Coastal Amusements SPIDER-BOT User manual

Version W820-B16
Coastal Amusements, Inc.
1935 Swarthmore Ave.
Lakewood, NJ 08701 [phone]

SPIDER-BOT
Redemption Version
(Version: W820-B16, Date: Aug.-25-10)
HOW TO PLAY
1. Insert coin(s). The spider’s back-light will go out after it returns to the start
position; then begin to scurry around the web.
2. A timer will start counting down and the player must “Zap” the spider with the
“Laser Gun”.
3. The player aims at the target on the spider’s back and “Zaps” the spider to win.
Each time the player successfully hits the spider, the “
Number of Hits Needed
to Win
” display will decrease by 1. When the number is “0”, the player wins.
4. 5 or 10 seconds before game over, the game will send a “bee” sound to alert
the player that time is about to expire.
5. When time expires, the spider will return to the home position (upper left
corner).
6. When the player successfully hits the spider enough times to win, the spider
will immediately return to the home position.
7. There are 4 levels difficulty that control the spider’s speed and movement. The
more the spider is hit, the faster the spider will crawl around the web.

※ DIP SW ADJUSTMENT
PCB:
W060101B SOFTWARE: W820B16
PS. DEFAULT SETUP. OON, XOFF
SW No ITEM SETTING DIP SW1
12
ON ON 1 : 2
ON OFF 4 : 1
OFF ON 2 : 1
SW1 - 1,2 COIN1 VS. CREDIT
OFF OFF 1 : 1
34
ON ON 1 : 2
ON OFF 4 : 1
OFF ON 2 : 1
SW1 - 3,4 COIN2 VS. CREDIT
OFF OFF 1 : 1
56
ON ON 5
ON OFF 2
OFF ON 1
SW1 - 5,6 REDEMPTION TICKET(S)/UPON
COINS INSERTED OFF OFF
0
78
ON ON Very hard
ON OFF Hard
OFF ON Easy
SW1 - 7,8 DIFFICULTY
OFF OFF Very easy
1 2 3 4 5 6 7 8
DIP SW1 FACTORY
DEFAULT X X X X X X O X
EXPLAINATION
If COIN1 and COIN2’s “COIN vs. CREDIT” are set the same, both inputs will be
counted together. Example:
If COIN1 and COIN2 are both set to 2 coins = 1
play, then 1 coin inserted into COIN1 and 1 coin inserted into COIN2, will equal
1 play.

SW No ITEM SETTING DIP SW2
1 2 3
ON ON ON 60 HITS
ON ON OFF 55 HITS
ON OFF ON 50 HITS
ON OFF OFF 45 HITS
OFF ON ON 40 HITS
OFF ON OFF 35 HITS
OFF OFF ON 30 HITS
SW2 – 1,2,3
Number of Hits to
Win Bonus”.
OFF OFF OFF 25 HITS
SW2 - 4,5,6 RESERVED 4 5 6
7 8
ON ON 30 SEC.
ON OFF 25 SEC.
OFF ON 20 SEC.
SW2 - 7,8 Game Time
OFF OFF 15SEC.
1 2 3 4 5 6 7 8
DIP SW2 FACTORY
DEFAULT O X O - - - O X
EXPLANATION
“”
HITS NEEDED TO WIN BONUS ”: Calculated as # of shots/game - # of misses
allowed = “Hits Needed to Win Bonus”.

 When DIP SW4-8 is OFF, the setting of Ticket payout (BONUS TICKET PAY) is as
below.
SW No ITEM SETTING DIP SW3
123 4
ON ON ON ON
16 HITS =
1 TICKET
ON ON ON OFF
15 HITS =
1 TICKET
ON ON OFF ON
14 HITS =
1 TICKET
ON ON OFF OFF
13 HITS =
1 TICKET
ON OFF ON ON
12 HITS =
1 TICKET
ON OFF ON OFF
11 HITS =
1 TICKET
ON OFF OFF ON
10 HITS =
1 TICKET
ON OFF OFF OFF
9 HITS =
1 TICKET
OFF ON ON ON
8 HITS =
1 TICKET
OFF ON ON OFF
7 HITS =
1 TICKET
OFF ON OFF ON
6 HITS =
1 TICKET
OFF ON OFF OFF
5 HITS =
1 TICKET
OFF OFF ON ON
4 HITS =
1 TICKET
OFF OFF ON OFF
3 HITS =
1 TICKET
OFF OFF OFF ON
2 HITS =
1 TICKET
SW3 -
1,2,3,4
HITS/TICKET
OFF OFF OFF OFF
1 HITS =
1 TICKET
56
ON ON 200
ON OFF 100
OFF ON 50
SW3 - 5,6 Bonus Reset Value
OFF OFF 25
78
ON ON 4 TICKETS
ON OFF 3 TICKETS
OFF ON 2 TICKETS
SW3 - 7,8 Bonus Value
Increment/Play
OFF OFF 1 TICKET
1 2 3 4 5 6 7 8
DIP SW3 FACTORY DEFAULT XOOOXOX X

When DIP SW4-8 is ON, the setting of Ticket payout (FLAT TICKET PAY GAME) is
as below.
SW No ITEM SETTING DIP SW3
1 2 3
ON ON ON
1 TICKET
ON ON OFF
2 TICKETS
ON OFF ON
3 TICKETS
ON OFF OFF
4 TICKETS
OFF ON ON
5 TICKETS
OFF ON OFF
6 TICKETS
OFF OFF ON
7 TICKETS
SW3 -
1,2,3
FLAT TICKET PAY
(If win, X tickets
are given)
OFF OFF OFF
8 TICKETS
4
ON
SW3 - 4 RESERVED OFF
SW No ITEM SETTING DIP SW4
1
ON YES
SW4 - 1 Keep CREDIT
after power off? OFF NO
2
ON YES
SW4 – 2 Keep tickets
owed after
power off? OFF NO
3
ON 10 SECONDS
SW4 – 3 “Bee” sound ON
before game time is
up OFF
5 SECONDS
4
ON YES
SW4 - 4 DEMO game OFF NO
5
ON Sound on
SW4 -5 Sound in attract OFF Sound on
6
ON
SW4 -6 Dispend unpaid
tickets after
power on OFF
7
ON YES
SW4 – 7 Keep Progressive
Bonus after Power
Off? OFF NO
8
ON FLAT TICKET PAY
SW4 – 8 Ticket Payout
model OFF BONUS TICKET PAY
1 2 3 4 5 6 7 8
DIP SW4 FACTORY
DEFAULT O O X X O O O X

※Ticket Payout model：
Bonus ticket pay：Within game time, Bonus tickets can be won if the hit numbers
are reached on the setting of DIP SW2, 1~3 “Number of Hits to Win Bonus”. If hit
number is not reached to win bonus tickets, the tickets payout is given by setting
of DIP SW3-1,2,3,4.
FLAT TICKET PAY：When DIP SW4-8 is ON, Tickets are only given by setting of DIP
SW3-1,2,3.
SYSTEM RESET:
PRESS “CLEAR” &“TEST SW” TOGETHER AND THEN TURN ON THE
GAME; RELEASE BOTH SWITCHES AFTER “BEE” SOUND IS HEARD .

※ ERROR CODES EXPLANATION
CODE DESCRIPTION TROUBLE SHOOT
E0
Gantry not in home
position on power up
Press the TEST SW for test mode.
The possible reasons:
1. UP/DOWN string reversed.
2. UP/DOWN motor fuse burned or UPPER SW
failure.
3. LEFT/RIGHT motor fuse burned or LEFT SW
failure.
4. Motor movement blocked by something.
5. Check if gantry JP1 harness pin is
disconnected.
6. Main board failure.
E1
Right-stop SW breakdown on
power up.
Press the TEST SW for test mode and check.
The possible reasons:
1. Right stop SW breakdown, harness
disconnected, or faulty connection.
2. Check if gantry JP1 harness pin
disconnected.
3. Main board failure.
E2
Lower stop SW breakdown
on power up.
Press TEST SW for test mode and check.
The possible reasons:
1. Lower-stop SW breakdown, harness
disconnected, or bad connection.
2. Check if gantry JP1 harness pin
disconnected.
3. Main board failure.
E3
Upper stop SW
breakdown on power
up. String is going down
but upper stop SW is not
changing its condition
from N.O. to N.C.
Press TEST SW for test mode and check.
The possible reasons:
1. UP/DOWN string reversed.
2. Right stop SW breakdown, harness
disconnected, or bad connection.
3. F2 FUSE burned. LEFT/RIGHT motor fuse
burned.
4. Check if gantry JP1 harness pin
disconnected.
5. Main board failure.

CODE DESCRIPTION TROUBLE SHOOT
E4
Spider not going up to home
position on power up.
Upon power up, the strin
g
g
oes down, then
g
oes up, but
Upper stop SW does not
receive a signal
Press TEST SW for test mode and check.
The possible reasons:
1. UP/DOWN string reversed.
2. Upper stop SW breakdown, harness
disconnected, or bad connection.
3. F2 FUSE burned. UP/DOWN motor fuse
burned.
4. Check if gantry JP1 harness pin
disconnected.
5. Main board failure.
E5 Coin mech error
On power up, the coin mech is signal checked
automatically. E5 is displayed when set into
N.C.
1. Check the N.O./N.C. SW and restart game
after set to N.O.
2. Coin mech failure.
3. Main board failure.
E6 TICKETS OUT ERROR Press CLEAR to restart ticket dispenser.
E9
Spider not returning to
home position on power
up.
E9 is displayed. The game will still start after
coin in. E9 will clear after 3 attempts.

※ FUSE POSITIONS ON THE MAIN BOARD
F1: Left/right motor fuse, 20mm slow 2A
F2: Up/Down motors fuse, 20mm slow 2A
F3: Claw coil fuse, 20mm slow 2A
F4: Forward/backward fuse, 20mm slow2A
TEST
Press TEST SW for 0.8 seconds to enter test feature. All motor power will shut down during
test. Press TEST SW to change test item, and restart the game to quit TEST＂feature.

Code ITEM DESCRIPTION
1
DISPLAY TEST ALL DISPLAYS, LED AT THE SPIDER, AND BULBS。
2
1. Test all I/O, including 6 items:
2. How to test:
A. Press SERVICE SW to change the test items
B. Press TEST SW to quit
DISPLAY ON “PLAY” DISPLAY
DISPLAY ON “TIME” DISPLAY
1 -
Test DIP SW1
SW1 ON/OFF
2 -
Test DIP SW2
SW2 ON/OFF
3 -
Test DIP SW3
SW3 ON/OFF
4 -
Test DIP SW4
SW4 ON/OFF
5 -
Not Used
6 -
OTHER INPUTS
KEY CODE displayed as below
CODE Inputs
0 Coin Mech 1
1 Coin Mech 2
2 Ticket dispenser SENSOR
3 CLEAR SW
4 SERVICE SW
5 TEST SW
6 Not Used
7 Not Used
8 I/R receiver SENSOR
11 Playfield UP SENSOR
12 Gantry UP-Stop SW
13 gantry Down-Stop SW
14 Gun trigger SW
16 Gantry right-stop SW
17 Gantry left-stop SW
18 Gantry up/down home position plate sensor
How to quit:
1. Press SERVICE SW for 2 seconds to quit, and back to “1“.
2. Press TEST SW for 2 seconds to quit and enter “Gantry Test”

CODE ITEM DESCRIPTION
3
GANTRY
TEST
1. Gantry and claw test:
2. How to test:
(1.) Press SERVICE SW to change the spider’s movement.
(2.) Press CLEAR SW to move spider. Press to energize
motor; press Stop SW to stop motor.
(3.) Press TEST SW to quit and enter next item (output).
(4.) Press gun trigger to grab.
3. Code:
(1.) '
7- ' on “CREDIT” displayGantry test
(2.) 7-segment display at the left of TIME display Movin
g
way limited
(3.) 7-segment display at the right of TIME display Moving
way, and flash when motor is working.
(4.) 7-segment display at the left of HIT display  UP-Down
home position calibration: Middle line "-" means the middle
p
la
y
field
range over. Bottom line "_" means the lower playfield range over.
(5.) 7-segment display at the right of HIT display  UP-Down
home position plate sensor. Middle line "-" means sensor status shows at
the lower column of the display.
(6.) Hits Needed to Win display show gantry up-down
home position. The display number will increase when
the gantry is going down, and decrease when going up.
(7.) Spider’s eyes light up when the claw is working.

4
OUTPUT
INTERFACE
1. Test output I/Os, including 4 items:
2. How to test:
i. Press SERVICE SW to change test items.
ii.Press TEST SW to quit for Sound Test.
Display on PLAY Display on TIME display
9 -
Ticket dispenser Test
1. Left 7-segment display for ticket dispenser sensor.
2. Press the trigger to test ticket dispenser motor.
1 0
I/R receiver and transmitter Test
1. Spider’s eyes light up when I/R light is received.
2. Press gun trigger to test I/R light. Aim at spider target to
check the receiver.
1 1
Counter Meter Test
1. 10 units up in sequence
2. Explanation:
7-segment display at the left of TIME
7-segment display at the right of TIME
1 X
Coin 1 Meter
Display in decreasing progressively
2 X
Coin 2 Meter
4 X
Ticket dispenser Meter
CODE ITEM DESCRIPTION
5
Sound
Test
1. Sound Test:
2. How to test:
A. Press SERVICE SW to change sound:
B. Press CLEAR SW to replay:
C. Press TEST SW to quit for “DISPLAY” item.
3. Explanation:
'
12 ' displayed on the CREDIT display
“Sound Test” code displayed on the TIME display

Wiring Diagram
1 1 1 1
1
J11 JP4 J6 1
1 J3 J15 J14
J4 JP5
1
1
J5
MAIN BOARD W060101B
J3 1
1
J10
J7
1
1
J12
JP1
J2
1
2 1
J1
1
J4 COLOR PIN J7 COLOR PIN
1 BE SP- SPEAKER - 1 12V +12V
2 SP- SPEAKER - 2 BN 12V +12V
3 SP+ SPEAKER + 3 GY/BK L-IN PLAYFIELD
SENSOR
PLAYFIELD
SENSOR
4 PE SP+ SPEAKER +
SPEAKER
4 BK B-OK SENSOR
SIGNAL
5 BE GND GND
J8 COLOR PIN 6 BE/WE GND GND
DEMO CAPSULE
HOME
POSITION
SENSOR
1 WE IN VR #PIN1
2 RD OUT VR #PIN2 J2 COLOR PIN (RED)
3 BK GND VR #PIN3
VOLUMN
VR
（1K）
1 OE M4+ MOTOR +
2 M4+ MOTOR +
J3 COLOR PIN 3 GN M4- MOTOR -
1 YW 12V +12V 4 M4- MOTOR -
CAPSULE
DISPLAY
SENSOR
2 BK GND GND 5 12V +12V
3 RD S5V +5V 6 BN 12V +12V
4 BK SGND GND
POWER
SUPPLY
(P2040)
PIN
7 BK B-SEN PRIZE OUT
MOTOR
8 W-SEN
9 BE GND GND
10 GND GND
PRIZE OUT
SENSOR
F4
2A
F3
2A
F2
2A
F1
2A
RY6 RY5 RY3 RY4 RY1 RY2
U16
ROM

JP4 （ 34P CONNECTOR ） JP5 TO DISPLAY （ 40P CONNECTOR ）
P#
COLOR PIN
P#
COLOR PIN
P#
COLOR PIN
P#
COLOR PIN
1
RD +12V
2
GN COIN1 INHIBIT
1
BN/
WE AA
2
RD BA
3
WE COIN1 SIGNA
4
BK GND
3
RD/
WE AB
4
OE BB
5
RD +12V
6
GN/
WE COIN2 INHIBIT
5
OE/
WE AC
6
YW BC
7
WE/
BE COIN2 SIGNAL
8
BK GND
7
YW/
GN AD
8
GN BD
9
RD +12V
10
WE/
BK TICKET IN
9
GN/
WE AE
10
BE BE
11
GN/
YW TICKET OUT
12
BK GND
11
BE/
WE AF
12
PE BF
13
RD +12V
14
OE/
WE COIN1 METER
13
PE/
WE AG
14
GY BG
15
+12V
16
YW/
GN COIN2 METER
15 16
17
+12V
18
GN/
WE PRIZE METER
17
BY/B
K CM0
18
WE CM2
19
+12V
20
BE/
WE TICKET METER
19
WE/
RD CM1
CREDIT
DISPLAY
20
PK CM3
HITS
DISPLAY
21
PE CLEAR SW
22
BK GND
21
BN CA
22
RD/
WE DA
23
GY SERVICE SW
24
GND
23
RD CB
24
OE/
WE DB
25
PK TEST SW
26
GND
25
OE CC
26
YW/
GN DC
27 28 27
YW CD
28
GN/
WE DD
29 30 29
GN CE
30
BE/
WE DE
31
+12V
32
START LIGHT
31
BE CF
32
PE/
WE DF
33
START SW
34
GND
33
PE CG
34
GY/B
K DG
35 36
J6
COLOR PIN
37
GY CM4
38
WE/
BE CM6
1 RD 12V 39
WE CM5
LASER
POWER
DISPLAY
40
PK/B
E CM7
TIME
DISPLAY
2 OE MOT
3 YW CTL
JP1 GANTRY PIN （ 20P ATX PIN ）
4 GN LED1
P#
COLOR PIN
P#
COLOR PIN
5 BE LED2
1 RD L/R MOTOR
+
2
RD/
BK L/R MOTOR
-
6 PE SW
3 OE U/D MOTOR
+
4
OE/B
K U/D MOTOR
-
7 BK GND
CONNECT TO J1 OF
GUN TRANSMITTER
W060103
（1 TO 1）
5 YW RIGHT STOP
SENSOR (N.C.)
6 WE LEFT STOP
SENSOR (N.C.)
J1
COLOR PIN
7
BE/
WE L/R STOP SW
(COM.)
8
GY/
WE U/D STOP SW
(COM.)

1 YW 12V +12V
2 BK GND GND
3
9 PK UP-STOP SW
(N.O.)
10 BK DOWN-STOP
SW (N.C.)
4 GR 24V +24V
11 TOP SW 12 GND
5 BK GND GND
POWER
SUPPLY
(P2040)
PIN
13 BN +24V 14 GN CLAW
-
15 16
YW/
BK DATA
17
GN/
RD CLK
18
PE/Y
W LASER-IN
19 BE GND 20
BE/O
E LATCH
#13~20 CONNECT TO J1 OF W060102

J10 COLOR PIN J11 COLOR PIN
1 BN TDA 1 BK GND
2 RD TDB 2 RD R1
3 OE TDC 3 OE G1
4 YW TDD 4 YW B1
CONNECT TO
LEFT LED BOARD LED
BOARD
5 GN TDE 5 BK GND
6 BE TDF 6 GN R2
7 PE TDG 7 BE G2
8 TDP 8 PE B2
CONNECT TO
RIGHT LED
BOARD LED
BOARD
9 GY CM8 9 GND
10 WE CM9
CONNECT TO
“HITSNEEDED TO
WIN” DISPLAY
10 LED-W
11 +12V
12 +12V
J12 COLOR PIN J13 COLOR PIN
1 BN TX 1 BN AC1
2 BK GND 2 BE AC2 TRANSFORMER
AC12V
3 OE RX
4 GND
CONNECT TO J3
OF MATRIX
BOARD W040314
J14 COLOR PIN J15 COLOR PIN
1 BN AC2 1 BN AC2
2 RD LED11 2 RD LED11
3 OE LED12 3 OE LED12
4 YW LED13 4 YW LED13
5 GN LED14 5 GN LED14
6 BE LED15 6 BE LED15
7 PE AC2
CONNECT TO
ROUND LED
BOARD W040420
10 PE AC2
CONNECT TO
ROUND LED
BOARD W040420

1 1
J2 J1
W060102A
I/R RECEIVER BOARD
J5 J3
1 1
1 1
LED J2
1 1 1
J1 J4
J4-1
W060103
I/R SHOOTING BOARD
J1A W060102A-1
1 SPIDER EYE LED PCB
W060102A-2
SPIDER BELLY LED PCB
W060103-LED
LASER GUN LED BOARD
※ W060102A I/R RECEIVER BOARD ※ W060103 I/R SHOOTING BOARD
J1
COLOR PIN LED COLOR PIN
1 BN 24V 1 R LED RED
2 GN CLAW- 2 - LED COM
3 BE GND 3 G LED GREEN
4 YW/BK DATA
5 GN/RD CLK J1 COLOR PIN
6 BE/OE LATCH 1 RD 12V
7 PE/YW LASER-
CONNECT TO
J2 PIN 13~29
OF W060101
2 OE MOT
3 YW CLT
J2 COLOR PIN 4 GN LED1
1 GN CLAW- CLAW COIL - 5 BE LED2
2 WE 24V CLAW COIL + 6 PE SW
7 BK GND
CONNECT TO J6
OF
W060101
J3 COLOR PIN
1 BE EYE LED1 J2 COLOR PIN
2 GN EYE LED2 1 PK LED + I/R LED +
3 YW +5V
CONNECT TO
W060102A-1
2 BK LED - I/R LED -
J5 COLOR PIN J4 COLOR PIN
1 PK Ball LED1 2.0” 9PIN
CONNECT TO LASER GUN LED BOARD
2 WE Ball LED2
3 YW +5V
CONNECT TO
W060102A-2
J4-1 COLOR PIN
2.0” 9PIN
CONNECT TO LASER GUN LED BOARD
J1B
1
1
J1

※ MATRIX DISPLAY W040314
J1
J2 J3
1 1 1
J1 COLOR PIN NOTE J3 COLOR PIN NOTE
1 YW +12V INPUT 1
2 BK GND（12V GND） 2
3 RD +5V INPUT 3
4 BK GND（5V GND）
POWER
SUPPLY
PIN
4
5
J2 COLOR PIN NOTE 6
NOT USED
1 BN TX
2 BK GND
3 OE RX
CONNECT TO J12 OF
W060101B
SW1
U15 U9 ROM
