Cobalt Digital Inc 5590 User manual

Specifications
Standards NTSC, PAL, PAL(M), PAL(N), Secam
Analog Inputs: Analog Composite, Y/C or Component
YPbPr
Differential Input Common Mode rejection < 4.8Vp-p
Input Return Loss > 35 dB at 5 MHz
Input A to D Quantization 10-bit
A/D sampling rate 8:4:4 (2x)
Frequency Response Y 0-5.0 MHz +/- 0.25 dB
K-Factor < 1%
SCH Phase < 1 degrees
Differential Gain < 1.8%
Differential Phase < 0.8%
S/N > 50 dB
Chroma Luma Delay < 2 ns
Y/C Separation 4-line adaptive, 4-line non-adaptive, 3-
line adaptive and notch filter
Conversion Time 1.25H
Digital Outputs: 6 with EDH
Output Quantization 10 bits
Output Return loss >17 dB @ 270Mbit
Output Error Coding SMPTE EDH
Jitter Filter LBW 2Hz
Operating Temperature Range 40-100 degrees F.
40-120F Optional Heat Sink
Humidity (non-condensing)
Power 4W Positive Rail
0.3W Negative Rail
This product is not authorized for use in life support systems. Product
liability limited only to the replacement of this unit. Cobalt Digital Inc. does
not assume any liability for loss of use due to failure of this component.
Specifications subject to change without notice.
Cobalt Digital Inc. 2406 E. University Ave. Urbana, IL 61802 USA
www.cobaltdigital.com Office: 217-344-1243 Fax: [phone]
Rev. 1.2 dml Copyright 2003 Cobalt Digital Inc.
Model 5590
10-bit A/D
Analog Composite (4-line Adaptive Comb)
Y/C or Component YPbPr to
270Mb 4:2:2 SDI Decoder with EDH
Owner’s Manual
Cobalt Digital Inc. 2003

The COBALT 5590 is a high quality full 10-bit analog to digital decoder for
converting 525 and 625 line, analog composite, Y/C and component signals (YPbPr)
to 270 Mb 4:2:2 SDI (SMPTE 259M compliant) output with SMPTE EDH. The
user can select four different Y-C separation modes (4-line adaptive, 4-line non-
adaptive, 3-line adaptive and notch filter) for composite input and three different
YPbPr inputs (BetaCam™, MII™, or SMPTE/N10) for component inputs.
Features include differential inputs, user configurable 75-ohm input termination, user
Proc. gain controls, de-jitter filter on/off, Color Bars on/off and Pedestal on/off.
User Proc adjustments can be saved and factory defaults can be restored. The
configuration controls are mounted on the card edge for in-frame adjustments.
Figure 2 - External Connections
SWITCH-1 SETTINGS (Up=On Down=Off)
S1-1..4 VIDEO INPUT AND COLOR SEPARATION MODE
On On On On Composite 4-Line Adaptive Comb
On On On Off Composite 4-Line Non-adaptive Comb
On On Off On Composite 3-Line Adaptive Comb
On On Off Off Composite Notch Filter
On Off xx xx Y/C (S-Video)
S1-1..4 SETTINGS (Continued)
Off On On On Component YPbPr BetaCam™
Off On Off Off Component YPbPr MII™
Off On Off On Component YPbPr SMPTE/N10
Off Off On On Component Y only BetaCam™
Off Off Off Off Component Y only MII™
Off Off Off On Component Y only SMPTE/N10
S1-5 MANUAL GAIN CONTROL
OFF -Manual gain control enabled
ON -Automatic gain control enabled
S1-6 COLOR BARS ON/OFF
OFF - Display Video
ON - Display COLOR BARS
S1-7 JITTER FILTER
OFF - Jitter Filter Off
ON - Jitter Filter On
S1-8 SETUP
OFF - Pedestal not removed (recommended for PAL)
ON - 7.5 IRE pedestal removed (recommended mode NTSC only)
TERMINATION CONFIGURATION
Moving S8, S9, S10 to the right to turn on 75 ohm termination, to the left to remove
termination.
LED INDICATOR
The front panel LED indicates video lock when On and loss of video when blinking.
A dark LED indicates loss of power.
DECODER ADJUSTMENTS S2, S3, S4, S5
Use S2 & S3 rotary switches to dial up the functions below and us S4 (Up) and S5
(Down) to adjust.
S2 S3
8 8 Restore factory defaults - press either S4 or S5.
9 9 Save user settings - press either S4 or S5.
5 1 Luma peaking filter up/down; both to reset (flat=default)
6 1 Vbit – Up=ITU; Down=SMPTE (default)
S2 S3 PROC CONFIGURATION:
To adjust Proc. set S2, S3 as shown below and press S4&S5 (Up-Down) to adjust.
Output Y-Gain Y-DC Saturation Hue
Composite and Y/C 1 – 1 1 – 2 1 – 3 1 – 4
Component 1 – 1 1 – 2 1 – 3 N/A
Differential Input,
Gain & Termination
Control
DA
10-bit 4-line
Adaptive Decode
Format and Proc
De-
Jitter
4:2:2 270 Mbit
SDI SMPTE
259M with EDH
User
Configuration
Switches
Analog
Composite,
Y/C or
Component
5590 Block Diagram
Serialize
with EDH
Micro-
processor
Bypass
Mux
In
1
3
5
2
4
6
7
8
Composite/Y
C / PrPb
SDI Output 1
SDI Output 2
SDI Output 3
SDI Output 5SDI Output 6
SDI Output 4
