Columbia Medical 5085 User manual

PVC High Back Bariatric ShowerPVC High Back Bariatric Shower
Commode Chair InstructionsCommode Chair Instructions
Model #5085Model #5085
Thank you for Choosing ColumbiaThank you for Choosing Columbia
Your Columbia PVC High Back Bariatric Shower/Commode Chair has been built to the highest standards of
quality to ensure years of superior service. Please take the time to read this informative instruction guide
and pay particular attention to the safety information provided. Thank you again for choosing Columbia!
Your Columbia PVC High Back Bariatric Shower/Commode Chair has been built to the highest standards of
quality to ensure years of superior service. Please take the time to read this informative instruction guide
and pay particular attention to the safety information provided. Thank you again for choosing Columbia!
Important Safety InstructionsImportant Safety Instructions
When using your, PVC High Back Bariatric Shower/Commode Chair always take basic safety precautions to
reduce the risk of injury to persons.
When using your, PVC High Back Bariatric Shower/Commode Chair always take basic safety precautions to
reduce the risk of injury to persons.
1. Read and understand all instructions.1. Read and understand all instructions.
2. Determine, with a physician or therapist, the suitability of this product for the intended user.2. Determine, with a physician or therapist, the suitability of this product for the intended user.
3. Do not leave user unattended unless you have determined that their abilities and requirements are
such that it poses no safety risk to leave them unsupervised.
3. Do not leave user unattended unless you have determined that their abilities and requirements are
such that it poses no safety risk to leave them unsupervised.
4. Place your PVC High Back Bariatric Shower/Commode Chair on a surface level; do not use near steps or
other hazards.
4. Place your PVC High Back Bariatric Shower/Commode Chair on a surface level; do not use near steps or
other hazards.
5. Keep your PVC High Back Bariatric Shower/Commode Chair clean and sanitary.5. Keep your PVC High Back Bariatric Shower/Commode Chair clean and sanitary.
6. Check regularly that all bolts, casters, caster locks engage properly and other parts are tight and in
good working order.
6. Check regularly that all bolts, casters, caster locks engage properly and other parts are tight and in
good working order.
7. Be sure that all caster locks are engaged before transferring a patient in or out of unit. It is further
suggested that all transfers be performed by at least two (2) care givers to ensure safety.
7. Be sure that all caster locks are engaged before transferring a patient in or out of unit. It is further
suggested that all transfers be performed by at least two (2) care givers to ensure safety.
8. Requires two (2) persons to adjust the height of your PVC High Back Bariatric Shower/Commode Chair,
Do Not
8. Requires two (2) persons to adjust the height of your PVC High Back Bariatric Shower/Commode Chair,
Do Not attempt to adjust without the proper help.
Save These Instructions
Assembly of PVC High Back Bariatric Shower/Commode Chair
Model #5085 is shipped with Base completely assembled, Backrest is shipped disassembled with Cover and
Commode Pail is strapped down underneath Base unit.
Base Backrest Commode Pail
C0000-10-27 Rev. A (Updated 9/11/07)
1

#5085 High Back Bariatric Shower/Commode Chair Instructions
Adjusting Height for Shower/Commode Chair
When adjusting the Height of your PVC High Back Bariatric Shower/Commode Chair, it will require two (2)
persons.
1. Remove all eight (8) Quick-Release pins from Base unit, (4) in the front and (4) in the back.
2. Once all eight (8) Quick-Release pins are removed, raise the Base to desired height.
3. Re-install all eight (8) Quick-Release pins, ensuring that Quick-release pin is properly locked.
Shown with Optional Footrests Model
#5000-P06
Installing Backrest
1. Install your Backrest Frame into Base, ensuring that the Backrest is inserted all the way down into
frame.
•Make sure back cover is properly fitted, between side frame tubes.
•Lace all four (4) back holding straps on back of chair.
2. Commode Pail is located underneath Chair. To remove Commode Pail, unsnap strap from chair and pull
pail out. Reverse procedure to re-install pail.
3. If you purchased the Footrests option with your Bariatric Chair, use the following procedures for
correct usage:
•Once the patient is seated, pull out the footrest platforms
•Your footrests platform should not be used as a step. This is a Safety Hazard, and may
cause damage to your footrests.
C0000-10-27 Rev. A (Updated: 9/11/07)
2

#5085 High Back Bariatric Shower/Commode Chair Instructions
Caster Lock Operations
Your Bariatric Shower/Commode Chair has six (6) 4” Deluxe Casters. Four (4) Deluxe Casters have the
locking mechanism.
1. To engage caster Lock, place foot on caster lock lever and push down.
2. To disengage caster Lock, push up on caster lock lever.
3. Be sure that all caster Locks are engaged before transferring a patient in or out of unit. It is further
suggested that all transfers be performed by at least two (2) care givers to insure safety.
LOCK
UNLOCK
LOCK
COLUMBIA MEDICAL MFG., LLC warrants this product to be free of defects in material and
workmanship. Our obligation under this warranty is limited to repair or replacement of any part
or entire unit at our option for a period of one year from date of delivery to the original purchaser.
The warranty does not include cost of inconvenience, property damage, misuse, abuse, accident or
similar incidents. The warranty will not apply if product has been tampered with or repaired by
unauthorized individuals. This warranty gives you specific rights which vary from state to state.
C0000-10-27 Rev. A (Updated: 9/11/07)
3
