COMECO PHG User manual

Specifications
Measurement Range
Output Signal
Power Supply
Consumption
Output Load (mA / V)
Measurement Error
Temperature rift
Warm-up Time
Response Time
Operating Temperature
Operating Humidity
Protection Class
Local Indicator
Serial Interface
Sintered Filter
Mounting
Connector
irectives
 0...3000 ppm,  0...5000 ppm,
 0...10000 ppm
 0...20 mA,  4...20 mA,  0...10 V
15...32 V C ± 1 Vp-p at 50 Hz
60...90 mA
max. 350 Ω (at 24V/20mA) / min.1 MΩ
± 2 ppm (0…3000 ppm) at 10…50 °C
10 ppm for 1 °C
max. 90 s (at 25 °C)
max. 30 s (w/o sintered filter)
0…50 °C
0…85% RH, non-condensing
IP65 (except gas inlet)
 mounted (4-digit red LE , 0.2% accuracy)
 mounted (CO2 transmitting, 9600 bps)
 mounted
 free,  duct
 top I,  top L,  bottom I,  bottom L
CE (2004/108/EC), LV (2006/95/EC)
Warranty and Support
………………………….
serial number
………………………….
manufacturing date
QC check mark …….……(passed)
(stamp)
88 Slavyanska Str.
P.O.Box 378
Plovdiv 4000, BULGARIA
tel: [phone], 646524
fax: [phone], 646517
e-mail: [e-mail]
Q -8.2.4-WC
Warranty
COMECO warrants this product
to be free from defects in materials
and workmanship for 1 year. If your unit
is found to be defective within that time,
we will promptly repair or replace it.
This warranty does not cover accidental
damage, wear or tear, or consequential
or incidental loss. This warranty
does not cover any defects caused
by wrong transportation, storage, installation,
or operating (see 'Specifications').
Technical support
In the unlikely event that you encounter
a problem with your COMECO device,
please call your local dealer or contact
directly our support team.
COMECO Inc., P.O.Box 378, Plovdiv 4000, BULGARIA, tel: [phone], 646524, fax: 634089
e-mail: [e-mail], WWW.COMECOGROUP.COM
PHG
OPERATION MANUAL
Please read this Operation Manual before mounting and operating!
Save the Manual for future references!
v
1-12.11
CARBON-DIOXIDE TRANSMITTER
TRANSMITTER

Overvie
The PHG transmitter measures CO2 concentration in in-door atmospheres and
converts it into standard current or voltage signal. PHG model uses dual N IR
carbon-dioxide sensor for better accuracy and sensitivity as well as low temperature
and humidity dependence. The transmitter can be equipped with local 4-digit LE
display and RS232 serial interface. PHG application area includes indoor air control,
ventilation, air-conditioning, mushroom control, etc.
Mounting
Free mounting
♦ Remove 2 protection plastic caps (1)
using a flat-screwdriver tip.
♦ Fix the unit using 4 M4 screws with
proper length through holes (2) to your
mounting construction or use the
supplied COMECO mounting
accessories.
♦ Return the protection caps to their
original places.
Duct mounting
♦ Place the supplied flange to duct wall
and mark 2~4 mounting holes.
♦ rill on duct wall d4.5mm flange holes
and a d17mm central hole.
♦ Fix the flange (3) using 2~4 M4 screws
(4) with proper length.
♦ Place the transmitter inlet tube to the
desired process depth and front rotation.
Fix it with flange fixing screw (5).
Important notes:
♦ Do not try to open the enclosure.
It can damage the transmitter!
♦ Sintered filter significantly increases
the response time!
Wiring
♦ Check the pin numbers of the male
connector located on housing top or
bottom.
♦ Turn off power supply!
♦ Attach the female connector part wired
to your system as shown on the left.
♦ Turn the power supply on.
♦ If RS232 interface is installed:
- Baud Rate: 9600 bps
- Transmit Update: 2 s
- Transmit Frame:
1 2 3 4 5 6
CO2 value CR LF
- Example for CO2 = 1000ppm:
1000 [13] [10]
(0x31, 0x30, 0x30, 0x30, 0x0 , 0x0A)
Waste Disposal
Do not dispose of
electronic devices
together with
household waste
material!
If disposed of within European Union,
this product should be treated
and recycled in accordance with the laws
of your jurisdiction implementing
the WEEE irective 2002/96
on the Waste Electrical and Electronic
Equipment.
