Combi Umbretta 4CAS User manual

Instruction manual
Umbretta 4CAS
繁體中文 說明書

Umbretta 4CAS
19
28

9
10
11
12
13
14
15
16
18
19
20
21
31
22
37
36
6
38
39
40
34
17

1.3 1.4
1.5
1.6

2.82.7

10
①
②
④
⑤
③
⑦
⑥

cba

(Incorrect operation may cause serious injury or death )

You are personally responsible for the safety of your child.
The stroller is suitable for children from 1month to 15 kg ( approximately 3
years of age ).
Always apply the parking brake when you are stationary.
Do not rely too much on the stoppers even when the stroller is parked empty.
When a baby is in the stroller, you should always pay attention to the stroller
to avoid any danger. In addition, both the left and right parking locks should
be used at the same time to avoid accidental sliding or overturning.
Keep all small parts away from children as they are choking hazard.
To prevent the risk of suffocation, always keep the plastic bags out of the
reach of children.
This product is not suitable for running or skating.
Overloading, incorrect folding and the use of non-approved accessories
such as buggy boards may damage or break this stroller.
Avoid serious injury from falling or sliding out. Always use seat belt.
The child being carried by the stroller must be tied with the seat belt that
contains the crotch belt, waist belt and shoulder belt. The front guard cannot
prevent the child from standing up from the cushion. Make sure the seat belt
is not loose to prevent the child from suddenly falling out of the stroller.
Pay attention to child even when seat belt is in use in case of any sudden
movement of child causing it to fall off.
Do not cross the shoulder belts with each other when securing the shoulder
belts to the insert plastic. Otherwise excessive pressure may be caused to
child’s neck.
Do not use the seat cushion on which rift is found. Otherwise the seat cushion
may not function as designed or the child may have chance swallow the
material inside the cushion.
Never leave the child in a stroller without seat cushion. The child’s hands or
feet maybe get jammed in between the stroller frame.
When a child is sitting in it, the caretaker is not allowed to leave.
Make sure the open-fold lock is engaged completely before use. Otherwise
the stroller may fold suddenly in use.

















(Incorrect operation may cause serious injury or death )
 To prevent the stroller from accidental slippage, or to avoid fall of the stroller
caused by loosening of the front guard, DO NOT hold the front guard or places
like that when moving the stroller.
Do not let the child operate the front guard. It may make the child to fall off
from the stroller.
Never leave your child unattended.
Do not allow your child to stand in or on the stroller, it may be dangerous.
Do not lean on or hang loads on the handle. Put any load on the handle will
affect the stability of the trolley.
Do not hang any object ( except original Combi parts ) on the hood or handle
to prevent the stroller from overturning.
Never carry more than one child in the stroller. Do not allow a child to ride
or sit on areas other than the seat.
Excessive weight may cause a hazardous unstable condition
( Maximum weiht: 15kg. Basket maximum load: 10kg )
Do not use the stroller on stairs.
Do not let children operate the baby stroller to avoid accident.
Be careful of those around you to avoid pinching their fingers when you
are opening or folding the stroller or adjusting the seat angle.
Keep your child and your fingers/hands away from moving/folding parts
when folding or unfolding or adjusting the stroller.
Do not apply a lifted seat to baby who cannot sit straight by itself, most
reclined seat must be used.
When pushing the stroller, please walk slowly to avoid any damage to the
stroller swivel wheels or any tipping over happened.
Open the baby stroller in clear area to avoid pinching baby’s finger.
Be careful not to pinch the baby’s hands or feet when reversing the handle.
Do not reverse handle while pushing the stroller. Othewise damage may
be caused.
Shoulder belt hole positions on the seat and the cushion must be aligned.
If upper shoulder belt hole on the seat is used, upper shoulder belt hole on
the cushion should be used; otherwise the child may be held tightly because
the shoulder belt is not long enough.
Do not adjust the seat angle while pushing the stroller because this is very
dangerous.
Please do NOT use the footmuff when the backrest is in the flat position.
The ASTM footcover can only be used in this situation.





















(Incorrect operation may cause serious injury or death )
WARNING: It may be dangerous to leave your child unattended.
WARNING: Ensure That all the locking devices are engaged before use.
WARNING: Use a harness as soon as your child can sit unaided.
WARNING: When the backrest angle less than 150 degree, it is not suitable
for baby under 6 months.
WARNING: Any loading attached to the handle affects the stability of the
pram/pushchair.
WARNING: Always use the crotch strap in combination with the waist belt.
WARNING: Check that the pram body or seat unit attachment devices are
correctly engaged before use.
WARNING: This product is not suitable for running or skating.
Child may slip into leg openings and strangle. Never use in reclined
carriage position(s) unless the ASTM-footcover is used.

(Incorrectoperationmaycause injuryor componentdamage )
Make sure all snaps are secured before use. Otherwise accident or damage to
stroller may be caused.
When adjusting the seat angle with a child in the stroller, loose the shoulder
belt first, and then adjust the angle with the other hand holding the backrest.
Please be careful not to change the seat angle suddenly.
Adjust the length of seat belt properly after change of the seat angle.
Please do not touch the folding lever except when folding the stroller.
When opening or folding up the stroller and reversing the handle, be careful
and avoid the seat cushion, seat belt, blanket and toys, etc., pinched into the
stroller body.
If one gives excessive shock to the front wheels when getting over the step,
stroller may fall down and cause damages. When stepping over, such as a
curb, please slow down even a slight difference level, pull downward the
handle and step on the foot-step, and make sure to pass the front wheel to
get over the step.
Never lift the stroller or use it on escalators or stairs when your child is
sitting or lying in the stroller.
This stroller requires regular maintenance by the user.
Before use check that the product and all its components have not
been damaged during transportation.
Please do not use the stroller in whatever purposes other than seating a
baby. Failure to comply may result in damage of the stroller.
Do not pull or twist or forcibly press down the front guard hardly. Otherwise
the stroller may be damaged.
Do not apply a lifted seat to baby who cannot sit straight by itself, most
reclined seat must be used.
Do not use an adult sit on the stroller, or add loading on the stroller to
avoid any damage to it.
Avoid continuous outdoor usage particularly during day time in summer.
Avoid storing the stroller in places that under high temperature, near a heat
source or inside a car. Exposure to high temperature may damage or deform
the stroller.
Check regularly that all screws, bolts and nuts are engaged tightly.
Swivel wheel lever should be secured at the same side of the pushing person.
Lever secured in wrong position may affect maneuvering or damage the product.
For use on trains: This product is not designed to be used on trains. When
user attempts to use the product at his /her own risk, please lock stoppers in
case of sudden brake or turning. Otherwise stroller may fall off.



















(Incorrect operation may causeinjury or componentdamage)
Do not press on the folding lever while lift the stroller to avoid damage to
the part.
Make sure the basket is empty before folding up the stroller.
Make sure the canopy is completely folded up before folding the stroller to
avoid damage of the parts.
Do not touch at the handle lock when folding or unfolding the stroller.
Otherwise damage may be caused to the stroller.
Do not lay down the stroller and do not put things on the canopy to avoid
deformation.
Do not get hold of an opened front guard to pull the baby stroller.
Please do not put the stroller near fire.
The stroller may slide or overturn accidentally even if the parking lock is
engaged.
Do not leave baby stroller at road side or slope even when it is not in use.
Do not use the stroller on steep slopes, stairs, escalators, rough roads,
beaches, mud, etc.
When pushing the stroller, be careful of the road depression to prevent the front
wheels from being trapped into the slot and overturning.
In the event of damage or operation problems, stop using the stroller
immediately.
If damage is identified, do not use the product and keep it out of reach of
children.
Never leave the stroller close to stairs or steps.
Only use on a flat, relatively smooth, stable and non-slippery surface. Only
use original accessories and parts that have been approved by the manufacturer.
Do not make any modifications to the product.
Do not use the most reclined angle if the baby's head touches at the head rest.
Do not use the stroller in snowy, windy days or wet road to avoid the stroller
or guardian from slipping.
Do not use the stroller in lightning days to avoid thunder stroke.
Do not reverse handle while pushing the stroller.
Do not attach other accessory like buggy board on the main body during
a child being carried in stroller, otherwise accident or damage to stroller
may cause.
Do not use in the bus trolley.






















(Incorrect operation may causeinjury or componentdamage)
Lift front wheels and pay particular attention to gaps or ditch when crossing
rail road.
No continuous use for a long period. Continuous use for a long period of
time may exhaust baby. No continuous use of more than 2 hours for a baby
seated in a reclined seat and 1 hour in an upright seat.
When feel jammed, please do not forcibly fold the stroller to prevent from
any damage. You should re-open the stroller to check and operate again.
Turn swivel wheels to inner side and lock up before folding the stroller.
Improper position may cause stroller becoming imbalanced after folded.
Do not put things that are too sharp or too large into the basket since it may
cause damage to the basket.
Please regularly clean and check the stroller. Only use neutral detergent to
clean the stroller body.
Make sure no oil or lubricant is left on parts such as front gurad or armrest
where baby may have chance to lick.







S
Footmuff
cover

1.7
2.5
Fold the canopy from backward by both hands as illustrated.
To fold the sun
To unfold the sun canopy
How to use the top window
Hold the canopy shelf with two hands and open it forward. Until it locts with a “click” sound.
The baby carriage can be directly folded if the canopy is in place. Be sure to fold the canopy
and pack to the rear side. Please read (figure 3.5) for canopy installation.
Opening the canopy without following the appropriate procedures may lead the canopy to be
out of shape.
(Figure 2.2)
Open the window cover to see the baby. The window covers are set at three positions
around
the canopy.
How to use under rain (Figure 2.4)
The canopy has the same waterproof level and fabrics as the umbrella which can
prevent the parts under the canopy from the short period of rain.
1.Totally open up the canopy.
2.Close the top window (2 points) and airthrough window and lock the buckles.
Please refer to the part “ How to use the top window ”. (Figure 2.3)
Top window and airthrough window.
The rain may enter into any leakage of top window and airthrough window.
In case of long-time rain or heavy rain, please use the rain cover.
crotch
2.6
Unlock the buckles of window covers.
Insert the buckles of different window covers.
If the canopy gets wet.
Please extend the canopy and put into the well-ventilated place.
If the canopy gets wet thoroughly, please dry the canopy with towel before natural dry.
If the wet canopy is left unattended, there may occur the water stain or color
change.
Avoid serious injury from falling or sliding out. Always use seat belt.

2.8
Attach shoulder belts to the shoulder belt hook of the left and right insert plastics.
Pull out the crotch belt and put the insert plastics into the buckle until a “Click”
sound is heard.
Tightening-As figure Pull out the crotch belt belt the inside a layer PP belt for pull to
the end, is the shortest state.
Extending-As figure According to the direction of arrow pull out the crotch belt
to end PP belt the end, then as figure Direction of arrow pull to the end.
Pull the crotch belt end pull the shoulder belts and waist belts to check if it is secured.
Upright Recling
reclining
Install and adjust the crotch belt (Figure 2.7)
When unstalling the canopy, press the joint claw of canopy roof and pull out from the stand
of canopy.
Fold the canopy.
Fully insert the canopy joint into the canopy stand.
Elect the backrest and fix the canopy buckle (1 place).
Folding

mm
A
G
Roll two fastening installation belts ①and ②in front of the basket into the stand and
lock with U-shape buckle in front of the installation belts.
Roll two fastening installation belts ③and ④in middle of the basket into the
installation shelf of basket under the carriage on the rear side and lock with U-shape
buckle.
Lead two fastening installation belts ⑤and ⑥behind the basket through the
installation belt holes on the left and right sides of the rear-wheel stand and fix them.
Roll the nylon buckle ⑦in the middle of the rear side of basket into to the middle
position of rear-wheel stand and fix it.
Pull the U-shape buckle, fastening installation belt and nylon buckle to make sure
whether they are fixed.
7
6
Remove the safety belt buckles (2 places) fixed on the back tube above the carriage
bottom. (4 places)
Remove the crotch
belt cover from crotch belt.
backrest
base seat
as illustrated.

footmuff
Warning:
This footmuff is an option part, subject to the market availability.
Please do NOT use the footmuff when the backrest is in the flat position. The ASTM
footcover can only be used in this situation.
6.2
Footmuff
footmuff
footmuff
Please STOP using the body and hip support which does not fit the
child’s body even if it is less than 3 years old. To detach, please kindly follow
the reverse steps.
Store inside head support
Store inside
