COLORATO CLHR-0013G User manual

ELECTRIC INFRARED HEATER
WITH GOLD HALOGEN
LAMP 1.3kW
MODEL:CLHR-0013G
www.colorato.net
INSTRUCTIONS MANUAL

1
Introd ction
This patio heater uses radiant heat to warm people and objects, and not the air in between.
This is the only method of heating that does not blow out or blow away. This heater is
specifically designed for outdoor use and is therefore weatherproof.
Important Safety Instr ctions
Before using this heater:
• Check that correct voltage is being used.
• Heater must be securely fitted in the chosen position.
• void touching front glass as much as possible.
• Heater must be disconnected from mains during any installation, cleaning or replacing
emitter.
• Heater must not be covered or obstructed during use.
• No objects should be inserted through any slots or openings of the heater.
• Heater must not be used if front glass is cracked or broken.
• Mains cables must be kept clear of heater body, which gets hot during use.
• Emitters must not be handled with bare hands when changing. ny finger marks should
be removed with soft cloth and methylated spirit.
• Do not Install less than 2.5m from the floor
Fire Risk
Heater must be mounted at least 0.9m / 3 feet away from any combustible materials –
curtains, furniture, clothes etc. When used outdoors, a waterproof socket is recommended.
Technical specification
Specification 1.3 kW Heater
Voltage (V) 220
Total Power (kW) 1.3
mps ( ) 5.9
Min. mounting height from floor 2.5m
Min. distance from ceiling 0.5m
Min. distance from side wall 1.5m
Dimensions W x H x D 400mm x 306mm x 190mm
Weight 3.7kg
Ingress protection IP54
Note: Measurements are nominal and subject to change without prior notification

2
Installation
Wiring
• This heater must be earthed
• Wired versions of this heater are fitted with 5 metres of cable and moulded plug.
• ny unwired heaters should be installed by a suitably qualified electrician, following the
instructions below*.
• RCD’s recommended where applicable.
• Outdoor connections should use weatherproof sockets / equipment, or the plug should
be connected to an indoor socket.
• Damaged cables should be replaced immediately by a suitably qualified electrician.
* Unwired versions
1. Remove terminal box cover and fit cable through compression gland.
2. Cable to be heat resistant with 2 poles and earth. Connect live and neutral wires to the
terminal block.
3. The green / yellow wire to be connected to the earth clamp.
4. Tighten compression gland nut ensuring cable is fully gripped by the gland seal.
5. Ensure that the terminal box cover is securely fitted to prevent water ingress.
Mo nting
1. Fasten “L” shaped bracket to mounting surface.
2. ttach heater to bracket using nut and bolt supplied. Ensure this is tight
3. The heater should be mounted so that the emitter is no more than 4° from the
horizontal. (as viewed from front of heater)
4. Please note minimum safe mounting distances.

3
Maintenance
If heater fails, please contact supplier in the first instance for advice.
• Before commencing any maintenance / cleaning, please disconnect power supply.
• For optimum efficiency, we recommend that, every approximate 100 hours of usage,
the heater glass and reflector should be cleaned internally with a soft cloth.
• This heater is fitted with toughened safety glass.
Replacing emitter.
1. Ensure power supply is disconnected, and heater body and emitter are cool.
2. Unscrew the 4 screws at back of casing.
3. Open front hinged cover.
4. Emitter is simply removed from spring holders by pushing it to one side and removing.
5. Refit in reverse order.
6. Contact supplier for replacement emitter.
Please Note:
Emitter sho ld not be handled with bare hands / fingers. Finger marks
sho ld be removed sing a soft, lint free cloth and methylated spirit.
Finger marks can b rn into the emitter ca sing premat re fail re.

4
1.3 kW Weatherproof Infra Red Heater
Installation Man al
1. Fix the fixed plate p to ceiling with some screws.
2. P t the longer shank into angle adj st plate and then lock with another shank.

5
3. Fix the fixed plate to angle adj st plate with a bolt.

6

7
The symbol on the prod ct means that at the end of its life, the appliance has
not to be considered a common waste. It is a special waste and has to be
demolished in specific recovery and disposal area, as prescribed by the EC Directive
2002/96/EC(WEEE). By disposing this prod ct correctly, yo can avoid negative
conseq ences for the environment and for the h man health, d e to the presence
of potentially dangero s s bstances in the prod ct.
