Pole Assembly
–Layout shelter with doors facing desired
direction. (illus. 2)
–You will need to assemble and connect
one pole at a time to the hub.
–Start with the two 4 Section Center Poles.
The center poles will go over the sides of
the shelter, not the doors.
–Do not completely assemble poles.
a) Beginning at spring-clip end of the
Center pole, assemble all but the last
shock-corded section. The pole and
one section should curve downward.
(illus. 2)
b) Insert the spring-clip end into one
of the hub ports until it clicks into
position. (illus. 1), (illus. 2)
c) The second center pole must go
in the hub directly opposite the
first center pole.
–Assemble 5 Section Main Poles
and follow steps a and b for
each pole. (illus. 2)
15’x12’ Insta-Clip Screen House
1
When You Are Ready To Set Up Your
Shelter
–Select a level area clear of rocks,
branches and other hard or sharp objects.
–Do not set up your shelter under trees.
–For easier set up, two or more people
are recommended.
–Place fabric in center of selected location
and assemble above fabric.
ASSEMBLY PARTS
Instructions apply to Part Number 9392-152
Center Poles (2)
4 Sections
Part No. 9392-2191
Main Poles (4)
5 Sections
Part No. 9392-2201
Hub (1) Part No. 9392-2351
Illus. 2
Screen House laid out in position
with partially assembled frame
locked into hub.
Illus. 1
Poles inserted
into hub
Main Poles
4 Section Center Pole
4 Section Center Pole
Hub
Hub
Insta-Clips

2
3
PRINTED IN SRI LANKA Rev. 12/05
Things You Should Know
• Never store shelter, even for a short period of time, without drying it thoroughly and
brushing off caked dirt. Do not pack stakes or poles inside your shelter. Use
separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF. NEVER
PULL ON THE SHELTER FABRIC OR STAKE LOOP TO REMOVE STAKE.
• SHELTER POLES SHOULD NOT BE LEFT TELESCOPED TOGETHER
DURING STORAGE.
• Do not leave your shelter set-up for weeks at a time, be aware that exposure to the
ultraviolet rays of the sun can seriously damage material and/or cause it to become
discolored.
WARNING: Keep all flame and heat sources away from this shelter fabric.
This shelter meets the flammability requirements of CPAI-84. The fabric will burn if
left in continuous contact with any flame source. The application of any foreign
substance to the shelter fabric may render the flame-resistant properties ineffective.
THE COLEMAN CO., INC.
3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN SRI LANKA
