Cole Parmer Stir-Pak 04555-00 User manual

OPERATING MANUAL
Cole-Parmer®Stir-Pak®
General-Purpose Laboratory Mixer
Model Number
04555-00
Cole-Parmer
625 East Bunker Court
Vernon Hills, Illinois U.S.A. 60061-1844
Toll-Free: 800-323-4340
Phone: [phone]
Fax: [phone]
www.coleparmer.com
E-mail: [email protected]
2772.1A

-- 2 --
SAFETY PRECAUTIONS
•High voltages exist and are accessible in the power supply.
Contact Cole-Parmer for servicing.
•Do not operate mixers where explosive vapors or flammable
materials exist. Death or serious injury could result. Check NEC
and local codes before installing.
•Never clean the controller or mixer head while power is applied
to the system power supply.
•Use only those mixer shafts that are properly sized for the mixer
head being used. Refer to mixer head specifications for the
proper shaft diameter or range to be used. Sizes other than
those specified can cause injury to personnel or damage to
equipment and result in poor product performance and
shortened service life.
•Disconnect the AC power input line cord before connecting
the mixer cable.
•Be sure speed control is fully counterclockwise before
connecting power to the mixer.
•Exercise extreme care when adjusting mixer height and/or
position to avoid personal injury. Never make these adjustments
while the mixer shaft is rotating.
•Never insert or remove the mixer shaft/impeller while the mixer
shaft is rotating.
•Check that all cords are clear of any moving parts and not
subject to splashes or spills.
•Use care when setting the operating speed of the mixer.
Operation at high speeds in small mixing vessels could result
in hazardous splashing on the operator and equipment.
•When running the mixer at full speed and load at higher ambient
temperatures, the mixer head may get very hot to the touch.
•Keep mixer shaft as short as possible to reduce resonant
vibrations caused by the shaft flexing at higher speeds.
•The mixer head is to be used only for mixing. It is not intended
for any other purpose.

-- 3 --
INTRODUCTION
The Stir-Pak 04555-00 mixing system covered in this manual consists of a combined mixer head and analog
controller for 115VAC operation.
04555-00 STIR-PAK CONTROLLER
The variable-speed controller, Figure 1, is used to turn on and set the speed of the mixer head and provides
a 100:1 adjustment range.
Figure 1
The controller ensures accurate, dependable motor speed (mixing) control, with “soft-start” and smooth, gradual
adjustment to the speed setting. Constant speed with a 100:1 adjustment range is maintained electronically via
automatic compensation for changes in load torque demands at both high and low speeds. Built-in motor current
compensation minimizes speed drift with changes in load. Motor current limiting protects the system in case of a
locked rotor condition. Output circuit protection protects against inadvertent output shorting.
INSTALLATION AND SETUP PROCEDURES
The mixer is equipped with a 5″mounting rod. The mounting assembly is designed to be attached to
an optional mixer support stand. Components supplied as part of the mixer package include the following:
•General-purpose mixer with integrated controller and 6-ft cable
•Power supply with 6-ft line cord
•Three-jawed keyless chuck
•12″x 3/8″stainless steel shaft
•1.5″stainless steel propeller
•Support rod and double (rod) clamp

-- 4 --
Installation of Support Rod
•Never insert or remove the mixer shaft/impeller while the mixer
shaft is rotating.
Attach mixer head to support rod, as shown in figure 2, using hex drive screw and lock washer provided:
Figure 2. Mixer with Support Rod attached
Note: The mixer is now ready to be attached to a support stand or to a tank clamp (not supplied).
Recommended stands, tank clamps, and a double (rod) clamp are available through Cole-Parmer.
Part numbers are listed in the ACCESSORIES section.
Installation Using a Support Stand
1. Set up support stand in accordance with the manufacturer’s instructions.
2. Attach a double (rod) clamp to the vertical rod on the support stand and tighten clamp screw.
3. Slide rod of mixer into clamp and secure with clamp screw.
4. Select an impeller and shaft for the required operation and install as follows:
a. Place impeller on shaft and tighten set screw.
b. Slide the shaft of the stirring device into the three-jawed chuck and tighten chuck.
5. Place support stand legs around vessel. Tilt angle is adjustable from 0 to 30 degrees.
•Exercise extreme care when adjusting mixer head height
and/or position to avoid personal injury. Never make these
adjustments while the mixer shaft is rotating.
6. Position the height of the mixer head by moving the clamp up or down on the support stand.

-- 5 --
Figure 3. Typical mixer setup using a support stand
Note: The power supply can be placed on any flat surface within six feet of the mixer.
•Check that all cords are clear of any moving parts and not
subject to splashes or spills.
7. Connect the 6-ft cable between the mixer head and the power supply.
8. Check that the controller is in the “0” or off position.
9. Connect the 6-ft line cord from the power supply to the appropriate 3-wire, grounded power source.
•Be sure the SPEED control is fully counterclockwise.
The mixer is now ready to operate.

-- 6 --
STIR-PAK MIXER OPERATION
POWER Indicator Mixer Head
The green LED indicator illuminates whenever the SPEED control is turned past 1.
POWER Indicator Power Supply
The green LED indicator illuminates whenever the power supply is energized.
SPEED Control
The SPEED control precisely sets the output speed of the shaft. The controller has a range of 100:1
depending on the shaft; speed can be as low as 40 rpm or as high as 4000 rpm.
Slowly adjust the SPEED Control from the 0 or OFF position to a setting that provides the desired mixing
speed. The controller will ramp up the mixing speed to match the setting of the control.
Always return the speed control to the 0 or OFF position when mixing is complete.
•To stop the mixer in an emergency, place the SPEED control
switch in the 0 or OFF position or remove the power plug.
•Use care when setting the operating speed of the
mixer. Operation at high speeds in small mixing vessels
could result in hazardous splashing on the operator
and equipment.
•When running the mixer at full speed and load at higher
ambient temperatures, the mixer head may get very hot
to the touch.
•Never insert or remove the mixer shaft/impeller while the
mixer shaft is rotating.
Note: With new mixers, allow approximately 20 minutes run-in time to allow warm-up drift to
become minimal.
Over-Current Indicator
The green LED indicator will change to a flashing red when the mixer control senses an over-current
situation. Over-current faults can be caused by too much load (torque) on the mixer or by a locked motor
condition. The mixer will remain in a stopped position until the unit is turned off and back on again.
Over Temperature Indicator
The green LED indicator will change to a flashing amber when the mixer control senses an
over-temperature situation. An over-temperature fault is caused by long running time at high loads.
The mixer will remain in a stopped position until the unit is turned off and back on again after it
has time to cool down.

-- 7 --
SPECIFICATIONS
Direction of Rotation:
Counterclockwise as viewed from the chuck end
Speed Range:
40 to 4000 rpm
Torque Output, max:
High Speed Shaft 7 in-oz Continuous 9.5 in-oz Intermittent
Mixer Shaft Interface:
Power Supply Input Voltage:
Three-jawed type chuck with key accepts 5/16 in. to 3/8 in. diameter shaft
100 to 132 V AC, 60 Hz
Power Supply Input Current, max:
2.0 amps AC, 60 Hz
Construction:
Weight 4 lb (1.8 kg)
Enclosure rating IP24 per IEC 34-5
Environment:
Operating temperature 0 to 40°C (32 to 104°F)
Storage temperature −45 to 65°C (−49 to 149°F)
Humidity (noncondensing) 0 to 90%
Altitude Less than 2000 m
Degree of pollution Pollution degree 2 per IEC 664 (Indoor usage—lab, office)
Chemical Resistance:
Exposed material is painted aluminum, plastic, and vinyl
Compliance:
CAN/CSA C22. 2, No.61010-1 2nd Edition and CANCSA-C22.2 No. 61010-2-051-04
ANSI/UL 61010-1 2nd Edition and UL61010A-051 1st Edition

-- 8 --
MAINTENANCE AND TROUBLESHOOTING
Maintenance is limited to cleaning the unit. If a fault is detected when troubleshooting and cannot be
corrected by the suggested remedy, contact Cole-Parmer or your dealer for service.
Cleaning the Mixer/Controller System
Keep the mixer housing and controller enclosure clean with mild detergents. Never immerse nor use
excessive fluid.
•Never clean the controller or mixer head while power is
applied to the system.
Replacement Parts
No user-serviceable parts are inside of this instrument. Refer servicing to Cole-Parmer or your dealer.
The following parts are user-replaceable:
Description Part Number
Speed control knob 04552-91
Three-Jawed chuck assembly 04552-90
ACCESSORIES
The accessories listed below, used for mounting the mixer head and controller, are available from
Cole-Parmer or your dealer. Many other accessories such as shafts and impellers are also available.
Contact Cole-Parmer or your dealer for the full line of available accessories.
Part Name Part Number
Tank clamp 04552-65
Double (rod) clamp 08041-22
Shaft, 12 inches (305 mm) 04552-25
Shaft, 18 inches (457 mm) 04552-35
Shaft, 24 inches (610 mm) 04552-00
Shaft, 30 inches (762 mm) 04552-05
Propeller, 1.5 inches (38mm) 04552-45
WARRANTY
The manufacturer warrants this product to be free from significant deviations from published
specifications. If repair or adjustment is necessary within the warranty period, the problem will be
corrected at no charge if it is not due to misuse or abuse on your part as determined by the manufacturer.
Repair costs outside the warranty period, or those resulting from product misuse or abuse, may be
invoiced to you.
The warranty period for this product is noted on the Warranty Card.
PRODUCT RETURN
To limit charges and delays, contact Cole-Parmer or manufacturer for authorization and shipping
instructions before returning the product, either within or outside of the warranty period. When
returning the product, please state the reason for the return. For your protection, pack the product
carefully and insure it against possible damage or loss. Any damages resulting from improper
packaging are your responsibility.
TECHNICAL ASSISTANCE
If you have any questions about the use of this product, contact Cole-Parmer or your local dealer.
