Sharp FU-NC01 User manual

FU-NC01
“Plasmacluster” and “Device of a cluster of
grapes” are trademarks of Sharp Corporation.
* The number in this technology mark
indicates an approximate number of ions
supplied into air of 1 cm3, which is measured
around the center of a room applicable floor
area (at 1.2 m height above the floor) when
the product is placed on the floor and is
operating with MAX mode.
ENGLISH
中文
AIR PURIFIER
OPERATION MANUAL
空氣清新機
使用說明書
FU-NC01A_EN.indd 1FU-NC01A_EN.indd 1 2021/06/24 13:05:032021/06/24 13:05:03

ENGLISH
Thank you for purchasing this SHARP Air Purifier.
Please read this manual carefully before using the product.
This manual should be kept in a safe place for handy reference.
IMPORTANT SAFETY INSTRUCTIONS ......................................... 1
PART NAMES .................................................................................. 4
FILTER INSTALLATION .................................................................. 6
CARE AND MAINTENANCE ........................................................... 7
FILTER REPLACEMENT................................................................. 8
TROUBLESHOOTING..................................................................... 9
SPECIFICATIONS............................................................................ 10
The air purifier draws in room air through the Air Inlet, circulates it through a
Pre-Filter, a Two in one dust collection and deodorizing Filter inside the product,
and then discharges it through the Air Outlet. The Two in one dust collection
and deodorizing Filter can remove dust particles and absorb odors as they pass
through the filter.
Some odors absorbed by the filters will break down over time, causing additional
odors. Depending on usage conditions, and especially if the product is used in
environments significantly more severe than a normal household, these odors
may become noticeable sooner than expected. If these odors persist, replace the
filters.
NOTE
• The air purifier is designed to remove air-suspended dust and the odors.
The air purifier is not designed to remove harmful gases such as carbon
monoxide contained in cigarette smoke.
The air purifier may not completely remove an odor if the source of the
odor is still present.
Please read before operating your new Air Purifier
CONTENTS
FU-NC01A_EN.indd 2FU-NC01A_EN.indd 2 2021/06/24 13:05:032021/06/24 13:05:03

EN-1
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
Always follow basic safety precautions when using electrical
appliances, including the following:
WARNING – Always observe the following to reduce the risk of
electrical shock, fire, or injury:
• Read all instructions before using the product.
• Use only a 220 - 240 volt outlet.
• Use only the AC adapter of the product.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure they do not play
with the appliance.
• If the power cord is damaged, it must be replaced by
the manufacturer, its service agent, a Sharp authorized
Service Center or similarly qualified persons in order to
avoid a hazard. Contact the nearest Service Center for any
problems, adjustments, or repairs.
• Do not repair or disassemble the product yourself.
• Be sure to remove the AC adapter before performing
maintenance, when removing and attaching and replacing
the filter and when not using for a long time. Failure to do
so can cause a short circuit resulting in electrical shock or
fire.
• Do not use the product if the power cord or AC adapter is
damaged or if the connection to the wall outlet is loose.
• Periodically remove dust from the AC adapter.
• Do not insert fingers or foreign objects into the Air Inlet or Air
Outlet.
• When removing the AC adapter, always hold the AC adapter
and never pull on the cord. Failure to do so can cause a short
circuit resulting in electrical shock or fire.
• Be careful not to damage the power cord. Failure to do so can
cause electric shock, heat generation, or fire.
FU-NC01A_EN.indd 1FU-NC01A_EN.indd 1 2021/06/24 13:05:032021/06/24 13:05:03

EN-2
• Do not remove the AC adapter when your hands are wet.
• Do not use this product near gas appliances or fireplaces.
When the product is operated with gas appliances in same
room, Ventilate a room periodically, otherwise it may cause
Carbon monoxide poisoning.
• Do not operate the product in rooms where aerosol insecticides
are present. Do not operate the product in rooms where there
is oily residue, incense, sparks from lit cigarettes, or chemical
fumes in the air.
• Keep the product away from water. Do not operate the product
in places where it may get wet, such as a bathroom.
• Do not expose the product to water. Doing so can cause a short
circuit or electrical shock.
• Be cautious when cleaning the product. Strong corrosive
cleansers can damage the exterior.
NOTE – What to do if the product interferes with radio or TV
reception
If the air purifier interferes with radio or television reception, try
one or more of the following measures:
• Adjust or reposition the receiving antenna.
• Increase the distance between the product and the radio or TV.
• Connect the equipment into an outlet on a circuit different from
that of the radio or TV receiver.
• Consult the dealer or a qualified radio or TV technician.
CAUTIONS CONCERNING OPERATION
• Do not block the Air Inlet or Air Outlet.
• Do not place the product near or on hot objects, such as stoves
or heaters, or where it may come into contact with steam.
• Always operate the product in an upright position.
• Do not move the product when it is in operation.
• If the product is on easily damaged flooring, an uneven surface,
or thick-piled carpet, lift it up when moving.
• Do not operate the product without the filters properly installed.
• Do not wash and reuse the Two in one dust collection and
deodorizing Filter. Doing so will not improve filter performance
and can also cause electric shock or operating malfunctions.
FU-NC01A_EN.indd 2FU-NC01A_EN.indd 2 2021/06/24 13:05:032021/06/24 13:05:03

EN-3
ENGLISH
• Clean the exterior with a soft cloth only. Do not use volatile
fluids or detergents. The product surface may be damaged or
cracked with Benzine paint thinner, alcohol or polishing powder.
• Do not scrub the Pre-Filter hard during its maintenance.
• Do not use the AC adapter for other products.
• Do not get or lean on the product.
INSTALLATION GUIDELINES
• Avoid locations where furniture, fabrics, or other objects can
come in contact with the product and interfere with the Air Inlet
and Air Outlet.
• Avoid locations where the product is exposed to condensation
or drastic changes in temperature. Appropriate room
temperature is between 0 – 35 ºC.
• Place the product on a level and stable surface with sufficient
air circulation. When placed on heavy carpet, the product may
vibrate slightly.
• Avoid locations with grease, oil smoke, alcohol, hypochlorous
acid, or chemicals in the air. Doing so can cause the product
exterior to crack.
• The surrounding walls and floor of the product may become
dirty over time. When using the product for an extended period
of time at the same location, periodically clean the walls and
floor adjacent to it.
• Do not use fluororesin or silicone-containing products
(cosmetics, hair care products, etc.,) near the product. The
fluororesin or silicone could get stuck inside the product,
preventing it from producing Plasmacluster ions.
FILTER GUIDELINES
• Follow the instructions in this manual for proper filter care and
maintenance.
FU-NC01A_EN.indd 3FU-NC01A_EN.indd 3 2021/06/24 13:05:032021/06/24 13:05:03

EN-4
PART NAMES
1 2
3
4
8
9
10
NOTE
• When using for the first time, please
remove the plastic bag from the Two in
one dust collection and deodorizing Filter.
(Page 6)
5
6
7
BACK SIDE
11
1Operation Panel 7Bottom Cover
2Night Light 8Power Code
3Air Outlet
9
Power Lamp (Blue)
• The lamp lights up while the AC
adapter is connected to the outlet.
4Air Inlet
5Two in one dust collection and
deodorizing Filter 10 AC Adapter
6Pre-Filter 11 AC Adapter Terminal
FU-NC01A_EN.indd 4FU-NC01A_EN.indd 4 2021/06/24 13:05:062021/06/24 13:05:06

EN-5
ENGLISH
NOTE
• In LOW mode, the lamps on the Operation Panel lights up dimly.
NOTE
• Plasmacluster ion will become
always ON when after
disconnecting and connecting
the AC adapter again.
OPERATION PANEL
POWER ON/OFF AND SETTING MODE
NIGHT LIGHT ON/OFF
PLASMACLUSTER ION ON/OFF
1Power ON/OFF and Mode Button
2Night Light Button
3Plasmacluster Ion Lamp (Blue)
4Mode Lamps (White)
1
3
2
4
LOW MED MAX POWER
OFF
ON
ON
OFF
OFF
Press for 3 sec.
The rear
lights up.
FU-NC01A_EN.indd 5FU-NC01A_EN.indd 5 2021/06/24 13:05:192021/06/24 13:05:19

EN-6
FILTER INSTALLATION
1
Turn the product upside
down.
2
Remove the Bottom Cover.
1
2
3
Remove the Pre-Filter ( 1)
and the Two in one dust
collection and deodorizing
Filter ( 2).
1
2
4
Remove the Plastic Bag.
5
Attach the Two in one dust
collection and deodorizing
Filter.
Tag
6
Attach the Pre-Filter.
1
2
Click
7
Attach the Bottom Cover.
1
2
Click
Always be sure to remove
the AC Adapter from the
wall outlet.
FU-NC01A_EN.indd 6FU-NC01A_EN.indd 6 2021/06/24 13:05:282021/06/24 13:05:28

EN-7
ENGLISH
NOTE About Pre-Filter
• Do not apply excessive pressure when scrubbing the Pre-Filter.
• How to clean hard to remove dirt.
1. Add a small amount of kitchen detergent to water and soak
for about 10 minutes.
2. Rinse off the kitchen detergent with clean water.
3. Completely dry the filter in a well ventilated area.
CARE AND MAINTENANCE
Always be sure to remove
the AC Adapter from the
wall outlet.
MAIN BODY
AIR INLET / PRE-FILTER
Wipe with a dry, soft cloth.
Remove the dust gently with a cleaning tool such as a vacuum
cleaner.
1 2
Once a month
When it gets dirty
Pre-Filter
Bottom Cover
FU-NC01A_EN.indd 7FU-NC01A_EN.indd 7 2021/06/24 13:05:342021/06/24 13:05:34

EN-8
Always be sure to remove
the AC Adapter from the
wall outlet.
Two in one dust collection and deodorizing Filter
Clean only the tagged surface. Do not
clean up the opposite surface. The filter
is fragile, so be careful not to give too
much pressure.
Remove the dust on the filter. NOTE
• Do not wash the filter. Do not
expose to sunlight. (Otherwise
these filter may lose efficacy.)
• Some odors absorbed by the filter
will break down over time, causing
additional odors. Depending on
usage conditions, and especially if
the product is used in environments
significantly more severe than a
normal household, these odors
may become noticeable sooner
than expected. Replace the filter in
those cases or if dust is unable to be
removed after maintenance.
FILTER REPLACEMENT
LIFE OF FILTER
Filter life varies depending on the room
environment, usage conditions, and
location of the product.
Lifespan of the Two in one dust collection
and deodorizing Filter and replacement
suggestions are based on purifying a
room in which 5 cigarettes are smoked
per day and the product’s dust collection
and deodorizing performance has
declined to half the level of a new filter.
We recommend replacing the filter
more frequently if the product is used
in conditions significantly more severe
(PM2.5 etc.,) than a normal household.
• The life of the Two in one dust
collection and deodorizing Filter is
about 1 year after opening.
REPLACEMENT FILTER
MODEL
Consult your dealer when purchasing a
replacement filter.
Two in one dust collection and
deodorizing Filter (1 unit)
FZ-N15SFE
Dispose of used filters according to local
laws and regulations.
material:
• Polypropylene
• Polyethylene
• Activated carbon
Whenever dust accumulates, or when odor emanates from the air outlet.
Tag
Two in one dust
collection and
deodorizing
Filter
FU-NC01A_EN.indd 8FU-NC01A_EN.indd 8 2021/06/24 13:05:372021/06/24 13:05:37

EN-9
ENGLISH
TROUBLESHOOTING
Before calling for service, please review the Troubleshooting list below, since the
problem may not be the product malfunction.
It doesn’t operate.
• Check if the AC adapter is correctly connected to the product and the outlet.
(It may take some time until the operation starts when after connecting the AC
adapter.)
Odor and smoke persists.
• Is the filter still in the plastic bag? Take out the filter.
• Has the wind from the Air Outlet been weakened?
In that case, clean the Bottom Cover, the Pre-Filter and tthe Two in one dust
collection and deodorizing Filter.
Air discharged from the product has an odor.
• Check to see if the filters are extremely dirty.
• Clean or replace the filters.
Smell from a new product and/or filter.
• Immediately after removing the plastic bag, a slight odor may occur. This odor is not
harmful for filter performance or human exposure.
The Plasmacluster Ion Lamp is turned off.
• When the Plasmacluster Ion is set to “OFF”, the Lamp automatically turns off. If you
do not want the light to be off, set the Plasmacluster Ion to “ON” setting. (Page 5)
The LOW mode Lamp is flashing.
• Unplug the product, wait one minute, and then plug the product in again.
If the flashing repeats periodically, please contact the customer service.
FU-NC01A_EN.indd 9FU-NC01A_EN.indd 9 2021/06/24 13:05:372021/06/24 13:05:37

EN-10
SPECIFICATIONS
Model FU-NC01
Power supply AC adapter
Rated input AC 100 - 240 V 50 - 60 Hz 1 A
Rated outlet DC 24 V 1.5 A
Fan Speed Adjustment MAX MED LOW
Fan Speed (m3/ hour) 90 48 18
Rated Power (W)
(Value when the Night Light is off.)
20
(20)
8.6
(8.1)
3.0
(2.5)
Noise Level (dBA) *148 34 22
Standby power (W) Approx. 0.5
Recommended Room Size (m2) *2~ 10
High density Plasmacluster ion
recommended room size (m2) *3~ 10
Filter Type Two in one dust collection and deodorizing
Cord Length (m) Approx. 1.8
Dimensions (mm) 190 (Φ) × 330 (H)
Weight (kg) Approx. 2.0
*1 • Noise level is measured based on the JEM1467 standard of the Japan Electrical
Manufactures’ Association.
*2 • The recommended room size is appropriate for operating the product of maximum fan speed.
• The recommended room size is an area in which a given amount of dust particles can be
removed in 30 minutes (according to JEM1467).
*3 • Room size in which approximately 7000 ions per cubic centimeter can be measured in the
center of the room, at a height of approximately 1.2 meters from the floor, when the product is
placed on the floor and is running at MAX mode.
Standby Power
When the product’s AC adapter is inserted in a wall outlet it consumes standby power in order
to operate electrical circuits.
To conserve energy, unplug the AC adapter when the product is not in use.
FU-NC01A_EN.indd 10FU-NC01A_EN.indd 10 2021/06/24 13:05:372021/06/24 13:05:37

EN-11
ENGLISH
MEMO
FU-NC01A_EN.indd 11FU-NC01A_EN.indd 11 2021/06/24 13:05:372021/06/24 13:05:37

感謝您購買 SHARP 空氣清新機。
在使用空氣清新機前， 請詳細閱讀本使用說明書。
請將本使用說明書放在安全的地方， 方便查閱。
重要安全事項........................................................................................... 1
各部份名稱............................................................................................... 4
安裝過濾網............................................................................................... 6
保養與清潔............................................................................................... 7
更換過濾網............................................................................................... 8
維修前的檢查事項 ................................................................................... 9
規格........................................................................................................ 封底
空氣清新機經吸風口吸入室內空氣， 使其通過主機內的前置過濾網和集塵 ・ 脫
臭二合一過濾網， 然後從出風口排出。 當空氣通過時， 集塵 ・ 脫臭二合一過濾
網能夠去除灰塵粒子。 當異味成分經過集塵 ・ 脫臭二合一過濾網時， 便逐步被
其吸收。
由於空氣清新機是收集房間整體的灰塵和異味成分的機器。 視使用情況， 尤其
是倘若主機在較普通家庭的空氣更嚴重的環境中使用， 該等異味可能比預期更加
明顯。 如果保養還是無法去除異味時， 請對集塵・脫臭二合一過濾網進行更換。
操作您的新空氣清新機之前， 請詳細閱讀本使用說明書
注意
• 本空氣清新機用於去除空氣中懸浮的灰塵和異味。
而不能去除有害氣體 ( 如 : 香菸煙霧中的一氧化碳 )。
如果異味源仍然存在， 空氣清新機可能無法徹底去除異味。
中文
目錄
FU-NC01A_CT.indd 2FU-NC01A_CT.indd 2 2021/06/24 13:01:522021/06/24 13:01:52

ZH-1
中文
重要安全事項
使用電器時， 必須遵守基本安全預防措施， 包括以下各方面 ：
警告 – 為了減少電擊、 火災或受傷等危險 :
• 在使用主機之前請閱讀所有注意事項。
• 只能使用 220 - 240 V 插座。
• 請使用本產品專用的 AC 電源供應器。
• 除非得到監護人或負責其安全人士的適當監督或指導，否則，本
機不適合身體機能或心智能力退化者，或缺乏操作經驗和知識的
人士 （包括兒童） 使用。兒童應受到適當的監管，以確保不會
以此機器作玩具。
• 如果電源線損壞，必須由製造商或代理商，台灣夏普公司特約維
修機構或具有同等資格的人員負責更換，以免發生危險。
若本機出現任何問題、需要調校或修理，請聯絡台灣夏普客戶服
務中心。
• 請勿自行維修或拆解本產品的主機。
• 於維修前，移除及連接及更換過濾器以及長期不使用時，確保移
除 AC 電源供應器。否則可能導致電擊或因短路引起火災。
• 如果電源線或 AC 電源供應器已經損壞，或者牆上的電源插座已
鬆脫，請勿使用主機。
• 定期清除 AC 電源供應器上的灰塵。
• 請勿將手指或異物插入吸風口或出風口。
• 當拔掉 AC 電源供應器時，必須緊握 AC 電源供應器插頭而不要
拉扯電線。否則可能導致電擊或因短路引起火災。
• 小心不要損壞電源線，以免導致觸電、過熱或起火。
• 手濕時請勿拔掉 AC 電源供應器。
• 請勿在氣體設備或壁爐附近使用主機。當將產品用於內有燃氣器
具的同一室內時，應定時給房間通風，否則可能造成一氧化碳中
毒。
• 當使用噴霧殺蟲劑時請勿使用主機。若空氣中有油性殘留物、薰
香、香菸火花或化學煙霧，則不得在室內操作主機。
• 請保持主機遠離水源。浴室等可能被淋濕的地方也不要使用主
機。
• 主機請勿碰水。碰水是產生觸電及短路的原因。
• 清潔主機時請注意，腐蝕性清潔劑可能會損壞外殼。
FU-NC01A_CT.indd 1FU-NC01A_CT.indd 1 2021/06/24 13:01:532021/06/24 13:01:53

ZH-2
注意 – 收音機或電視干擾
如果本空氣清新機對收音機或電視接收造成干擾， 請嘗試以下列其
中一項或多項措施修正干擾 ：
• 重新調整或重新放置接收天線。
• 增加主機與收音機／電視機接收器之間的距離。
• 將主機與接收器連接至不同的電源插座或供電線路。
• 如需協助，請聯絡經銷商或專業的收音機 / 電視技術人員。
操作注意事項
• 請勿堵塞吸風口或出風口。
• 不要靠近或在熱源物體上 （如爐灶或暖爐式可能接觸到蒸汽的場
所） 使用主機。
• 對主機進行操作時，請始終保持其處於直立狀態。
• 當主機處於運行狀態時，切勿對其進行移動。
• 在榻榻米墊、易損的地面、不平坦處及較厚地毯上要將設備抬起
來移動。
• 正確安裝過濾網之前切勿運行主機。
• 切勿用水清洗和重新使用集塵 ・ 脫臭二合一過濾網。
這樣做不僅無法改善過濾網的性能，而且可能會導致觸電或機件
故障的發生。
• 僅可使用柔軟的布對主機外部進行清潔。切勿使用揮發性液體或
清潔劑。主機表面可能被汽油、油漆稀釋劑或酒精、拋光粉損壞
或破裂。
• 保養與清潔時，不得用力擦洗前置過濾網。
• 本產品專用的 AC 電源供應器請勿使用在其他產品上。
• 主機上方請勿放置其他物品。
FU-NC01A_CT.indd 2FU-NC01A_CT.indd 2 2021/06/24 13:01:532021/06/24 13:01:53

ZH-3
中文
安裝指南
• 避免在有可能與傢俱、織物或其他物品接觸的位置使用主機，否
則可能無法保證吸風口或出風口的通暢。
• 請勿安裝在由於溫度劇烈變化而導致主機直接暴露於冷凝環境的
地方。只適宜在 0 - 35 ℃之間的室溫下使用。
• 安裝必須穩固且通風良好。建議放置在室內中間的位置，空氣清
淨的效果最佳。把主機放置在鋪有厚地毯的地方時，可能導致主
機微微震動。
• 避免在會產生油脂、 油煙、 酒精、 次氯酸或化學物質的場所使
用。否則可能會導致主機表面發生裂開。
• 請將主機遠離牆壁或床，經過一段時間後正對吹出口後方的牆壁
可能會變髒。在相同位置長期使用主機時，請定期清潔附近的牆
壁。
• 勿在自動除菌離子產生器附近，使用含氟樹脂或含矽配方化粧品
或護髮產品等。當主機內附著氟樹脂或矽之後，有可能不再產生
自動除菌離子。
過濾網指南
• 遵照說明書指示，了解正確保養和清潔過濾網的方法。
FU-NC01A_CT.indd 3FU-NC01A_CT.indd 3 2021/06/24 13:01:532021/06/24 13:01:53

ZH-4
各部份名稱
1 2
3
4
8
9
10
注意
• 使用本機前， 須將集塵 ・ 脫臭二合一過
濾網從塑膠袋中取出。 ( 請參考第 6 頁 )
5
6
7
背面
11
1操作面板 7底蓋
2夜燈 8電源線
3出風口 9電源燈 (藍)
• AC 電源供應器插入電源插座後燈亮。
4吸風口
5集塵 ・ 脫臭二合一過濾網 10 AC 電源供應器
6前置過濾網 11 AC 電源供應器連接端子
FU-NC01A_CT.indd 4FU-NC01A_CT.indd 4 2021/06/24 13:01:562021/06/24 13:01:56

ZH-5
中文
注意
• 風量 「弱」 模式時操作面板燈光會變暗。
注意
• 自動除菌離子運轉設定為關閉
時， 當 AC 電源供應器拔除再插
上後自動除菌離子運轉會自動設
定為打開。
操作面板
電源開 / 關和風量切換
夜燈 開 / 關
自動除菌離子運轉 開 / 關
1電源開 / 關和風量切換按鈕
2夜燈按鈕
3自動除菌離子運轉指示燈 (藍)
4風量指示燈 (白)
1
3
2
4
弱 中 強 停止
開燈
開
關燈
關
長按 3 秒
背面亮起。
FU-NC01A_CT.indd 5FU-NC01A_CT.indd 5 2021/06/24 13:02:072021/06/24 13:02:07

ZH-6
1
倒放機台。
2
取出底蓋。
1
2
底蓋
3
1 取下前置過濾網。
2 取出集塵 ・ 脫臭二合一過
濾網。
2
1
前置過濾網
集塵 ・ 脫臭
二合一過濾網
安裝過濾網
4
從塑膠袋中取出集塵 ・ 脫臭
二合一過濾網。
5
安裝集塵 ・ 脫臭二合一過濾
網。
標籤
6
安裝前置過濾網。
1
2
喀噠聲
7
安裝底蓋。
1
2
喀噠聲
確保將 AC 電源供應器從
牆壁的插座上拔出。
FU-NC01A_CT.indd 6FU-NC01A_CT.indd 6 2021/06/24 13:02:162021/06/24 13:02:16
