Code Alarm ca5554 Professional series User manual

CCJCc~LAi=lm
i=»r:lOFESSIONA
I
SEr:liES
Automatic
I Manual Transmission
Remote Start
with
Keyless Entry
Installation Guide
for
models:
ca5554
2014 Voxx Electronics Corporation. All rights reserved. 4280607

Table
of
Contents
Before You Begin.........................................................................................3
Wire
Connection
Guide
...............................................................................4
11
Pin Main Harness .................................................................................5
3 Pin Parking Light Harness......................................................................8
6 Pin Start Harness ...................................................................................9
4 Pin Alternate Harness...........................................................................10
2 Pin Door Lock Harness ........................................................................
11
Additional
Ports
.........................................................................................15
Antenna
I
LED
I
Programming Port........................................................ 15
OBI
Port...................................................................................................15
Telematic Interface Port...........................................................................15
Set Up &
Programming
.............................................................................16
Transmitter Programming........................................................................16
Manual Feature Programming.................................................................16
Programming Feature Banks ..................................................................17
Tach Programming ..................................................................................20
Smart Tachless Mode..............................................................................20
Feature
Descriptions
.................................................................................
21
Transmitter
Button
Functions
..................................................................29
Remote Start
Shutdown
Diagnostics
......................................................30
System
Layout
...........................................................................................
31
2 ca5554 Install rev A

•
...
.
BEFORE YOU BEGIN
PROFESSIONAL INSTALLATION
STRONGLY RECOMMENDED
Roll down window to avoid locking keys
in
vehicle
during installation
Avoid mounting components or routing wires near
hot surfaces
Avoid mounting components or routing wires near
moving parts
Use a Digital Multi Meter for testing and verifying
circuits. DO NOT USE A TEST LIGHT, OR
"COMPUTER SAFE PROBE" as these can set off air
bags or damage vehicle computers.
Technical Support
(BOO)
421-3209
or
go to
http://avxtech1.com
2014
Voxx.
Electronics Corporation. All rights reserved.
3

4
z
<(
~
z
c..
~
~
en
zr-
-I
0...(9
M-
.....J
.....
0::
<(
.....
en
z
c..
(.0
11
Pin Main Harness
GRAY/RED
PARKING
BRAKE
INPUT ( - )
PURPLE DOOR INPUT (
+)
GREEN
DOOR INPUT ( - )
BLACK/WHITE
ILLUMINATED ENTRY
OUTPUT
(-)
BROWN/BLACK
HORN OUTPUT
(-)
RED/WHITE TRUNK
RELEASE
OUTPUT ( - )
BLUE/BLACK
START STATUS
I
ACTIVE
OUTPUT
( - )
PURPLE/WHITE
TACH INPUT
GRAY
HOOD PIN INPUT ( - )
BROWN/RED
BRAKE
INPUT ( + )
VIOLET/BLACK
AUX
1 OUTPUT ( - )
3 Pin Parking Light Harness
BLACK GROUND
WHITE/RED PARKING LIGHT INPUT
WHITE PARKING LIGHT OUTPUT
6 Pin Start Harness
PURPLE STARTER OUTPUT -MOTOR SlDE
RED BATTERY 12V (
+)
ORANGE ACCESSORY 1 ( + )
PINK/WHITE IGNITION 2 ( + )
RED/WHITE BATTERY 12V (
+)
PINK IGNITION 1 ( + )
ca5554 Install rev A

z~
-(.)
a. a
N.....J
1
4 Pin Alternate Harness
BLACK/YELLOW PULSE DURING CRANK ( - )
GREEN/WHITE PULSE AFTER
SHUlDOWN
( - )
LT BLUE FACTORY ARM
I
PULSE AFTER START ( - )
LT GREEN/BLACK FACTORY DISARM
I
PULSE BEFORE START ( - )
2 Pin Door Lock Harness
BLUE UNLOCK
(-)
GREEN LOCK
(-)
11
Pin Main Harness
GRAY/RED PARKING BRAKE INPUT
(-)
Locate the vehicle's parking brake wire.
Verification: This wire will register ground when the vehicle's PARKING
BRAKE is engaged.
NOTE: The following connection
is
required for Manual
Trans~ission
Mode.
2 PURPLE DOOR TRIGGER INPUT ( + )
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register positive voltage (POS) when the door is
opened and the interior light is on. This wire will
register ground
or
"0" Volts when the door is closed and the interior light is
off.
Connect the PURPLE wire to the vehicle's positive door input wire(s).
NOTE:
Certain vehicles may require multiple connections. Refer to vehicle
application guide.
2014 Voxx Electronics Corporation. All rights reserved.
5

6
3
GREEN DOOR TRIGGER INPUT ( - )
Locate the vehicle's dome light or door pin switch wire.
Verification:
This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door
is
closed and the interior light
is
off.
Connect the GREEN wire to the vehicle's negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
4
BLACK/WHITE ILLUMINATED ENTRY OUTPUT
(-)
This wire provides a ( - ) 200mA output for 30 seconds when the system is disarmed
capable
of
driving relays.
Locate the vehicle's dome light or pin switch wire.
5
Verification:
This wire will register positive voltage or ground when the
vehicle's dome light is turned ON.
BROWN/BLACK HORN OUTPUT ( - )
Locate the vehicle's horn wire.
Verification:
This wire will register at positive voltage and register
ground when the horn switch is pressed.
Connect the BROWN/BLACK wire to the vehicle's horn wire. This is a low current
output, 200mA.
6
RED/WHITE TRUNK RELEASE OUTPUT ( - )
Locate the vehicle's trunk release wire at the trunk release switch.
Verification:
This wire will register either positive voltage
or
ground when
the trunk release
is
activated.
This
is
a low current output, 200mA and is configurable
in
option programming.
ca5554 Install rev A

7 BLUE/BLACK START STATUS I ACTIVE OUTPUT ( - )
This wire provides a ground output when the remote start function is activated and
remains until 4 seconds after the remote start
is
shutdown. If this wire will be used
for multiple application's a 1 amp diode is required in-line with the stripe facing the
control module.
8
PURPLE/WHITE TACH INPUT
Locate the vehicle's ignition coil or fuel injector
in
the engine compartment.
Verification: Test using the following procedure:
1.
Set voltmeter to AC VOLTS.
2.
Attach positive lead
of
a volt meter to a constant 12-volt source.
3.
Attach negative lead
of
a volt meter to the wire to be tested.
4.
Start the engine.
5.
Have someone press on the gas pedal slightly as you monitor the meter. If
connected to the correct wire, the voltage reading will increase as the engine's
RPM increases.
Connect the PURPLE/WHITE wire to the negative side
of
the vehicle ignition coil
or
fuel injector.
9 GRAY HOOD
PIN
INPUT ( - )
Install a Hood Pin Switch and connect to the GRAY wire. This connection is required
for Remote Start.
Verification: This wire when connected will register ground when the
vehicle's hood
is
opened.
Connect the GRAY wire to the hood pin.
NOTE: Be sure to loom the wire, and seal the grommet.
1
0 BROWN/RED BRAKE INPUT (
+ )
Locate the vehicle's brake light wire at the brake pedal mounted switch. This
connection
is
required for Remote Start.
Verification: This wire registers positive voltage when the brake pedal is
pressed.
Connect the BROWN/RED wire to the vehicle's brake light wire.
2014 Voxx Electronics Corporation. All rights reserved.
7

8
1
11
VIOLET/BLACK AUX 1
This wire provides a
(-)
200mA output capable ofdriving relays. For Control
of
optional accessories (i.e. Power Window/Sunroof, etc.).
To
activate refer to the transmitter button configuration chart. Please refer to the
selectable options for timing.
3 Pin Parking Light Harness
BLACK GROUND
Connect the BLACK wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection. The recommended grounding point
is
a metal surface
in
the driver's side kick panel area.
NOTE: Do not ground the BLACK wire with any other vehicle components.
2
WHITE/RED PARKING LIGHT INPUT
3
WHITE PARKING LIGHT OUTPUT
Locate the parking light output wire at the vehicle's light switch.
Verification:
This wire registers positive voltage when the parking lights are
turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
ca5554 Install rev A

6 Pin Start Harness
1 PURPLE STARTER
OUTPUT
( + )
Locate the vehicle starter wire.
Verification: This wire registers voltage onlywhen the key is turned
to
the
START position.
Verification: The starter wire registers voltage when the
key
is turned to the
START position.
Connect the PURPLE wire to the vehicle starter wire.
2 RED BATTERY
12V
(
+)
Locate 1
of
the vehicle's constant 12 Volt battery wires
at
the ignition switch.
Verification: This wire will register ( + ) voltage in all positions
of
the ignition
switch.
Connect
the
RED wire to the constant 12 Volt battery wire.
NOTE:
Remove
all fuses until all connections are made.
3
ORANGE
ACCESSORY
1 ( + )
Locate the vehicle's accessory wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to
ACC
(Accessory) and the ON (or RUN) position.
The
voltage
drops
out
when
the
key is turned to the START (or CRANK) position.
Connect the
ORANGE
wire to the vehicle's accessory wire.
Programmable output: IGN, ACC, Start.
4 PINK/WHITE IGNITION 2 ( + )
Locate the vehicle's 2nd ignition wire at the ignition switch (if equipped).
Verification: This wire registers voltage
when
the key is turned to
the
ON
(or
RUN) position, but not the
ACC
(Accessory) position.
The
voltage
does
not
drop
out
when the key is turned to the START (or
CRANK)
position.
Connect
the
PINK/WHITE wire to the vehicle's ignition 2 wire.
Programmable output: IGN, ACC, Start.
2014 Voxx Electronics Corporation. All rights reserved.
9

10
5 RED/WHITE BATTERY 12V (
+)
Locate 1
of
the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions
of
the ignition
switch.
Connect the RED/WHITE wire to the constant 12 Volt battery wire.
NOTE:
Remove all fuses until all connections are made.
6 PINK IGNITION 1 ( + )
Locate the vehicle's ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the PINK wire to the vehicle's Ignition wire.
This wire is also used for Ignition 1 Output.
4 Pin Alternate Harness
1 BLACK/YELLOW PULSE DURING
CRANK
(-)
Locate the vehicle's second starter (crank) wire at the ignition switch. (if equipped)
Verification: This wire registers voltage only in the start (crank) position
of
the ignition switch.
This wire will supply a
(-)
200mAoutput and can be configured in option
programming.
2 GREEN/WHITE PULSE
AFTER
SHUTDOWN
( - )
This wire will supply a
(-)
200mA pulse after the remote start shuts down. This
is typically used to re-lock the vehicle's doors ifthey unlock upon remote start
shutdown. It can also be used to pulse a
door
pin-switch wire to prevent the vehicle's
accessories from remaining on after remote start shutdown.
This output is configurable in option programming.
ca5554 Install rev A

3
LT BLUE FACTORY ARM I
PULSE AFTER START ( - )
This wire will supply a ( - ) 200mA pulse both upon arming the system and upon
successful completion
of the remote start activation sequence and is typically used to
re-lock the vehicle's doors upon remote start if necessary.
This output
is configurable in option programming.
4 LT GREEN/BLACK FACTORY DISARM I
PULSE BEFORE START ( - )
This wire will supply a ( - ) 200mA pulse both upon disarming the system and when
the remote start feature
is activated. Locate the factory perimeter alarm disarm wire
from the key cylinder inside the drivers door.
Verification: This wire registers ground ifthe key is turned to the unlock
position
in the driver's door cylinder.
This output is configurable
in option programming.
1 BLUE UNLOCK (-)
2 GREEN LOCK
(-)
The door lock I unlock outputs are designed to control several different types of
systems which may require additional parts. Please review the wire and location
chart to see which type
of door lock system is in your vehicle. The most common
types are shown in the following diagrams.
These wires supply a ( - ) 500mA output.
2014 Voxx Electronics Corporation. All rights reserved.
11

12
Negative Switching Locks
All Door Lock and Unlock: Locate the lock I unlock wire at the vehicle's lock I unlock
switch.
Verification: These wires will register ground when the Lock and Unlock
switches are activated.
Connect the GREEN and BLUE wires shown
in the diagram below.
Negative Locks:
Positive Switching Locks
GREEN ( - ) Lock Output
Vehicle Door Lock
Control Relays
BLUE ( - ) Unlock Output
All Door Lock and Unlock: Locate the lock I unlock wire at the vehicle's lock I unlock
switch.
Verification: These wires will register positive voltage when the Lock and
Unlock switches are activated.
Connect the GREEN and BLUE wires shown
in the diagram below.
Positive Locks:
ca5554 Install rev A

Reverse Polarity Locks (5-Wire Door locks)
All Door Lock and Unlock: Locate the lock
I
unlock wire at the vehicle's lock
I
unlock
switch.
Verification:
These wires will rest at ground and register positive
voltage when the Lock and Unlock switches are activated.
Connect
the
GREEN and BLUE or BLUE/GREEN wires shown
in
the diagram below
using (2) SPOT relays (not supplied).
Reverse Polarity Locks:
GREEN ( - ) Lock Output
Cut
Negative Multiplexed Locks
All Door Lock and Unlock: Locate the lock
I
unlock wire at the vehicle's lock
I
unlock
switch.
Verification:
This wire will show variable ground when the switch is activated.
Please consult the wire and location chart for specific resistor values for
your vehicle.
Connect
the
GREEN and BLUE or BLUE/GREEN wires shown in the diagram below
using (2) SPOT relays (not supplied).
Multiplex Locks:
BLUE ( - ) Unlock Output
2014 Voxx Electronics Corporation_ All rights reserved. 13

14
Positive Multiplexed Locks
All Door Lock and Unlock: Locate the lock
I
unlock wire at the vehicle's lock
I
unlock
switch.
Verification:
This wire will show variable positive voltage when the switch
is
activated. Please consult the wire and location chart
for
specific resistor
values for your vehicle.
Connect the GREEN and BLUE or BLUE/GREEN wires shown
in
the diagram below
using (2) SPOT relays (not supplied).
Multiplex Locks:
Adding
Aftermarket
Actuators
After installing aftermarket actuators, (not supplied). Connect the GREEN and BLUE
wires shown
in
the diagram below using (2) SPOT relays (not supplied).
BLUE (
-)
Unlock Output
ca5554 Install rev A

Additional Ports
Antenna I LED I Programming Port
Mount the supplied antenna/receiver to a clear spot
on
the vehicle's windshield that
will not block the driver's vision. A good location
is
usually high on the windshield
near the rear view mirror.
Be
careful not
to
mount the antenna/receiver on any
metallic window film, as this will effect system range. Route the antenna/receiver
cable to the control module and plug into the antenna port.
Data Bus Interface Port
This 4 pin port is used for Flashlogic Door Lock and Transponder Databus Interfaces
to communicate with the vehicle's Databus. When using the
OBI
port to control the
Flashlogic Door Lock and Transponder Interface modules the following options may
be available. Please refer to the
020
(Data to Data) function list available per vehicle
on the tech service web site.
Tach Input
Trunk/Hatch Open
Door Lock Control
Dome Light Supervision
Factory Alarm Arm I Disarm
Telematic Interface Port
Brake Safety Shut Down
Diesel Glow Plug Input
Passlock I Passkey Interface
(GM
Only)
Transponder Interface Activation
Manual Arm I Disarm Inputs (factory keyless
controls system)
This 4 pin port is used for Telematic Interface accessories, such as Car Connection
Pro, which can control some of the following features.
Door Lock Control Trunk Release
Sliding Doors AUX Output
Car Find Remote Start
2014 Voxx Electronics Corporation. All rights reserved. 15

16
Set Up & Programming
Transmitter Programming -Feature Bank 1
1.
Turn the ignition ON.
2.
Press and hold the valet/override button.
3.
Within
10
seconds the system will chirp (3) three times.
4.
Press 1 button of each transmitter you wish to program.
5.
The system will respond with 1 chirp for each accepted transmitter.
6.
Pressing the override button at anytime during programming will advance to
the next bank.
NOTE:
The system will exit transmitter programming after 15 seconds of inactivity.
NOTE:
This system has 1 button programming which programs all channels
of
the
system.
NOTE:
The system will hold
up
to 4 transmitters
in
memory, programming a 5th
transmitter will erase the oldest transmitter
in
memory.
NOTE:
This system has
PTN-
Programmed Transmitter Notification. Each time the
ignition is turned
ON,
the LED will flash the number of transmitters programmed to the
system.
Manual Feature Programming -Feature Bank 2 - 5
1.
Turn the ignition ON.
2.
Press and hold the valet/override button.
3.
Within
10
seconds the system will chirp (3) three times.
4.
Use the valet/override button to advance through each option bank. For
feature programming advance
to
Feature Bank
2,
3,
4 or
5,
which
is
(4)
four, (5) five, (6) six and (7) seven chirps.
5.
Use the transmitter 0 button to scroll through the selections
in
each feature
bank, the system will chirp to match the feature number.
6.
Press the transmitter
@
button to change the desired feature. The LED will
flash indicating the changed feature.
Defaulting All Features:
Pressing the
riJ
button anytime while
in
any of the feature
banks will default all features and return
you
to feature bank 2 - 4 chirps.
NOTE:
The system will remain
in
feature programming mode
as
long
as
the ignition
is
on, there
is
no
time limit.
To
exit programming turn the IGNITION
OFF.
ca5554 Install rev A

2
Feature
Bank
1 - 3 Chirps
Transmitter
Programming
Refer to transmitter programming.
Factory Disarm
Lt Green
I
Black
Factory
Disarm
2nd
Unlock Factory Disarm Factory Disarm Factory Disarm
I
Start Status
350mS
SOOmS
NOTE: On
this
model
the
Lt
Green I
Black
Output
wire
can
be
configured
in
Bank
3
or
Bank
5.
Any
changes
to
this
feature
in
Bank
5
will
override
changes
made
in
Bank
3.
2014 Voxx Electronics Corporation. All rights reserved. 17

18 ca5554 Install rev A

Feature
Bank
5-7
Chirps
4
Pin
Alternate
Output Control
2014 Voxx Electronics Corporation. All rights reserved.
19

Tach Programming
The unit will not operate unless a tach signal
is
programmed or the tach
less
option
is
turned ON. If
an
attempt is made
to
start the vehicle via the remote start
without first programming tach, the unit will flash the parking lights 7 times indicating
tach has not been learned and stored. If the tach rate
is
not properly programmed
to
the specific vehicle, the unit may not realize that the vehicle is running
in
certain
instances and reengage the starter motor.
The Remote Start unit will learn the tach rate of most vehicle's single coil, multiple coil
packs, or single injector.
To
learn tach:
1.
Turn the ignition key to the
ON
position.
2.
Press and release the valet/override button 3 times.
3.
Immediately turn the ignition key
OFF.
4.
Press and hold the valet/override button, then start the vehicle using
the
key.
5.
When the unit senses the tach signal, the parking lights will begin to
flash.
6.
Allow the vehicle to settle to a normal idle speed.
7.
Release the valet/program push-button switch. 1 long chirp and the
parking lights will turn on for 2 seconds, indicating that the learned
tach signal is stored and the unit has exited tach learn mode.
NOTE: If the unit fails to learn tach rate due
to
an
improper tach connection or a
poor tach source, the parking lights will not flash.
To
correct this situation, locate and
connect the PURPLE/WHITE wire to the proper tach signal, and then repeat the tach
learn routine.
Smart Tachless Mode
Smart Tachless Mode is available only if a tach signal has never been learned to the
system and when activated will automatically change the
Tach
Mode feature
in
option
programming to Tachless without the need
to
enter the feature programming mode.
1.
Activate the remote start. The parking lights should begin flashing 7
times indicating no tach signal has been learned.
2.
Within the 7 flash time period, press and hold the
()
button.
3.
The system will chirp 1 time indicating the system is now
in
tachless
mode.
20
ca5554 Install
rev
A
