What’s Included with Your UK 29 LTD ST
1. CB transceiver
2. Microphone
3. Transceiver bracket
4. Microphone bracket
5. Operating Manual
6. DC power cord (not shown)
The CB Story
A1
3
2
4
5
1
NOTICE
A licence is required for
use in the UK.CB licens-
ing applications can be
obtained from The Radio
Licensing Centre, P.O.
Box 885,Bristol,BS99
5LG,UK or contact your
local CB dealer for
additional information.
29 UK-English.qx 6/22/99 12:15 PM Page 38

Thank you for purchasing the Cobra UK 29 LTD ST
CB Radio.Properly used,this Cobra product will
give you many years of reliable service.
SoundTrackerTM
“Cuts noise coming in...strengthens signals
going out.”
This Patent-pending technology dramatically
improves transmission and reception of CB
signals.
The revolutionary SoundTrackerTM System recon-
figures the transmission signal,allowing it to be
transferred more efficiently through cluttered
airwaves.
At the same time,it significantly reduces the
amount of static on all incoming CB signals.
The end result is cleaner,clearer sounding
reception of signals and a more powerful
transmission which dramatically improves CB
communications.
Controls and Indicators
CobraontheWorldWideWeb:
FrequentlyAskedQuestions
(FAQ)canbefoundon-lineat:
www.cobraelec.com
Our Thanks to You
A3
A2
1. 4-PinMicrophone
Connector
2. PowerOn/Off,Volume
3. Squelch
4. RFGain/Dynamike
5. Tone
6. Dimmer/SWRCAL
7. BandSelector
8. ChannelSelector
9. LEDChannelDisplay
10. SoundTracker™LED
11. RX(Receive)/TX(Transmit)
LEDIndicator
12. SoundTracker™On/Off
13. S/RFSWRCALSwitch
14. Channel19/Channel9/
NormalSwitch
15. Delta-Tune
16. CB/PASwitch
17. NB/ANLANLOffSwitch
18. SignalStrengthMeter
19. Microphone
RearPanel
20. PublicAddressSpeaker
Jack
21. ExternalSpeakerJack
22. AntennaConnector
23. PowerJack
12 4 5
3
6 7 8
22 23
18 9
10
11
20 21
13
1415
16
17
12
19
29 UK-English.qx 6/22/99 12:15 PM Page 39

How to Use Your
Cobra UK 29 LTD ST
Contents
Section A(English)
Features..................................................................................................1
Included Accessories
Controls & Indicators.......................................................................A2
Our Thanks toYou.............................................................................A3
SoundTracker™
Installation
Location.............................................................................................2
Mounting and Connection.........................................................2
Antennas
CB Antenna.......................................................................................6
Marine Installation.........................................................................6
Ignition Noise Interference..........................................................7
OperatingYour UK 29 LTD ST
Turning On Your CB........................................................................8
Setting Channel Selector.............................................................9
Setting Band Selector...................................................................9
Calibrating For SWR (StandingWave Ratio)..........................10
To Receive..........................................................................................12
Selecting a Channel.......................................................................13
S-Meter...............................................................................................13
SoundTracker™System................................................................14
Activating SoundTracker™..........................................................15
NB-ANL/ANL/Off (Noise Blanker/Automatic.........................16
Noise Limiter Switch)
Dimmer Switch................................................................................17
RF Gain Control................................................................................17
Setting Delta Control....................................................................18
Setting Squelch...............................................................................18
ToTransmit........................................................................................20
Setting Dynamike...........................................................................20
Transmit..............................................................................................21
RF Meter.............................................................................................22
External Speaker.............................................................................23
PA (Public Address)........................................................................24
Home And Office Set-Up .............................................................26
Temporary Mobile Set-Up...........................................................27
HowYour CB Can Serve You..........................................................28
A Few Rules You Should Know..................................................28
LocalLaws or Regulations...........................................................29
CB 10-Codes.....................................................................................30
Frequency Ranges.............................................................................32
UK 29 LTD ST Specifications.........................................................33
Accessories............................................................................................34
Deutsch ................................................................................Abschnitt B
Español.....................................................................................Sección C
Français....................................................................................Section D
Italiano .....................................................................................Sezione E
Featuresof ThisProduct
• CompliesWithUKMPT1382
• 2.75metremicrophonecord
• 40UKCBRadioChannels,
40CEPT(EU)Channels
• SoundTracker™System
• Heavy-Duty Dynamic
Microphone
• Full4WattsFMRFPowerOutput
• SWRCalibrationMeter
• InstantChannel19and9
• FrontPanel4-PinMicrophone
Connector
• DeltaControl
• SwitchableAutomaticNoise
Limiter&NoiseBlanker
• TactileControls
• IlluminatedFrontPanel
• DimmerControl
1
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN !!
29 UK-English.qx 6/22/99 12:14 PM Page 1

InstallationInstallation
Location
32
Mounting and
Connection
Mounting and Connection
Hold the radio with the mounting bracket in
the exact desired location.If there is no inter-
ference,remove the bracket and use it as a
template to mark the location for the mount-
ing screws.
Location
Plan location of transceiver and microphone
bracket before starting the installation.
Select a location that is convenient for operation,
yet does not interfere withthe driver or passenger.
The transceiver is usually mounted to the under-
side of the dash with the microphone bracket
beside it.
Note
Thetransceiverisheldinthe
universalmountingbracketby
twothumbscrewswhichallow
foradjustmentataconvenient
angle.
Thebracketincludestwoself-
tappingscrewsandstarwash-
ers.Themountingmustbe
mechanicallystrongand
convenientlylocated.
continued
Drill the holes and secure the bracket.
2
1
Connect the antenna cable plug to the recep-
tacle marked“ANT” on the back of the unit.
3
cb transceiver
29 UK-English.qx 6/22/99 12:14 PM Page 2

InstallationInstallation
54
Note
Beforeinstallingthe CBradio,
visuallycheckthe vehicle’s
batteryconnectionto deter-
minewhichterminal, positive
ornegative,is earthed tothe
engineblock (orchassis). A
negativelyearthedvehicle
hasitsnegative leadearthed
tothechassis.
Note
Connectingtoafusecircuitcon-
trolledbytheignitionswitch
preventstheunitfrombeingleft
onaccidentally,andalsoper-
mitsoperatingtheunitwithout
runningtheengine.
Note
Inpositiveearthvehiclesthered
wiregoesto the chassis andthe
blackwireisconnectedtothe
ignitionswitch.
In a negative earthed vehicle,connect the red
lead of the DC power cord to an accessory 12
volt fuse.
Connect the black lead to the negative side of
the vehicle.This is usually the chassis.Any con-
venient location with a good electrical contact
(remove paint) may be used.
4
5
Plug power cable into back of unit marked
“Power”. Be sure to observe polarity markings.
Mount the microphone
bracket on right side of
the unit (nearer the driver)
using two screws sup-
plied.Bracket should be
placed under the dash
so that microphone is
readily accessible.
6
7
Attach the 4-pin microphone cable to recepta-
cle on front of unit and Install unit in bracket
securely.
8
29 UK-English.qx 6/22/99 12:14 PM Page 4

Ignition Noise InterferenceAntennas
Use of a mobile receiver at low signal levels is
normally limited by the presence of electrical
noise.The primary source of noise in cars is from
the alternator and the ignition system. Typically,
when signal level is adequate,the background
noise does not present a serious problem.Also,
when extremely low-level signals are being
received,the transceiver may be operated with
the vehicle’s engine turned off.The unit requires
very little current and therefore will not signifi-
cantly discharge the vehicle’s battery.
Even though the Cobra UK 29 LTD ST has an auto-
matic noise limiter, in some installations ignition
interference may be high enough to make good
communications impossible.Many possibilities
exist and variations between vehicles require
different solutions.Consult your COBRA dealer or
a 2-way radio technician for help in locating the
source of a severe noise.
CB Antenna
The antenna is critical in affecting transmission
distance.Only a properly matched antenna sys-
tem will allow maximum power output. Cobra
loaded type antenna models are highly recom-
mended for most installations.Consult your
Cobra dealer for further details.
Marine Installation
The transceiver will not operate at maximum effi-
ciency in a boat without an earth plate, (unless it
has a steel hull). Before attempting installation ,
consult your dealer for information regarding an
adequate earthing system and prevention of
electrolysis between fittings in the hull and water.
CB Antenna
7
Note
Foroptimumperformancein
passengercarstheidealanten-
nalocationisonthecentreof
theroof.Secondchoiceisonthe
centreoftheboot.
Note
Antennamustbeearthedtothe
chassisofthevehicle.
6
1A standard antenna connector is provided
on the transceiver for easy connection.
29 UK-English.qx 6/22/99 12:14 PM Page 6

The CB/PA button should be in the
CB position.
Operation
9
Operation
Turning On Setting Channel
Selector
8
Turning On
Make sure the power cord,antenna and micro-
phone are connected to their proper connectors
before starting.
Setting Channel Selector
2
1
Rotate theOn/OffVolume knob clockwiseto
a normal listening level.
The CH19/CH9/NOR switch should be in
the NOR position
Select one of forty channels and adjust
volume.The selected channel is indicated by
the LED readout directly above the channel
selector knob.
Setting Band Selector
Select band Selector:either UK 40
channels FM or EU European 40 channels
FM,(CEPT).
2
1
1
Setting Band
Selector
29 UK-English.qx 6/22/99 12:14 PM Page 8

While holding micro-
phone button adjust
the SWR CAL knob so
that the meter needle
swings to the CAL ▼
mark on the meter (located on the right).
OperationOperation
Calibrating For
SWR (Standing
Wave Ratio)
1110
continued
Note
Calibrationmustbemadeinan
openarea(neverinagarage).
Vehicledoorsmustbeclosed.No
oneshouldbe standing near the
antenna.(See your antenna
directionsformorecomplete
information).
Note
Thereadingwillbeslightly
higheronChannels1and40
comparedtoChannel20.
Pushandhold microphone button.
Switch to the CAL position.
2
1
3
Calibrating for SWR (Standing Wave Ratio)
SWR calibration is done to properly adjust the
length of the antenna and to monitor the quality
of the coaxial cable and all RF connections.
This calibration is critical in order to achieve opti-
mum performance.
Select channel 20.
4
29 UK-English.qx 6/22/99 12:14 PM Page 10

Rotate the On/OffVolume knob clockwise.
The green RX/TX LED will be illuminated.
Repeat the same steps 2 to 5 on Channel 1
and 40.This will check SWR for all channels.
The S/RF switch must be in the S/RF position
to read the meter.
6
While still holding down the microphone
button,set the S/RF-SWR-CAL switch to the
SWR position,to read the SWR reading.
5
Operation
13
Operation
12
1
Note
With the S/RF-SWR-CALswitch
intheSWRpositionthemeter
needleshouldideally be as far
totheleftaspossible.
Anythingover3isnotaccept-
able. Aslight antennaheight
adjustment(higherorlower)
mayberequired.Repeat
relcalibrationsteps.
S-Meter
S-Meter
Swings proportionately to strength of incoming
signal when receiving.
Switch to NOR to select desired channel.
1
Selecting A
Channel
Selecting A Channel
Note
Switchto9 or19 forinstant
accesstothesechannels.
To Receive
1
To Receive
29 UK-English.qx 6/22/99 12:14 PM Page 12

OperationOperation
1514
Activating
SoundTracker
™
Pushandrelease the ST button.Red LED
is illuminated when SoundTracker™ is
turned on.
1
The SoundTrackerTM System
While previous systems only “blanket out”or limit
noise in higher sound frequencies, the revolution-
ary new SoundTrackerTM System actually reduces
noise while leaving the signal intact in the recep-
tion mode. In the transmission mode,it actually
strengthens the signal,providing you with a
significant reduction in noise on reception
and transmission.
Sound clarity is measured by the ratio
of the signal level to the noise level.
The higher the signal-to-noise ratio,
the better the sound.
How SoundTrackerTM Works
OnReception-“Cutsnoisecomingin”
With a normal CB,distant signals fall below
the squelch level and are unintelligible.With a
SoundTrackerTM CB,the noise level is cut by up to
90%,which increases the signal-to-noise ratio
and dramatically improves signal clarity.This also
allows you to reduce the squelch level significant-
ly,which greatly expands your listening range.
OnTransmission-“Strengthenssignalsgoingout”
A SoundTrackerTM CB strengthens the transmit
signal by more effectively using the available RF
power output of the CB.The result is improved
transmission signal clarity and an expanded
transmission range.
Note
SoundTracker™givesyou
clearer,cleanerreceptionto
improveCBcommunications
whileontheair.
Activating SoundTracker™
29 UK-English.qx 6/22/99 12:14 PM Page 14

Whenswitched to ANL the Automatic Noise
Limiter is activated.This helps reduce noise
created by the vehicle’s electronics.
Whenswitched to NB/ANL position the RF
Noise Blanker is also activated,providing
increased noise filtration.
Whenswitched to OFF position all noise
filtration will be turned off.
OperationOperation
1716
NB-ANL/ANL/
OFF (Noise
Blanker/
Automatic
Noise Limiter)
Switch
RF Gain Control
Dimmer Control
RF Gain Control
The RF Gain is used to optimize reception in
strong or weak signal areas.
Dimmer Control
Note
TheRFGainisusedtooptimize
receptioninweaksignalareas.
Note
TheRFnoiseblankerisvery
effectiveinreducingrepetitive
noisessuchasignitioninterfer-
ence.
Rotate the RF Gain knobanticlockwise to
reduce gain in strong signal areas.In weak
signal areas turn clockwise to increase gain.
1
NB-ANL/ANL/OFF (Noise
Blanker/Automatic Noise Limiter) Switch
1
1Rotatethe Dimmer knob clockwiseformaxi-
mumbrightness;anticlockwiseforminimum
Note
TheDimmercontrolsthe
brightnessofthefrontpanel,
signalstrengthmeterand
channeldisplay.
29 UK-English.qx 6/22/99 12:14 PM Page 16

Switch to Delta+ or Delta - to control tuning.
Rotate theToneControl to desired level.
Full clockwise rotation closes the “gate”
allowing only very strong signals to enter.
Full anticlockwise rotation opens the “gate”
allowing all signals in.
To achieve the Desired Squelch Setting (DSS),
turn the Squelch control anticlockwise until
you hear noise. Now turn the control clockwise
until the noise just stops. This is the DSS
setting.
Setting Delta Control
Delta Tone Control is used to set the desirable
level of received audio.
Setting Squelch
Squelch is the “control gate”for incoming signals.
19
Setting Delta
Control
18
Operation Operation
1
2
2
1
3
Gate open
Gate settoDesired
SquelchSetting(DSS)
Gateclosed
Setting Squelch
29 UK-English.qx 6/22/99 12:14 PM Page 18

Setting Dynamike
This controls the microphone sensitivity
(outgoing audio level).
ToTransmit
21
To Transmit Transmit
20
Setting
Dynamike
Caution!
Besuretheantennaisproperly
connectedtotheradiobefore
transmitting.Prolongedtrans-
mitting without an antenna,or
withapoorly-matchedanten-
na,cancausedamagetothe
transmitter.
Operation Operation
1
Select desired channel.
1
Initially,set fully clockwise so that maxi-
mum voice volume is available. Dynamike
may have to be reduced in some conditions.
Transmit
Pushandhold microphone button to transmit.
Transmitter is now activated.When transmit-
ting,hold the microphone two inches from
your mouth and speak in a clear,normal voice.
Release to receive.
1
29 UK-English.qx 6/22/99 12:15 PM Page 20

OperationOperation
RF Meter
23
22
External Speaker
RF Meter
This meter swings proportionately to the RF
output (outgoing signal) while transmitting.
External Speaker
The external speaker jack is used for remote
receiver monitoring.
The S/RF-SWR-CAL switch must be in the
S/RF position.
1
Note
Theexternalspeakershould
have8-ohmimpedanceandbe
ratedtohandleatleast4watts.
Whentheexternalspeakeris
plugged in,the internal speaker
isautomaticallydisconnected.
Note
Cobraexternalspeakersare
ratedat10watts.
Connect an external speaker to the external
speaker jack on the rear panel.
1
29 UK-English.qx 6/22/99 12:15 PM Page 22

OperationOperation
PA (Public
Address)
2524
PA (Public Address)
Connect an external PA speaker to the PA jack
on the rear panel.
Set CB/PAswitchtoPAposition.
Pushandhold microphone button and speak
in a normal voice.Your voice will now transmit
on the PA speaker.
Adjust PA speaker volume with the
Dynamike control.
Note
Speakershouldhave8-ohm
impedanceandberatedto
handleatleast4watts.
Note
Thespeakershouldbedirected
awayfromthemicrophoneto
preventacousticfeedback.
Note
ActivityontheCBchannel
willbeheard through the PA
speaker.AdjustVolumeControl
fornormallisteninglevel.
1
2
3
4
29 UK-English.qx 6/22/99 12:15 PM Page 24

Temporary Mobile Set-Up
27
Base Station
Operation
(From 220/240V
AC Domestic
Current)
Temporary
Mobile Set-Up
Temporary Mobile Operation
For temporary mobile operation you may want to
purchase an optional cigarette lighter adapter
from your COBRA dealer.This adapter and a mag-
netic mount antenna allow you to“install”your
transceiver quickly for temporary use.
Base Station Operation
(From 220/240V AC Domestic Current)
To operate your transceiver from home or office
you will need a 13.8 volt DC Power Pack rated at a
minimum of 2 amps,and a properly installed base
station antenna.
Home And Office Set-Up
26
Warning!
Donotattempttooperatethis
transceiverbyconnectingit
directlyto 220/240V AC.
1
Connect properly installed and matched base
station antenna.
Connect the red (+) and black (-)
leads of the transceiver to the corresponding
terminals of the power pack.
Plug power cable into back of unit marked
“Power”. Be sure to observe polarity markings.
2
3
29 UK-English.qx 6/22/99 12:15 PM Page 26

How Your CB Can Serve YouHow Your CB Can Serve You
2928
THEUSEOFTHISCBPRODUCTINVOLVES
THEPUBLICAIRWAYSANDITSUSEMAYBE
SUBJECTTO LOCALLAWSORREGULA-
TIONS.BEFOREUSINGTHEPRODUCTYOU
SHOULD CHECKTOSEETHATTHECON-
TEMPLATEDUSE DOES NOTVIOLATEANY
APPLICABLELOCALLAWORREGULATION.
• Warn of traffic problems
• Provide weather and road data
• Provide help in an emergency
• Provide direct contact with home or office
• Get local information to find destination
• Communicate with family and friends
•Suggest spots to eat and sleep
• Keep you alert while travelling
A Few Rules You Should Know
A. Conversations should not last morethan 5 min-
utes with another station. A one-minute break
should be taken to let others use the channel.
B. You should not blast others off the air by use
of illegally amplified transmitters or illegally
high antennas.
C. You should not use CB to promote illegal
activities.
D. Bad language should not be used.
E. You should not transmit music with a CB.
F. You should not use your CB to sell
merchandise and/or professional services.
A Few Rules
You Should
Know
Local Laws or
Regulations
Local Laws or Regulations
29 UK-English.qx 6/22/99 12:15 PM Page 28

How Your CB Can Serve YouHow Your CB Can Serve You
3130
Code Meaning
10-29 Time is up for contact
10-30 Does not conform to FCC rules
10-33 Emergency traffic
10-34 Trouble at this station
10-35 Confidential information
10-36 Correct time is
10-37 Breakdown truck needed at
10-38 Ambulance needed
10-39 Message delivered
10-41 Turn to channel
10-42 Traffic accident at
10-43 Traffic delay at
10-44 Have a message for
10-45 All units within range please report
10-50 Break channel
10-60 What is next message number?
10-62 Unable to copy. Use phone
10-63 Net directed to
10-64 Net clear
10-65 Awaiting your next message/assignment
10-67 All units comply
10-70 Fire at
10-71 Proceed, transmission in sequence
10-77 Negative contact
10-81 Reserve hotel room for
10-82 Reserve room for
10-85 My address is
10-91 Talk closer to microphone
10-93 Check my frequency on this channel
10-94 Give me a long count
10-99 Mission completed,all units secure
10-200 Police needed at
CB 10-Codes
Citizen Bands have adopted the“10-CODES”for
standard questions and answers. These codes
provide quick and easy communication,especially
in noisy areas. Following are some of the more
common codes and meanings:
Code Meaning
10-1 Receiving poorly
10-2 Receiving well
10-3 Stop transmitting
10-4 OK,message received
10-5 Relay message
10-6 Busy, stand by
10-7 Out of service,leaving air
10-8 In service,subject to call
10-9 Repeat message
10-10 Transmission completed, standing by
10-11 Talking too rapidly
10-12 Visitors present
10-13 Advise weather/road conditions
10-16 Make pick up at
10-17 Urgent business
10-18 Anything for us?
10-19 Return to base
10-20 My location is
10-21 Call by phone
10-22 Report in person to
10-23 Stand by
10-24 Completed last assignment
10-25 Can you contact
10-26 Disregard last info
10-27 Moving to channel
10-28 Identify your station
CB 10-Codes
29 UK-English.qx 6/22/99 12:15 PM Page 30

29 UK LTD ST SpecificationsFrequency Ranges
3332
1 26.965 21 27.215
2 26.975 22 27.225
3 26.985 23 27.255
4 27.005 24 27.235
5 27.015 25 27.245
6 27.025 26 27.265
7 27.035 27 27.275
8 27.055 28 27.285
9 27.065 29 27.295
10 27.075 30 27.305
11 27.085 31 27.315
12 27.105 32 27.325
13 27.115 33 27.335
14 27.125 34 27.345
15 27.135 35 27.355
16 27.155 36 27.365
17 27.165 37 27.375
18 27.175 38 27.385
19 27.185 39 27.395
20 27.205 40 27.405
Channel Channel
CB Freq. CB Freq.
Channel In MHz Channel In MHz
The COBRA UK 29LTD ST transceiverrepresentsoneofthemostadvancedFM two-
way radios used.This unit featuresadvancedPhase LockLoop(PLL) circuitryprovid-
ingcompletecoverage ofall 40CEPTand 40 UKFMCB channels.
1 27.60125 21 27.80125
2 27.61125 22 27.81125
3 27.62125 23 27.82125
4 27.63125 24 27.83125
5 27.64125 25 27.84125
6 27.65125 26 27.85125
7 27.66125 27 27.86125
8 27.67125 28 27.87125
9 27.68125 29 27.88125
10 27.69125 30 27.89125
11 27.70125 31 27.90125
12 27.71125 32 27.91125
13 27.72125 33 27.92125
14 27.73125 34 27.93125
15 27.74125 35 27.94125
16 27.75125 36 27.95125
17 27.76125 37 27.96125
18 27.77125 38 27.97125
19 27.78125 39 27.98125
20 27.79125 40 27.99125
Channel Channel
CB Freq. CB Freq.
Channel In MHz Channel In MHz
CEPT Frequencies UK Frequencies
GENERAL
CHANNELS. . . . . . . . . . . . . . . . . . . . . . . 40 CH FM British,40 Channel FM CEPT (EU)
FREQUENCY RANGE. . . . . . . . . . . . . . . 26.965TO 27.405 MHz FM CEPT
BRITISH FM 40 CH
FREQ.RANGE 27.60125 TO 27.99125
FREQUENCYTOLERANCE . . . . . . . . . . 0.005 %
FREQUENCY CONTROL . . . . . . . . . . . . PLL (PHASE LOCK LOOP) SYNTHESIZER
OPERATING TEMPERATURE
RANGE. . . . . . . . . . . . . . . . . . . . . . . . . . . -20° CTO + 55° C
MICROPHONE . . . . . . . . . . . . . . . . . . . . PLUG-IN DYNAMIC
INPUTVOLTAGE . . . . . . . . . . . . . . . . . . 13.2 V DC nom.(positive or negative earth)
CURRENT DRAIN TRANSMIT:AM FULL MOD.,1.5A (MAXIMUM)
RECEIVE:SQUELCHED,0.3A;
FULL AUDIO OUTPUT,1.2A (NOMINAL)
SIZE 219 mm x185 mm x 56 mm
(8-5/8”D x 7-9/32”W x 2-13/64”H)
WEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . .1.8 kg (4 LBS.)
ANTENNA CONNECTOR . . . . . . . . . . . .UHF;SO-239
METER . . . . . . . . . . . . . . . . . . . . . . . . . . .ILLUMINATED;INDICATES RELATIVE
POWER OUTPUT,RECEIVED
SIGNAL STRENGTH AND VSWR
TRANSMITTER
POWER OUTPUT . . . . . . . . . . . . . . . . . .4 WATTS FM
MODULATION . . . . . . . . . . . . . . . . . . . .FM (FREQUENCY MODULATION)
FREQUENCY RESPONSE . . . . . . . . . . . .300TO 3000 Hz
OUTPUT IMPEDANCE . . . . . . . . . . . . . .50 OHMS,UNBALANCED
RECEIVER
SENSITIVITY . . . . . . . . . . . . . . . . . . . . . . .LESS THAN 6dB µV FOR 20 dB SINAD
SELECTIVITY . . . . . . . . . . . . . . . . . . . . . .6dB@ 7 kHz,60 dB@ 10 kHz
IMAGE REJECTION . . . . . . . . . . . . . . . . .80 dB,TYPICAL
ADJACENT-CHANNEL REJECTION . . .60 dB ,TYPICAL
IF FREQUENCIES . . . . . . . . . . . . . . . . . .DOUBLE CONVERSION:1ST:10.695 MHz
2ND:455 kHz
AUTOMATIC GAIN CONTROL (AGC) .LESS THAN 10 dBCHANGE IN AUDIO
OUTPUT FOR INPUTS FROM 10 TO 50,000
MICROVOLTS
RF GAIN RANGE . . . . . . . . . . . . . . . . . . .40 dB
NOISE BLANKER . . . . . . . . . . . . . . . . . . .RFTYPE
SQUELCH . . . . . . . . . . . . . . . . . . . . . . . . .ADJUSTABLE;THRESHOLD LESS THAN 1µV
AUDIO OUTPUT POWER . . . . . . . . . . .4 WATTS
FREQUENCY RESPONSE . . . . . . . . . . . .300TO 3000 HZ
DISTORTION . . . . . . . . . . . . . . . . . . . . . .LESS THAN 7% @3WATTS @ 1000 HZ
BUILT-IN SPEAKER . . . . . . . . . . . . . . . . .8 OHMS,5W
EXTERNAL SPEAKER (NOT SUPPLIED) 8 OHMS; DISABLES INTERNAL SPEAKER
WHEN CONNECTED
PA SYSTEM
POWER OUTPUT . . . . . . . . . . . . . . . . . .4 WATTS INTO EXTERNAL SPEAKER
EXTERNAL SPEAKER FOR PA . . . . . . . .8 OHMS,4W MIN.
(NOT SUPPLIED)
(SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE)
29 UK-English.qx 6/22/99 12:15 PM Page 32
