109877482 en / 07.11.2008
Operating Instructions
Floor Saw FSD930
Index 001
Congratulations!
You have decided to purchase a tried and tested TYROLIT-Hydrostress unit and have thus
acquired a highly sophisticated and reliable state-of-the-art unit. The exclusive use of only
TYROLIT Hydrostress spare parts ensures quality and interchangeability. If maintenance work is
neglected or carried out inexpertly we will be unable to honour our warranty obligations. Any
repair work must be carried out by trained personnel only.
Should you need more details concerning your TYROLIT Hydrostress unit in order to keep it in
perfect condition, please contact our after-sales service for further information.
We hope that you enjoy untroubled and fault-free working with your TYROLIT unit.
TYROLIT Hydrostress
Copyright© TYROLIT Hydrostress
TYROLIT Hydrostress AG
Witzbergstrasse 18
CH-8330 Pfäffikon
Switzerland
Tel. 0041 (0) 44 952 18 18
Fax 0041 (0) 44 952 18 00
Page 2 Floor Saw FSD930
TYROLIT Hydrostress AG
1Safety
These instructions are just one part of the documentation which is supplied together with the
floor saw. These instructions go together with the "Safety Manual / System Description for Floor
Saws" to form a complete set of documentation.
DANGER
Failure to comply with the safety instructions in the "Safety Manual / System Description" may
result in serious injury or death.
►Please ensure that the "Safety Manual / System Description for Floor saws" has been read
and understood in full.
Floor Saw FSD930 Page 3
TYROLIT Hydrostress AG
2Design
Components
1 Operating console
2 Name plate
3 Main motor
4 Front cut guide
5 Shaft cover
6 Blade guard
7 Saw blade
8 Rocker wheel
9 Drive wheel
10 Rear cut guide
11 Water feed
2.1 Saw blade drive
Saw blade drive (schematic)
1 Blade drive shaft
2 Drive belt
3 Main motor drive shaft
Page 4 Floor Saw FSD930
TYROLIT Hydrostress AG
2.2 Lift drive
Lift drive (schematic)
1 Hydraulic cylinder
2.3 Travel drive
Travel drive (schematic)
1 Drive shaft (main motor)
2 Hydrostat drive belt
3 Hydrostatic motors
4 Drive chain
5 Wheel drive shaft
6 Drive wheel
Floor Saw FSD930 Page 5
TYROLIT Hydrostress AG
3Transport
DANGER
Inexpert transport may result in death or serious injury.
►Floor saws must only be transported with the main motor switched off.
►Only transport vehicles, lifting tools and load suspension devices with sufficient load-
bearing capacity must be used.
►Floor saws must only be hitched by the hitching points provided.
►Appoint an expert marshaller.
►When transporting by crane do not stand underneath suspended load.
►Always have the floor saw in your line of vision while it is being transported.
3.1 Hitching points
Hitching points
1 Crane hitching device
Page 6 Floor Saw FSD930
TYROLIT Hydrostress AG
4Initial start-up
4.1 Fitting battery
►Fit battery (for type see Technical Data).
Floor Saw FSD930 Page 7
TYROLIT Hydrostress AG
5Assembly / Set-up
5.1 Mounting grip
►
5.2 Mounting saw blade
1. Apply hand brake
Page 8 Floor Saw FSD930
TYROLIT Hydrostress AG
2.
DANGER
Parts that fly off (segments, concrete splinters, saw blade, etc.) may cause serious injury
or even death.
►Floor saws must only be operated with a blade guard.
►When assembling the saw blade on the right-hand side use the anchoring screw with the
left-hand thread.
When assembling the saw blade on the left-hand side, use the anchoring screw with the
right-hand thread.
►Note the direction or rotation arrows on the saw blade.
3.
1 Anchoring screw
*Note the direction of rotation
Floor Saw FSD930 Page 9
TYROLIT Hydrostress AG
4.
C: To prevent the saw blade rotating while being tightened, carefully place the saw blade on the floor.
5.3 Mounting saw blade on the other side
5.3.1 Disassemble the blade guard
►
Page 10 Floor Saw FSD930
