Combi I-Thruller User manual

21
31

25
26
16
20
15
19
14
12
21
22
23
24
List of components (P15)
部件名称（详见P25）

1.1
①
②
③
1.2 1.3
1.5
×2 ×2
1
1.4

2.1 2.2
2.3 2.4
2.5 2.6
2.7
2.9
2.8
Switch buckle
坐卧转换调节扣
스위치 버클
Hub slot
座席固定插座
허브 슬롯
2

3.1
3.2
3.4
① ②
④ ⑤
③
3.3
3

4.1
4.2
4.4
AB C
4.3
4

5.1
5.3
5.2
①
①
①
②
②
③
5
Front guard
buttons
前护栏松脱掣
안전가드 버튼

6.1
6.2
6.46.3
①
②③
④ ⑤
6

7.1
7.2
7.3
7.4
①
②
③
7

8.1 8.2
8.3
8.4 8.5
8
Above 3cm
3cm 以上
3cm 이상

(Incorrect operation may cause serious injury or death )

The stroller is suitable for children from newborn 1 month to 18kg
( approximately 4 years old ) .
Always apply the parking brake when you are stationary.
Do not rely too much on the stopper even when the stroller is parked empty.
Even with all stopper engaged, always stay close to the stroller when it is
carrying a child. Make sure to engage all stopper to avoid sudden
movement or tipping over.
Keep all small parts away from children as they are choking hazard.
To prevent the risk of suffocation, always keep the plastic bags out of the
reach of children.
This product is not suitable for running or skating.
Overloading, incorrect folding and the use of non-approved accessories
such as buggy boards may damage or break this stroller.
Always let the child wear the seat belt in the stroller to avoid any possible
accident.
Avoid serious injury from falling or sliding out. Always use seat belt ( crotch
belt, waist belt and shoulder belt ). The front guard is not designed to
prevent the child from standing up. Check if the seat belt fits properly,
otherwise the baby may fall off from the stroller.
Pay attention to child even when seat belt is in use in case of any sudden
movement of child causing it to fall off.
Do not cross the shoulder belts with each other when securing the shoulder
belts to the insert plastic. Otherwise excessive pressure may be caused
to child’s neck.
Do not use the seat cushion on which rift is found. Otherwise the seat
cushion may not function as designed or the child may have chance to
swallow the material inside the cushion.
Never leave the child in a stroller without seat cushion. The child’s hands
or feet maybe get jammed in between the stroller frame.
Do not leave the stroller when the child is seated.
Make sure the open-fold lock is engaged completely before use. Otherwise
the stroller may fold suddenly in use.
Do not get hold of the front guard and to lift it, otherwise the stroller may
accidentally slip off, or the front guard maybe detached, all of which will
cause the stroller to fall down.
Do not let the child operate the front guard. It may make the child to fall off
from the stroller.

















9

( Incorrect operation may cause serious injury or death )













Do not allow your child to stand in or on the stroller, it may be dangerous.
Do not lean on or hang loads on the handle. Put any load on the handle
will affect the stability of the stroller.
Do not hang parcels or accessory items (except Combi original
accessories ) on the stroller, otherwise damage may happen to stroller.
Never carry more than one child in the stroller. Do not allow a child to ride
or sit on any area other than the seat.
Excessive weight may cause a hazardous unstable condition exist.
( Maximum load:18kg. Basket maximum load:10kg )
Do not use the stroller on stairs.
Do not let children operate the baby stroller to avoid accident.
Be careful of those around you to avoid pinching their fingers when you
are opening or folding the stroller or adjusting the seat angle.
Keep your child’s fingers/hands away from moving/folding parts when
folding or unfolding or adjusting the stroller.
Do not apply a lifted seat to baby who cannot sit straight by itself, most
reclined seat ( infant bed mode ) must be used.
When pushing the stroller, please walk slowly to avoid any damage to
the stroller swivel wheels or any tipping over.
Open the baby stroller in clear area to avoid pinching baby’s finger.
Turn the swivel wheels to inner side and lock up before folding the stroller.
Improper position may cause stroller become unstable after folding.
Do not touch at the handle lock when folding or unfolding the stroller.
Otherwise damage may be caused to the stroller.
Never leave your child unattended.

WARNING: It may be dangerous to leave your child unattended.
WARNING: Ensure that all the locking devices are engaged before use.
WARNING: Always use the restraint system.
WARNING: Any loading attached to the handle affects the stability of the
stroller.
WARNING: Always use the crotch belt in combination with the waist belt.
WARNING: Check that the stroller body or seat unit attachment devices
are correctly engaged before use.
WARNING: This product is not suitable for running or skating.
WARNING: Do not let your child play with this product.
WARNING: Do not place the stroller near fire, pool, or electric source.
10


(Incorrect operation may cause injury or component damage )
Make sure all snaps are secured before use. Otherwise accident or damage
to stroller may happen.
Loose the shoulder belts and support the backrest with the other hand before
lowering the seat angle with a child seated. Do not suddenly change the seat
angle while a child is seated.
Adjust the length of seat belt properly after change of the backrest angle.
Please do not touch the folding lever except when folding the stroller.
When opening or folding up the stroller, be careful and avoid the seat cushion,
seat belt, blanket and toys, etc., being pinched into the stroller body.
If one gives excessive shock to the front wheels when getting over the step,
stroller may fall down and cause damages. When stepping over, such as a
curb, please slow down even a slight difference level, pull downward the
handle and step on the foot-step, and make sure to pass the front wheels
to get over the step.
Never lift the stroller or use it on escalators or stairs when your child is
sitting or lying in the stroller.
This stroller requires regular maintenance by the user.
Before use, check that the product and all its components have not been
damaged during transportation.
Please do not use the stroller in whatever purposes other than seating a
baby. Failure to comply may result in damage of the stroller.
Do not pull or twist or forcibly press down the front guard hardly.
Otherwise the stroller may be damaged.
Do not apply a lifted seat to baby who cannot sit straight by itself, most
reclined seat (infant bed mode) must be used.
Do not let an adult sit on the stroller, or add loading on the stroller to avoid
any damage to it.
Avoid continuous outdoor usage particularly during day time in summer.
Avoid storing the stroller in save places under high temperature, near
a heat source or inside a car. Exposure to high temperature may damage
or deform the stroller.
Check regularly that all screws, bolts and nuts are engaged tightly.
For use on trains
This product is not designed to be used on trains. When user attempts to
use the product at his /her own risk, please lock stopper in case of sudden
brake or turning. Otherwise stroller may fall off.
Do not press on the folding lever while lift the stroller to avoid damage to
the part.
















11


(Incorrect operation may cause injury or component damage )
Make sure to release the lock before opening the stroller, misuse may
damage parts.
Make sure the basket is empty before folding up the stroller.
Make sure the canopy is completely folded up before folding the stroller
to avoid damage of the parts.
Do not lay down the stroller and do not put things on the canopy to avoid
deformation.
Do not get hold of an opened front guard to pull the baby stroller. Please
do not put the stroller near fire.
Even have parking lock, this stroller may also be accidental slip or
overturned.
Do not leave baby stroller at road side or slope even when it is not in use.
Do not use the stroller on steep slopes, stairs, escalators, rough roads,
beaches, mud, etc.
Make sure no oil or lubricant is left on parts such as front guard or armrest
where baby may have chance to lick.
Do not use the stroller in lightning days to avoid thunder stroke.
In the event of damage or operation problems, stop using the stroller
immediately.
If damage is identified, do not use the product and keep it out of reach of
children.
Never leave the stroller close to stairs or steps.
Only use on a flat, relatively smooth, stable and non-slippery surface.
Only use original accessories and parts that have been approved by the
manufacturer. Do not make any modifications to the product.
Do not use the most reclined angle ( infant bed mode ) if the baby's head
touches at the head rest.
Do not use the stroller in snowy, windy days or wet road to avoid the
stroller or guardian from slipping.
Do not attach other accessory like buggy board on the main body during
a child being carried in stroller, otherwise accident or damage to stroller
may happen.
Do not use in the bus trolley.
Lift front wheels and pay particular attention to gaps or ditch when crossing
rail road.
No continuous use for a long period.
Continuous use for a long period of time may exhaust baby. No continuous
use of more than 2 hours for a baby in a reclined seat and 1 hour in an
upright seat.





















12

(Incorrect operation may cause injury or component damage )
When feel jammed, please do not forcibly fold the stroller to prevent from
any damage. You should reopen the stroller to check and operate again.
Turn swivel wheels to inner side and lock up before folding the stroller.
Improve position may cause stroller become unstable after folding.
Do not put things that are too sharp or too large into the basket since it
may cause damage to the basket.
Please regular cleaning and checking the stroller. Only use neutral
detergent to clean the stroller body.
Make sure no oil or lubricant is left on parts such as front guard or armrest
where baby may have chance to lick.
Parking device shall be engaged when placing and removing the children.
Any load attached to the handle and/or on the back of the backrest and/or
on the sides of stroller will affect the stability of the stroller.
Only replacement parts supplied or recommended by the manufacturer/
distributor shall be used.







13

14

Checking the sales package ( Figure 1.1 )
Make sure all snaps are complete before use.
Assembly of Front Wheels ( Figure 1.2 )
Line up the tab on front wheel axle with the groove in front wheel housing of the stroller.
You will hear the "click" when the wheel is locked in place.
Assembly of Rear Wheels ( Figure 1.3 )
Line up the tab on rear wheel axle with the groove in rear wheel housing. You will hear
the "click" when the wheels are locked in place. Repeat the same steps for another rear
wheel.
Open the stroller ( Figure 1.4 )
Push the handle down, lift the front wheels up.
① Grip and pull the folding lever upwards simultaneously.
② Slide the safety lock as demonstrated direction and hold it in place.
③ Slightly lift the stroller and open it. Once the stroller is opened,you can release the
folding lever and safety lock. (The folding lever will be locked automatically.)
Make sure the open/fold lock is engaged completely after open. ( Figure 1.5 )
Using the stopper
① To lock wheels, press the stopper down which is located at rear right wheel. ( Figure 2.1 )
Try to push the stroller back and forth slightly to ensure that the stopper is properly engaged.
Lift the stopper to unlock. ( Figure 2.2 )
Using the swivel wheels ( Figure 2.3-2.4 )
① To use the swivel wheels - Lift the swivel wheel locks ( left and right ) to release.
② Swivel wheels not in use - Press down the swivel wheel locks to lock.
WARNING: Don't use the stroller before the seat unit was assembled
to frame.
WARNING: After assembly, please be sure to check the wheels
are securely attached by pulling outwards.
15
1. Handle
2. Front guard
3. Seat unit
4. Seat cushion
5. Foot rest
6. Swivel wheel lock
7. Front Wheel
8. Basket
9. Rear Wheel
10. Remove seat unit knob
11. Waist belt insert outlet
12. Shoulder belt cover
13. Shoulder belt insert outlet
14. Head support insert outlet
15. Shoulder belt
16. Waist belt
17. Crotch belt buckle
18. Crotch belt cover
19. Open/Fold Lock
20. Stopper
21. Seat position
adjustment button
22. Seat cushion
snaps
23. Reclining buckle
24. Reclining belt
25. Safety Lock
26. Folding Lever

According to age and weight of a child, there are two operating modes.
Seat Mode
Assembly steps
① Unfasten snap buttons as shown. ( Figure 2.5 )
② Pull out the strap from foot area of seat unit, make sure the strap goes as illustrated.
Secure the switch buckle as show. ( Figure 2.6-2.8 )
③ Fasten the snaps. (Figure 2.9)
④ Lift up and insert the hubs on both sides of the seat into the hub slots on the stroller
frame as shown. (Figure 3.1)
If unable to fasten switch buckle properly doing step ②, push the foot end of seat unit
upwards slightly and then repeat step ②again.
Infant Bed Mode
Note: When the left and right hub slots are not flush with each other,
adjust and make them flush with each other before attaching to
the stroller.
Note: It is recommended to adjust the seat unit before assembling with
stroller frame for easy handling. Customer can also choose to adjust
the seat unit after assembling with stroller frame.
Note:
Seat mode is suitable for child over 6 months to 4 years old ( around 18kg ).
The seat unit and the frame are not assembled together when shipped.
Steps of converting the seat unit into an infant bed: ( Figure 3.2 )
① Pull down the seat reclining buckle.
② Pull seat position adjustment button downwards until the seat unit is completely flat.
③ Unfasten the switch buckle on one side of the seat unit.
④Smooth flat the bottom of seat unit.
⑤Fasten the snap buttons as shown.
WARNING: For the safety of the infant, do not carry the infant bed.
( Figure 3.3 )
Note:
Infant bed mode is suitable for infant from newborn to 6 months old.
Please do not use infant bed if the baby’s head touches at the headrest.
Note: Infant bed mode is restricted for use by infant who cannot sit up
unaided, roll or use arms and knees to support themselves only.
Maximum carrying weight: 9kg.
Note: Ensure to check switch buckle is firmly secured when carrying
a child.
Note: When the head of the child is low, tighten the reclining belt at
the back slightly to raise the backrest. ( Figure 3.4 )
Please do not adjust the seat position adjustment button when using
as infant bed mode.
16

Reclining the Seat Unit
The seat unit can be adjusted in three different positions (ABC).Please do not adjust
the seat unit to horizontal position when using as a seat mode.
① To adjust the entire seat unit, press seat position adjustment button located at the
front end of seat unit. ( Figure 4.2 )
② To recline backrest, use the reclining buckle to adjust seat unit into desired position.
When the backrest reclining belt is too long, retract the unnecessary part as shown
in the figure. ( Figure 4.3 )
Adjusting the canopy ( Figure 4.4 )
Pull canopy forward or backward to adjust the canopy size.
Folding the stroller ( Figure 5.2 )
Please fold the canopy backward before folding.
① Slide to release the safety lock of direction as illustrated.
② Grip the folding lever and slightly lift up the handle, then press down the handle as
illustrated to fold the stroller.
The stroller is equipped with a removable front guard.
① To remove, press the buttons located on both sides together to release.
② To open for the child to get in and out, press one button only.
To assemble, line up the tab on front guard with groove on both sides of the stroller.
Note: To keep a closer look at the infant while operating as infant bed,
install seat unit in rear facing position.
Assembly and removal of front guard ( Figure 5.1 )
WARNING: Do not get hold of the front guard to lift the stroller.
WARNING: When removing any side of the front guard, be sure
to turn the front guard downward. Otherwise it may
hurt the head or eyes of the child.
WARNING: Do not pull or drag the front guard when removing
any side of the front guard, to avoid the child from
falling off in case of stroller overturn. Make sure to
lock the front guard if any child is seated.
Reversing the Seat Unit ( Figure 4.1 )
① Rotate the knob as shown with both hands, lift upwards and remove seat unit from the mounts.
② Turn the seat unit and re-insert into seat unit mounts.
③ Pull up the seat unit gently to check it is securely attached.
WARNING: Do not reverse the seat unit with infant in it.
17
