Combi Ninna Nanna F-180 User manual

Instruction Manual
For safety of your children, read this
instruction manual carefully and use
the baby carrier accordingly. After
reading please keep this instruction
manual for future reference.
Please also attach this user guide in
case the carrier is to be transferred to
others to use.
1 way 2 way
3 way 4 way

1
Before use
Before use
Thank you for purchasing Ninna Nanna 4-way 8-style baby soft carrier. This product is a
general single-baby carrier designed for cradling or back-carrying the baby during shopping
or outdoor activities. Before use, please read "naming of components" in page 6 and check
out the parts.
•This product can be applied in several carrying positions including cradling, face-
in cuddling, face-out cuddling and back carrying.
This product is suitable for a child who meets the following conditions
Using styles Age reference Weight
Way 1: Cradle position
From birth until neck muscle
has developed (around 4 months old) Below7.0kg
Way 2: Face-in cuddling position
style 1
style 2
style 3
style 4
After neck muscle has developed.
(until around 12 months old)
Below11.3kg
After baby can sit straight
(until around 12 months old)
style 2-3
Way 3 : Face-out cuddling position
style 4
style 5
style 6
style 5
style 6
After neck muscle has developed.
(until around 12 months old)
After baby can sit straight
(until around 12 months old)
Below11.3kg
Way 4 : Back carrying position
style 7
style 8
After neck muscle has developed.
(until around 30 months old) Below14.9kg
The waist size of user should not exceed 110cm.
The product may not be applicable to particular baby with extraordinary body size and having heavy coat in
winter. Please choose appropriate clothes to your baby accordingly.
new born neck muscle
has developed sit straight 12 months 30 months

Before use
For your safety
Caution about safety
The caution items mentioned here are about how to use the product properly and safely
so as to prevent any possible injury to user and baby and any damage to the product.
Moreover, the caution items are categorized according to the degree of injury and damage
to the product and are indicated as "Warning" and "Caution" respectively.
Caution and using conditions mentioned below are very important. Please read and
follow accordingly.
WARNING Improper operation may
directly cause death or
severe damage.
Improper operation may
cause injury or damage to
the product.
CAUTION
Details of the caution item are written inside the frame (page 2-4)
This sign indicates there is warning or caution item mentioned.
2
WARNING
Please choose a safe
place to seat and
unseat the baby to
avoid the baby from
falling off accidentally.
Please fix the shoulder
buckle and the waist
buckle on both sides
while in use.
Otherwise, there is a
danger that baby may
fall off if the shoulder
belt is detached from
the shoulder.
•Baby with weight exceeding
7.0kg.
•Baby with head uncovered by
head guard during cradle-use
cushion setting.
•Baby with habit turning
from side to side in bed.
Failure to do so may
become cause of accidents.
Please do not use the cradle position
for the following babies:
When the carrier is in
use, please do not run,
jump, lean forward for
more than 45 degree,
or lean to the side.
Otherwise, there is a
danger that baby may
fall down.
Please use cradle-use
cushion while cradling
and use cuddle-use
cushion while cuddling
or back carrying.
In cradle position, support
the baby's head with one
hand in case the feet of
baby are in a higher
position than its head.
Improper cradling may
exhaust the baby or cause
accidents.

Before use
For your safety (continued)
3
WARNING
The hook of the U-shape
support must be passed
through the D-ring and
secured by the hook outlet
while cradle position is in
use. Otherwise, there is a
danger that baby may fall
off the carrier.
While in cuddling or back
carrying position, make sure
to adjust the "Depth
adjustment belt" to proper
length, in case the shoulder
of baby is too tight leaning
against the head support
belt, which may in turn
become cause of accidents.
Cuddling and back
carry position should
not be used for baby
whose neck muscle
has yet to develop.
Otherwise,
unexpected damage
will be inflicted to the
baby* neck.
Please support the
baby with one hand
while cuddling to
prevent the baby from
accidentally falling off.
Please make sure the
holding belt is secured.
Otherwise, there is a
danger that baby may
fall off the carrier..
Please tighten the "Safety
belt" on both sides while
cuddling or back carrying.
If the space in between
the user and baby is too
large, or the lengths of the
belt ends are different,
there is a danger that baby
may fall off the carrier
accidentally.
Please adjust the
projected belt end of the
"head support belt" until it
touches at the extension
point of the belt. Do not
extend the belt further or
the baby may have
chance to fall off
accidentally.
Please do not re-structure
the product. Otherwise, it
may cause accidents
while used.
Hook
outlet
D-ring Hook
Holding belt
The length of belt while
back carrying.
Head support belt

Before use
4
CAUTION
Please do not use the carrier
continuously for over 2 hours,
or within 30 minutes after
breastfeeding. Otherwise,
unexpected burden will be
inflicted to user or baby. Also,
please stop using the carrier
immediately in case of any
pain and discomfort.
Please do not leave the
product near fire or
unattended outside.
Otherwise, the buckle or
other fabric parts may be
deteriorated by heat or rain
and it may cause accidents
while used.
While cuddling or back
carrying, in case the depth
adjustment belt is set to
maximum length
"Securing tape" must be
used to prevent the space
between user and baby
too large. Securing tape
In case of using face-out
cuddling position, width
adjustment snap must be
used to secure baby
position for preventing
blood congestion on thigh
of the baby.
Width adjustment snap
Please set the length of
"Base vest" to shortened
state while cuddling and
set to lengthened state
while back carrying.
Otherwise, unexpected
burden will be inflicted to
the user. Length adjustment snap
at shortened state
In case of any
damage of product
found, please stop to
use it to avoid
accidents.
Please do not use this
product for the
purposes other than
cuddling or back
carrying to avoid any
damage to the product.
Please adjust the shoulder
belt and safety belt such
that the remainders from
both sides are about the
same length. Otherwise,
unbalanced belts from
both sides may make the
baby tilt to one side.
Safety belt
Shoulder belt
Please adjust the depth
adjustment belt such that
the remainders from both
sides are about the same
length. Otherwise,
unbalanced belts from
both sides may make the
baby tilt to one side. Depth adjustment belt

Before use
Using styles of "4-way 8-style new birth baby carrier"
5
There are different combinations of components below for "4-way 8-style New Birth Baby
Carrier" Also, "4-way 8-style" is classified in accordance with the age of baby and using
methods.
Combination of product
Cradle-use cushion
(U-shape support) Base vest
Length adjustment snap at
lengthened state while used.
Combination
of product
Cuddle-use cushion
Base vest
Length adjustment snap of "Base
vest" should be set to shortened
state while cuddling and set to
lengthened state while back carrying
style
1
Way 1: Cradle position
From birth until
neck muscle has
developed.
style
2
Way 2: Face-in cuddling position
style
3
style
4
From neck muscle developed From sitting straight
style
5
Way 3: Face-out cuddling
position
style
6
style
7
style
8
Way 4: Back carrying
position
From neck muscle developedHead support belt From neck
muscle developed
From sitting
straight
Please refer to page 21 for the details
about the length of head support belt.
Please check the content of the package.
The content of the package is the following. Please check before using.
Base vest
Cradle-use cushion
U-shape support
Cuddle-use cushion (with 2 hook cover)
Manual (this book)
Quick Manual

Before use
6
Naming of components
Cradle-use cushion (U-shape support)
U-shape support
Hook outlet Hanging hook
D-ring stopper Snap D-ring
Head guard
U-shape support
insertion outlet
Holding belt
Crotch belt hook
Protective pad
Protect the baby by holding
belt and crotch belt.
Crotch belt
Cuddle-use cushion
Base vest
Head support belt
Hook cover (removable)
Head support hook
Safety belt
Holding buckle (female)
Depth adjustment belt
Buckle (male)
Head support
Support the head of baby. It
can be folded inside while face-
out cuddling position is used.
Safety buckle
Holding buckle (male)
Holding belt
Width adjustment snap
The width at cushion hip
position can be narrowed by
fixing the snap while face-out
cuddling position is used
Belt stopper
Shoulder buckle
(male)
Outlet for head
support hook
D-ring
Buckle (female)
Waist buckle (male)
Pad
Shoulder buckle
(female)
Shoulder belt
Waist belt
Securing tape
Waist buckle
(female)
(inside)
Length adjustment snap

Before use
Adjustment methods of components
7
To ensure "New Birth Baby Carrier" to be used under the best conditions, the following is the
explanation of the adjustment methods of "Base vest" and "cuddle-use cushion".
Base vest
Shoulder belt
Shoulder buckle
Length adjustment snap
To shorten the belt, raise the buckle
and pull out the end of the belt. To lengthen the belt, raise the buckle and pull back the belt.
Length adjustment snap can be used to change the length of vest for
"Cuddling" or "Back carrying" mode.
Shoulder buckle Shoulder buckle
Lengthened state <back carrying>Shortened state <cuddling>
Cuddle-use cushion
If the shoulder of baby is pressed by head support belt of cuddle-use cushion,
please lengthen the depth adjustment belt to enlarge the size of cushion.
Depth adjustment belt
1Draw out the depth adjustment belts from both
sides in same length.
Pull out the end of the cloth.
2
In case of using under
face-out cuddling position,
use the width adjustment
snap to decrease the
width size in order to
prevent blood congestion
on thigh of the baby.
Face-out cuddling position
Narrow state
Face-in cuddling position
Back carry position
Wide state
Width adjustment snap
Depth adjustment belt
Adjust the length of shoulder belt
Adjust length adjustment snap
Adjust the length of depth adjustment belt
Adjust width adjustment snap

Cradle position
• Before using cradle position, user should wear the base
vest and put the baby inside cradle-use cushion.
•Length adjustment snap should be set at shortened state.
•The installation method of U-shape support in cradle-use
cushion (refer to page 9) is applicable to both left-cradling
and right-cradling. The following is the explanation of left-
cradling method.
Cradle position (From birth until neck muscle has developed)
Left cradling Right cradling
Cradle-use cushion (U-shape support is installed.)
Base vest (Length adjustment snap is set at shortened state.)
Parts required
Preparing the base vest
Secure the waist buckle
Wind the waist belt to the back. Use the buckle
to fix and adjust the length of the belt.
Waist buckle
Waist belt
1
Please adjust the length until the pad of
the base vest is fixed at the lower abdomen.
Secure the shoulder buckle
Wear the base vest fit to the chest. Place the
shoulder belt in cross position at the back. Use
the shoulder buckle to fix and adjust the length
of the belt. (Please refer to page 7 for the
"Adjustment of length of shoulder belt")
2
Please fasten the belt tightly so that the
upper part of the base vest is fit to the body.
Shoulder
belt
Shoulder
buckle
WARNING
Please fix the shoulder buckles on both
sides for preventing the baby from falling
down.
CAUTION
Please adjust the shoulder belt such that
the remainders from both sides are about
the same length. Unbalanced belts from
both sides may make the baby tilt to one
side.
8
way 1

Cradle position
Use of carrier by cradling
9
Please check the following points after wearing the base vest:
The part of shoulder belt near the chest should be fit to
your body.
Length adjustment snap should be set at the shortened
state.
Waist belt and pad should be fixed well at lower part of
abdomen.
1
2
3
Putting a baby into cradle-use cushion.
1
When a baby is put in sleeping position:
Please place the hip of baby at the "Hip
seat of baby" as illustrated.
Put a baby in sleeping position
and fix the holding belt.
Put a baby in sleeping position inside cradle-
use cushion placed at a safe place. Lay the
protective pad on the baby and pass the holding
belt through the belt insertion outlet. Use the
buckle to fix the position.
2
Illustration below is based on left-cradling.
Prepare cradle-use cushion and
U-shape support
Take the D-ring of the U-shape support first
and then insert it into the insertion outlet of
cradle-use cushion (Same for right-cradling).
Use the snap to fix the position (both sides)
•Left-cradling
•Right-cradling
U-shape
support
Snap
Hip seat of baby
Protective pad
Holding belt
Belt insertion outlet
WARNING
Please ensure the "Buckle of the holding
belt" is fixed well to prevent the baby from
falling down.
Checking of Base Vest

10
Cradle position
3
•When right-cradling is used, the hook of
the U-shape support should be passed
through the D-ring positioned at the right-
chest of the base vest.
• The mechanism of the D-ring stopper
allows the detached hook stopped at
the D-ring.
Passing the hook from the lower
direction
User should stoop down first and hold the hook
of the U-shape support. Then, Pass it from
the lower direction through the D-ring positioned
at the left-chest of the base vest. Pass it
from the lower direction through the D-ring of
U-shape support. Hang it up with the hook
outlet of the belt. The hook is fixed completely
until a "Click" sound is produced.
1
Checking installation of protective
pad.
Make sure there is sufficient space (2-3 fingers
can be inserted) between the protective pad
and the baby. Please adjust the length of the
holding belt if it is too tight or too loose.
Holding belt
Cradling a baby
1
2
3
D-ring
D-ring stopper
Hook
Hook outlet
D-ring
2Hanging up crotch belt hook
The crotch belt hook of the cradle-use cushion
should be hanged up with the D-ring positioned
at right-chest of the base vest. The hook is fixed
completely until a "Click" sound is produced.
Crotch belt hook

Use of carrier by cradle position
11
3Cradling a baby
Use your hands support the head and the hips
of the baby at the same time and then raise
your body to cradle the baby.
Please adjust the length of the crotch belt
if you want to change the positioning angle
of the baby. When the belt is in shortened
state, the body of the baby will be in level
position. When the belt is in lengthened
state, the hip-side of the baby will be lower.
At that time, The "D-ring stopper" of the U-
shape support is used to fix the D-ring of the
base vest.
D-ring
stopper
Crotch belt
WARNING
When cradling the baby, use one hand to
support the baby's head and make sure
the baby's head is in a higher position than
the feet. Failure to do so may exhaust the
baby or become the cause of accident.
Use of D-ring stopper
When you want to cradle the baby in level
position, use the stopper closer to your
chest.
Stopper for level
position cradling
When you want to cradle the baby slightly
facing inward, use the stopper away from
your chest.
Stopper for face-in
position
Unfastening method
Use the opposite steps of installation to
unfasten it.
Cradle position completed
Cradle position

When the baby is growing bigger
Face-in cuddling position
•Cuddling position is divided into [Face-in cuddling position](P.13) and [Face-out cuddling position](P.16).
• When use in cuddling position, one should put on the base vest to which the cuddle-use cushion
has been attached, and then seat the baby into the carrier.
• The length adjustment snap must be snapped in shortened position for either face-in or face-out
position.
• Newborn baby whose neck muscle has not yet developed should use in cradle position.
Face-in cuddling position (After neck muscle has developed until ~ around 11.3kg)
Cuddle-use cushion
Base vest (Length adjustment snap in shortened position)
Parts required
Preparing the base vest
Setting the cuddle-use
cushion
Fasten the 2 lower buckles (male)
on the cuddle-use cushion to the
centre belt buckle (female) on the
base vest. Secure the snap.
1
12
way 2
Base vest
Snap Cuddle-use cushion
Adjust the depth adjustment belt
Extend the depth adjustment belt to
increase the sitting depth of the cuddle-
use cushion when the baby is growing
bigger with its shoulders starting to lean
against the head support. (Refer to P.7 to
adjust the depth adjustment belt)
WARNING
The baby may have chance to fall off the
carrier if the sitting depth of the cuddle-
use cushion is too shallow.
CAUTION
Make sure both left and right side of the
belt end is of same length.Any imbalance
may cause the baby to fall off.
Apply the securing tape
After adjusting the depth adjustment belt,
set the lower end of the cuddle-use
cushion through the securing tape on the
base vest.
Check if the fabric is too thick to pull through
the securing tape.
CAUTION
Make sure to apply the securing tape
when the depth adjustment belt is
completely extended.
Securing tape
Lower end of the cuddle-use cushion

Face-in cuddling position
Face-in cuddling position
13
2Secure the waist buckle (Refer to P.8 Step 1)
Pull the waist belt round to the back and fasten the buckle. Adjust the belt to a suitable length.
For safety purpose, the safety buckle
is designed to be automatically secured
at the D-ring when it gets detached
accidentally.
3Secure the shoulder buckle (Refer to P.8 Step 2)
Fit the base vest tight to your body. Round the
shoulder belt to the back, cross over one with another
and then fasten the buckle.Adjust the shoulder belt
to suitable length. (Refer to P.7 to adjust the shoulder
belt)
CAUTION
Please adjust the shoulder belt such that
both the left and right extending belt ends
are of the same length. Failure to do so
may cause the baby to tilt to one side.
Checking of base vest
Please check the following points after wearing
the base vest:
Shoulder belt should fit tight to your body.
Length adjustment snap should be set at
the shortened position.
Waist belt and pad should fit tight to your
waist part securely.
1
2
3
4Pull one of the safety buckle through
the D-ring and fasten it
Pull the safety buckle through the D-ring
on the base vest from the lower side and
secure it back to the cuddle-use cushion.
12D-ring
Safety buckle

14
Face-in cuddling position
1
Make sure to leave a gap of around
2 ~ 3 adult fingers width in between
the holding belt and the baby. Adjust
the belt when it is too loose or too tight.
Secure another safety buckle
Pull the safety buckle through the D-ring
on the base vest from the lower side and
secure it back to the cuddle-use cushion.
2
Cuddle the baby
Cuddle the baby facing in and seat it into the
cuddle-use cushion.
12
3Secure the holding buckle
Set the holding buckle on the cuddle-use
cushion through the parent and the base
vest and secure it firmly.
Seat the baby into the cuddle-use cushion
WARNING
Operate at a safe place to avoid the baby
from accidentally falling off.
WARNING
Safety belt must be tightened
The baby may have chance to fall off if
the gap between the baby and parent is
too large, or if the length of the left and
the right belt end are different from each
other.
D-ring
Safety buckle
Holding belt
Holding buckle

Face-in cuddling position
Face-in cuddling position
15
5Secure the head support hook
Secure the head support hooks, one at each
side, to the outlets on the base vest until a
"Click" sound is heard.
Detaching the head support hook
Reverse the steps to detach the head
support hook.
Outlet for head
support hook Head support hook
Click
To release the head support hook
Secure the outlet with the thumb.
Lift and open the head support hook. Face-in cuddling
position completed
1
2
Outlet for head
support hook
Head support hook
style
2
Application of the head support
style
3
style
4
The head support can
support the baby's head
when it is asleep.
Fold the head support
outward to widen the
baby's vision while
securing it's neck.
Fold the head support
outward completely and the
baby can extend its hands
from above. The head
support belt must be
completely extended in
such usage.
The 4th style can be applied
after the baby can sit up
straight.
Head
support
belt

Face-out cuddling position
Face-out cuddling position (After neck muscle has developed until ~ around 11.3kg)
Preparing the base vest
Tighten the crotch part of the
cuddle-use cushion
Secure the width adjustment snap to
tighten the crotch part of the cuddle-use
cushion.
1
16
way 3
CAUTION
Make sure to adjust the crotch part or
it may cause discomfort to the baby.
Put on the base vest referring to [face-in cuddling position] step 1 to step 3 (P.12~).
Width adjustment snap
Pull one of the safety buckle
through the D-ring and fasten it
Pull the safety buckle through the D-
ring on the base vest from the lower side
and secure it back to the cuddle-use
cushion.
21
2
For safety purpose, the safety buckle
is designed to be automatically secured
at the D-ring when it gets detached
accidentally.
D-ring
Safety buckle
Seat the baby to the cuddle-use cushion
Cuddle the baby
Cuddle the baby facing out and seat it into
the cuddle-use cushion.
1

Face-out cuddling position
Face-out cuddling position
17
2Secure another safety buckle
Pull the safety buckle through the D-ring on the
base vest from the lower side and secure it back
to the cuddle-use cushion.
3Secure the holding buckle
Set the holding buckle on the cuddle-use cushion
through the parent and the base vest and secure
it firmly.
WARNING
Safety belt must be tightened
The baby may have chance to fall off if the gap
between the baby and parent is too large, or
if the length of the left and the right belt end
are different from each other.
4Secure the head support hook
Secure the head support hooks, one at each
side, to the outlets on the base vest until a "Click"
sound is heard.
Make sure to leave a gap of around 2 ~ 3
adult fingers width in between the holding
belt and the baby. Adjust the belt when it is
too loose or too tight. Holding belt
Holding buckle
Face-out cuddling
position completed
Detaching the head support hook
Reverse the steps to detach the head support
hook.
style
5
Application of the head support
style
6
The head support can
secure the baby's
shoulder.
Fold the head support
outward completely and the
baby can extend its hands
from above. The head
support belt must be
completely extended in
such usage.
The 4th style can be applied
after the baby can sit up
straight.

Back carry position
Back carry (After neck muscle has developed ~ around 14.9kg)
Preparing the base vest
Extend the base vest
Release the length adjustment snaps on the
lower part of the base vest, pull out the
base vest and secure it back to the snaps
for back carry position.
1
18
way 4
•When use in cuddling position, one should put on the base vest to which the cuddle-use cushion has
been attached, and then seat the baby into the carrier.
• The length adjustment snap must be snapped in extended position.
• Newborn baby whose neck muscle has not yet developed should use in cradle position.
Cuddle-use cushion (Head support belt must be set to the back carry position /
as demonstrated)
Base vest (Length adjustment snap in extended position)
Parts required
1
2
Snaps for cuddling
(front) Snaps for back carry (rear)
Setting the cuddle-use cushion
Fasten the 2 lower buckles (male)
on the cuddle-use cushion to the
centre belt buckle (female) on the
base vest. Secure the snap.
2
Snap Cuddle-use cushion
When the baby is growing bigger with its shoulders starting to lean against the head support,
Extend the depth adjustment belt to increase the sitting depth of the cuddle-use cushion.Apply
also the securing tape when the adjustment belt is pulled out completely. (Refer to P.12)
Secure the waist buckle
Pull the waist belt round to the front and
fasten the buckle.Adjust the belt to a suitable
length.
3
Set the pad on the base vest such that it
fits well to the waist.
Pad Waist belt
Base vest
Waist buckle
Proper length of the
head support belt Proper belt length in
back carry position

Back carry
Back carry position
19
4Secure the shoulder buckle
Fit the base vest tight to your body. Round the
shoulder belt to the back, cross over one with
another and then fasten the buckle. Adjust the
shoulder belt to suitable length. (Refer to P.7 to
adjust the shoulder belt)
Checking of base vest
Please check the following points after wearing
the base vest:
Shoulder belt should fit tight to your
shoulders.
Length adjustment snap should be set at
the extended position.
Waist belt and pad should fit tight to your
waist part securely.
Head support belt has been set to back
carry position.
1
2
3
Shoulder belt
Shoulder buckle
4
5Put off the base vest temporarily.
Release the waist buckle and put off the base vest.
CAUTION Do not release the shoulder buckle at this stage.
6Pull one of the safety buckle through
the D-ring and fasten it
Pull the safety buckle through the D-ring
on the base vest from the lower side and
secure it back to the cuddle-use cushion.
12
D-ring
Safety buckle
