Atari PONG 4P User manual

IMPORTANT
4P Version
Operation Manual

PONG 4P D&B Manual
11/18/2019
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
When contacting Service, you will need the following information
and the name of your authorized distributor.

PONG 4P D&B Manual
11/18/2019
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 8
3. PART NAME......................................................................................................... 10
4. SET UP & INSTALLATION....................................................................................11
5. HOW TO PLAY......................................................................................................22
6. GAME OPTION..................................................................................................... 24
7. TROUBLESHOOTING............................................................................................35
8. MAINTENANCE & INSPECTION..........................................................................38
9. OVERALL CONSTRUCTION................................................................................. 54
10. WIRING DIAGRAM............................................................................................ 84
Appendix 1: LED Blacklight Instruction................................................................ 88
Appendix 2: Video & Scroll Letters Replacement Instruction............................88

PONG 4P D&B Manual
11/18/2019
3
Thank you for purchasing PONG 4P. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

PONG 4P D&B Manual
11/18/2019
4
Note: The contents of this manual may be updated without notice.
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.

PONG 4P D&B Manual
11/18/2019
5
1. SPECIFICATIONS
Rated power supply: AC110V~ 50/60Hz
Min. Power consumption: 180W
Max. Power consumption: 480W
Dimension: Width: 61.00’’ (1550mm)
Depth: 61.00’’ (1550mm)
Height: 116.34’’ (2955mm)
Weight：Approximately 860 lb (390kg)
Part No: P163
Model No: A-439
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game specifications are subject to change without notice.

PONG 4P D&B Manual
11/18/2019
6
This machine will be divided into a few parts.
Main Cabinet:
Width: 61.00’’ (1550mm)
Depth: 61.00’’ (1550mm)
Height: 32.68’’ (830 mm)
Monitor Assembly:
Width: 63.39’’ (1610mm)
Depth: 11.81’’ (300mm)
Height: 66.34’’ (1685mm)

PONG 4P D&B Manual
11/18/2019
7
Rotational Marquee & PONG Foam Core Sign:
Width: 47.49’’ (1206mm)
Depth: 7.56’’ (192mm)
Height: 37.13’’ (943mm)
Note: Game specifications are subject to change without notice.

PONG 4P D&B Manual
11/18/2019
8
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
1.1 Following accessories (Package 1)
1.2 Following accessories (Package 2)
No.
Part No.
Name
SPEC
Qty
1
P163-801-000
Power cord
3×16AWG 1.8M
1
2
P163-432-000
Fuse
Φ5×20mm
T6.3A 250VAC
1
3
P163-444-000
Fuse
Φ5×20mm T10A
250VAC
1
4
P163-802-000
Key
171A
2
5
P163-803-000
Manual
D&B
1
6
P163-131-000
Adjust plate A (Short)
δ1.5
1
7
P163-132-000
Adjust plate B (Long)
δ1.5
1
8
P163-362-000
Cross recessed pan
head screw set
M4×10 Color
zinc
2
9
P163-311-000
Standard spring washer
4×1.1h
GB/T93-1987
2
10
P163-101-000
Adjustment weight
White zinc plated
1
11
P163-804-000
Teflon
973UL-S
0.13X25X10
1
No.
Part No.
Name
SPEC
Qty
1
P163-159-000
Ball
Assembly
2
2
P163-160-000
Paddle
Assembly
4

PONG 4P D&B Manual
11/18/2019
9
2. Accessory KIT
NOTE: Part models are subject to change without notice.
No.
Part No.
Name
Qty
1
P163-435-000
Cup holder LED ring
1
2
P163-462-000
42MM Stepping motor
1
3
P163-463-000
57MM Stepping motor
1
4
P163-477-000
Motor driver
1
5
P163-461-000
24V Table lifting motor
1
6
P163-134-000
Anti-scratch foam A
10
7
P163-135-000
Anti-scratch foam B
8
8
P163-159-000
Ball
1
9
P163-160-000
Paddle
1
10
P163-482-000
Y axle Toothed belt (XL type)
75.90inX1
11
P163-483-000
X axle Toothed belt (XL type)
74.92inX1
12
P163-484-000
Paddle axle Toothed belt (XL type)
65.63inX1
13
P163-901-000
Jog assembly(with Encoder)
1

PONG 4P D&B Manual
11/18/2019
10
Jog
Playfield
Ready for Card Reader
Rotational Marquee Assembly
Cup holder
Speaker
Monitor Assembly
PONG Foam Core Sign
Display
Launch Button
3. PART NAME
Key Components

PONG 4P D&B Manual
11/18/2019
11
Leveler
About 0.2 in/5mm
We do not recommend using power tools as they may cause damage.
NOTICE
Make sure the machine is level.
NOTICE
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for items to avoid.
Place the unit on a dry and level surface.
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground by 0.2 in/5mm. Repeat the same for all
levelers.
Leveler
Leveler
Leveler

PONG 4P D&B Manual
11/18/2019
12
Your unit must be leveled to operate properly.
NOTICE
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 20 in

PONG 4P D&B Manual
11/18/2019
13
4.4 Machine Installation
Before processing with assembly assure you have the following tools.
Component Weight:
When installing the machine, be very careful and pay attention to ensure that the player
can enjoy the game safely.
Inappropriate handling running counter to the cautionary matters can cause personal injury
or damage to the machine.
Step 1 Guide the Monitor assembly cables to the bottom cable hole of Support post.
Tighten 5 screws and washers on each side to secure the Support posts to Monitor
assembly.
Guide the Speaker cable through the hole indicated by triangle to the Monitor assembly
and connect on each side.
Note: Tighten the screw in the middle of the hole to ensure that it is secured well.
No.
Name
1
Allen wrench
2
Spanner
3
Phillips screwdriver
4
Ladder
No.
Name
Weight
1
Support post
(with a Speaker)
22lb
(10kg)
2
Monitor assembly
135lb
(61kg)
3
Rotational marquee
40lb
(18kg)

PONG 4P D&B Manual
11/18/2019
14
Step 2 Place the Monitor assembly on the cabinet.
Note: The Support post with cable slot should be installed to the brackets between Yellow
player(P2) and Red player(P1).
Notice: Due to the size, weight and balance, it is required that multiple installation
personnel be available for this task.
Name
Cross recessed
hexagon screw set
SPEC
M6×20 black
Qty
10
Name
C washer
SPEC
6×1h black
Qty
10
Monitor assembly
Support post
Cable hole

PONG 4P D&B Manual
11/18/2019
15
Step 3 Utilize Allen wrench to loosen 4 screws indicated by circles; remove the Metal
plates.
Step 4 Place the Rotational marquee on the Monitor assembly. Guide the cable from
Monitor assembly to Rotational marquee and connect.
Tighten 4 screws to secure the Rotational marquee to the Monitor assembly.
Secure back the Metal plates.
Step 5 Utilize dual adhesive to affix the PONG foam core sign to the top Rotational
marquee.
Note: Use of Ladders should be supervised and extreme caution exercised.
Name
Cross recessed
hexagon screw set
SPEC
M6×16 black
Qty
4
Metal plate
Monitor assembly
Rotational marquee
PONG foam core sign

PONG 4P D&B Manual
11/18/2019
16
Upper
door
Step 6 Open the Upper doors on Yellow player(P2) side and Green player(P4) side.
Utilize Spanner to tighten 4 bolts and nuts to fix the 4 posts.
Step 6 Locate Yellow player(P2) side. Plug connectors indicated by circle according to cable
color.
Name
Hexagon flange nut
SPEC
M8 color zinc
Qty
4
Name
C Washer
SPEC
8×1.6h
Qty
8
Name
Hexagon bolt
SPEC
M8×55 white zinc
Qty
4

PONG 4P D&B Manual
11/18/2019
17
Step 7 Utilize Allen wrench to tighten 3 screws to fix the Metal plate on the cabinet.
Note: The installation method is the same on 4 Metal plates.
Step 8 Locate Green player(P4) side to power on the machine.
Finish!
Name
Hexagon socket
button head screw
SPEC
M5×8 black
Qty
12

PONG 4P D&B Manual
11/18/2019
18
4.5 Ball and Paddles Placement
Red player(P1)
Red player(P1)
Place the Ball in the
middle. Please assure
that the magnets
stick to the Playfield.
Pay attention to the
direction.
Place the Paddle
in the middle.
Please assure that
the magnets stick
to the Playfield.
Pay attention to
the direction.

PONG 4P D&B Manual
11/18/2019
19
4.6 Voltage Conversion (110V to 220V)
Step 1 Locate Green player(P4) side to power off the machine.
Step 2 Locate the power supply on Yellow player(P2) side.
Step 3 Toggle the switch from 115V to 230V on the power supply.
Step 4 Power on the machine.
4.7 Card Reader Installation Safety Notice
Take precaution to assure that all wiring voltages are confirmed prior to installation
of card reader. All warranties are void if not properly installed resulting in logic board
damage.
Important: This game is pre-wired to AAMA standards. It is highly recommended to utilize
this wiring for Card reader installation.
4.8 Program Update Instruction
4.8.1 Monitor Program Update
Step 1 Locate Yellow player(P2) Upper door and open it. Locate the Monitor Program
Update cable.
