Cochlear Baha 5 SuperPower User manual

2797
Sound processor type designations for
models included in this User Manual are:
FCC ID: QZ3BAHA5SUP, IC: 8039C-BAHA5SUP, IC model:
Baha®5 SUP.
Statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from the one in which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
• Changes or modifications can void the user’s authority to
operate the equipment.
Intended use
The Cochlear™Baha®5 SuperPower uses bone conduction
to transmit sounds to the cochlea (inner ear). It is indicated
for people with conductive hearing loss, mixed hearing
loss and single sided sensorineural deafness (SSD).
Furthermore it is indicated for bilateral and paediatric
recipients. Fitting range up to 65 dB SNHL. It works by
combining a sound processor and a small titanium implant
that is placed in the skull behind the ear. The skull bone
integrates with the titanium implant through a process
called osseointegration. This allows sound to be conducted
via the skull bone directly to the cochlea, which improves
hearing performance. The sound processor can be used
together with the Baha Softband.
The fitting is to be done either at a hospital, by an
audiologist, or in some countries, by a hearing care
professional.
List of countries:
Not all products are available in all markets. Product
availability is subject to regulatory approval in the
respective markets.
The products are in compliance with the following
regulatory requirements:
• In EU: the device conforms to the Essential
Requirements according to Annex I of Council Directive
93/42/EEC for medical devices (MDD) and essential
requirements and other relevant provisions of Directive
2014/53/EU (RED). The declaration of conformity may
be consulted at www.cochlear.com.
• Other identified applicable international regulatory
requirements in countries outside the EU and US. Please
refer to local country requirements for these areas.
• In Canada the sound processor is certified under the
following certification number: IC: 8039C-BAHA5SUP
and model no.: IC model: Baha®5 SUP.
• This device complies with Industry Canada licence-
exempt RSS standard(s).
• This Class B digital apparatus complies with Canadian
ICES-003. Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
• Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation
of the device. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas produire
de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d’en compromettre le
fonctionnement.
Equipment includes RF transmitter
Note: The sound processor is suited for use
in a home healthcare environment. The
home healthcare environment includes locations such as
homes, schools, churches, restaurants, hotels, cars, and
airplanes, where equipment and systems are less likely to
be administered by healthcare professionals.
Cochlear™
Baha® 5 SuperPower Sound Processor
ZONE 2
English
Español
Ελληνικά
Português
תירבע
315 27 39 51
EN-GB ES EL PT HE
User manual part A
Cochlear Bone Anchored Solutions AB, Konstruktionsvägen 14, 435 33 Mölnlycke, Sweden
Tel: [phone], Fax: [phone]
Regional Offices
Cochlear Ltd, (ABN 96 002 618 073), 1 University Avenue,
Macquarie University, NSW 2109 Australia
Tel: [phone], Fax: [phone]
Cochlear Americas, 10350 Park Meadows Drive, Lone Tree,
CO 80124, USA
Tel: [phone], Fax: [phone]
Cochlear AG, EMEA Headquarters, Peter Merian-Weg 4, 4052 Basel,
Switzerland
Tel: [phone], Fax: [phone]
Cochlear Latinoamerica, S. A., International Business Park
Building 3835, Office 403 Panama Pacifico, Panama
Tel: [phone], Fax: [phone]
Local Offices
Cochlear Europe Ltd, 6 Dashwood Lang Road, Bourne Business Park,
Addlestone, Surrey, KT15 2HJ, United Kingdom
Tel: [phone], Fax: [phone]
Cochlear Deutschland GmbH & Co. KG, Karl-Wiechert-Allee 76A,
30625 Hannover, Germany
Tel: [phone], Fax: [phone]
Cochlear Benelux NV, Schaliënhoevedreef 20 I, 2800 Mechelen,
Belgium
Tel: [phone], Fax: [phone]
Cochlear France S.A.S., 135 route de Saint Simon, 31035 Toulouse,
France
Tel: [phone] (international), Tel: [phone] (national),
Fax: [phone]
Cochlear Italia SRL, Via Larga 33, 40138 Bologna, Italy
Tel: [phone], Fax: [phone]
Cochlear Tıbbi Cihazlar ve Sağlık Hizmetleri Ltd. Sti.,
Cubuklu Mah. Bogazici Cad. Bogazici Plaza, No: 6/1 Kavacik,
TR-34805 Beykoz-Istanbul, Turkey
Tel: [phone], Fax: [phone]
Cochlear Nordic AB, Konstruktionsvägen 14, 435 33 Mölnlycke,
Sweden
Tel: [phone], Fax: [phone]
Cochlear Canada Inc, 2500-120 Adelaide Street West, Toronto,
ON M5H 1T1, Canada
Tel: [phone], Fax: [phone]
Nihon Cochlear Co Ltd, Ochanomizu-Motomachi Bldg 2-3-7 Hongo,
Bunkyo-Ku, Tokyo 113-0033, Japan
Tel: [phone], Fax: [phone]
Cochlear Limited (Singapore Branch), 238A Thomson Road #25-06,
Novena Square Office Tower A, Singapore 307684, Singapore
Phone: [phone], Fax: [phone]
Cochlear Medical Device (Beijing) Co Ltd, Unit 2608-2617,
26th Floor,No.9 Building, No.91 Jianguo Road, Chaoyang District,
Beijing 100022, PR China
Tel: [phone], Fax: [phone]
Cochlear (HK) Ltd, Room 1404-1406, 14/F, Leighton Centre,
77 Leighton Road, Causeway Bay, Hong Kong
Tel: [phone], Fax: [phone]
Cochlear Korea Ltd, 1st floor, Cheongwon Building 33,
Teheran-ro 8 gil, Gangnam-gu, Seoul, Korea
Tel: [phone], Fax: [phone]
Cochlear Medical Device Company India PVT Ltd,
Platina Bldg, Ground Floor, Plot No. C 59, G Block, BKC, Bandra East,
Mumbai 400051 India
Tel: [phone], Fax: [phone]
Cochlear Colombia, Avenida Carrera 9 #115-06
Of. 1201 Edificio Tierra Firme, Bogota D.C., Colombia
Tel: [phone]
Cochlear México, SS.A. de C.V, Av. Tamaulipas 150 Torre A piso 9,
Col. Hipódromo Condesa, 06170 Cuauhtémoc, Ciudad de México,
México
Tel: [phone]
www.cochlear.com
Please seek advice from your health professional about treatments for hearing loss. Outcomes may vary, and your health professional
will advise you about the factors which could affect your outcome. Always read the instructions for use. Not all products are available
in all countries. Please contact your local Cochlear representative for product information. Cochlear Baha 5 sound processors are
compatible with iPhone, iPad and iPod touch. For compatibility information visit www.cochlear.com/compatibility.
Cochlear, Baha, 科利耳, コクレア , 코클리어, Hear now. And always, SmartSound, the elliptical logo, and marks bearing an ® or ™ symbol,
are either trademarks or registered trademarks of Cochlear Bone Anchored Solutions AB or Cochlear Limited (unless otherwise noted).
The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Cochlear
Limited is under license. Apple, the Apple logo, FaceTime, iPhone, iPad and iPod touch are trademarks of Apple Inc., registered in the U.S.
and other countries. App Store is a service mark of Apple Inc.
© Cochlear Bone Anchored Solutions AB 2020. All rights reserved. 2020-09.
95966 633639-V7. Translation of 631286-V11.

Fold-out only 140 mm width. Use manual cut marks
20
1
14
35 2
13
6
17
16
3
1
18
21 3 4
3
15
10
3
21
21
9
1 2
19
5
4
1 2
8
2
1 2
3
7
7
5
1
6
4
98
4
8
134
2
24
3
2
2
1
11
1 2
12
21
1
34
2
1
14
3
2
1
3
24

3
English
Congratulations on your choice of the Cochlear™Baha®5 SuperPower Sound
Processor. You are now ready to use Cochlear’s highly advanced bone conduction
sound processor, featuring sophisticated signal processing and wireless technology.
This manual is full of tips and advice on how to best use and care for your Baha sound
processor. By reading this manual and then keeping it handy for future reference, you
will ensure that you get the most benefit out of your Baha sound processor.
Key to device See figure 1
1. Sound Processing unit
2. Actuator unit
3. Cable
4. Microphones
5. Battery
6. Ear hook
7. Plastic snap connector
8. Buttons
9. Visual indicator
Note on figures: The figures included on the
cover correspond to information specific to this
model of sound processor. Please reference the
appropriate figure when reading. The images
shown are not to scale.
Introduction
To ensure optimal performance, your hearing
care professional will fit the processor to suit
your needs. Be sure to discuss any questions
or concerns that you may have regarding your
hearing or use of this system with your hearing
care professional.
Warranty
The warranty does not cover defects or
damage arising from, associated with, or
related to the use of this product with any
non-Cochlear processing unit and/or any
non-Cochlear implant. See the “Cochlear
Baha Global Limited Warranty card” and
the “Addendum to Warranty Card” for
more details.
Welcome

4
Contacting Customer Service
We strive to provide you with the best possible
products and services. Your views and experiences
with our products and services are important to
us. If you have any comments you would like to
share, please contact us.
Customer Service – Cochlear Americas
10350 Park Meadows Drive, Lone Tree,
CO 80124, USA
Toll free (North America) 1800 523 5798
Tel: [phone], Fax: [phone]
E-mail: [e-mail]
Customer Service – Cochlear Europe
6 Dashwood Lang Road, Bourne Business Park,
Addlestone, Surrey KT15 2HJ, United Kingdom
Tel: [phone], Fax: [phone]
E-mail: [e-mail]
Customer Service – Cochlear Asia Pacific
1 University Avenue, Macquarie University,
NSW 2109, Australia
Toll free (Australia) 1800 620 929
Toll free (New Zealand) 0800 444 819
Tel: [phone], Fax: [phone]
or Toll free Fax [phone]
E-mail: [e-mail]

5
English
Key to symbols
The following symbols will be used throughout this document.
Please refer to the list below for explanations:
“Consult instructions for use”
or “Operating instructions” Bluetooth®
“Caution” or “Caution, consult
accompanying documents” Manufacturer
Audible signal Catalogue number
2797
CE mark and Notified Body
number Date of manufacture
Interference risk By prescription
Batch Code Temperature limitation
Serial Number Humidity limitation
Refer to instructions/booklet
Note: Symbol is blue Recyclable material
ACMA (Australian
Communications and Media
Authority) compliant
Waste of Electrical and
Electronic Equipment
Made for iPod, iPhone, iPad Radio compliance certification
for Korea
Radio compliance certifica-
tion for Japan

6
Using your sound processor
The buttons on your sound processor let you
adjust your volume level, choose from your
pre-set programs, and enable/disable wireless
streaming. You can choose to enable the audible
and visual indicators to alert you of changes to the
settings and processor status.
Your sound processor is programmed to be
used as either a left or right-sided device. Your
hearing care professional will have marked your
processor(s) with a L or R indicator. If you are a
bilateral user, changes you make to one device will
automatically apply to the second device.
On/off See figure 2
12Turn on your sound processor by
connecting the battery module.
3Turn off your sound processor by
disconnecting the battery.
When your sound processor is turned off and
then back on again, it will return to the default
setting (program one).
Status indicator See figure 3
Your sound processor is equipped with audible and
visual indicators. For an overview of the audible
and visual indicators, refer to the table at the back
of this section.
Your hearing care professional can disable the
audible and/or visual indicators if you prefer.
Change program See figure 4
Together with your hearing care professional you
will have selected up to four pre-set programs for
your sound processor:
Program 1:
Program 2:
Program 3:
Program 4:
These programs are suitable for different listening
environments. Ask your hearing care professional
to fill in your specific programs.
To switch programs, press and hold the upper
button on your sound processor. If enabled,
audible and visual indicators will let you know
which program you are using:
Program 1: 1 beep and 1 flash
Program 2: 2 beeps and 2 flashes
Program 3: 3 beeps and 3 flashes
Program 4: 4 beeps and 4 flashes
Adjust volume
See figure 5
1Press and release the upper button to increase
volume.
2Press and release the lower button to decrease
volume.
You can adjust the volume level with the
optional Cochlear Baha Remote Control, the
Cochlear Wireless Phone Clip or an iPhone,
iPad or iPod touch (see Made for iPhone
section).
Wireless accessories
You can use Cochlear Wireless accessories to
enhance your listening experience. Ask your
hearing care professional to learn more about
your options or visit www.cochlear.com.
To activate wireless audio streaming, press
and hold the lower button until you hear a
melody. See figure 6
To end wireless audio streaming, press and
hold the upper button. The sound processor will
return to the previous program.
Flight mode See figure 8
When boarding a flight, wireless functionality
must be deactivated because radio signals may
not be transmitted during flights. To disable
wireless operation:

7
English
1Turn off the sound processor by
disconnecting the battery.
2Press and hold the lower button and connect
the battery at the same time.
To deactivate flight mode, turn the sound
processor off and back on again by disconnecting
and connecting the battery.
Made for iPhone MFi
Your sound processor is a Made for iPhone (MFi)
hearing device. This allows you to control your sound
processor and stream audio directly from iPhone,
iPad or iPod touch. For full compatibility details and
more information visit www.cochlear.com.
Talk on the phone See figure 7
For best results, use a Cochlear Wireless Phone
Clip or stream the conversation directly from
your iPhone. When using a normal handheld
phone, place the receiver near the microphone
inlet of your sound processor instead of near
your ear. Ensure the receiver does not touch the
sound processor as this may result in feedback.
Batteries
There are two different batteries for the Baha 5
SuperPower: the Standard Rechargeable Battery
Module and the Compact Rechargeable Battery
Module. Ask your hearing care professional for
more information about the choice of battery.
Battery life
Batteries should be replaced as needed just as
you would with any other electronic device.
Battery life varies according to the programs used
each day, the sound environment use of wireless
accessories, and the size of battery.
The rechargeable battery’s lifespan is at least 365
charge cycles. A completely empty rechargeable
battery will take approximately four hours to
recharge.
Rechargeable batteries may take longer to fully
recharge with age. To get the longest life from the
rechargeable batteries, always recharge before use.
When there is approximately one hour of battery
power remaining, you will hear an audio indicator
comprising of two sets of four short beeps, and
the visual indicator will flash repeatedly. At this
time you may experience low amplification. If
the battery runs down completely, the sound
processor will beep and then stop working.
Replace the battery
Remove the battery See figure 2
Twist the battery module to remove it from the
processing unit.
Attach the battery See figure 2
Align the battery module to the processor socket
to fit the parts together. Twist the battery module
as shown to attach the parts. The processor will
turn on automatically.
Lock/Unlock the battery (tamper-proof)
See figure 9
1To increase tamper resistance, push the lock to
the far left with your battery cover locking tool
to lock the battery module.
2Push the lock to the far right to unlock the
battery module.
Charge battery modules See figure 10
1Angle and fit the rechargeable battery module
into a socket on the Cochlear Nucleus®Battery
Charger.
2Twist clockwise to connect.
3Connect the battery charger to the power
adaptor and plug into mains power.

8
3Wipe the battery charger sockets with a soft
dry cloth.
Cycle batteries in different sockets when
recharging to wear the sockets evenly.
If it gets wet
If the battery charger ever gets splashed with
liquid, carefully shake out the liquid and dry the
battery charger for 24 hours. Do not use the
battery charger until it is dry.
Care for your battery charger
Every day
Check that your battery charger is clean. If you
notice any dust or dirt:
1Unplug the power adaptor and remove any
battery modules.
2Hold the battery charger upside down and tap
it gently to remove any dirt from the battery
charger sockets. Carefully blowing on the
battery charger sockets may also help remove
dirt.
Mains power light What it means
Steady green
Battery charger power is on.
Does not light up Power adaptor is not plugged in or mains power is not available (or, if
switched, is not turned on).
Battery socket light What it means
Steady orange
Battery module is charging.
Steady green
Battery module is fully charged.
Flashing orange
There is a problem with the battery module. Try a different socket.
Replace the rechargeable battery module.
Does not light up Battery module is not properly placed, is over-discharged or there is
no power. Check the battery charger is powered on and reconnect the
battery charger. If it still does not light up, replace the battery module.

9
English
Using Share the Experience
See figure 12
Family members and friends can “share the
experience” of bone conduction hearing. The test
rod can be used by others to hear with the sound
processor.
To use the test rod
1Turn on your sound processor and snap the
Actuator unit onto the test rod using the tilt
technique.
2Place the Sound Processing unit on the ear.
Hold the rod against the skull bone behind an
ear. Plug both ears and listen.
Wear an Earhook+ or Earhook 2+
The Earhook+ or Earhook 2+ is used when wearing
the sound processor in the under-the-ear (UTE)
position. Both are available in different sizes.
Earhook+ is available in different colours and
Earhook 2+ is transparent..
Attach an Earhook+ See figure 13
1Press firmly on the top of the Earhook with
your thumb to click it off the sound processor.
2Click the Earhook+ into place.
3Attach and adjust the silicone band to ensure
the Earhook+ sits securely.
4Carefully bend the upper part into shape to
suit your ear.
Remove an Earhook+
Remove your Earhook+ by clicking it off the
processor and removing the silicone band.
Attach an Earhook 2+ See figure 14
1Press firmly on the top of the Earhook with
your thumb to click it off the sound processor.
2Slide the Earhook 2+ into place.
3Make sure that your sound processor is
thoroughly seated within the Earhook 2+.
Remove an Earhook 2+
Remove your Earhook 2+ by sliding the sound
processor out of the Earhook 2+.
Wear a Snugfit
The Snugfitholds your sound processor more
securely in place than an earhook alone. It gives
carers easy access to controls and accessories and
is available in large, medium and tamper resistant
(small).
Attach a Snugfit See figure 15
1Press firmly on the top of the earhook with
your thumb to click it off the sound processor.
2Click your Snugfit into place.
3Carefully bend the lower part into shape to suit
your ear.
Remove a Snugfit
4Remove your Snugfit by clicking it off the
processor.
Wear a Mic Lock See figure 16
The Mic Lock helps hold the processor securely on
the ear.
To attach the Mic Lock the first time
1Push the Mic Lock band onto the processor
with the tubing facing forward.
2Place the processor on your ear and bring the
tubing up to the earhook.
3Trim the tubing to a length that will hold the
processor firmly in place without discomfort.
Do not cut it too short.
4Soften the end of the tubing in warm water and
push it onto the tip of your earhook.
5Let the tubing cool before wearing.

10
4Press the microphone protectors all the way
into the microphone holes one at a time.
5Remove the applicator carefully, peeling it
upwards from the earhook end.
Change the Earhook See figure 19
Earhooks come in large, medium and small
sizes. The smallest earhook can be made tamper
resistant.
1Press firmly on the top of the Earhook with
your thumb and click it off the sound processor.
2Click the Earhook into place.
Note: Remove your Earhook only when necessary
– it may become loose if it is removed too often.
Assemble and change cables
See figure 20
Changing the cable is something you should only
have to do occasionally. Using the correct method
reduces the risk of accidentally damaging the cable
and the cable sockets in the Sound Processing unit
and the Actuator unit.
Remember to leave the Actuator unit connected
when storing the sound processor in the Dry &
Store unit overnight.
1Hold the cable by the grips and firmly pull
it straight out of the socket on the Sound
Processing unit. Do not twist.
2Hold the base of the plug and firmly pull the
cable.
3To attach a new cable, push the cable plug into
the Actuator unit until it clicks into place.
4Push the cable into the cable socket on the
Sound Processing unit until it clicks into place.
Attach and remove processor
covers See figure 17
1To attach, slide the cover onto the processor.
2To remove, pull the cover away from the
processor.
Note: Snugfit, Mic Lock, and Processor covers are
available as accessories. For more information,
ask your hearing care professional or visit
www.cochlear.com
Replace microphone protectors
See figure 18
Replace your microphone protectors every three
months, whenever they look dirty or whenever
you notice any loss in sound quality. Always
replace both microphone protectors at the same
time.
Remove microphone protectors
1Remove the protective cap from the
Microphone Protector Removal Tool.
2Push the tip of the tool into the middle of the
microphone protector.
3Turn the tool 90° clockwise.
4Lift out the microphone protector and discard.
Repeat steps 2 to 4 to remove the other
microphone protector.
Insert new microphone protectors
See figure 19
1Pull the Microphone Protector Applicator out
of its sleeve.
2With the microphone protectors facing the
processor, gently push the slotted end of the
applicator under the coil cable plug.
3Lay the applicator over the processor,
aligning the microphone protectors with the
microphones.

11
English
General processor care
Your Baha sound processor is a delicate electronic
device. Follow these guidelines to keep it in proper
working order:
• When not in use, turn off your sound processor
and store it free from dust and dirt.
• If you will not be using your sound processor
for a long period, remove the battery. Remove
your sound processor before applying hair
conditioners, mosquito repellent and or similar
products.
Water, sand and dirt See figure 11
Your sound processor is resistant to water, sand
and dust. However, it is still a precision electronic
device so the following precautions should be
taken.
1If your processor ever gets wet, dry it with a
soft cloth, change the microphone protectors
and place it in the dry aid kit for eight hours.
2If sand or dirt ever enter the processor, shake
the components carefully to remove it and
change the microphone protectors.
Warnings
General advice
A sound processor will not restore normal
hearing and will not prevent or improve a hearing
impairment resulting from organic conditions.
• Infrequent use of a sound processor may not
enable a user to attain full benefit from it.
• The use of a sound processor is only part of
hearing rehabilitation and may need to be
supplemented by auditory and lip reading
training.
• The patient is an intended operator of the
device.
• The Model reference is Baha 5 SuperPower
Sound Processor.
Warnings
• The sound processor is a digital, electrical,
medical instrument designed for specific use. As
such, due care and attention must be exercised
by the user at all times.
• The sound processor is not waterproof!
• Never wear it in heavy rain, in the bath or
shower!
• Do not expose the sound processor to extreme
temperatures. It is designed to operate within
the temperature ranges +5 °C
(+41 °F) to +40 °C (+104 °F).
The processor should not
be subjected, at any time,
to temperatures below
-10 °C (+14 °F) or above
+55 °C (+131 °F).
• Contains small parts that may present a choking
hazard.
• This product is not suitable for use in flammable
and/or explosive environments.
• The sound processor and other external
accessories should never be brought into a room
with an MRI machine, as damage to the sound
processor or the MRI equipment could occur.
• The sound processor must be removed before
entering a room where an MRI scanner is
located.
• If you are to undergo an MRI (Magnetic
Resonance Imaging) procedure, refer to the MRI
Reference Card included in the document pack.
• Portable and mobile RF (radio frequency)
communications equipment can affect the
performance of your sound processor.
• The sound processor is suitable for use in
electromagnetic environments with mains
power of typical commercial or hospital quality,
and power frequency magnetic fields of typical
commercial or hospital levels. It is intended for
use in an electromagnetic environment in which
radiated RF (radio frequency)
disturbances are controlled.
• Interference may occur in the
vicinity of equipment with the
symbol to the right.
-10 °C
(+14 °F)
+55 °C
(+131 °F)

12
• Dispose of batteries and electronic items in
accordance with your local regulations.
• Discard your device as electronic waste
according to local regulations.
• When the wireless function is activated, the
sound processor uses low-powered digitally
coded transmissions in order to communicate
with other wireless devices. Although unlikely,
nearby electronic devices may be affected. In
that case, move the sound processor away from
the affected electronic device.
• When using wireless functionality and the
sound processor is affected by electromagnetic
interference, move away from the source of this
interference.
• Be sure to deactivate wireless functionality
when boarding flights.
• Turn off your wireless functionality by using
the flight mode in areas where radio frequency
emission is prohibited.
• Cochlear Baha wireless devices include an
RF transmitter that operates in the range of
2.4 GHz–2.48 GHz.
• For wireless functionality, only use Cochlear
Wireless accessories. For further guidance
regarding e.g. pairing, please refer to the
user guide of the relevant Cochlear Wireless
accessory.
• No modification of this equipment is allowed.
• Parents and carers are advised that unsupervised
use of long cables may present a risk of
strangulation.
• Do not let your processor or parts entangle
with any jewellery (e.g. earhook and earrings) or
machinery.
• Do not attach or wear a body-worn battery
configuration beneath layers of clothing in direct
contact with the skin (e.g. in pocket or under a
child’s vest).
• Make sure all cables used by a child are securely
attached to their clothing.
• Do not use a dry aid kit that has an Ultra Violet
C (UVC) lamp
• The microphone protector removal tool is a
sharp object. It is not recommended for use by
children.
• The tamper resistant earhook fitting tool and
fitting pin are sharp objects. They are not
recommended for use by children
• Only use rechargeable batteries and battery
chargers supplied or recommended by Cochlear.
Use of other batteries or battery chargers may
result in harm or injury.
• Charge rechargeable batteries before use.
• Do not allow children to replace batteries
without adult supervision.
• Do not touch the battery charger contacts
or allow children to use the battery charger
without adult supervision.
• Do not short-circuit batteries (e.g. do not let
terminals of batteries contact each other, do
not place batteries loose in pockets, etc.).
• Store unused batteries in original packaging, in
a clean and dry place. When processor is not in
use, remove the batteries and store separately
in a clean and dry place. Wipe batteries with a
clean dry cloth if they become dirty.
• Battery life means the time a device will run
before the rechargeable batteries must be
recharged.
• Battery charge cycle is a full charge and
discharge of the rechargeable battery.
• Battery lifespan means the total number of
charge cycles a rechargeable battery will last
before the battery life degrades to 80% of its
original fullycharged capacity.
• Use only Baha 5 SuperPower Actuator units. Do
not connect the sound processor to any other
type of stimulating equipment such as Cochlear
Implant coils.
• Portable RF communications equipment
(including peripherals such as antenna cables
and external antennas) should be used no closer
than 30 cm (12 in.) to any part of your Baha 5
SuperPower, including cables specified by the
manufacturer. Otherwise, degradation of the
performance of this equipment could result.
• Use of accessories, transducers and cables other
than those specified or provided by Cochlear
could result in increased electromagnetic
emissions or decreased electromagnetic
immunity of this equipment and result in
improper operation.

13
English
Functions and audible/visible indicators
Function On the device Audible indicator Visible indicator
Turn ON Connect battery
10 beeps Steady light for 10 seconds
Turn OFF Disconnect battery None None
Change program Press and hold upper
button
1 beep for program 1
2 beeps for program 2 etc
1 flash for program 1
2 flashes for program 2 etc
Change Volume Press and release upper/
lower button to increase/
decrease volume
1 beep indicates volume
increase/decrease
1 flash indicates volume
increase/decrease
Low battery warning
4 beeps 2 times Rapid flashes
When using Cochlear Wireless Accessory or MFi
Change volume With Cochlear Baha
Remote Control,
Cochlear Wireless Phone
Clip or with an iPhone
1 beep indicates volume
increase/decrease
1 short flash indicates
volume increase/decrease
Volume limit reached
1 long beep 1 long flash
Enable wireless
audio streaming
Press and hold lower
button
5 beeps (melody in upward
scale)
1 long flash, followed by 1,
2 or 3 short flashes
Disable wireless
audio streaming
Press and hold upper
button
1 beep for program 1
2 beeps for program 2 etc
1, 2 or 3 short flashes
Pairing confirmation
6 beeps followed by a ripple
tone (melody in upward scale)
None
Toggle between
wireless accessories
Long press lower button
5 beeps (melody in upward
scale)
Long flash, followed by
one short flash
Turn ON flight mode Insert battery and hold
lower button
10 x dual beeps
4 x dual flashes
Mute Mute button on Wireless
Accessory or with an
iPhone 1 long beep 1 long flash
Note: Your hearing care professional may have disabled some or all of the audible and/or visible indicators.

14
Sound processor type designations for models
included in this User Manual are:
FCC ID: QZ3BAHA5SUP, IC: 8039C-BAHA5SUP, IC model:
Baha®5 SUP.
Statement:
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from the one in which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
• Changes or modifications can void the user’s authority
to operate the equipment.
Intended use
The Cochlear™Baha®5 SuperPower uses bone conduction
to transmit sounds to the cochlea (inner ear). It is
indicated for people with conductive hearing loss, mixed
hearing loss and single sided sensorineural deafness (SSD).
Furthermore it is indicated for bilateral and paediatric
recipients. Fitting range up to 65 dB SNHL. It works
by combining a sound processor and a small titanium
implant that is placed in the skull behind the ear. The
skull bone integrates with the titanium implant through a
process called osseointegration. This allows sound to be
conducted via the skull bone directly to the cochlea, which
improves hearing performance. The sound processor can
be used together with the Baha Softband.
The fitting is to be done either at a hospital, by an
audiologist, or in some countries, by a hearing care
professional.
List of countries:
Not all products are available in all markets. Product
availability is subject to regulatory approval in the
respective markets.
The products are in compliance with the following
regulatory requirements:
• In EU: the device conforms to the Essential
Requirements according to Annex I of Council Directive
93/42/EEC for medical devices (MDD) and essential
requirements and other relevant provisions of Directive
2014/53/EU (RED). The declaration of conformity may
be consulted at www.cochlear.com.
• Other identified applicable international regulatory
requirements in countries outside the EU and US.
Please refer to local country requirements for these
areas.
• In Canada the sound processor is certified under the
following certification number: IC: 8039C-BAHA5SUP
and model no.: IC model: Baha®5 SUP.
• This device complies with Industry Canada licence-
exempt RSS standard(s).
• This Class B digital apparatus complies with Canadian
ICES-003. Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
• Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2)
this device must accept any interference, including
interference that may cause undesired operation
of the device. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas produire
de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même
si le brouillage est susceptible d’en compromettre le
fonctionnement.
Equipment includes RF transmitter
Note: The sound processor is suited for use
in a home healthcare environment. The home healthcare
environment includes locations such as homes, schools,
churches, restaurants, hotels, cars, and airplanes, where
equipment and systems are less likely to be administered
by healthcare professionals.

15
Español
Enhorabuena por elegir el procesador de sonido Cochlear™Baha®5 SuperPower.
Ahora, está preparado para usar el avanzado procesador de sonido de conducción
ósea de Cochlear, que le ofrece un procesamiento sofisticado de la señal y tecnología
inalámbrica.
Este manual está repleto de sugerencias y consejos sobre cómo puede usar y cuidar
de la mejor manera su procesador de sonido Baha. Lea este manual y guárdelo en un
lugar accesible para futuras consultas; de esta forma, se asegurará de sacar el máximo
provecho al procesador de sonido Baha.
Partes del dispositivo Ver la figura 1
1. Procesador de sonido
2. Actuador
3. Cable
4. Micrófonos
5. Pila
6. Codo
7. Conector plástico snap
8. Botones
9. Indicador visual
Nota sobre las figuras: Las figuras que se
incluyen en la cubierta se corresponden a
información específica de este modelo de
procesador de sonido. Consulte la figura
correspondiente cuando lea el manual. Las
imágenes no están a escala.
Introducción
Para garantizar un rendimiento óptimo, el
profesional de la audición ajustará el procesador
según sus necesidades concretas. Asegúrese de
comentarle cualquier pregunta o duda que pueda
tener acerca de su audición o del uso de este
sistema.
Garantía
La garantía no cubre defectos o daños
causados por, asociados con, o relativos al
uso de este producto con un procesador
de sonido que no sea de Cochlear y/o un
implante que no sea de Cochlear. Consulte
la "Tarjeta de garantía global limitada de
Cochlear Baha" y el "Apéndice de la tarjeta
de garantía" para obtener más detalles.
Bienvenido

16
Contacto con el servicio de
atención al cliente
Intentamos proporcionar los mejores productos y
servicios posibles a nuestros clientes. Su opinión y
experiencia con nuestros productos y servicios son
importantes para nosotros. Si desea realizar algún
comentario, póngase en contacto con nosotros.
Customer Service – Cochlear Americas
10350 Park Meadows Drive, Lone Tree,
CO 80124, USA
Toll free (North America): 1800 523 5798
Tel: [phone], Fax: [phone]
E-mail: [e-mail]
Customer Service – Cochlear Europe
6 Dashwood Lang Road, Bourne Business Park,
Addlestone, Surrey KT15 2HJ, United Kingdom
Tel: [phone], Fax: [phone]
E-mail: [e-mail]
Customer Service – Cochlear Asia Pacific
1 University Avenue, Macquarie University,
NSW 2109, Australia
Toll free (Australia): 1800 620 929
Toll free (New Zealand): 0800 444 819
Tel: [phone], Fax: [phone]
or Toll free fax: [phone]
E-mail: [e-mail]

17
Español
Aclaración de los símbolos
Los siguientes símbolos se utilizarán en todo el documento.
Consulte la lista para ver la descripción de cada uno:
Consultar las “Instrucciones
de uso” o las “Instrucciones
de funcionamiento”
Bluetooth®
"Aviso" o "Aviso, consultar los
documentos que se incluyen" Fabricante
Señal acústica Número de referencia en el
catálogo
2797
Marca CE y número de
organismo
notificado
Fecha de fabricación
Riesgo de interferencia Bajo prescripción
Código de lote Limitación de temperatura
Número de serie Limitación de humedad
Consultar las
instrucciones/el folleto
Nota: El símbolo es azul
Material reciclable
Cumple con la
Autoridad Australiana de
Comunicaciones y Medios
(ACMA, por sus siglas en
inglés)
Desecho de aparatos
eléctricos y electrónicos
Made for iPod, iPhone, iPad Certificación de conformidad
de radio para Corea
Certificación de
conformidad de radio
para Japón

18
Uso del procesador de sonido
Los botones del procesador de sonido le permiten
ajustar el nivel de volumen, elegir uno de sus
programas preajustados y activar/desactivar la
transmisión inalámbrica. Puede optar por activar los
indicadores sonoros y visuales para que le avisen de
los cambios en los ajustes y el estado del procesador.
El procesador de sonido puede utilizarse tanto
en el lado derecho como en el lado izquierdo
de la cabeza. El profesional de la audición habrá
marcado su procesador de sonido como izquierdo
o derecho (L o R, respectivamente). Si es un
usuario bilateral, los cambios que realice en un
dispositivo se aplicarán automáticamente al otro.
Encendido/apagado Ver la figura 2
12Encienda el procesador de sonido; para
ello, conecte el módulo de las pilas.
3Para apagar el procesador de sonido,
desconecte la pila.
Al apagar y volver a encender el procesador
de sonido, este retornará al ajuste por defecto
(Programa 1).
Indicador de estado Ver la figura 3
El procesador de sonido está equipado con
indicadores sonoros y visuales. Para ver una lista
de los indicadores sonoros y visuales, consulte la
tabla al reverso de esta sección.
Si lo prefiere, el profesional de la audición
puede desactivar los indicadores sonoros o
visuales.
Cambio de programa Ver la figura 4
Junto con el profesional de la audición, podrá
seleccionar hasta cuatro programas preajustados
para el procesador de sonido:
Programa 1:
Programa 2:
Programa 3:
Programa 4:
Estos programas son adecuados para diferentes
entornos de audición. Pídale al profesional de la
audición que anote en un papel sus programas
específicos.
Para cambiar de programa, mantenga pulsado el
botón superior del procesador de sonido. Si están
activados, los indicadores sonoros y visuales le
indicarán qué programa está utilizando:
Programa 1: 1 pitido y 1 parpadeo
Programa 2: 2 pitidos y 2 parpadeos
Programa 3: 3 pitidos y 3 parpadeos
Programa 4: 4 pitidos y 4 parpadeos
Ajuste del volumen
Ver la figura 5
1Pulse y suelte el botón superior para subir el
volumen.
2Pulse y suelte el botón inferior para bajar el
volumen.
Puede ajustar el nivel de volumen con uno
de los accesorios opcionales Cochlear Baha
Remote Control o Cochlear Wireless Phone
Clip, o bien con un iPhone, iPad o iPodTouch
(consulte la sección "Made for iPhone").
Accesorios Wireless (inalámbricos)
Para mejorar su experiencia auditiva, puede
utilizar los accesorios Cochlear Wireless. Póngase
en contacto con su profesional de la audición para
obtener más información sobre cuáles son sus
opciones o visite www.cochlear.com.
Para activar la transmisión de audio inalámbrica,
mantenga pulsado el botón inferior hasta que se
escuche una melodía. Ver la figura 6
Para desactivar la transmisión de audio
inalámbrica, mantenga presionado el botón
superior. El procesador de sonido volverá al
programa anterior.
Modo de vuelo Ver la figura 8
Cuando embarque en un vuelo, debe desactivar
la funcionalidad inalámbrica porque las señales
de radio no deben usarse durante el vuelo. Para
desactivar el funcionamiento inalámbrico:

19
Español
1Desconecte la pila para apagar el procesador
de sonido.
2Mantenga pulsado el botón inferior mientras
conecta la pila.
Para desactivar el modo de vuelo, apague el
procesador de sonido y vuelva a encenderlo
desconectando y conectando la pila.
Made for iPhone MFi
Su procesador de sonido es un dispositivo de
audición Made for iPhone (MFi). Esto le permite
controlar su procesador de sonido y transmitir
audio directamente desde su iPhone, iPad o iPod
touch. Para obtener los datos completos sobre la
compatibilidad y más información, visite
www.cochlear.com.
Habla por teléfono Ver la figura 7
Para obtener los mejores resultados, use Cochlear
Wireless Phone Clip o transmita la conversación
directamente desde su iPhone. Al utilizar un
teléfono de mano normal, coloque el receptor
cerca de la entrada del micrófono del procesador
de sonido en lugar de cerca del oído. Asegúrese de
que el receptor no toque el procesador de sonido,
ya que podría producirse feedback.
Pilas
Hay dos pilas diferentes para el
Baha 5 SuperPower: el módulo de pila recargable
estándar y el módulo de pila recargable compacto.
Solicite más información sobre la elección de la
pila al profesional de la audición.
Duración de la pila
Deben cambiarse las pilas cuando sea
necesario, tal como lo haría con cualquier otro
dispositivo electrónico. La vida de la pila varía
según los programas utilizados a diario, el
ambiente acústico empleado por los accesorios
inalámbricos y el tamaño de la pila.
La vida útil de la pila recargable es de 365 ciclos
de carga como mínimo. Se tarda unas cuatro
horas en recargar por completo una pila
recargable.
A medida que envejecen, las pilas recargables
pueden tardar más tiempo en recargarse. Para
aprovechar al máximo la vida útil de las pilas
recargables, recárguelas siempre antes de usarlas.
Cuando queda aproximadamente una hora de
funcionamiento, un indicador sonoro emite cuatro
pitidos cortos dos veces y el indicador visual
parpadea repetidamente. En este momento puede
experimentar una amplificación baja. Si la pila
se agota por completo, el procesador de sonido
emite un pitido y después deja de funcionar.
Cambio de la pila
Retirada de la pila Ver la figura 2
Gire el módulo de las pilas para retirarlo del
procesador de sonido.
Colocación de la pila Ver la figura 2
Alinee el módulo de las pilas con el conector del
procesador para que las partes coincidan. Gire el
módulo de las pilas como se indica en la figura
para acoplar las partes. El procesador se encenderá
automáticamente.
Bloqueo/desbloqueo de la batería (fijación
de seguridad) Ver la figura 9
1Para aumentar la seguridad, empuje el
bloqueo hacia la izquierda hasta el tope con la
herramienta de bloqueo de la tapa de las pilas
a fin de bloquear el módulo de las pilas.
2Para desbloquear el módulo de las pilas,
empuje el bloqueo hasta el tope derecho.
Carga de los módulos de las pilas
Ver la figura 10
1Oriente e introduzca el módulo de pila
recargable en el conector del cargador de pilas
Cochlear Nucleus®.
2Gírelo en el sentido de las agujas del reloj para
acoplarlo.
3Conecte el cargador de las pilas al adaptador
de alimentación y enchúfelo a la toma
eléctrica.

20
3Limpie los conectores del cargador con un
paño suave y seco.
Cuando cargue las pilas, vaya cambiando de
conector para que estos se desgasten por igual.
Si se moja
Si salpica algún líquido al cargador de las pilas,
sacúdalo con cuidado y déjelo secar durante
24 horas. No utilice el cargador de las pilas hasta
que esté seco.
Cómo cuidar el cargador de las
pilas
A diario
Compruebe que el cargador de las pilas esté
limpio. Si percibe polvo o suciedad:
1Desconecte el adaptador de alimentación y
retire los módulos de las pilas.
2Sujete el cargador de las pilas boca abajo y
golpéelo ligeramente para eliminar la suciedad
que se pueda haber acumulado en los
conectores. También puede intentar eliminar
la suciedad soplando sobre los conectores del
cargador.
Piloto de la alimentación
eléctrica Significado
Verde continuo
El cargador de pilas está encendido.
No se enciende El adaptador de alimentación no está enchufado o no recibe
alimentación eléctrica (o no está encendida).
Piloto del conector de la
pila Significado
Naranja continuo
El módulo de las pilas se está cargando.
Verde continuo
El módulo de las pilas está cargado por completo.
Naranja intermitente
Hay un problema con el módulo de las pilas. Pruebe en otro conector.
Cambie el módulo de pila recargable.
No se enciende El módulo de las pilas no está colocado correctamente, está
demasiado descargado o no recibe suministro eléctrico. Compruebe
que el cargador de pilas esté encendido y vuelva a conectarlo. Si sigue
sin encenderse el piloto, cambie el módulo de las pilas.
