -45°/0°/+45°
Table    420x160mm
Maxlumberdimensionat90° 200x60mm
Maxlumberdimensionat45° 140x60mm
Maxlumberdimensionat2x45° 140x37mm(doublemitrecut)
The package contains
• Clamp
• Key
• Dustbag
• Supports(2x)
• Operationsmanual
Measures to take before putting the machine to use
• Themachinemustbemountedrmlyonaworkbenchorstand,orsimilar.
• Allcoversandsafetydevicesmustbecorrectlyinstalledbeforestarting
themachine.
• Thesawblademustbepermittedtorunfreelyinallsettings.
• Whenworkingwithpre-usedwood,youmustbeattentiveofandlookfor
foreignobjectsintheworkpiecesuchasnailsandscrews.
• Beforestartingthemachine,verifythatthebladeiscorrectlyinstalledandthat
allmoveablepartsoperatefreely.
• Beforeconnectingthemachinetoanelectricsocket,youshouldmakesure
thatitismadeforthesamevoltageasyouhaveinthesocket.

13
ENGLISH
19
14
16
3
8
7
42
1
Cutting
Cutting with the blade at an angle of 0°
Whencuttingworkpiecesupto120mmwide,theslidingfeatureofthesawisnot
neededandthesawcanbelockedinitsbacksettingwiththelockingwheel(14).
Whencuttingworkpieceswiderthan120mm,checkthatthelockingwheel(14)
isloosenedandthatthesawhead(4)ismoveablebeforebeginningtocut.
1. Releasethesawhead(4)toitsuppersettingbyremovingthestop(16).
2. Movethesawhead(4)backwardswiththehandle(2)andxitinthisposition
ifneeded(dependingonthewidthoftheworkpiecebeingcut.)
3. Placetheworkpiecebeingcutagainstthefence(7)onthemitreplate(8).
4. Fastenitwiththeclamp(19)tothebottomplatetopreventtheworkpiecefrom
givingwayduringthecutting.
5. Pressthepowerswitch(3)tostartthemotor,pressthereleaseleverandcalmly
andevenlybringdownthehandle(2)andletthesawbladecuttheworkpiece.
6. Afternishingcutting:Releasethepowerswitch(3)andwhenthemotorhas
stopped,thesawhead(4)canbebroughttoitsupperposition.
Caution:Thebalancespringsofthemachinewillautomaticallypressthesaw
headupwardsaftercutting.Thus,donotreleasethehandle(2)afternishingcut-
ting,holdthehandleandbrakecarefullywhenthesawheadspringsupwards.

14
ENGLISH
25
15
13
16
24
13
Cutting with the blade
at an angle of 0° - 45°
Youcancutatanangleof0°-45°withthissaw.
1. Loosenthelockinglever(13)afterwhich
thebladecanbeleanedinthedesired
anglewiththehelpofthescale(15).
2. Pullthelockinglever(13)tight.
3. Cutaccordingtothedirectionsabove.
Fine-tuning of the 0° and 45° angles
1. Loosenthelockinglever(13)andangleto
sawtowardsposition0°.
2. Verifytheanglebetweenthebladeandthe
sawtablewitha90°angleguide.
3. Ifneeded,adjustthebottompositionwiththe
adjustmentscrew(24)bylooseningthenut
andadjustingthescrew,xthescrewafter
theadjustmentbytighteningthenutagain.
4. Whenadjustingthe45°bottomposition,
doasdescribedabove,however,adjust
withadjustmentscrew(25)andusea45°
angleguide.

15
ENGLISH
4
26
12 10
Mitre sawing - 45° / 0° / + 45°
Youcanmitresawwiththissawatanangleof-45°/0°/+45°.
1. Releasethesawhead(4)toitsupperpositionbyremovingthestop(16).
2. Releasethelockingwheel(10).
3. Pressthestop(26)andadjusttothedesiredmitreanglebyusingthescale(12).
4. Tightenthelockingwheel(10)andcutaccordingtothedirectionsabove.

16
ENGLISH
Correct Incorrect
17
16
Sawing of curved workpieces
Whencuttingatitems,itisnecessarytocheckiftheitemisbent.Turnitasin
theleftillustrationshows,otherwisetheitemwillpinchthebladeattheendof
thecutting.
Dust bag
Thesawcontainsadustbag(23).Itcanbeemptiedbyopeningthezipperatthe
bottom.Youmayalsousedustsuction.
1. Unplugthepowercord.
2. Removethestop(16)and
releasethesawheadcarefully.
Replacing the saw blade
3. Loosenthescrews(21)and
foldawaythebladeguard(6).

17
ENGLISH
Loosen
Tighten
4. Pressthespindlelock(17)withonehandandturnthebladewiththeother
untilthebladeislocked,keepthespindlelockpressedanduseakeytoloosen
thebladebolt(turnclockwise).
5. Removethebladeboltandtheouterbladeangecompletely.
6. Removethesawbladefromtheinnerbladeangeandtakeoutthesawblade.
7. Installthenewsawbladeintheoppositeorder.
8. Becarefultocleanthebladeangeandboltbeforeinstalling.Therotation
directionofthesawblademustcorrespondtothearrowonthesawhouse.
9. Installtheslidingbladeguard(6)intheoppositeorder.
10.Makesurethatthespindlelockisreleased.
11.Checkthatallcoversarecorrectlyinstalledandfunctioningwellbeforethe
sawisstarted.
Note:Thespindlehasadiameterof16mmandaninsetringis
installedtogetherwiththeoriginalbladewhichhasaninsidediameterof
30mm–Bladeswithboth16and30mminsidediametercanbeused.
Caution:Alwaysmakesurethatthebladerunsfreelyinallpossiblesettings
afteryouhavereplacedthesawblade.
Caution:Removethekeyandloosenthespindlelockbeforethemachine
isstarted.

18
ENGLISH
18
Min.length6mm
Inspection and replacement of carbon brushes
Caution:
Unplugthepowercordbeforeinspectingthecarbonbrushes.
Thelifeexpectancyofthecarbonbrushesvariesdependingontheusageof
themotor.Checkthemafter50machinehoursifthesawisneworifyouhave
replacedthebrushes.Aftertherstinspection,checkthemaftereverytenth
machinehouruntilitistimefornewbrushes.
Check the brushes in the following manner
1. Removethetwolids(18),oneoneachsideofthemotor.
2. Thecarbonbrushesareplacedinsidethelids,pulloutthecarbonbrushes.
3. Checkthelengthofthebrushes(atleast6mm).
4. Replacebothcarbonbrushesifeitheroneisbelow6mmorifanyspringor
shuntthreadisburntordamagedinanyway.

19
ENGLISH
Fault localization when there
is a problem with the motor
1. Toavoidoverheatingthemotor,youshouldregularlyblowthemachineclean
orvacuumitsothatsawdustandshavingsdonotaffectthecooling.
2. Connectthesawtoanearthedoutletwithatleasta10Afuse.
3. Immediatelyreleasethepowerswitchifthemotordoesnotstartrightup.
Unplugthepowercord,checkthatthebladerunsfreely;trystartingthemotor
againifitrunsfreely.
4. Ifthemotorstopsduringsawing:Immediatelyreleasethepowerswitchand
unplugthepowercord,releasethebladefromtheworkpiece,thentrytostart
themotoragain.
5. Checkconnections,overload(severalunitsconnectedtothesamecircuit,
spotlights,etc.),range(atleast1.5mm²upto7metrelength,atleast2mm²
at7to15metreslength),cablelength(nomorethan15metres.)
Ordering spare parts
Pleasesupplythefollowinginformationwhenorderingspareparts:
• Typeofmachine
• Thetypenumberofthemachine
• Thearticlenumberofthemachine
Disposal
Followlocalordinanceswhendisposingofthisproduct.
Ifyouareunsureabouthowtodisposeofthisproduct
contactyourmunicipality.

20
