Code GS290K User manual

Working Environment Temperature: -10°C - 50°C
Alarm Status Loop Current
Operating Voltage :<50mA @ 24VDC
Energy, ready, error and alarm on the device
:max 2 min.
Supply Alarm Current
There are 4 LED indicators.
:<7 mA @ 24 VDC (Led On)
The device
detects methane, butane (cylinder gas), propane, LPG and natural gases.
The detection line and the supply line must be entered into the device separately.
In case of any gas leakage, it detects the leak thanks to the sensor on the device and sends information to the control panel via the
detection line.
Standby Loop Current
: 12 to 30 VDC
The device should be installed away from areas where there is no air flow and where
food is cooked.
Opening Preparation Time
:<600µA @ 24
Detection Area Volume
Dimensions
GS290K Gas detector is designed to detect gas leaks in the environment in which it operates.
Working Environment Humidity Level: 10% to 93% Relative Humidity, Non-condensing
:max 50 m3
:90 x 90 x 38 mm
Doc: KK-GS290K-0319-TR S ayfa | 1
GS290K GAS DETECTOR WITH RELAY OUTPUT
The gas detector consists of two main parts: a body containing
the electronic card and a hanging bracket for hanging on the
wall. During assembly, the hanging apparatus is first fixed by
passing the cables through it. After the cable connections are
made to the body, the body is attached to the hanging apparatus.
If it is to detect all gases, the device must be mounted at the
breathing level of an average human.
Security technologies
www.codesectech.com
GS290K INSTALLATION GUIDE
FEATURES
INSTALLATION
The installation of the device should be done according to the type of
gas it will detect. For example, LPG (Liquified Petrolium Gas) is a type
of gas that is heavier than air, so the detector should be mounted 30-40 cm
above the floor.
GENERAL DESCRIPTIONS
Machine Translated by Google

We warrant its enclosed smoke detector to be free from defects in materials and workmanship under normal use and service for a period of three years from date of
manufacture. We make no other express warranty for this smoke detector. No agent, representative, dealer, or employee of the Company has the authority to
increase or alter the obligations or limitations of this Warranty. The Company’s obligation of this Warranty shall be limited to the repair or replacement of any part of
the smoke detector which is found to be defective in materials or workmanship under normal use and service during the two year period commencing with the date
of manufacture. After calling Code Security’s technical support number for a Return Authorization number, send defective units postage prepaid to Code Security
local representative office. Please include a note describing the malfunction and suspected cause of failure. The Company shall not be obligated to repair or replace
units which are found to be defective because of damage, unreasonable use, modifications, or alterations occurring after the date of manufacture. In no case shall
the Company be liable for any consequential or incidental damages for breach of this or any other Warranty, expressed or implied whatsoever, even if the loss or
damage is caused by the Company’s negligence or fault. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
GS290K INSTALLATION GUIDE
Security technologies
www.codesectech.com
TWO-YEAR LIMITED WARRANTY
WIRING
OPERATION AND TESTING
After the device tests are carried out, these checks must be carried out weekly.
The functionality of the device can be checked by pressing the test button on the device. 3sec. When pressed for a long
time, the alarm LED will turn on and an audible warning will be heard. It returns to normal when the hand is released from the test
button of the device.
After the installation of the device, checks and tests must be carried out.
After the device is operated, its functionality should be checked weekly. During the first
start-up, the LED pointers on it are prepared by flashing for 90 seconds. At the end of this period, the device will be ready for
detection. When the "Ready" LED turns on continuously, your device is ready.
Doc: KK-GS290K-0319-TR S ayfa | 2
The power must be cut off while making cable
connections. The cables to be used must be colored
cables. In this way, problems that may occur as a
result of faulty connections will be prevented.
First, the supply cable is connected in accordance
with its directions. If it is to be connected to the
detection line later, it is connected to the detector's
NO and COM terminals with a series resistor. The
connection diagram is seen in Figure -1-.
Figure 1-
