Coastal Amusements TOY SOLDIER User manual

COASTAL
TOY SOLDIER
(MODEL WMH-288B)
OPERATING MANUAL
COASTAL AMUSEMENTS, INC.
1935 SWARTHMORE AVE.
LAKEWOOD, NJ 08701
TEL: [phone]
FAX: [phone]
E-MAIL: [e-mail]

- 1 -
WMH-188B/288B SERIAL INDEX
※GENERAL DESCRIPTION …………………………………………………… 2
※WIRING DIAGRAM ………….………………………………………………… 4
※DIP SW INSTRUCTIONS …………………………………………………….. 6
※INNER-VALUE SET UP INSTRUCTIONS ………………………………….. 9
※TESTING INSTRUCTION …………………………………………………….. 11
※WINDING CORD INSTRUCTIONS ………………………………………….. 12
※TROUBLE SHOOTINGS ……………………………………………………… 13
※GANTRY & ASSEMBLY I ……………………………………………………… 14
※GANTRY & ASSEMBLY II ……………………………………………………… 15

- 2 -
WMH-188B/288B GENERAL DESCRIPTION
1. Function:
In general, this model consists of two sections, the Software and the Hardware. Follow below its
applications:
Software: It edited in the INTEL MCS-51 assembly, main CPU is 8052.
Hardware: It consists of 6 sections listed below. (Pls. refer to the Hardware Provision Drawing.)
A. Display: It mainly displays the number of coin insertion and the operation data of machine.
B. Gantry: It includes 3 drive motors, claw coil and scout SW. It employs a joystick or controlling SW
to control the movement of seizing objects.
C. Operation: It employs a joystick or controlling SW to control the movement of Gantry.
D. Music: It employs 8052 to coordinate high quality music IC AP8942A and 8910 to produce beautiful
music sound.
E. Voice: The coordination of 8052 to AP8910A produces voice sound reporting the state of machine.
~ Hardware Provision Drawing ~
AC Power SW
Power Supply
MAIN BOARD
Light Control Board
GANTRY
Voice VR
Control BOX
Counter
Claws VR
Speaker
AD LAMP

- 3 -
2. How to play:
1. Insert coins/tokens into coin slot, the display shows credits and the coin counter takes record of
coin in.
2. Press【RUNNING】button to move turning disc and mix objects. It may roll up your selected
objects to the top for easier catching. (Invalid if the machine is set for ‘candy crane’ function /
program.)
3. Joystick operation: Use joystick to move claws above your selected object.
Push button operation: Use【Right】and【Front】buttons to move claws to above your selected
object.
4. Joystick operation: At pressing【DESCEND】button or time’s up (game’s playing time is
adjustable), the gantry drives motor to lower down claws and then catch
object. If ‘Catch in air’function is available, press【DESCEND】button again
and the claws can catch item in the air.
Push button operation: At pressing any buttons right after releasing【Right】and【Front】buttons
or time’s up (game’s playing time is adjustable), the gantry drives motor
to lower down claws and then catch object. If ‘Catch in air’function is
available, press any button again and the claws can catch item in the air.
5. After movement of catching (claws closes), the claws rise up till it touches Stop-Up SW. Then the
claws move to exit area and releases.

- 4 -
WMH-188B/288B Serial Main PCB Wiring Diagram
1 1 1 1 1 1 1
J10 J11 J8 J7 J2 J3 J1
1
J12
1
J9 U3
主機板
S4 W030934 / W070514
J6 J5 13 1
1 1 1 25 12
J1
Color
Connection
J7
Color
Connection
1
Black
GND
1
RD / WE
+12V output
2
Brown
Joystick -- Front SW(N.O.)
2
OE / WE
COIN1 Meter
3
Red
Joystick -- Back SW (N.O.)
3
YW / GN
COIN2 Meter
4
Orange
Joystick -- Right SW (N.O.)
4
GN / WE
OUTPUT Meter
5
Yellow
Joystick -- Left SW (N.O.)
5
BE / WE
TICKET Meter
6
Green
Descend SW (N.O.)
7
Blue
Running SW (N.O.)
J8
Color
Connection
8
Black
GND
1
Brown
TILT SW (N.O.)
9
Gray
Descend button lamp
2
Purple
TEST SW (N.O.)
10
White
3
Black
GND
4
Black
Coin Selector 1-- GND
J3
Color
Connection
5
WE / GN
Coin Selector 1 -- Coin Signal
1
Black
Reserve.
6
Red
Coin Selector 1 -- +12V
2
Green
7
Red
Coin Selector 2 -- +12V
3
Yellow
8
WE / BE
Coin Selector 2 –Coin Signal
4
Orange
9
Black
Coin Selector 2 -- GND
5
Red
10
Black
Ticket dispenser -- GND
6
Brown
11
GN / WE
Ticket dispenser-- OUT
7
12
White
Ticket dispenser -- IN
8
Blue
13
Red
Ticket dispenser -- +12V
14
Red
+12V
J2
Connected to Display Board
15
Grey
Turn Disk SSR
16
Black
GND
17
18
Green
Coin Inhibit input –
JP1
J4
Main ROM
SW1
K2
SW2
SW3
K1
K4
K3
K5
K6

- 5 -
J11
Color
Connection
JP1
Color
Connection
1
Reserve.
1
Black
GND
2
2
Black
GND
3
3
Black
GND
4
4
Yellow
+5V Input
5
5
Yellow
+5V Input
6
Red
+12V Input
J10
Color
Connection
7
Red
+12V Input
1
Blue
Output Sensor -- GND
8
Orange
+24V Input
2
Gray
Output Sensor -- signal
9
Orange
+24V Input
3
Brown
Output Sensor -- +12V
10
Purple
+48V Input
JP4
Reserve.
J4
Color
Connection
1
BN / WE
Front / Back Motor +
J12
Color
Connection
2
RD / WE
Left / Right Motor -
1
Reserve.
3
OE / WE
Up / Down motor -
2
4
White
Claws Coil
3
5
GN / WE
4
6
BE / WE
Stop-Front / Back SW (N.O.)
5
7
WE / BN
8
PE / WE
Stop-Left / Right SW (N.O.)
J13
Color
Connection
9
Pink
Stop-UP SW (N.C.)
1
Reserve.
10
Black
Stop-Down SW (N.O.)
2
11
WE / BE
12
GY / BK
J6
Color
Connection
13
WE/GN
+12V Output
1
White
Volume VR -- PIN1
14
Brown
Back / Front Motor -
2
Red
Volume VR -- PIN2
15
Red
Left / Right Motor +
3
Black
Volume VR -- PIN3
16
Orange
Up / Down Motor +
4
Black
Speaker -
17
Yellow
Claws Coil
5
Purple
Speaker +
18
Green
19
Blue
Stop-Front / Back SW COM.
J5
Color
Connection
20
Purple
Stop-Left / Right SW COM.
1
Red
VR1 Signal
21
Gray
Stop-Up / Down SW COM.
2
Orange
VR1 COM.
22
WE / PE
GND
3
Yellow
VR2 Signal
23
PK / BE
4
Green
VR2 COM.
24
RD / YW
5
Pink
Voltmeter +
25
YW / GN
6
Black
Voltmeter -

- 6 -
DIP SW INSTRUCTIONS
Program no.: UM288BC3 (T Soldier) Main Board: W030934 / 070514
DIP SW1
1
2
3
4
5
6
7
8
When the DIP SW PIN #6
is setup on "Play till you
win", the claw strength
voltage
VR1 Adj. of Power
ON
+48V
OFF
Position where claws
open at the exit
Claws lower down then
release object
ON
Claws release object at
the top position
OFF
Coin 1 & Coin 2 Linked
Together
Yes
ON
No
OFF
Demo music
With
ON
Without
OFF
Speech / Noise for
Shaking machine
NO
ON
YES
OFF
Claw moving to playfield
when game begins
YES
ON
NO
OFF
Demo Game when
nobody is playing
With
Claws play automatically every 5
minutes. (But claws do not close.)
ON
Without
OFF
At the moment the
program sends strong
strength on the basis of
the setup winning
percentage, the system
will keep sending
strongest strength to the
claw until a prize is
caught.
With
Output Sensor must be included.
ON
Without
OFF
※When Coin 1 and Coin 2 adjust to Linked Together, the credit value will follow Coin 1
(DIP SW pin 1 & 2)

- 7 -
DIP SW2
1
2
3
4
5
6
7
8
Coin1 of method
(Coin Selector of Coin Pulse vs. Play)
8 : 1
ON
ON
6 : 1
OFF
ON
4 : 1
ON
OFF
2 : 1
OFF
OFF
Coin2 of method
(Bill Acceptor of Coin Pulse vs. Play)
4 : 1
ON
ON
3 : 1
OFF
ON
2 : 1
ON
OFF
1 : 1
OFF
OFF
Operation mode
Button
ON
Joystick
OFF
Play till you win function
(Output Sensor must be included.)
With
Will deduct 1 credit when win.
ON
Without
Will deduct 1 credit for each game.
OFF
Ability to change the Inner-Values
Yes
ON
No
OFF
Machine conditions
Auto demo
ON
Normal play
OFF
※Program will keep the credits even after powering off.
DIP SW3
1
2
3
4
5
6
7
8
Adjustment of Credit Value
Inner Value
ON
DIP SW
OFF
NOT USED
FIXED
OFF
OFF
OFF
OFF
OFF
OFF
OFF
※Adjustment of Credit Value ：
Inner Value：The setup for 1 credit = N coins is adjusted based on the item 3~6 of the inner value
only。
DIP SW：The setup for 1 credit = N coins is adjusted based on the DIP SW 2 pin #1~4 on。
CLAWS STRENGTH INSTRUCTIONS
VR1: The first stage of grabbing power for claws. This is when the claws is descended to grab objects.
The stronger the grabbing power is, the easier and higher opportunity to grab objects and vise versa.
VR2: The second stage of grabbing power for claws. This is when the claws holds the grabbed object
then rises up and moves towards the exit. The stronger the grabbing power is, the tougher the grabbed
object slips off from the claws and vise versa.
The adjustment of grabbing power is related to the object’s size and weight. It is recommended to test
grabbing power with its grabbing objects before operation. The lighter and bigger the object is, the tougher
(lesser) the opportunity for the object to slip off from the claws and vise versa.
※Adjustment procedures:
1. Adjust COIN1 to N.C. then power on, the displays will show〔 C0 〕. Adjust COIN1 back to N.O.
2. Pull joystick to【Back】: to adjust VR1, the displays will show C1 .
3. Pull joystick to【Right】: to adjust VR2, the displays will show C2 .
4. Pull joystick to【Front】: to check the strongest power of claws, the displays will show C3 .

- 8 -
Inner-Value Set Up Instructions
Adjust the 7th pin of DIP SW2 to ON and turn power on. A voice “Good Luck” is heard
after the displays run a self-testing. Adjust the coin mechs back to N.O. and the
displays will blink『 00 』. This means ready to proceed with setting ups.
§ SW operations:
1. Move Joystick【Front】or press Button2 : to adjust for Display1.
2. Move Joystick【Right】or press Button1 : to adjust for Display2.
3. Press【DESCEND】button : to confirm set up values.
～displays ～
Display2 Display1
W991907
Item
Set up contents
Inside
Value
Notes
00
Ready to proceed with set ups
-
7th pin of DIP-SW2 has to be adjusted back
to OFF.
01
COIN1 –quantity of pay-out tickets after
inserting coins (coin selector 1)
0
02
COIN2 –quantity of pay-out tickets after
inserting coins (coin selector 2)
0
03
COIN1 –quantity of Inserted coins (coin
selector 1)
1
Coins quantity to get Credit. If adjusted to 0,
automatically will modify to 1.
04
COIN1 –quantity of game’s credits (coin
selector 1)
1
Game’s credits. If adjusted to 0,
automatically will modify to 1.
05
COIN2 –quantity of Inserted coins (coin
selector 2)
1
Coins quantity to get Credit. If adjusted to 0,
automatically will modify to 1.
06
COIN2 –quantity of game’s credits (coin
selector 2)
1
Game’s credits. If adjusted to 0,
automatically will modify to 1.
07
Quantity of pay-out tickets won
0
08
Quantity of pay-out tickets without
winning
0
09
Number of times for claws’ strong power
given as bonus
10
If adjusted to 0, automatically will modify to
256 times
10
Game’s play time（unit: second）
50
Set up value＜5 will automatically adjust to 5
seconds.

- 9 -
TESTING INSTRUCTION
1. Systems testing:
Adjust COIN1 & COIN2 to N.C. then power on, the display will show [ CC ]. Adjust DIP SW2 to proceed
with the testing in each item (function). Press【DESCEND】button to scroll thru each item, but make sure
that all switches are properly adjusted per your requirement.（a special purpose for QC Engineer）
DIP SW2
Description
Notes
1
Display
2
DIP SW
1. 1ST : a row, 2ND : b row, …, 7TH : g row, 8TH : blink.
2. ON : Light, OFF : Dark.
3. DIP SW1 shown in Display 1.
4. DIP SW2 shown in Display 2.
3
-
4
3567
Press any buttons to switch around songs.
5
API8001
Press any buttons to switch around voice sound.
6
8910
Press any buttons to switch around music sound.
7
Clear record
1. Displays show〔CL〕.
2. Clear all record back to 0 then re-enter set up value into the
memory chip.
8
Enter set up value
1. Displays blink〔Ld〕.
2. Set up value is saved when displays stop blinking.
2. Claws strength:
Adjust COIN1 to N.C. then power on. Displays will show [ C0 ].
Joystick operation
Testing items
Displays showing
Pull joystick to【Back】
VR1
C1
Pull joystick to【Right】
VR2
C2
Pull joystick to【Front】
Check strongest power of claws
C3
3. Gantry:
Adjust COIN2 to N.C. /or press switch【TEST】then power on. Displays will show〔 a0 〕.
Joystick/Button operation
Case
Displays showing
【Back】
Claws lower down
a3
【Front】
Claws rises up
a4
【Descend】＋【Right】
Motor moves to right
b1
【Descend】＋【Left】
Motor moves to left
b2
【Descend】＋【Back】
Motor moves backward
b3
【Descend】＋【Front】
Motor moves forward
b4
4. Error code description:
Error code
Description
Error code
Description
E0
CPU Bit breakdown
E6
Flap door motor and/or
control board breakdown
E1
Stop-up SW breakdown
E9
Counter meter not properly
connected
Ee
Output sensor breakdown

- 10 -
WINDING CORD INSTRUCTIONS
●Conductive-Cord Wheel (Winding Cord & Assembly II No.9)
●Winding-Cord Wheel
(Winding Cord & Assembly II No.6)
●Conductive-Cord Wheel
(Winding Cord & Assembly II No.7)
Connected to Claws
【 Correct winding method 】
●Conductive-Cord Wheel (Winding Cord & Assembly II No.9)
●Winding-Cord Wheel
(Winding Cord & Assembly II No.6)
●Conductive-Cord Wheel
(Winding Cord & Assembly II No.7)
Connected to claws
【 Improper winding method 】
⊙When displays show『d』blinking at power on and after displays run a testing, this means the cord
is incorrectly wound. Turn power off and adjust COIN2 to N.C. then power on again. This time the
displays will show『a0』. Hold joystick【forward】the motor will lower down claws and the displays will
show『a4』. Adjust COIN2 back to N.O., the claws is now properly wound and the machine is back to
correct and normal operation.
Note: The program will automatically adjust to operate under normal condition although the claws is
improperly wound up as above drawing, but it will reduce the life span of the cord.

- 11 -
TROUBLESHOOTING
1. Take caution with the positive and negative poles of the DC power (+5V, +12V, +24V, +48V) in this
machine when repairing it. Connect the poles correctly in order to avoid burning the PCB and/or
operation under abnormal condition.
2. Coins/tokens can not be inserted into coin slot:
(1) Check if anything is stuck in the coin slot
(2) Check if coin slot is dis-formed or intentionally damaged
(3) Check if the coin selector is of correct specification
3. Coins/tokens are returned after coin in:
(1) Check if coins/tokens are of correct specification
(2) Check if connecting pin is properly connected (only in electronic coin selector)
(3) Check if coin selector is of correct specification
4. No credit after coin in:
(1) Check if sliding end of coin selector is properly matched the Y-type funnel
(2) Check if coin SW is properly positioned to end of Y-type funnel
(3) Check if coins/tokens properly touch the coin SW after coin in
5. Claws does not lower down:
(1) The winding cord is improperly wound up. Hold stop-up SW (Gantry & Assembly II No. 29) and
power off then power on again. The winding cord should be properly wound up now.
(2) Check if winding cord is out of the track. If so, wind the cord properly back to track and power
on. The claws should go back to its normal function.
Note: unscrew and dissemble the top and front covers of gantry motor to check the winding
cord.
(3) Shaking the machine beyond the normal limits during playing could cause to this
mal-functioning.
6. When displays show『C0』blinking, coin selector is at improper position N.C. (normal position is
N.O.), possible conditions could be:
(1) If『C0』keeps blinking after holding coin SW and re-power on, it is then at condition for
adjusting claws strength. Pls. refer to Claws ‘Strength Instructions’.
(2) 『C0』will also blink during the operation when coin SW is stuck or out of position causing it
unable to detect whether it is or it’s not already coin in. Adjust the coin SW back to its proper
position.

- 12 -
(3) 『C0』will also blink during the operation when players try to damage and/or cheat the machine
with improper method to touch coin SW. Power off and on again, the machine should return
back to its normal operation.
(4) At using coin selector with sensor device to count coin ins,『C0』will blink when sensor device
is out of function or blocked.
7. Gantry does not return to its home position:
(1) If power off and on again the gantry still does not return to its home position, then check if
stop-back SW (Gantry & Assembly I No. 23) or stop-left SW (Gantry & Assembly I No. 21) are in
proper position. Also check if their connecting wires are properly connected.
(2) P.C.B. is out of function.
8. Gantry does not move either forward and/or backward by joystick operation:
(1) Check if forward and backward SW wires of joystick are properly connected or if SW are out of
function.
(2) Check if J1 connecting pin of P.C.B. is properly connected.
(3) Check if stop-front SW (Gantry & Assembly I No. 22) or back-stop SW (Gantry & Assembly I No.
23) are in proper position. Also check if their connecting wires are properly connected.
(4) Check if Front/Back motor is out of function or if its wires are properly connected. Also check
if its shaft pinion is properly positioned.
(5) Check if J4 connecting pin of P.C.B. is properly connected.
(6) Check if all connecting pins of gantry are properly connected to the machine.
9. Gantry does not move to left and/or right:
(1) Check if left and/or right SW are out of function or if their wires are properly connected.
(2) Check if J1 connecting pin of P.C.B. is properly connected.
(3) Check if stop-left SW (Gantry & Assembly I No. 21) is in proper position.
(4) Check if Left/Right motor is out of function or if its wires are properly connected. Also check if
its shaft pinion is properly positioned.
(5) Check if J4 connecting pin of P.C.B. is properly connected.
(6) Check if all connecting pins of gantry are properly connected.
10. Claws does not lower down by【Descend】button operation, but only until time’s up:
(1) Check if【Descend】button is functioning properly.
(2) Check if connecting wires of【Descend】button are properly connected.
(3) Check if J1 connecting pin of P.C.B. is properly connected.

- 13 -
11. Claws does not lower down, but the【Descend】button is in normal condition:
(1) Check if Up/Down motor is out of function of if its wires are properly connected. Also check if
its shaft pinion is in proper position.
(2) Check if winding cord is properly wound up.
(3) Check if J4 connecting pin of P.C.B. is properly connected.
12. Claws does not lower down or only down a bit and close up in the air then it returns to its home
position:
(1) Check if winding cord is stuck.
(2) Check if stop-down SW is functioning properly.
13. Claws does not fully lower down:
(1) Check if winding cord is of proper length.
(2) Follow same procedures in point 12 above.
14. Claws does not open when reached to exit door after seizing:
(1) Check if stop-back or stop-left SW are out of function or if their wires are properly connected.
(2) Check if the gantry wire connecting to J4 connecting pin of P.C.B. is properly connected.
15. Claws does not rise up after seizing and is returned back to its home position:
(1) Check if stop-up SW is in proper position and in normal function.
16. Claws does not rise up and gantry does not move at all:
(1) Check if Up/Down motor is out of function of if its wires are properly connected. Also check if
its shaft pinion is in proper position.
17. Claws does not close up and is returned to its home position:
(1) Check if fuse of power supply is burnt. If not, then the P.C.B. is out of function.
(2) If fuse is burnt down then replace it. If it burns again after the replacement, then replace the
claws coil.
(3) If claws still does not close up after replacing the claws coil, then the P.C.B. is out of function.
(4) Check if VR1 and VR2 are functioning properly.

- 14 -
GANTRY ASSEMBLY DRAWINGS I
ITEM #
DESCRIPTION
COASTAL PART #
WU-MAR PART #
1,3,18,20
Front/Back Wheel
PE-WHL-FB-002
S002
2,19
Crane Fixing Plate
P008
4
Right Plate
P015
5
Fixed Bearing
S004
6
Rotating Shaft
S014
7,8
Fixed Shaft
S013
9
Black Cog
PE-GEA-SHT-001
S007
10
Bearing mounting Plate
P007
11
Bearing
PE-BEA-GAN-S001
S001
12
Motor Mounting Bracket
P006
13
Motor Shaft Pinion
PE-SHT-PIN-S016
S016
14
Front/Back Motor
PE-MTR-F/B
SE5475M-21145-30Y
15
Stop Left Switch Bracket
P004
16
Left Cover Plate
P014
21
Stop Left switch
PE-SWI-GA-PL
22
Stop Front switch
23
Stop Back switch

- 15 -
GANTRY ASSEMBLY DRAWINGS II
ITEM #
DESCRIPTION
COASTAL PART #
WU-MAR PART #
1
Carriage Rear Cover
P013
2
Rotating Shaft
S008
3
Rotating Shaft
S009
4,5,21,22
Left/Right Wheel
PE-WHL-L/R-006
S006
6
Claw Cord Wheel
PE-WOW-S003
S003
7,9
Claw Cord Pulley
PE-WHL-GAN-3005
S005
8
Claw Pulley Mounting Arm
P009
10
Steel Motor mounting Plate
P001
11,12
Bearing
PE-BEA-GAN-S001
S001
13
Middle Bearing Bracket
P003
14,15
Black Cog
PE-GEA-SHT-007
S007
16,23
Motor Mounting Bracket
P006
17
Conduit
S015
18
Up/Down Spring
L002
19,24
Motor Shaft Pinion
PE-SHT-PIN-S016
S016
20
Up/Down Motor
PE-MTR-U/D
SE5075M-27095-30Y
25
Left/Right Motor
PE-MTR-L/R
SE5475M-21145-30Y
26
Carriage Front Cover
P012
27
3- Claw Kit (coil included)
28
Stop Down Switch
PE-SWI-GA-PL
29
Stop Up Switch
PE-SWI-PC-OP29
