Coleman Quickbed User manual

How to Use and Enjoy Your Coleman®
Quickbed®Airbed with
Built-in Electric Pump
4010004489 (20091021)
Please call or write us with any comments or questions
www.coleman.com
Manufactured in China
Coleman, , , and Quickbed®are registered trademarks and
Double LockTM is a trademark of The Coleman Company, Inc.
GROUNDING INSTRUCTIONS (IF APPLICABLE):
This pump should be grounded while in use to protect the operator form electric shock.
The pump is equipped with a 3-conductor cord and 3-prong grounding type plug to
fit the proper grounding type receptacle. The green (or green and yellow) conductor
in the cord is the grounding wire. Never connect the green (or green and yellow) wire
to a live terminal. This pump is for use on less than 150V, and has a plug that looks
like that shown in sketch (A). An adapter, see sketch (B), is available for connecting
sketch (A) type plugs to 2-prong receptacles. The green colored rigid ear, lug, or the
like, extending from the adapter must be connected to a permanent ground, such as a
properly grounded outlet box.
EXTENSION CORDS:
Make sure your extension cord is in good condition. When using an extension cord, be
sure to use one heavy enough to carry the current your product will draw. An undersized
cord will cause a drop in the line voltage resulting in loss of power and overheating. The
following table shows the correct size to use depending on cord length and nameplate
ampere rating. If in doubt, use the next heavier gage. The smaller the gage number, the
heavier the cord.
Volts Total length of cord in feet
120V 0-25’ 26’ -50’ 51’ -100’ 101’ -150’
Ampere rating
More Than Not More Than AWG
0-6 18 16 16 14
5-10 18 16 14 12
10-12 16 16 14 12
12-16 14 12 Not recommended
WARNINGS:
Never leave pump unattended while in use.•
Carefully inspect the pump for damage before first use and every use thereafter.•
Do not use if found damaged.
Do not change pump in any way.•
Keep pump out of reach of children.•
Do not use in or around water.•
Do not open case, electrical hazards may result. There are no user serviceable parts.•
Do not attempt to put any objects into the inflation or deflation port at any time.•
Never allow paper, debris or small articles to be sucked into pump while operating.•
Do not let your airbed come in contact with sharp, pointed objects.•
Do not use or place near heaters, open flame or other hot objects.•
For indoor use only.•
TROUBLESHOOTING
If your product seems to be leaking air, ensure that the Double LockTM Valve is properly
closed. Valve should appear depressed into itself when properly closed. Make sure the
valve is sealed around the internal stopper before closing the cap. Do this by pressing in
on the valve before closing the cap.
CLEANING
CAUTION: Before cleaning any area of this product (pump or bed) make sure the pump
is unplugged from an electrical outlet.
AIRBED
Airbed itself may be cleaned using a mild soap and water. Do not use strong chemicals
or detergents. Allow your bed to completely dry before storing.
IMPORTANT SAFETY INSTRUCTIONS:
READ AND SAVE THESE INSTRUCTIONS.•
This appliance has a polarized plug (one blade is wider than the other). To reduce the•
risk of electric shock, this plug is intended to fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact
a qualified electrician. Do not attempt to defeat this safety feature.
Unplug or disconnect the appliance from the power supply before servicing.•
WARNING• - To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With
Any Solid-State Speed Control Device.
Do not operate any fan with a damaged cord or plug. Discard fan or return to an•
authorized service facility for examination and/or repair.
Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar•
coverings. Arrange cord away from traffic area where it will not be tripped over.
DO NOT BLOCK THE AIR VENTS DURING OPERATION, THIS COULD DAMAGE THE•
MOTOR.
For products purchased in the United States:
The Coleman Company, Inc.
3600 North Hydraulic
Wichita, KS 67219 U.S.A.
1-800-835-3278 • TDD: 1-316-832-8707
For products purchased in Canada:
Sunbeam Corporation (Canada) Limited
DBA Jarden Consumer Solutions
20B Hereford Street
Brampton ON L6Y 0M1
1-800-387-6161

Control dial in
OFF position
Turn Control dial to
INFLATE position
Turn Control dial to
DEFLATE position
3. Deflate Airbed
Turn the control dial to DEFLATE.–
For storage, fold the bed and roll it up–
to store in carry bag.
2. Inflate Airbed
Connect pump to power source.–
Turn control dial to INFLATE and–
begin inflation. When bed is fully
inflated, turn dial to OFF position
To adjust firmness briefly turn control dial:
DEFLATE decreases firmness
INFLATE increases firmness
1. Position Airbed
Unroll and layout airbed in position.–
Close secondary valve as shown in–
Double LockTM Valve Operation.
Inflation/Deflation Instructions Double LockTM Valve
Operation
