Coleman RANGEVIEW 5 9230-110 User manual

STITCH LINE
RANGEVIEWTM 5MODEL 9230-110
Before you begin
Read all instructions before set up.
• Select a level campsite clear of rocks, branches, and other hard
or sharp objects, to install your tent.
WARNING: Keep clear of overhead power lines.
• Do not set up your tent under trees.
• For best results in windy conditions, position end of tent into
the wind.
• Enlist the help of at least one other person to assist you when
it is time to assemble the tent.
Fig. 2
To Set Up Tent
1. Unfold tent and spread out on a clean, level surface with the
door facing the desired direction. Unzip door.
2. Stretch six corners of tent until
floor is taut then hammer stakes
through loops to secure. (Fig.1)
3. Assemble all interlocking shock-
corded, black and gray tent poles,
separate by size and set aside.
4. Insert black & gray poles through
sleeves in top of tent as shown. (Fig. 2)
5. Insert one end of each diagonal
black pole into pins in rear corners
of tent. (Fig. 3)
6. Go to opposite end of each pole
and gradually apply pressure to the
pole forming an arch. Insert the pin
into the pole
end at the tent
corners. Repeat
with remaining
Gray Side Poles
and long, Side-
to-Side Black
Pole. (Fig. 4)
Fig. 4
Parts and Components
Description Part Number
Main Poles, Black (2) 9230-1151
Side Poles, Gray (2) 9230-1161
Long, Side-to-Side Pole, Black (1) 9230-1171
Rainfly Pole, Black with Plastic Tips (1) 9230-1181
Rainfly 9230-1191
7. Attach frame clips along edges
of tent to all gray and black
frame poles (Fig. 5)
Fig. 5
To Attach Rainfly
1. Open rainfly and lay out flat
with seams and small pockets
facing up.
2. Insert plastic tip of black rainfly
pole into first pocket on rainfly.
(Fig. 6)
3. Insert other plastic tipped end
of rainfly pole into pocket on opposite side of rainfly.
4. Turn rainfly over and drape over tent making sure rainfly pole
is centered over the door. (Fig. 7)
NOTE: When positioned properly, seams on rainfly will
always align with
poles on tent.
Fig. 6
Fig. 8
6. Hook clips on elastic
loops of rainfly onto rings
on all corners of the tent.
(Fig. 9 & 10)
5. Secure rainfly to tent poles
with hook & loop fasteners
located on underside of rain-
fly. (Fig. 8)
To Set Up Tent (continued)
(continued on other side)
Long, Side-to-Side,
Black Pole
Gray Side Poles
(front to back)
Black Main Poles
(diagonally)
Fig. 1
Front Door of tent
Fig. 3
Fig. 10
Fig. 9
Fig. 7

The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN CHINA • PRINTED IN CHINA
© 2006 The Coleman Company, Inc.
Coleman®and are registered trademarks of The Coleman Company, Inc.
STITCH LINE
7. Tie guylines onto web
straps located at front
and back of rainfly,
stretch until taut, and
secure with stakes.
(Fig. 11,12 & 13)
Fig. 13
Guylines
Door and Window Vents
1. To use the door vent, undo
zipper from inside of tent,
then roll down flap and fasten
with toggle and fabric loop.
(Fig. 14 & 15)
2. To open rear window vent for
more ventilation, unzip, then
roll down and insert toggles
through fabric loops. (Fig. 16)
3. Door flap can be rolled back
and secured with toggle and
fabric loops. (Fig. 14 & 15)
To Attach Rainfly continued
Fig. 14
Cooler Access
The smaller zippered opening at the
side of the tent is designed for added
ventilation and easy access to your
beverage cooler.
1. To use as a vent, unzip flap to
expose screen. (Fig.17)
2. To use as a cooler access, unzip
other flap to make an avenue to
bring beverages into the tent.
(Fig.18)
Fig. 17
Fig. 18
Electrical Cord Access
1. Unzip access panel in
the lower right corner
of tent and bring in
electrical cord.
Use only UL approved
cords that are rated
for outdoor usage.
(Fig. 19) Fig. 19
Things You Should Know:
• Under certain conditions (cold weather, high humidity, etc.) condensa-
tion will form on the inside of your tent. Condensation is caused by
water vapor from your breath, perspiration, or any wet clothing inside
the tent. It is NOT LEAKAGE through the tent fabric. It can be minimized
by removing wet clothing from your tent and by providing good ventila-
tion through the tent.
• Never store tent, even for a short period of time, without drying it
thoroughly and brushing off caked dirt. Do not pack stakes or poles
inside your tent. Use a separate storage bag.
• Stakes should be removed by pulling on the stake itself. Never pull on
the tent to remove stake.
• TENT POLES SHOULD NOT BE LEFT TELESCOPED TOGETHER
DURING STORAGE.
• Do not leave your tent set-up for weeks at a time. Be aware that exposure
to ultraviolet rays from the sun can seriously damage material and/or
cause it to become discolored.
WARNING: Keep all flame and heat sources away
from this tent fabric.
This tent meets the flammability requirements of CPAI-84. The
fabric may burn if left in continuous contact with any flame source.
The application of any foreign substance to the tent fabric may
render the flame-resistant properties ineffective.
To Store
1. All metal poles and stakes must to be placed in the storage
bag to prevent damage to the fabric items placed in the
carry case.
2. Make sure tent is clean and dry before placing in carry case.
3. Remove rainfly, spread out on floor of tent, then unzip
door & vents before taking tent down for storage.
4. Neatly fold tent to width of pole storage bag, place on tent,
roll tightly, and place in carry case.
5. Store in a clean, dry area.
12/06
Fig. 12
Fig. 11
Fig. 15
Fig. 16
Door Vent
Door Flap
Window
Flap
Storage
Pocket
Door Mat
1. Unfold door mat and
secure with stakes.
(Fig. 20)
Fig. 20
