Co2meter SAN-10 User manual

PERSONAL CO2 SAFETY MONITOR
AND DATA LOGGER
User Manual
SAN-10
User Manual R2.0
CO2Meter, Inc. 06321
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

CONTENTS
INTRODUCTION ................................................................................................................................. 2
FEATURES .........................................................................................................................................2
MONITOR ...........................................................................................................................................3
LCD DISPLAY ..................................................................................................................................... 3
OPERATION .......................................................................................................................................4
Power button ................................................................................................................................4
Temperature Units Button ............................................................................................................. 4
Menu Status ................................................................................................................................. 4
Alarm Threshold ...........................................................................................................................5
Automatic Atmospheric Pressure Compensation .......................................................................... 6
Man Down Alarm ..........................................................................................................................6
Reset Button................................................................................................................................. 6
DOWNLOADING DATA LOGS............................................................................................................ 7
CALIBRATION................................................................................................................................... 10
MAINTENANCE ................................................................................................................................ 11
Calibration .................................................................................................................................. 11
Cleaning and Storage ................................................................................................................. 11
SPECIFICATIONS............................................................................................................................. 12
Device Specifications.................................................................................................................. 12
CO2 Sensor Specifications ......................................................................................................... 12
Temperature Sensor Specifications ............................................................................................ 12
Relative Humidity Sensor Specifications..................................................................................... 12
TROUBLESHOOTING....................................................................................................................... 13
SUPPORT & WARRANTY................................................................................................................. 14
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

2
INTRODUCTION
Congratulations on your purchase of the SAN-10 Personal CO2 Monitor and Data Logger. It is
designed to alert employees who work in enclosed areas where carbon dioxide buildup may
cause personal harm. If CO2 buildup occurs, it will show the level on screen, flash, alarm and
vibrate. In addition the SAN-10 includes built-in data logging and a man-down alarm that uses
an accelerometer to set off the alarm if a sudden shock to the unit (like the wearer falling down)
occurs.
The SAN-10 uses a non-dispersive infrared CO2 sensor to provide long term stability. It is
shipped fully tested and calibrated and, with proper use, will provide years of reliable service.
FEATURES
•Audible, visual strobe and vibrating alarms
•Large LCD display
•Rugged design with protective rubber enclosure
•Heavy duty metal clip
•Front facing sensor unit
•Rechargeable Battery 4.2v, 1500mAh
•Micro USB cable and Wall USB charger
•Rechargeable Li-Ion battery – 20+ hours per charge
•Man down alarm - leveraging accelerometer technology
•Dual calibration methods: Ambient Air (300-600ppm) and Nitrogen (0-200ppm)
•Automatic atmospheric pressure compensation for CO2 concentrations
•No over-exposure or negative memory effects
•Stable NDIR sensor for CO2detection.
•CO2, and alarm!log data logging with time stamping
•Up to 149,500 time-stamped records in internal memory. Data can be exported via!
USB
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

3
MONITOR
1. Visual alarm/strobe
2. Front facing sensor
3. Charging indicator
4. LCD display
5. Power button
6. Menu button
7. USB port and charging inlet (bottom
side)
8. Heavy duty metal clip
9. Factory reset button
LCD DISPLAY
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021
1. Low alarm indicator
2. High alarm indicator
3. Battery indicator
4. CO2 concentration
5. CO2 concentration units (ppm or %
when >9,999 ppm)
6. Calibration icon
7. Man down alarm
8. Data logging indicator

4
© Copyright CO2Meter.com. All rights reserved.
OPERATION
2.0 Power button
1.!When the Monitor isturned off, press the power button to turn on the unit.
2.!When the Monitor isturned on, press the power button for 3 seconds to turn off the
unit.
When the unit is first turned on, it performs 5 seconds countdown for Monitor warm up, then
enters normal display with current CO2 readings displayed. The monitor starts taking
measurements when power on and updates readings every 2seconds.
2.1 Menu Status
Menu Items
Functional
Description
AIR (“AIR”)
Ambient Air Calibration. User presses the power button to
implement Ambient Air Calibration (300~600ppm).
N2 (“ ”)
Nitrogen Calibration. Press the power button to start
nitrogen calibration (0~200ppm).
High Alarm Threshold setup.
L0.5/L0.5T/L1.0
/L1.5/L3.0
Low Alarm Threshold setup.
Press the power button to switch the low alarm threshold:
L0.5 (5000 ppm), L0.5T (5000 ppm TWA), L1.0 (10000 ppm),
L1.5
(15000 ppm), and L3.0 (30000 ppm).
A ON
A OFF
Man down alarm set on/off.
Press the power button to switch “A ON” to turn on the man
down alarm or “AOFF” to turn off the man down alarm)
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021
By pressing the menu button for 5 seconds, the unit enters into "Menu
status". There are six menu items by pressing the menu button shortly to
loop switching between AIR, N2, Hx.x, Lx.x, A ON/AOFF, SC, Px, Log and E
(exit).
The menu times are further described in the table below:
H0.5/H0.5T/
H1.0/H1.5/H2.
0/H2.5/H3.0/
H3.5/H4.0
User presses the power button to switch the high alarm
threshold: H0.5 (5000ppm), H0.5T (5000 ppm TWA), H1.0
(1000ppm), H1.5 (15000ppm), H2.0 (20000ppm), H2.5 (25000ppm),
H3.0 (30000 ppm), H3.5 (35000 ppm) and H4.0 (4000ppm).

5
SC (“ ”)
Real time clock setup
Press the power button to enter the real time clock setup:
a. Press the button to switch between Year ( ), Month (),
Day ( ), Hour ( ), Minute ( ), Second ( ) and . to exit.
b. Press the power button to increase the value until the
correct time is set. This value is a cyclic change. Press the
power button again to save and exit the menu status.
For example, set the month to February by pressing the
power button in “ ”:
Px
Data logging period setup
Press the power button to switch the data logging period
between: P30 (30 seconds), P60 (60 seconds), P120 (120
seconds or 2 minutes), P300 (300 seconds or 5 minutes), P600
(600 seconds or 10 minutes) or P900 (900 seconds or 15
minutes).
Log (“ ”)
Data logging memory operation
Press the power button to switch the data logging memory
operation between:
•EP (Export data logging by USB)
•RES (Reset the memory)
•E (Exit without operation).
E
Exit. Press the power button to exit the menu status.
3.0 Alarm Threshold
The SAN-10 is equipped with audible, visual and vibration alarms to alert users when the
ambient oxygen concentration exceeds either of the two factory preset alarm levels:
•Danger High Alarm: LED will flash and audible alarm will sound 3x / sec.
•Warning Low Alarm: LED will flash and audible alarm will sound 2x / sec.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021
There are high and low alarm thresholds in the SAN-10. Both high and low alarms have
five thresholds: 5000ppm, 5000ppm TWA, 1.0%, 1.5%, 2.0%, 2.5%, 3.0%, 3.5% and
4.0%. Obviously, the high alarm threshold should not be less than the low threshold.
They can be the same alarm level.

6
Automatic Atmospheric Pressure Compensation
The CO2 measurement is affected by atmospheric pressure or altitude changing. When
users are at high altitude, compensation is made internally to ensure maximum monitor
accuracy.
This device has automatic atmospheric pressure compensation for CO2 concentrations by
means of a digital atmospheric pressure sensor integrated in the unit.
Man Down Alarm
Falling by breathing dangerous gases can cause serious injury and even fatality to workers.
If the Man downalarm function in SAN-10is set on, SAN-10 can detect falls and send a
man down alert which will activate the audible and visual alarms and alert other people in
the area.
The man-down detection uses a three-axis accelerometer to automatically monitor the user’s
movements in order to identify a sudden fall or impact and a lack of movement for a period of
6 seconds.
Once alerted, you can turn off the man-down alarm by pressing either of the two buttons.
Reset Button
Users can reset the unit by pushing a reset button through a hole on back of shell.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

7
© Copyright CO2Meter.com. All rights reserved.
DOWNLOADING DATA LOGS
1. Download latest version of GasLab®: https://www.co2meter.com/pages/downloads
2. Power on the SAN-10device
3. Wait for 5 second warm upcountdown
4. Connect the SAN-10 to your Windows PC with the USB cable
5. Open the Gaslab software
6. Set Sensor Select options.
7. Select the Port in which your SAN-10 device is connected.
8. Do not select a Product.
9. Select SAN-XY under Series/Model.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

8
10.Press Connect. When connected the window should appear as shown below:
11.Click Configure Sensor and the following page will appear:
12.Make sure the Serial Number matches the one found on the back of your device.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

9
13.Select the Datalogs tab.
14.Click the Download Datalog button. Name and select a location to save your file.
Data logs are .CSV (common separated values) files which can be opened or imported into
any spreadsheet program.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

10
CALIBRATION
Step 1. Power the unit on by pressing and holding the power button for 3 seconds
Step 2. Press and hold the ºF/ºC button for 5-10 seconds to open the first menu
Step 3. Use the ºF/ºC button to scroll through the first menu which will read:
a) AIR (Ambient Air Calibration Option)
b) N2 (Zero Nitrogen Calibration Option)
c) L 0.5 (Low alarm threshold)
d) H 3.0 (High alarm threshold)
e) A ON (Alarm option. Turns the alarm on and off)
f) E (To exit the menu and return to home screen)
Step 4. Perform AIR or N2 calibration
“AIR” Ambient air calibration
•Follow above instructions to
access the menu
•The “AIR” option is the first to
appear
•Bring the unit OUTSIDE or use
400ppm CO2
•Press the power button to start
the calibration
•If the screen reads “FAIL” repeat
until the calibration passes
*IF THE MONITOR DOES NOT READ IN
THE 300-600 PPM RANGE BEFORE
PERFORMING THE CALIBRATION, IT
WILL NOT CALIBRATE IN THE FIRST
MENU.
“N2” Nitrogen calibration
•Follow above instructions to
access the menu
•Go to “N2” option
•Expose the device to nitrogen gas
•Press the power button to start
the calibration
•If the screen reads “FAIL”
repeat until the calibration
passes
*IF THE MONITOR DOES NOT READ
IN THE 0-200 PPM RANGE IT WILL
NOT CALIBRATE IN THE FIRST
MENU.
Step 5. (USE ONLY IF THE DEVICE IS NOT IN RANGE AND FAILED TO CALIBRATE IN
THE FIRST MENU)
To open the second menu press and hold the ºF/ºC button while already in the first menu.
Step 6. This menu will allow you to calibrate without range limitations. The second menu will
read:
o-AIR (Ambient Air Calibration Option without limits)
o-N2 (Zero Nitrogen Calibration Option without limits)
oE(To exit the menu and return to home screen)
Step 7. When calibration is complete make sure the unit is reading within the span
values. You can test with fresh air which should read about 400ppm CO2.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

11
MAINTENANCE
Calibration
The SAN-10 comes pre-calibrated from the factory. However, the CO2 sensor should be
calibrated at least once a year, or as described in your company’s safety procedures. You
can perform the calibration yourself, or you can return itfor factory calibration at a nominal
fee.
Cleaning and Storage
Apply sparingly with a soft cloth and allow drying completely before using. Do not use
soap or Alcohol cleaning. Do not use aromatic hydrocarbons or chlorinated solvents for
cleaning.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

12
SPECIFICATIONS
Dual Beam NDIR (Non-dispersive-Infrared) CO2 diffusion sensor with Automatic Background
Calibration (ABC) turned off.
Device Specifications
Operating
Environment
32°F~122°F (0°C~50°C), <95% RHnon-condensing
Storage 14°F~140°F (-10°C~60°C), <99% RHnon-condensing
Power Supply Li-ion battery (4.2V,1500mAh),Micro USB cable w. Wall
USB charger
Dimensions 3.9x2.0x1.7 Inch (98x50x42mm)
Weight 4.76 oz.(135 grams)
Out ofrange of operating conditions will impact the accuracy of CO2 measurement.
CO2 Sensor Specifications
Measurement Range 0-50,000ppm
Display Resolution 1ppm / 0.01%
Accuracy
Repeatability ±20ppm @ 400ppm
Temperature
Dependence
Typ. ±0.3% of reading per °C or ±4ppm per °C, whichever is
greater, referenced to 25 °C
Pressure Dependence
Response Time About 2 min for 90% of step
change
Warm-up Time <5 seconds at 22°C
Measurement interval 2 seconds
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021
±70ppm +5% of reading
500mbar - 10bar

13
TROUBLESHOOTING
Symptom / Issue
Possible Cause / Resolution
Cannot power on
Press the Power Button for more than 5 seconds
Check that the Li-ion battery is charged
If monitor is charged but will not turn on, contact support
Monitor is not
recognized by
computer or software
Verify that software and drivers are installed correctly
before attaching monitor to PC.
Verify the software and drivers were installed before the
monitor was plugged into the PC with the USB cable.
Verify that the ftd2xx.dll file is in the same folder as the
executable program.
Try using a different USB cable.
Windows reports
“unknown device”
error
Follow these instructions for troubleshooting GasLab driver
installation.
Slow response
The log file stored in the monitor is very large. The monitor
needs time to transfer data to your computer.
Readings do not
change
Confirm the monitor is correctly connected to the computer.
Make sure the computer recognizes your monitor and
connects with your monitor successfully.
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021

14
SUPPORT & WARRANTY
The quickest way to obtain technical support is via email. Please include a clear, concise
definition of the problem and any relevant troubleshooting information or steps taken so far,
so we can duplicate the problem and quickly respond to your inquiry.
For more information visit our website:
https://www.co2meter.com/
We are here to help!
For information or technical support, please contact us.
[e-mail]
(386) 310 - 4933
CO2Meter, Inc.
131 Business Center Drive Ste A3
Ormond Beach, FL 32174 USA
© Copyright 2021, CO2Meter, Inc. All Rights Reserved. Last modified June 2, 2021
