Coaster 224261Q User manual

ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
224261Q (B1
-
B3)
Queen Bed
REVISION 0 : 01/24/2022 PAGE 1 OF 5 COASTERFURNITURE.COM

ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
2. This product is for home use only and not intended for commercial establishments.
B1 (BOX 1)
B2 (BOX 2)
B3 (BOX 3)
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
COASTERFURNITURE.COM
1PC
224261KE (B1) FROM BOX 1
HEADBOARD COMPLETE
224261KE (B2) FROM BOX 2
FOOTBOARD
BED SLAT SUPPORT WITH LEVELER
RIGHT HEADBOARD LEG
LEFT HEADBOARD LEG
HB
D
1PC
1PC
1PC
1PC
2PCS
BED SLAT
BED RAIL
HEADBOARD PANEL
FOOTBOARD
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
ASSEMBLY TIME 30 MINUTES
A
PARTS IDENTIFICATION
B
4PCS
4PCS
D
F
G
C
PAGE 2 OF 5
ITEM:224261Q (B1-B3)
E
1PC

ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
WARNING!
2. This product is for home use only and not intended for commercial establishments.
Z-B3 (BOX 3) - HARDWARE PACK IS LOCATED IN 224261Q (B3)
BOLT
(M8 X 40mm - RBW)
LOCK WASHER
(M8 - RBW)
ALLEN WRENCH
(M5 - BLK)
FLAT HEAD SCREW
(CSK M4 X 30mm - BLK)
NOTE:
Phillips head screw driver is required in the assembly process; however, manufacturer does not provide this item.
COASTERFURNITURE.COM
2 10PCS
5 8PCS
PAGE 3 OF 5
HARDWARE IDENTIFICATION
110PCS
4 1PC
1. Don’t attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
ASSEMBLY TIME 30 MINUTES
FLAT WASHER
(M8 - RBW)
3 10PCS
ITEM:224261Q (B1-B3)

ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
COASTERFURNITURE.COM
PAGE 3 OF 5
ITEM:224261Q (B1-B3)
HB

ASSEMBLY INSTRUCTIONS
STEP 3
STEP 4
COASTERFURNITURE.COM
PAGE 4 OF 5
ITEM:224261Q (B1-B3)
HB
HB

COASTERFURNITURE.COM
Note : Dimension tolerance ± 5%
64"
55"
56.3"
26.6"
81"
86"
19.7"
56.3"
64"
2.7"
6"
7"
INNER SIZE: 61" X 81"
ITEM:224261Q (B1-B3)
