Coaster 183516 User manual

ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
REVISION 0 : 06/27/2022
PAGE 1 OF 5 COASTERFURNITURE.COM
183516
Fine Furniture for every stage of life
BAR TABLE

ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
COASTERFURNITURE.COM
ASSEMBLY TIME 35 MINUTES
PARTS IDENTIFICATION
183516
ITEM:
WARNING!
PAGE 2 OF 5
PARTS IDENTIFICATION
A1PC
TOP
B1PC
CENTER LEG FRAME
HARDWARE IDENTIFICATION
3PCS
1
6PCS
2
Z
4PCS
4PCS
LONG BOLT
(1/4" x 25mm SR)
BOLT
(1/4" x 12mm SR)
3CAP
(20 x 40mm BLK)
4LEVELER
(1/4" x 15mm BLK)
C2PCS
SIDE LEG FRAME
D1PC LEG FRAME SUPPORT
1PC
5ALLEN WRENCH
(4mm)

ASSEMBLY INSTRUCTIONS
COASTERFURNITURE.COM
ITEM:
PAGE 3 OF 5
ASSEMBLY INSTRUCTIONS
COASTERFURNITURE.COM
183516
ITEM:
STEP 1 Do not tighten until each step is completed or instructed.
STEP 2
C
C
A
B
2
1
D

ASSEMBLY INSTRUCTIONS
183516
ITEM:
COASTERFURNITURE.COM
PAGE 4 OF 5
STEP 3
STEP 4
COMPLETE
3
4
3
4
3
4
3
4

ASSEMBLY INSTRUCTIONS
183516
ITEM:
COASTERFURNITURE.COM
PAGE 5 OF 5
Note : Dimension tolerance ±5%
Product Size : 895 DIA X 1086 H (MM)
Product Size : 35.25" DIA X 42.75"
21.25"
21.25"
42.75"
35.25"
41.25"
