BEFORE YOU BEGIN

4 2009 Audiovox Electronics Corporation. All rights reserved.
6 Pin Input / Output Harness
5 Pin Main Harness
2 Pin Door Lock Output Harness

52009 Audiovox Electronics Corporation. All rights reserved.
3 BLACK GROUND
Connect the BLACK wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection. The recommended grounding point is a metal surface
in the driver’s side kick panel area.
NOTE: Do not ground the BLACK wire with any other vehicle components.
5 Pin Main Harness
1 WHITE/RED PARKINGLIGHTINPUT
2 WHITE PARKINGLIGHTOUTPUT
Locate the parking light output wire at the vehicle’s light switch.
Verification: This wire registers positive voltage when the parking lights
are turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
4 BROWN SIRENOUTPUT(+)
Locate a suitable mounting location in the engine compartment for the siren, away
from moving parts.
With the bell of the siren aiming downwards, secure the siren in place using self
tapping screws, being careful not do drill into any hoses, wiring or components.
Connect the BLACK siren wire to a chassis ground using a ring terminal and self
tapping screw (not supplied).
Route the BROWN siren output wire from the control module through the firewall
and connect to the RED wire on the siren.
NOTE: Be sure to loom the siren wires, and seal the grommet.

6 2009 Audiovox Electronics Corporation. All rights reserved.
5 RED BATTERY 12V ( + )
Locate 1 of the vehicle’s constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
6 Pin Input / Output Harness
1 PURPLE DOORTRIGGER INPUT (+)
Locate the vehicle’s dome light or door pin switch wire.
Verification: This wire will register positive voltage (POS) when the door is
opened and the interior light is on. This wire will
register ground or "0" Volts when the door is closed and the interior light is
off.
Connect the PURPLE wire to the vehicle’s positive door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide
2 BLUE TRUNKPININPUT ( - )
Locate the vehicle’s trunk pin switch wire and connect to the BLUE wire.
Verification: This wire when connected will register ground when the
vehicle's trunk is opened.
Connect the BLUE wire to the trunk pin.

72009 Audiovox Electronics Corporation. All rights reserved.
5 ORANGE GROUNDWHENARMEDOUTPUT(-)
This wire will have a continuous ( - ) 500mA output when the system is Armed. This
wire is typically used for controlling window modules or additional sensors.
4 YELLOW IGNITIONINPUT(+)
Locate the vehicle’s ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START(or CRANK) position.
Connect the YELLOW wire to the vehicle’s Ignition wire.
6 RED/WHITE TRUNKRELEASEOUTPUT( - )
Locate the vehicle’s trunk release wire at the trunk release switch.
Verification: This wire will register either positive voltage or ground when the trunk
release is activated.
This is a low current output, 500mA.
3 GREEN DOORTRIGGERINPUT(- )
Locate the vehicle’s dome light or door pin switch wire.
Verification: This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door is closed and the interior light is off.
Connect the GREEN wire to the vehicle’s negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide

8 2009 Audiovox Electronics Corporation. All rights reserved.
2 Pin Lock Output Harness
1 BLUE UNLOCK ( - )
2 GREEN LOCK ( - )
The door lock / unlock outputs are designed to control several different types of
systems which may require additional parts. Please review the wire and location
chart to see which type of door lock system is in your vehicle. The most common
types are shown in the following diagrams.
Negative Switching Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /
unlock switch.
Verification: These wires will register ground when the Lock and Unlock
switches are activated.
Connect the GREEN and BLUE wires shown in the diagram below.
Lock
Unlock
Vehicle Door Lock
Control Relays
GREEN (-) Lock Output
BLUE (-) Unlock Output
Negative Locks:

92009 Audiovox Electronics Corporation. All rights reserved.
Positive Switching Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /
unlock switch.
Verification: These wires will register positive voltage when the Lock and
Unlock switches are activated.
Connect the GREEN and BLUE wires shown in the diagram below.
Lock
Unlock
87
87a
86 85
30
87
87a
86 85
30
Vehicle Door Lock
Control Relays
Fused +12 Volt
Battery Souce
Fused +12 Volt
Battery Souce
GREEN (-) Lock Output
BLUE (-) Unlock Output
Positive Locks:
Reverse Polarity Locks (5-Wire Door locks)
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /
unlock switch.
Verification: These wires will rest at ground and register positive
voltage when the Lock and Unlock switches are activated.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram
below using (2) SPDT relays (not supplied).
Lock
Unlock
87
87a
86 85
30
87
87a
86 85
30
Fused +12 Volt
Battery Souce
Fused +12 Volt
Battery Souce
GREEN (-) Lock Output
BLUE (-) Unlock Output
Reverse Polarity Locks:
X
Cut
X
Cut
To Door Lock Motor
To Door Lock Motor

10 2009 Audiovox Electronics Corporation. All rights reserved.
Negative Multiplexed Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /
unlock switch.
Verification: This wire will show variable ground when the switch is activated.
Please consult the wire and location chart for specific resistor values for
your vehicle.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram
below using (2) SPDT relays (not supplied).
Lock
Unlock
Vehicle Door Lock
Control Relays
GREEN (-) Lock Output BLUE (-) Unlock Output
Multiplex Locks:
87
87a
86
30
87
87a
86
30
85 85
Fused +12 Volt
Battery Source
Ground
Resistor
Positive Multiplexed Locks
All Door Lock and Unlock: Locate the lock / unlock wire at the vehicle’s lock /
unlock switch.
Verification: This wire will show variable positive voltage when the switch is
activated. Please consult the wire and location chart for specific resistor
values for your vehicle.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram
below using (2) SPDT relays (not supplied).
Lock
Unlock
Vehicle Door Lock
Control Relays
GREEN (-) Lock Output BLUE (-) Unlock Output
Multiplex Locks:
87
87a
86
30
87
87a
86
30
85 85
Fused +12 Volt
Battery Source
Resistor

112009 Audiovox Electronics Corporation. All rights reserved.
Adding Aftermarket Actuators
After installing aftermarket actuators, (not supplied). Connect the GREEN and
BLUE wires shown in the diagram below using (2) SPDT relays (not supplied).
30
87
87a
86 85
Fused +12 Volt
Battery Source
Door Lock
Actuator
30
87
87a
86 85
Chassis
Ground
Chassis
Ground
GREEN (-) Lock Output
BLUE (-) Unlock Outpu
t
Fused +12 Volt
Battery Source
M

12 2009 Audiovox Electronics Corporation. All rights reserved.
LED Port
The LED included in the kit will serve as a visual indicator of the alarm’s status. It
should be installed in the dash, located where it can be easily seen from outside
the vehicle, yet not be distracting to the driver. Once a location has been
selected, check behind the panel for wire routing access, and to confirm the drill
will not damage any existing components as it passes through the panel. Drill a
1/4" hole, and pass the red and blue wires from the LED through the hole, from
the front of the panel. Firmly press the body of LED into the hole until fully seated.
Additional Ports
Programming / Valet Button Port
Select a mounting location that is within reach of the ignition switch, as this
switch in combination with the ignition switch, will be used to program the certain
features of the system. It is suggested that the switch be mounted to the lower
dash panel in the driver’s area within reach of the driver.
On-Board Shock Sensor
Select a solid mounting surface for the alarm module inside the passenger
compartment (behind the dash), and mount the sensor using cable ties. Refer to
feature programming for on-board shock sensor adjustment.

132009 Audiovox Electronics Corporation. All rights reserved.
Manual Feature Programming - Feature Bank 2 - 4
1. Turn the ignition ON.
2. Press and hold the valet/override button.
3. Within 10 seconds the system will chirp (3) three times.
4. Use the valet/override button to advance through each option bank. For
feature programming advance to Feature Bank 2 or 3, which is (4) four, (5) five
or (6) six chirps.
5. Use the transmitter button to scroll through the selections in each feature
bank, the system will chirp to match the feature number.
6. Press the transmitter button to change the desired feature. The LED will
flash indicating the changed feature.
Set Up & Programming
Transmitter Programming - Feature Bank 1
1. Turn the ignition ON.
2. Press and hold the valet/override button.
3. Within 10 seconds the system will chirp (3) three times.
4. Press 1 button of each transmitter you wish to program.
5. The system will respond with 1 chirp for each accepted transmitter.
6. Pressing the override button at anytime during programming will advance to the
next bank.
NOTE: The system will exit transmitter programming after 15 seconds of inactivity.
NOTE: This system has 1 button programming which programs all channels of the
system.
NOTE: The system will hold up to 4 transmitters in memory, programming a 5th
transmitter will erase the oldest transmitter in memory.
Defaulting All Features: Pressing the button anytime while in any of the
feature banks (except during shock sensor programming) will default all features
and return you to feature bank 2 - 4 chirps.
NOTE: The system will remain in feature programming mode as long as the
ignition is on, there is no time limit. To exit programming turn the IGNITION OFF.

14 2009 Audiovox Electronics Corporation. All rights reserved.
Feature Bank 1 - 3 Chirps
Transmitter Programming
Refer to transmitter programming.
Feature Bank 4 - Shock Sensor Adjustment
1. Enter Feature Bank 4
2. Press and release to select full trigger.
3. Use or to adjust the settings. The system will give short chirps upon each
press.
4. Press + for 2 seconds to lock in the change and advance to the lite touch
setting, the system will give 2 long chirps to confirm.
3. Use or to adjust the settings.
4. Press and release + to lock in the change, the system will exit
programming and give 1 long chirp to confirm.

152009 Audiovox Electronics Corporation. All rights reserved.
Dome Light Delay / Theater Dimming
The system can be programed to delay arming after the lock button is pressed (60
second max) for vehicles with a dome light delay or theater dimming feature. Once
programed the system will ‘learn’ the timing of the dome light delay and add 2
seconds before arming.
1. Close all doors with ignition off.
2. Using the transmitter press LOCK, UNLOCK, LOCK ,UNLOCK, LOCK ,
UNLOCK, LOCK. The LED will light solid to indicate the system has entered
DOME DELAY LEARN MODE.
3. Immediately OPEN then CLOSE the door WITHOUT disarming the
system. The system will then monitor the door trigger wire. Once the dome
light turns off, the system will then add 2 seconds and then exit the learning
mode.
4. The LED will begin to flash indicating the system has exited the learning
mode and is now armed.
Chirp Delete - User Accessible
System ARM/DISARM chirps can be toggled ON or OFF without entering the
programming feature banks.
1. Turn the ignition ON then OFF.
2. Press and release the valet/programming button 3 times. The system will
respond with 1 chirp for ON or 2 chirps for OFF.
Feature Descriptions
Feature Bank 2 - Security
1 - Silent Choice: Controls the normal arm/disarm chirps of the security system.
ON - Silent arming/disarming upon first press of lock/unlock, pressing lock/
unlock a second time will activate the arm/disarm chirps respectively. The
system will only sound the arm/disarm chirps upon a second press of the
lock/unlock buttons.
OFF - normal arm/disarm chirps upon the first press of lock/unlock.

16 2009 Audiovox Electronics Corporation. All rights reserved.
2 - Passive Locks: Determines manual or automatic locking of the vehicle’s
doors.Active - Requires use of the transmitter to lock the vehicle’s doors.
Passive - Automatically locks the vehicle’s doors 1 minute after the last door
is closed
3 - Passive Arming: Determines manual or automatic locking of the vehicle’s
doors.Active - Requires use of the transmitter to arm the security system.
Passive - Automatically arms the security system 1 minute after the last door
is closed
4 - Hi Jack: Controls hi jack mode - ON / OFF.
OFF - Standard security system operation.
ON - Enables Hi Jack mode functionality as described in the owners manual
Feature Bank 3 - Output Control
1 - Extended Lock Pulse: Controls the timing of the BLUE and GREEN lock output
wires.
1 Second - Single 1 second lock pulse, single 1 second unlock pulse.
3.5 Seconds - Single 3.5 second lock pulse, single 3.5 second unlock pulse.
1 Second Lock, Double Pulse Unlock - Single 1 second lock pulse, double 1
second unlock pulse.
30 Second Lock, Double Pulse Unlock - Single 30 second lock pulse, double
1 second unlock pulse.
Double Pulse Lock, 1 Second Unlock - Double 1 second lock pulse, single 1
second unlock pulse.
2 - Ignition Controlled Locks: Control of door locks when the ignition is cycled
ON or OFF.
OFF - Door locks not activated by ignition.
Lock and Unlock - Doors lock when ignition is turned on and unlock when
ignition is turned off.
Lock Only - Doors lock when ignition is turned on.
Unlock Only - Doors unlock when ignition is turned off.

172009 Audiovox Electronics Corporation. All rights reserved.
Transmitter Button Functions
Security Trigger Zones
If the security system has been triggered the LED will flash one of the patterns
below indicating the zone.
LEDFLASHESTRIGGERZONE
2 Flashes Hood / Trunk Input
3 Flashes Door Input
4 Flashes Shock Sensor
5 Flashes IgnitionInput

18 2009 Audiovox Electronics Corporation. All rights reserved.
PURPLE DOOR TRIGGER INPUT ( + ) BLUE TRUNK PIN INPUT ( - ) GREEN DOOR TRIGGER INPUT ( - ) YELLOW IGNITION INPUT ( + ) ORANGE ARMED OUTPUT ( - ) RED/WHITE TRUNK RELEASE OUTPUT ( - )
WHITE/RED PARKING LIGHT INPUT WHITE PARKING LIGHT OUTPUT BLACK GROUND BROWN SIREN OUTPUT ( + ) RED BATTERY 12V ( + )
BLUE UNLOCK OUTPUT ( - ) GREEN LOCK OUTPUT ( - )
CA 1050
PROGRAMMING / VALET PORT
LED PORT

192009 Audiovox Electronics Corporation. All rights reserved.

20 2009 Audiovox Electronics Corporation. All rights reserved.
Audiovox Electronics Corporation.
Customer Service 1-800-421-3209
WWW.CODE-ALARM.COM
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference
that may cause undesired operation.
Warning!
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
