Code Alarm ca5154 professional Series User manual

CCCc~LA~m
i=)r:lOFESSIONAI
SEr:liES
Automatic
I Manual Transmission
Remote Start
with
Keyless
Entry
Installation Guide
for
models:
ca5154
2014 Voxx Electronics Corporation. All rights reserved. 4280605

Table
of
Contents
Before You Begin.........................................................................................3
Wire
Connection
Guide...............................................................................4
11
Pin Main Harness .................................................................................5
3
Pin
Parking Light Harness......................................................................8
6 Pin Start Harness ...................................................................................9
4 Pin Alternate Harness...........................................................................1
0
2
Pin
Door Lock Harness ........................................................................
11
Additional
Ports
.........................................................................................15
Antenna
I
LED
I
Programming Port........................................................15
OBI
Port...................................................................................................15
Telematic Interface Port...........................................................................15
Set Up &
Programming
.............................................................................16
Transmitter Programming........................................................................16
Manual Feature Programming.................................................................16
Programming Feature Banks ..................................................................17
Tach
Programming ..................................................................................20
Smart Tachless Mode..............................................................................20
Feature
Descriptions
.................................................................................
21
Transmitter
Button
Functions
..................................................................29
Remote Start
Shutdown
Diagnostics
......................................................
30
System
Layout
...........................................................................................
31
2 ca5154 Install rev A

•
...
.
BEFORE YOU BEGIN
PROFESSIONAL INSTALLATION
STRONGLY RECOMMENDED
Roll down window to avoid locking keys
in
vehicle
during installation
Avoid mounting components or routing wires near
hot surfaces
Avoid mounting components or routing wires near
moving parts
Tape or loom wires under hood for protection and
appearance
Use a Digital Multi Meter for testing and verifying
circuits. DO NOT USE A TEST LIGHT, OR
"COMPUTER SAFE PROBE" as these can set off air
bags or damage vehicle computers.
Technical Support [phone]
orgoto
http://avxtech1.com
2014 Voxx Electronics Corporation. All rights reserved. 3

4
z
<(
~
z
a..
"r"
"r"
(/)
ZI-
-I
a..(!)
('t')-
_J
1-
0:::
<(
1-
(/)
z
a..
<.0
11
Pin Main Harness
GRAY/RED PARKING BRAKE INPUT ( - )
PURPLE DOOR INPUT (
+)
GREEN DOOR INPUT
(-
)
BLACK/WHITE ILLUMINATED ENTRY OUTPUT ( - )
BROWN/BLACK HORN
OUlPUT
( - )
RED/WHITE TRUNK RELEASE OUTPUT ( - )
BLUE/BLACK START STATUS I ACTIVE OUTPUT ( - )
PURPLE/WHITE TACH INPUT
GRAY HOOD PIN INPUT ( - )
BROWN/RED BRAKE INPUT (
+ )
VIOLET/BLACK AUX 1
OUlPUT
( - )
3 Pin Parking Light Harness
BLACK GROUND
WHITE/RED PARKING LIGHT INPUT
WHITE PARKING LIGHT OUTPUT
6 Pin Start Harness
PURPLE STARTER
OUTPUT-
MOTOR SIDE
RED BATTERY 12V (
+)
ORANGE ACCESSORY 1 ( + )
PINK/WHITE IGNITION 2 ( + )
RED/WHITE BATTERY 12V (
+)
PINK IGNITION 1 ( + )
ca5154 Install rev A

z~
-o
a..o
N.....J
1
4 Pin Alternate Harness
BLACK/YELLOW PULSE DURING CRANK
(-)
GREEN/WHilE
PULSE
AFlER
SHUIDOWN
( - )
LTBLUE FACTORY ARM
I
PULSE
AFlER
START
(-
)
LT GREEN/BLACK FACTORY DISARM
I
PULSE BEFORE START
(-
)
2 Pin Door Lock Harness
BLUE UNLOCK
(-)
GREEN LOCK
(-)
11
Pin Main Harness
GRAY/RED PARKING BRAKE INPUT ( - )
Locate the vehicle's parking brake wire.
Verification: This wire will register ground when the vehicle's PARKING
BRAKE is engaged.
NOTE: The following connection is required for Manual Transmission Mode.
2 PURPLE DOOR TRIGGER INPUT ( + )
Locate the vehicle's dome light
or
door pin switch wire.
Verification: This wire will register positive voltage (POS) when the
door
is
opened and the interior light is on. This wire will
register ground
or
"0" Volts when the door is closed and the interior light is
off.
Connect the PURPLE wire to the vehicle's positive door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
2014 Voxx Electronics Corporation. All rights reserved.
5

6
3
GREEN DOOR TRIGGER INPUT ( - )
Locate the vehicle's dome light or door pin switch wire.
Verification: This wire will register ground (NEG) when the door
is
opened
and the interior light
is
on. This wire will register positive voltage when the
door is closed and the interior light is off.
Connect the GREEN wire to the vehicle's negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide.
4 BLACK/WHITE ILLUMINATED ENTRY OUTPUT ( - )
This wire provides a ( - ) 200mA output for 30 seconds when the system is disarmed
capable
of
driving relays.
Locate the vehicle's dome light or pin switch wire.
5
Verification: This wire will register positive voltage or ground when the
vehicle's dome light
is
turned ON.
BROWN/BLACK HORN OUTPUT ( - )
Locate the vehicle's horn wire.
Verification: This wire will register at positive voltage and register
ground when the horn switch is pressed.
Connect the BROWN/BLACK wire to the vehicle's horn wire. This is a low current
output, 200mA.
6 RED/WHITE TRUNK RELEASE OUTPUT ( - )
Locate the vehicle's trunk release wire at the trunk release switch.
Verification: This wire will register either positive voltage or ground when
the trunk release is activated.
This is a low current output, 200mA and is configurable
in
option programming.
ca5154 Install rev A

7 BLUE/BLACK START STATUS
I
ACTIVE OUTPUT ( - )
This wire provides a ground output when the remote start function is activated and
remains
until4
seconds after the remote start is shutdown. Ifthis wire will be used
for multiple application's a 1 amp diode is required in-line with the stripe facing the
control module.
8
PURPLE/WHITE TACH INPUT
Locate the vehicle's ignition coil or fuel injector
in
the engine compartment.
Verification: Test using the following procedure:
1.
Set voltmeter to AC VOLTS.
2.
Attach positive lead
of
a volt meter to a constant 12-volt source.
3.
Attach negative lead
of
a volt meter to the wire to be tested.
4.
Start the engine.
5.
Have someone press on the gas pedal slightly as you monitor the meter. If
connected to the correct wire, the voltage reading will increase as the engine's
RPM increases.
Connect the PURPLE/WHITE wire to the negative side
of
the vehicle ignition coil or
fuel injector.
9 GRAY HOOD PIN INPUT ( - )
Install a Hood Pin Switch and connect to the GRAY wire. This connection is required
for Remote Start.
Verification: This wire when connected will register ground when the
vehicle's hood is opened.
Connect the GRAY wire to the hood pin.
NOTE: Be sure to loom the wire, and seal the grommet.
10 BROWN/RED BRAKE INPUT ( + )
Locate the vehicle's brake light wire at the brake pedal mounted switch. This
connection is required for Remote Start.
Verification: This wire registers positive voltage when the brake pedal
is
pressed.
Connect the BROWN/RED wire to the vehicle's brake light wire.
2014 Voxx Electronics Corporation. All rights reserved. 7

8
1
11
VIOLET/BLACK AUX 1
This wire provides a ( - ) 200mA output capable
of
driving relays. For Control
of
optional accessories (i.e. Power Window/Sunroof, etc.).
To
activate refer to the transmitter button configuration chart. Please refer to the
selectable options for timing.
3 Pin Parking Light Harness
BLACK GROUND
Connect the BLACK wire to a solid chassis ground point using a ring terminal and
self tapping screw (not supplied). Scrape away paint from the grounding point to
ensure a good connection. The recommended grounding point is a metal surface
in
the driver's side kick panel
area:
NOTE: Do not ground the BLACK wire with any other vehicle components.
2 WHITE/RED PARKING LIGHT INPUT
3 WHITE PARKING LIGHT OUTPUT
Locate the parking light output wire at the vehicle's light switch.
Verification: This wire registers positive voltage when the parking lights are
turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
ca5154 Install rev A

6 Pin Start Harness
1 PURPLE STARTER OUTPUT ( + )
Locate the vehicle starter wire.
Verification: This wire registers voltage onlywhen the key is turned to the
START position.
Verification: The starter wire registers voltage when the key is turned to the
START position.
Connect the PURPLE wire to the vehicle starter wire.
2 RED BATTERY 12V ( +)
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage
in all positions ofthe ignition
switch.
Connect the RED wire to the constant
12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
3 ORANGE ACCESSORY 1 ( + )
Locate the vehicle's accessory wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to ACC
(Accessory) and the
ON (or RUN) position. The voltage drops out when the
key is turned to the START (or CRANK) position.
Connect the ORANGE wire to the vehicle's accessory wire.
Programmable output: IGN, ACC, Start.
4 PINK/WHITE IGNITION 2 ( + )
Locate the vehicle's 2nd ignition wire at the ignition switch (if equipped).
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position, but not the ACC (Accessory) position. The voltage does not
drop out when the key
is turned to the START (or CRANK) position.
Connect the PINK/WHITE wire to the vehicle's ignition 2 wire.
Programmable output: IGN, ACC, Start.
2014 Voxx Electronics Corporation. All rights reserved. 9

10
5 RED/WHITE BATTERY 12V (
+)
Locate 1 of the vehicle's constant 12 Volt battery wires at the ignition switch.
Verification: This wire will register ( + ) voltage in all positions of the ignition
switch.
Connect the RED/WHITE wire to the constant 12 Volt battery wire.
NOTE: Remove all fuses until all connections are made.
6 PINK IGNITION 1 ( + )
Locate the vehicle's ignition wire at the ignition switch.
Verification: This wire registers voltage when the key is turned to the ON (or
RUN) position. The voltage does not drop out when the key is turned to the
START (or CRANK) position.
Connect the PINK wire to the vehicle's Ignition wire.
This wire is also used for Ignition 1 Output.
4 Pin Alternate Harness
1 BLACK/YELLOW PULSE DURING CRANK ( - )
Locate the vehicle's second starter (crank) wire at the ignition switch. (if equipped)
Verification: This wire registers voltage only in the start (crank) position of
the ignition switch.
This wire will supply a ( - ) 200mA output and can be configured
in option
programming.
2 GREEN/WHITE PULSE AFTER SHUTDOWN ( - )
This wire will supply a ( - ) 200mA pulse after the remote start shuts down. This
is typically used to re-lock the vehicle's doors if they unlock upon remote start
shutdown. It can also be used to pulse a door pin-switch wire to prevent the vehicle's
accessories from remaining
on after remote start shutdown.
This output is configurable
in option programming.
ca5154 Install rev A

3
LT
BLUE
FACTORYARM I
PULSE
AFTER
START ( - )
This wire will supply a ( - ) 200mA pulse both upon arming the system and upon
successful completion
of
the remote start activation sequence and is typically used to
re-lock the vehicle's doors upon remote start if necessary.
This output is configurable in option programming.
4 LT GREEN/BLACK FACTORY DISARM I
PULSE BEFORE START ( - )
This wire will supply a
(-)
200mApulse both upon disarming the system and when
the remote start feature is activated. Locate the factory perimeter alarm disarm wire
from the
key
cylinder inside the drivers door.
Verification:
This wire registers ground
if
the key is turned to the unlock
position in the driver's door cylinder.
This
output
is configurable in option programming.
2 Pin Door Lock Harness
1
BLUE
UNLOCK
(-)
2
GREEN
LOCK
(-)
The
door
lock
I unlock outputs are designed to control several different types
of
systems which may require additional parts. Please review the wire and location
chart to
see
which type
of
door
lock system is in
your
vehicle. The most common
types are shown
in
the following diagrams.
These
wires
supply a ( - ) 500mAoutput.
2014 Voxx Electronics Corporation. All rights reserved.
11

12
Negative
Switching
Locks
All Door Lock and Unlock: Locate the lock
I
unlock wire at the vehicle's lock
I
unlock
switch.
Verification: These wires will register ground when the Lock and Unlock
switches are activated.
Connect the GREEN and BLUE wires shown
in
the diagram below.
Negative Locks:
Positive
Switching
Locks
GREEN ( - ) Lock Output
Vehicle Door Lock
Control Relays
BLUE ( - ) Unlock Output
All Door Lock and Unlock: Locate the lock
I
unlock wire at the vehicle's lock
I
unlock
switch.
Verification: These wires will register positive voltage when the Lock and
Unlock switches are activated.
Connect the GREEN and BLUE wires shown
in
the diagram below.
Positive Locks:
GREEN
( - ) Lock Output
ca5154 Install rev A

Reverse Polarity Locks (S-Wire Door locks)
All Door Lock and Unlock: Locate the lock I unlock wire at the vehicle's lock I unlock
switch.
Verification: These wires will rest at ground and register positive
voltage when the Lock and Unlock switches are activated.
Connect the GREEN and BLUE or BLUE/GREEN wires shown
in
the diagram below
using (2) SPOT relays (not supplied).
Reverse Polarity Locks:
GREEN ( -) Lock Output
BLUE ( -) Unlock Output
-e-----~
To Door Lock Motor
Cut
Negative Multiplexed Locks
All Door Lock and Unlock: Locate the lock I unlock wire at the vehicle's lock I unlock
switch.
Verification: This wire will show variable ground when the switch is activated.
Please consult the wire and location chart for specific resistor values for
your vehicle.
Connect the GREEN and BLUE or BLUE/GREEN wires shown
in
the diagram below
using (2) SPOT relays (not supplied).
Multiplex
Locks:
BLUE
(-
) Unlock Output
-----l~l-----+-
2014 Voxx Electronics Corporation. All rights reserved.
13

14
Positive Multiplexed Locks
All Door Lock and Unlock: Locate the lock
I
unlock wire at the vehicle's lock
I
unlock
switch.
Verification:
This wire will show variable positive voltage when the switch
is
activated. Please consult the wire and location chart for specific resistor
values for your vehicle.
Connect the GREEN and BLUE or BLUE/GREEN wires shown in the diagram below
using (2) SPOT relays (not supplied).
Multiplex Locks:
Adding Aftermarket Actuators
After installing aftermarket actuators, (not supplied). Connect the GREEN and BLUE
wires shown
in
the diagram below using (2) SPOT relays (not supplied).
86
BLUE ( - ) Unlock Output
ca5154 Install rev A

Additional Ports
Antenna I LED I Programming Port
Mount the supplied antenna/receiver
to
a clear spot
on
the vehicle's windshield that
will not block the driver's vision. A good location
is
usually high on the windshield
near the rear view mirror.
Be
careful not
to
mount the antenna/receiver
on
any
metallic window film,
as
this will effect system range. Route the antenna/receiver
cable to the control module and plug into the antenna port.
Data Bus Interface Port
This 4 pin port
is
used for Flashlogic Door Lock and Transponder Databus Interfaces
to
communicate with the vehicle's Databus. When using the
OBI
port to control the
Flashlogic Door Lock and Transponder Interface modules the following options may
be
available. Please refer to the
020
(Data to Data) function list available per vehicle
on
the tech service web site.
Tach
Input Brake Safety Shut Down
Trunk/Hatch Open Diesel Glow Plug Input
Door Lock Control Passlock I Passkey Interface
(GM
Only)
Dome Light Supervision Transponder Interface Activation
Factory Alarm Arm I Disarm Manual Arm I Disarm Inputs (factory keyless
controls system)
Telematic Interface Port
This 4 pin port
is
used for Telematic Interface accessories, such as Car Connection
Pro,
which can control some
of
the following features.
Door Lock Control Trunk Release
Sliding Doors AUX Output
Car Find Remote Start
2014 Voxx Electronics Corporation. All rights reserved.
15

16
Set Up &Programming
Transmitter Programming -Feature Bank 1
1.
Turn the ignition
ON.
2.
Press and hold the valet/override button.
3.
Within 10 seconds the system will chirp (3) three times.
4.
Press 1 button
of
each transmitter you wish to program.
5.
The system will respond with 1 chirp for each accepted transmitter.
6.
Pressing the override button at anytime during programming will advance to
the next bank.
NOTE:
The system will exit transmitter programming after 15 seconds of inactivity.
NOTE:
This system has 1 button programming which programs all channels
of
the
system.
NOTE:
The system will hold up
to
4 transmitters
in
memory, programming a 5th
transmitter will erase the oldest transmitter
in
memory.
NOTE:
This system has
PTN
-Programmed Transmitter Notification. Each time the
ignition is turned ON, the LED will flash the number
of
transmitters programmed
to
the
system.
Manual Feature Programming -Feature Bank 2 - 5
1.
Turn the ignition ON.
2.
Press and hold the valet/override button.
3.
Within 10 seconds the system will chirp (3) three times.
4.
Use the valet/override button to advance through each option bank. For
feature programming advance to Feature Bank
2,
3,
4 or
5,
which is (4)
four, (5) five, (6) six and (7) seven chirps.
5.
Use the transmitter 0 button to scroll through the selections
in
each feature
bank, the system will chirp to match the feature number.
6.
Press the transmitter @ button to change the desired feature. The LED will
flash indicating the changed feature.
Defaulting All Features:
Pressing the
CJ
button anytime while
in
any of the feature
banks will default all features and return you to feature bank 2 - 4 chirps.
NOTE:
The system will remain
in
feature programming mode as long
as
the ignition
is on, there is no time limit.
To
exit programming turn the IGNITION
OFF.
ca51541nstall rev A

2
Feature Bank 1 - 3 Chirps
Transmitter Programming
Refer to transmitter programming.
Factory Disann
Lt
Green I Black
Factory
Disarm
2nd
Unlock Factory Disann Factory Disann Factory Disann
Start Status 350mS 500mS
NOTE: On
this
model
the
Lt
Green
I
Black
Output
wire
can be
configured
in
Bank
3
or
Bank
5.
Any
changes
to
this
feature
in
Bank
5
will
override
changes
made
in
Bank
3.
2014 Voxx Electronics Corporation. All rights reserved.
17

18
ca5154 Install rev A

Feature
Bank
5 •
7 Chirps
4
Pin
Alternate
Output
Control
4 Black I Yellow Output Pulse
During
Ground While
Crank
Running Ignition
NOTE:
On
this
model
the
Lt
Green
I
Black
Output
wire
can be
configured
in
Bank
3
or
Bank
5.
Any
changes
to
this
feature
in
Bank
5
will
override
changes
made
in
Bank
3.
2014 Voxx Electronics Corporation.All rights reserved.
19

Tach Programming
The unit will not operate unless a tach signal
is
programmed
or
the tachless
option
is
turned ON.
If an attempt is made to start the vehicle via the remote start
without first programming tach, the unit will flash the parking lights 7 times indicating
tach has not been learned and stored. If the tach rate is not properly programmed
to the specific vehicle, the unit may not realize that the vehicle is running
in
certain
instances and reengage the starter motor.
The Remote Start unit will learn the tach rate of most vehicle's single coil, multiple coil
packs, or single injector.
To
learn tach:
1.
Turn the ignition key to the
ON
position.
2.
Press and release the valet/override button 3 times.
3.
Immediately turn the ignition key
OFF.
4.
Press and hold the valet/override button, then start the vehicle using
the
key.
5.
When the unit senses the tach signal, the parking lights will begin to
flash.
6.
Allow the vehicle to settle to a normal idle speed.
7.
Release the valet/program push-button switch. 1 long chirp and the
parking lights will turn
on
for 2 seconds, indicating that the learned
tach signal is stored and the unit has exited tach learn mode.
NOTE:
If the unit fails to learn tach rate due to
an
improper tach connection or a
poor tach source, the parking lights will not flash.
To
correct this situation, locate and
connect the PURPLE/WHITE wire to the proper tach signal, and then repeat the tach
learn routine.
Smart Tachless Mode
Smart Tachless Mode is available only if a tach signal has never been learned to the
system and when activated will automatically change the
Tach
Mode feature
in
option
programming to
Tach
less without the need to enter the feature programming mode.
1.
Activate the remote start. The parking lights should begin flashing 7
times indicating no tach signal has been learned.
2.
Within the 7 flash time period, press and hold the
0
button.
3.
The system will chirp 1 time indicating the system is now
in
tachless
mode.
20
ca5154 Install rev A
