Norton TT 200 EM User manual

TT 200 EM
OPERATING INSTRUCTIONS

2

3
Le constructeur soussigné:
SAINT - GOBAIN ABRASIVES S.A.
190, BD. J. F. KENNEDY
L-4930 BASCHARAGE
Déclare que le matériel neuf désigné ci-après :
Scie de carrelage: TT 200 Code : 70184625701
est conforme aux dispositions des Directives :
•"MACHINES" 2006/42/CE
•"BASSE TENSION" 73/23/CEE
•"Compatibilité électromagnétique" 2004/108/CE
Pierre Mersch
Business Manager Machines Europe
Déclaration de conformité

4

5
TT200EM
OPERATING INSTRUCTIONS
1 Basic Safety Instructions 6
1.1 Symbols 6
1.2 Machine plate 6
1.3 Safety instructions for particular operating phases 7
2 Machine description 7
2.1 Short description 8
2.2 Purpose of use 8
Layout 8
2.3 Technical Data 9
3 Assembly and commissioning 10
3.1 Tool assembly 10
3.2 Guide-a-cut assembly 10
3.3 Electrical connections 10
3.4 Starting the machine 10
3.5 Water cooling system 11
4 Transport and storing 12
4.1 Securing for transport 12
4.2 Long period of inactivity 12
5 Operating the machine 13
5.1 Site of work 13
5.2 Cutting methods 13
5.3 General advice for the cutting 13
6 Maintenance and servicing 14
7 Faults: causes and cures 15
7.1 Fault-finding procedures 15
7.2 Trouble-shooting guide 15
7.3 Customer service 15

6
1 Basic Safety Instructions
The TT200EM is exclusively designed for the cutting of tiles mainly on construction sites.
Uses other than the manufacturer's instructions shall be considered as contravening the
regulations. The manufacturer shall not be held responsible for any resulting damage. Any risk shall
be borne entirely by the user. Observing the operating instructions and compliance with inspection
and servicing requirements shall also be considered as included under use in accordance with the
regulations.
1.1 Symbols
Important warnings and pieces of advice are indicated on the machine using symbols. The following
symbols are used on the machine:
Read operator’s instructions Ear protection must be worn
Hand protection must be worn Eye protection shall be worn
Rotation direction of the blade Pump on Pump off
1.2 Machine plate
Important data can be found on the following plate located on the machine:
Machine Model Machine Code Weight Year of production Bore diameter
Maximum blade diameter

7
1.3 Safety instructions for particular operating phases
Before commencing work
•Before commencing work, make yourself familiar with the working environment at the place of
use. The working environment includes: obstacles in the area of work and manoeuvre, the
firmness of the floor, necessary protection at the site relating to public thoroughfares and the
availability of help in the event of accidents.
•Site the machine on an even, firm and stable base!
•Check for correct mounting of the blade regularly.
•Immediately remove damaged or badly worn blades, as they endanger the operator whilst
rotating.
•The material to be cut must be held securely in place on the table to allow no unexpected
movement during cutting operation.
•Always cut with the blade guard in position.
•Only fit CLIPPER diamond blades with continuous rim to the machine! The use of other tools
can damage the machine!
•Read the blades’ specifications carefully to choose the correct tool for your application.
•Attention is drawn to the use of BS2092 safety goggles in conformity with specified Processes
No.8 of the Protection of Eyes Regulation 1974, Regulation 2(2) Part 1.
Electrical powered machine
•Always turn off the machine and separate it from the main source of electricity before any work
on the machine is done.
•Make all electrical connections securely to eliminate contact of live wires with spray water or
dampness.
•When the machine is used with water, it is IMPERATIVE that you earth the machine properly.
Let a qualified electrician check in case of doubt.
•In case of emergency, you can stop the machine by pushing on the front cover of the switch.
•In the event of the machine breaking down or stopping for no apparent reason, switch off the
main electricity supply, even in case of power supply failure. Only a qualified electrician is
allowed to investigate the trouble and remedy the fault.
2 Machine description
Any modification, which could lead to a change in the original characteristics of the machine, may
be done only by Saint-Gobain Abrasives who shall confirm that the machine is still in conformity
with the safety regulations.
Machine type Serial number Power Safety standard Blade speed

8
2.1 Short description
The TT200EM Tile saw is designed for durability and high performance for onsite wet and dry
cutting operations of a wide range of tiles.
As with all other CLIPPER products, the operator will immediately appreciate the attention given to
detail and quality of materials used in construction. The machine and its component parts are
assembled to high standards assuring long life and minimum maintenance.
2.2 Purpose of use
The machine is designed for wet and dry cutting of a large range of tiles. It is not designed for
cutting wood or metals.
Layout
1
2
4
3
5
6

9
Frame (1)
The frame is made of a strong plastic to ensure perfect rigidity. It supports the motor, the cutting
table and the switch.
Cutting table (2)
Zink coated steel top for an excellent resistance to corrosion with engraved measurements for
precise guide-a-cut alignment.
Electrical Motor and switch (3)
Motor with 800W. The ON-OFF switch also serves as emergency stop.
Bevel cut (4)
You can make bevel cuts with the machine by loosening the two screws on the side and pivoting
the table.
Guide-a-cut (5)
The guide-a-cut can be adjusted to the desired cutting width. It is locked using two screws. A guide
to make mitre cut is also supplied with the machine.
Blade guard (6)
Blade guard with 200mm-diameter blade capacity, which offers maximum operator protection and
increased visibility of the work piece. The guard is assembled on the frame.
2.3 Technical Data
Electric motor 800W
Voltage 230V
Protection rating IP 54
Max. blade diameter 200 mm
Bore 25,4 mm
Rotation speed of the blade 2950 min
-1
Flange diameter 50 mm
Cutting depth mm 40 mm
Cutting depth bevel cut 20 mm
Sound pressure level 72 dB (A) (ISO EN 11201)
Sound energy level 80 dB (A) (ISO EN 3744)
Table dimension (LxW) 460x360 mm
Machine dimensions (LxWxH) 510x400x230 mm
Weights
Machine cpl. 16 kg
Ready for use (with water) 19 kg

10
3 Assembly and commissioning
The machine is delivered fully equipped. It is ready for operation after assembly the diamond blade,
the blade guard and the guide-a-cut, and after connection to the appropriate power supply.
3.1 Tool assembly
Only CLIPPER continuous rim blades with a maximum diameter of 200 mm can be used with the
TT200EM.
All tools used must be selected with regard to their maximum permitted cutting speed for the
machine’s maximum permitted rotation speed.
Before mounting a new blade into the machine, switch off the machine and isolate it from the main
source of electricity.
To mount a new blade, follow these steps:
•Loosen the two screws on the side of the blade protection remove the front cover.
•Loosen the hexagonal nut which holds the removable outer flange on the blade shaft with the
19mm wrench and the special tool to lock the flange.
•Remove the outer flange.
•Loosen the two screws holding the blade guard support and remove it from the machine.
•Clean the flanges and blade shaft and inspect for wear.
•Mount the blade on the flange ensuring that the direction of rotation is correct (check with the
arrow on the blade guard). Wrong direction of rotation blunts the blade quickly.
•Replace outer blade flange.
•Tighten hexagonal nut.
•Retighten the two screws holding the front cover, and reassemble the blade guard support on
the table.
The blade bore must correspond exactly to the diameter of the blade shaft. Cracked or damaged
bore is dangerous for the operator and for the machine.
3.2 Guide-a-cut assembly
To assemble the guide a cut:
•Put the guide a cut on the table.
•Use the handle on the side of the guide-a-cut to pinch it on the table
3.3 Electrical connections
Check that,
•the voltage/phase supply corresponds to the information indicated on the motor plate.
•Available power supply must have ground connection in conformity with safety regulations.
•The connecting cables should have at least a 2.5mm
2
-section per phase.
3.4 Starting the machine
Press the green button to start the machine. Press on the red button to stop the machine. The red
button is also the emergency switch.

11
3.5 Water cooling system
•Fill the water pan with clean water up to 5mm from the upper edge of the water tray.
•Ensure that water is delivered adequately to both sides of the blade, as insufficient water supply
may result in premature failure of the diamond blade.
•Always make sure that there is enough water in the pan and refill if necessary.
•In case of frost, empty the water cooling system from its water.

12
4 Transport and storing
4.1 Securing for transport
Before transporting the machine, always remove the blade and empty the water pan.
4.2 Long period of inactivity
If the machine is not going to be used for a long period, please take the following measures:
•Completely clean the machine
•Empty the water system
The storage site must be clean, dry and at a constant temperature.

13
5 Operating the machine
5.1 Site of work
5.1.1 Siting the machine
•Remove from the site anything, which might hinder the working procedure!
•Make sure the site is sufficiently well lit!
•Observe manufacturer's conditions for connecting to power supplies!
•Place electric cables in such a way that damage by the device is excluded!
•Make sure you have a continual adequate view of the working area so you can intervene in the
working process at any time!
•Keep other staff out of the area, so you can work securely.
5.1.2 Space required for operation and maintenance
Leave 2 m around the machine for usage and maintenance of the TT200EM.
5.2 Cutting methods
To use the machine correctly, you must face it with the two hands on the tile to be cut, pushing the
tile against the blade. Always keep your hands away from the moving blade.
To set the guide-a-cut at the desired cutting width, release it, and use the two scales on the table to
align the guide. Then tighten it back.
5.3 General advice for the cutting
•Only tiles with max. dimensions 400x400x6mm and max. weight 3kg can be cut with the
machine.
•Before commencing work make sure tools are firmly seated!
•Select the right tools as recommended by the manufacturer depending on the material to be
worked, the working procedure (dry or wet cut) to be carried out and the required efficiency.
•Make sure the water tray contains enough water.
•Set the guide-a-cut to the desired width of cut, using the two engraved measurements to align it
correctly.
•Do not force on the motor. This machine is not designed for a continuous use.

14
6 Maintenance and servicing
To ensure a long-term quality from the cutting with the TT200EM, please follow the maintenance
plan below:
Begin of the day During the changing of tool End of the day or more often if required Every week After a fault After a damage
Visual control (general aspect,
watertightness)
Whole machine
Clean
Flange and blade fixing devices Clean
Motor cooling fans Clean
Water pan Clean
Engine housing Clean
Reachable nuts and screws Tighten up
Maintenance of the machine
Always perform the maintenance of the machine with the machine isolated from the electrical
supply.
Lubrication
The TT200EM uses life-lubricated bearings. Therefore, you don’t need to lubricate the machine at
all.
Cleaning of the machine
Your machine will last longer if you clean it thoroughly after each day of work, especially water pan,
motor and blade flange.

15
7 Faults: causes and cures
7.1 Fault-finding procedures
Should any fault occur during the use of the machine, turn it off, and isolate it from the electrical
supply. Any works dealing with the electrical system or supply of the machine can only be carried
out by a qualified electrician.
7.2 Trouble-shooting guide
Trouble Possible source Resolution
No electricity Check the electrical supply (fuse for
example)
Connection cable section too small Change connection cable
Defective connection cable Change connection cable
Defective switch CAUTION : can only be solved by
qualified electrician
Motor is not running
Defective motor Change motor or contact motor
manufacturer
No water on the blade Not enough water in the pan Refill the water pan
7.3 Customer service
When ordering spare parts, please mention:
•The serial number (7 digits).
•The code of the part.
•The exact denomination.
•The number of parts required.
•The delivery address.
•Please indicate clearly the means of transportation required such as "express" or "by air".
Without specific instructions, we will forward the parts through the means which seem
appropriate to us --- but which is not always the quickest way.
Clear instructions will avoid problems and faulty deliveries.
If not sure, please send us the defective part.
In the case of a warranty claim, the part must always be returned for evaluation.
Spare parts for the motor can be ordered with the manufacturer of the motor or with their dealer,
which is often quicker and cheaper.
This machine has been manufactured by Saint-Gobain Abrasives S.A.
190, Bd. J.F. Kennedy
L- 4930 BASCHARAGE
Grand-Duché de Luxembourg.
Tel. : [phone]
Fax : [phone]
http://www.construction.norton.eu
e-mail: [email protected]

16
Guarantee can be claimed and technical support obtained from your local distributor where
machines, spare parts and consumables can be ordered as well:
Benelux and France:
From Saint-Gobain Abrasives S.A.
Free telephone numbers:
Belgium : 0 800 18951
France: 0 800 90 69 03
Holland: 0 8000 22 02 70
e-mail: [e-mail]
Czech Republic
Norton Diamantove Nastroje Sro
Vinohrdadska 184
CS-13000 PRAHA 3
Tel: [phone]
Fax : [phone]
e-mail : norton.[email protected]z
Germany
Saint-Gobain Diamond Products GmbH
Birkenweg 45-49,
D-50389 WESSELING
Tel : [phone]
Fax : [phone]
e-mail: [e-mail]
Spain
Saint-Gobain Abrasivos S.A.
C/. Verneda del Congost s/n
E-08160 MONTMELó (Barcelona)
Tel: [phone]
Fax: [phone]
e-mail:Comercial.s[email protected]
Poland
Saint-Gobain Diamond Products Sp.zO.O.
AL. Krakowska 110/114
PL-00-971 WARSZAWA
Tel: [phone]
Tel/Fax: [phone]
e-mail: [email protected]
United Kingdom
Saint-Gobain Abrasives Ltd.
Doxey Road
Stafford
ST16 1EA
Tel : [phone]
Fax : [phone]
e-mail : nort[email protected]
Austria
Saint-Gobain Abrasives GmbH
Telsenberggasse, 37
A-5020 SALZBURG
Tel : [phone]
Fax : [phone]
e-mail: off[email protected]
Hungary
Saint-Gobain Abrasives KFT.
Banyaleg Utca 60B
H-1225 BUDAPEST
Tel: ++36 1 371 2250
Fax: ++36 1 371 2255
e-mail: [email protected]
Italy
Saint-Gobain Abrasivi S.p.A.
Via per Cesano Boscone, 4
I-20094 CORSICO-MILANO
Tel: [phone]
Fax : [phone]
e-mail : Norton.edilizi[email protected]

17

18

19

20
SAINT-GOBAIN ABRASIVES
190, Bd. J. F. Kennedy
L-4930 BASCHARAGE
LUXEMBOURG
Tel.: ++352 50401-1
Fax: ++352 501633
e-mail: [email protected]
www.construction.norton.eu
08.12.2008
