Coleman QUICKPUMP User manual

12 VDC QUICKPUMP™
UNIT INSTRUCTIONS
(Photo may vary from actual product.)
Warning
Things You Should Know
•Keepthisairpumpawayfromthereachof
children.
• DO NOT EXCEED 10 MINUTES OF
CONTINUOUS OPERATION. ALLOW
30 MINUTES OFF BETWEEN EACH
OPERATION.
•CAUTION:Donotblocktheairportalsduring
operation,thiscoulddamagethemotor.
•Carefullyinspectthepumpfordamage
beforefirstuseandeveryusethereafter.Do
notuseiffounddamaged.
•Checkthecharger,plugpinsandcableif
thesearedamageddonotuse.Ifdamaged
thewholechargermustbedisposedof
properly.
•Donotchangethepluginanyway.
•Powersupplymustbe12voltsD.C.
•Autoplugfuserating:10amps,250volts.
•Makesureyour12Velectricaloutletis
fusedwitha15-20ampfuse.
•Keepunitoutofreachofchildren.
•Donotexposetorainorsunlight.
Householduseonly.
•Thispumpisahigh-volume,low-pressure
pump.Itisintendedtoinflateitems
requiringlowpressure(suchasinflatable
beds,inflatablerafts,airmattresses,etc.).
•Forfastinflationandmaximummotor
cooling,alwaysusethelargestsizenozzle
possible.
•Caution-Riskoffireandelectricshock!Do
notoperateformorethan10minutes.Allow
30minutesoffbetween
eachoperation.
•Notforusearoundsaltwater.Saltwater
cancausethepumptocorrode.
•Thispumpisnotdesignedforcontinuous
useorforfillingtires.Extendedoperation
canoverheatanddamagethepump.
•Connectthepumponlytoacigarettelighter
socket,i.e.inacarorsportboat.
Note: Pump will not work on stem valves
or needle valves commonly used on bike
tires, basketballs, etc.
•Childrenshallnotplaywiththeappliance.
Cleaningandusermaintenanceshallnotbe
madebychildren.
•Followtheinstructionscarefullyonarticles
tobeinflated,neverexceedrecommended
pressure.Burstingitemscancause
seriousinjury.
•Donotopencase,electricalhazardsmay
result.Therearenouserserviceableparts.
•Neverlookintoorpointanyopeningtoward
youreyeswhilepumpisoperating.
•Donotattempttoputanyobjectsintothe
inflationordeflationportatanytime.
•Neverleavepumpunattendedwhileinuse.
•Donotleavepumpconnectedtothepower
supplywhennotinuse.
•Nevertwistthecord.
•Neverallowsand,paper,debrisorsmall
articlestobesuckedintopumpwhile
operating.
•Letpumpcoolbeforestoringthepumpinside
theboxafteruse.
•Usewith12VoltDCPowerOutletsonly;not
cigarettelighteroutlets.
•Donotuseunderwetconditions.Keepaway
fromwater.
•Donotattempttoputhandorfingersintothe
inflationportatalltime.

1.Tobeginination,open
externalcapandpullrmlyon
thelanyardtoextendout.This
willopeninternalyellowseal.
(Fig.1)
2.Attachadapternozzleto
inationendofpump.Insert
pumpandturnon.(Fig.2)
Note: Thepumpmaylook
differentfromyours.Itisfor illustrationpurposesonly.
3.Whenfullyinated,sealvalvebypushinginwithpump
nozzle.Thiswillsealtheinternalyellowstopperand
keepairfromescapingwhileclosingcap.Gentlytwist
adaptersleevetorightwhilebackingpumpoutofvalve.
(Fig.3)
4.Fullyremovepumpandcloseexternalcap.Valveshould
appeardepressedintoitself.(Fig.4)
5.Removeadapternozzlefrominationendandattachto
deationsideofpump.Repeatsamestepsasination.
Thiswilldrawtheairoutquickly.(Fig.5)
Inflating Standard Pinch Valve
• Attachpinchvalveadaptertoinflationendofpump.
• Insertpinchvalveadapterintopinchvalve.(Fig.6)
• Make sure tip of adapter is
extended past inner “Flap”
inside of valve. Turnpump
on.
• Whenfullyinflated,remove
pumpfromvalveandseal
valve.
Other valves
Thispumpiscompatiblewithmostvalvesoninatable
products.Ifyouhaveaninatableproductwithavalve
otherthanthosedescribedabove,rotatetheadapter
sleeveuntilnozzleendtsvalve.
Inflation and Deflation
4010045465 (ECN20060957-02)
Fig. 6
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
If Pump Will not Run
• Twistandpushpluginreceptacleforbettercontact.
• Checkreceptacleforforeignobjects.
• Checkpoweroutletfuse.
• Checkfuseinpumpplug(Fig.7).
• Replacefusewith10A/250Vstandardautomotivebuss
fuseonly.
To Replace Pump Plug Fuse
• Unscrewplugcap.
• Removeplugcap&fusecollar.
• Besurenottolosefusecollar.
• Removefuse.
• Replacefusewith10A/250Vstandardautomotivebuss
fuseonly.
• Reassembleinreverseorder.
Plugcap Fuse
Spring
Fusecollar
Fig. 7
Please call or write us with any comments or questions:
Coleman Brands Pty. Ltd.
Unit 5-6, 13 Lord Street,
Botany NSW 2019
Australia
Telephone: [phone]
Email: [email protected]
www.colemanaustralia.com.au
Made in China
© 2017 The Coleman Company, Inc. All right reserved.
Coleman®, , and are registered trademarksand
QuickPump™, Double Lock™, QuickBed™ and Wrap ‘N’ Roll™ are
trademarks of The Coleman Company, Inc.
