Coltech DF-HT5233P User manual

Important!
Read the entire instruction manual carefully
and make sure that you fully understand
it before you use the equipment. Keep the
manual for future reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den
innan du använder utrustningen. Spara
bruksanvisningen för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre deg om
at du forstår dem, før du tar produktet ibruk.
Ta vare på anvisningene for seinere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin alat
käyttää laitetta. Säilytä ohjeet myöhempää
tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette Bedienungs-
anleitung durchlesen und aufbewahren.
ENGLISHSVENSKANORSKSUOMIDEUTSCH
Värmefläkttorn | Vifteovntårn
Tornilämpöpuhallin | Heizlüfter Turmmodell
Art.no Model
36-6541 DF-HT5233P
Tower Fan Heater
Ver. 20170621
Original instructions
Bruksanvisning i original
Originalbruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung

2

3
ENGLISH
Tower Fan Heater
Art.no 36-6541 Model DF-HT5233P
Please read theentire instruction manual before using theproduct and then save
it for future reference. Wereserve theright for any errors in text or images and any
necessary changes made to technicaldata. Ifyou have any questions concerning
technical problems please contact our Customer Services.
Safety
• Thefan heater must be kept out of reach of children under 3 years of age unless
they are under constant supervision.
• Children between theages of 3 and 8 years should only switch theappliance on/
off provided that it has been placed or installed in its intended normal operating
position and they have been given supervision or instruction in thesafe use of
theappliance and understand thehazards involved.
• Children between theages of 3 and 8 years must not plug in, change thesettings
or perform any user maintenance to theappliance.
• Warning: Theproduct becomes very hot during use – Burn hazard. Particular
attention has to be given where children and vulnerable people are present.
• This product must not be used by anyone (including children) suffering from
physical or mental impairment. Thisproduct should not be used by anyone that
has not read theinstruction manual unless they have been instructed in its use by
someone who will take responsibility for their safety.
• Never let children play with thefan heater.
• Make sure that none of theventilation openings is blocked.
• Thefan heater must only be used on aflat surface.
• Always unplug theappliance when it is not in use and before cleaningit.
• Never leave thefan heater unattended when it is in operation.
• Thefan heater is only intended for normal domestic use and only in themanner
described in this instruction manual.
• Always place thefan heater at least 90cm away from combustible materials such
as furniture, curtains and bedlinen.
• Never use thefan heater if it is in any way damaged or malfunctioning. Donot use
thefan heater if themains lead or plug is damaged in anyway.
• Never place thefan heater close to abathtub, shower or swimmingpool.
• Never immerse thefan heater in water or allow water to come into contact with
theplug, thermostat or power switch.
• Ensure that dust or fluff does not accumulate inside theheater as this could
lead to overheating of theelement. Makesure that no foreign objects can enter
theventilation openings as this can present arisk of electric shock orfire.
• Children in thearea where theappliance is used must be kept under supervision.

4
ENGLISH
• Always keep thefan heater out of reach of children and invalids, do not let them
use thefan heater without supervision.
• Thefan heater should only be connected to a230 V, 50 Hz power supply.
• Thefan heater must not be placed directly below awall socket.
• Thefan heater must not be placed on or next to astove, cooker hob or heat source.
• Do not leave thefan heater switched on unattended overnight.
• Before connecting thefan heater to themains, make sure that it is turned off and
that your hands are completelydry.
• Do not use extension leads for this product. Connect it directly to amains outlet.
• Thefan heater is intended for indoor useonly.
• Thefan heater must not be taken apart or modified. Thecasing houses non-
insulated components. Contact with these can lead to fire or electricshock.
• Themains lead must be changed if damaged. Thisis to prevent therisk of electric
shock or fire and should only be carried out by themanufacturer, qualified service
facility or qualified technician.
• Make sure to route themains lead behind thefan heater so that it is not heated by
thehot air from thefan heater.
• Never use water or awet cloth to clean thehousing of thefan heater, doing so will
pose arisk of electric shock or short-circuiting.
• Thefan heater must not be used in humid environments.
• Always let thefan heater cool down before movingit.
• Thefan heater may not be controlled by anexternal timer or any type of remote control.
Warning: Donotcover. Toavoid overheating, never cover theappliance.
Product description
• Two independent PTC ceramic heating elements
• Touch-button controls
• Remote control
• Timer (1–12 hours)
• Thermostat (15–35 °C)
• Quietmotor
• Dual thermal cut-out overheating protection
• Tip-over switch
• Removable dust filter for easy cleaning

5
ENGLISH
1
2
3
4
5
2
3
6
7
8
9
10
11
12
11
12
13
Buttons and functions
1. Powerbutton
2. Protective grille
3. Exhaustport
4. Controlpanel
5. Display
6. Backpanel
7. Mainpower switch
8. Base
9. Locking ring for base
10. Handle
11. Filter grille
12. Filter
13. Mainslead

6
ENGLISH
A
B
C F
D E
A B C D E F
Touchbuttons on fan heater and remote control
A. [HEATER (1) ], upper heating element.
Touchrepeatedly to select power setting:
max– min –off.
B. [HEATER (2) ], lower heating element.
Touchrepeatedly to select power setting:
max– min –off.
C. [+] Increase temperature setting/hours for
thetimer depending onmode: temp ortimer.
D. [ – ] Decrease temperature setting/hours for
thetimer depending onmode: temp ortimer.
E. [TEMP./TIMER] Press repeatedly to select
temperature setting (°C) or timer setting (H).
F. [SWING] Press to start theoscillating motion.
Assembly
1. Takethefan heater, base and remote control out of thebox and packaging material.
2. Laythefan heater on atable so that thebottom sticks out over theedge.
3. Remove thelocking ring (9) by turning it anticlockwise.
4. Fitthebase onto thebottom of thefan heater and lock it in place by turning
thelocking ring clockwise.
5. Placethefan heater on ahard, flat and level surface.

7
ENGLISH
Remote control
1. Remove any insulation film from thebattery.
2. Insert thebattery (CR2032) into theremote control asshown.
3. Aimtheremote control at thedisplay panel on thefan heater.
Placement
• Place thefan heater on ahard and level surface.
• Never place thefan heater on soft surfaces such as beds, blankets and thickrugs.
• Do not place thefan heater in abathroom, laundry room, or close to thebath or shower.
• Do not use thefan heater in damp or dusty environments.
• Place thefan heater some distance from furniture, curtains or other flammable
objects. Makesure that thefan heater is at least 90cm from combustible materials.
Operating instructions
Display
Illuminates when both themain power switch (7) and power
button(1) are set to ON.
Illuminates when theheating elements are set to lowpower.
Illuminates when theheating elements are set to highpower.
Shows current room temperature.
Shows timer setting inhours.
Illuminates in oscillating (swing)mode.

8
ENGLISH
Modes
1. Plugthefan heater into a230V socket and set themain power switch (7) on
theback panel to ON.
2. Pressthepower button (3) on thecontrolpanel.
3. Thefan heater starts on half power and thedisplayshows:
4. Press (A) and/or (B) once if you want to increase to fullpower. Pressthebutton
again to switch thefan heateroff. Pressonce again to switch thefan heater
backon. Thefan will continue rotating for about 10 seconds after switch-off to
cool theheating elements.
5. Press (F) to start thefan heater oscillating. Pressthebutton once again to stop
theoscillation.
Setting thedesired temperature
1. Switch thefan heateron.
2. Press (E)twice. Thethermostat setting “88°C” will flash on thedisplay.
Setthedesired room temperature (15–35 °C) using (C) and (D) while
thetemperature setting is flashing. Thesetting will be saved when thetemperature
stops flashing.
3. Theheating elements will be switched off automatically when thedesired room
temperature has been reached. Thefan heater will continue to maintain theset
thermostat temperature.
Setting theduration of operation
1. Switch thefan heateron.
2. Press (E)once. Thetimer setting “88H” will flash on thedisplay. Setthedesired
operating time (1–12 hours) using (C) and (D) while thetime setting is flashing.
Thesetting will be saved when thetime stops flashing.
3. Thefan heater will switch off automatically after theset time has elapsed.
Overheating protection
Thefan heater has two built-in thermal cut-out switches. Ifthethermal cut-out switch
is triggered, theheating element is automatically shutoff. Allowthethermal cut-out
switch to cool for 5 minutes. Startthefan heater again as normal.
Tip-over switch
Thefan heater also has atip-over switch which switches thefan heater off if it
is inclined at anangle. Thefan heater can be started again once it is standing
verticallyagain.

9
ENGLISH
Responsible disposal
This symbol indicates that this product should not be disposed of with
general householdwaste. Thisapplies throughout theentire EU. Inorder
to prevent any harm to theenvironment or health hazards caused by
incorrect waste disposal, theproduct must be handed in for recycling
so that thematerial can be disposed of in aresponsible manner.
Whenrecycling your product, take it to your local collection facility or
contact theplace of purchase. Theywill ensure that theproduct is
disposed of in anenvironmentally sound manner.
Care and maintenance
• Switch thefan heater off, disconnect it from thepower supply and let it cool before
cleaning.
• Clean theproduct using asoftcloth.
• Use avacuum cleaner to remove any fluff from theinlet and exhaust openings.
• If thefan heater is not to be used for along time it should be covered to keep it
clean and free of dust andfluff. Storethefan heater in its original box together with
theinstruction manual in acool, dryplace.
Cleaning thedust lters
Theair filters should be cleaned everymonth.
1. Remove thefilter grilles (11).
2. Remove thedust filters (12) and soak
them iwater for afew minutes.
3. Wringout thefilters and let them dry
before refittingthem.

10
ENGLISH
Troubleshooting
Thefan heater does notstart.
• Is theplug securely connected to thewall socket?
• Make sure that theelectrical socket islive.
• Is thepower switch on theback panel set to ON?
• Has thethermostat turned off thefan heater? Checkthetemperature setting.
Thefan starts but stops after ashorttime:
• Thetemperature setting is lower than theroom temperature.
Checkthetemperature setting.
Specifications
Supply voltage 220–240V, 50/60 Hz
Power 1200W/2000W
Airspeed ≥ 1.3m/s
Oscillation 76°
Timer 1–12hours
Noiselevel ≤ 50 dB (at adistance of 1 m)
Tip-over switch Cutspower when at anangle of 40 ± 10°
Weight 4.3kg
Height 84cm (with base)
Remote control battery 1×CR2032, 3V (included)
