Coaster 201301QB1 User manual

REVISION 0 : 07/04/2011
REVISION 1 : 09/27/2011
PAGE 1 OF 3
QUEEN SIZE BED
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
www.coastercompany.com
201301Q (B1-B3)

ASSEMBLY INSTRUCTIONS
AHEADBOARD PANEL
BBED RAIL
CFOOTBOARD
DHEADBOARD LEG
EBED SLAT
FBED SLAT SUPPORT WITH 4 PCS
LEVELER
1ALLEN WRENCH
2BOLT
3LOCK WASHER
4FLAT WASHER
5FLAT HEAD SCREW
www.coastercompany.com
ITEM :
PAGE 2 OF 3
2 PCS
2 PCS
1 PC
4 PCS
PARTS IDENTIFICATION
HARDWARE IDENTIFICATION
1 PC
8 PCS
1 PC
8 PCS
8 PCS
8 PCS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size
2. Please check to see that all hardware and parts are present prior start of assembly.
3. Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
!Warning!
1. Don't attempt to repair or modify parts that are broken or defective. Please contact the
store immediately.
2. This product is for home use only and not intended for commercial establishment
201301Q (B1-B3)
LEFT & RIGHT

ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
Align and hook the bed rails to headboard and footboard.
ITEM :
Align and fasten headboard legs to headboard panel using bolt, lock washer and flat washer and tighten with allen
wrench.
201301Q (B1-B3)
STEP 3
Align and fasten bed slat supports to bed slat by turning the bed slat support counter clockwise until tight.
Adjust leveler to level on floor.
Align and fasten bed slat to bed rail using screw and tighten with screw driver. (not included)
www.coastercompany.com
www.coastercompany.com
PAGE 3 OF 3
