Comfee CDC17P0AWW User manual

Please keep the manual
for future reference.
MODEL NUMBER CDC17P0AWW
)UHHPRQWKV
HxWHQVLRQRIWKH
RULJLQDOOLPLWHGZDUUDQW\
SHULRG6LPSO\WH[WD
SLFWXUHRI\RXUSURRIRI
SXUFKDVHWR

7KHZDUUDQW\H[WHQVLRQLVIRUWKH
WKUHHPRQWKVLPPHGLDWHO\IROORZLQJ
WKHFRPSOHWLRQRIWKHSURGXFW¶V
RULJLQDOZDUUDQW\SHULRG

or
2
1
Water Inlet
Drain Pipe
QUICK START GUIDE
Please read the corresponding content for detailed operating method.
Connecting to Power Supply
The clamp must be tightened by a screwdriver.
Fix the drain pipe with
suction cups
The power supply is 120VAC 60Hz
The specification of the socket is 10A 120VAC
The connection of the drain pipe: Put end of the drain into a sink or bucket.
Adding Water to the Tank
There are two ways to keep the tank filled.
1. Before starting:
When the tank is full of water, the machine will
beep fleetly for 3 seconds.
2. After starting:
Water is not enough, light is on;
Water is enough, light will be off and the machine will
beep fleetly for 3 seconds.
There are two ways to add water into the tank:
1
2
Connect inlet hose to the tap
Open the cap and slowly add water into the dishwashers
tank manually
Note:Before adding water, you need to press the power
button to turn on the diswasher
Or 33
ubber
1 2

Pull open
Starting The Dishwasher
Loading The Dishwasher
Place dishes in the dishwasher in order by size and starting from the two ends,
then load into the middle. All cutlery are suggested to be tilted to improve
cleaning performance.
The top arm will be blocked if cutlery is improperly placed and the
cleaning effect may not be ideal.
Do not place the cutlery in the
upright direction or the cleaning
performance may be effected. Try
to leave the dirty side facing
towards the spray arm.
Detergent Dispenser. (Do not use
detergent when running the
FRUIT program.)
Prep the Dishware
Remove the large residue on the dishware and
glasses before placing into the dishwasher.
Close the front door, choose the
program and press START.

CONTENTS
Please carefully read this manual before using the dishwasher, it will help you
use and maintain the dishwasher properly .
IMPORTANT SAFETY INSTRUCTIONS
5
INSTALLATION INSTRUCTION
25
Installation Preparation
About Power Connection
Water Connection
Connection Of Drain Hoses
26
27
26
25
28
31
TROUBLESHOOTING TIPS
Before Calling For Service
Error Codes
Technical Information
GETTING TO KNOW YOUR APPLIANCE
Dishwasher Features
Control Panel
10
10
11
USING YOUR DISHWASHER
Loading The Dishwasher Baskets
15 Loading The Detergent
12
12
17
18
18
PROGRAMMING THE DISHWASHER
Wash Cycle Programs
Turning On The Appliance
Change The Program
Forget To Add A Dish?
End Of The Wash Cycle
Forced Drainage Operation
20
19
MAINTENANCE AND CLEANING
Filter System
Dishwasher Care
Dishwasher Maintenance
21
21
22
17
28
20
24
32
Warranty
33

IMPORTANT SAFETY INSTRUCTIONS
WARNING
When using your dishwasher , follow the
precautions listed below:
This appliance is intended to be used in household and similar applications such as:
-Staff kitchen areas in shops, offices and other working environments;
-Households;
-by clients in hotels, motels and other residential type environments;
-bed and breakfast type environments.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not be made by
children without supervision.
This appliance is not intended for use by persons(including children )with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
This appliance is for indoor use only, for household use only.
To protect against the risk of electrical shock, do not immerse the unit, cord or
plug in water or other liquid.
Please unplug before cleaning and maintaining the appliance .
Use a soft cloth moisten with mild soap, and then use a dry cloth to wipe it again.
Grounding instructions
This appliance must be grounded. In the event of a malfunction or breakdown,
grounding will reduce the risk of an electric shock by providing a path of least
resistance of electric current. This appliance is equipped with a cord having an
equipment-grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet that is installed and
grounded in accordance with all local codes and ordinances.
Do not modify the plug provided with the appliance. If it does not fit the
outlet, have a proper outlet installed by a qualified electrician.
Improper connection of the equipment-earthing conductor can result in the
risk of an electric shock. Check with a qualified electrician or service
representative if you are in doubt whether the appliance is properly grounded.
-5-

General use
Do not abuse, sit on, or stand on the door or dish rack of the dishwasher.
Do not operate your dishwasher unless all enclosure panels are properly in place.
Open the door very carefully if the dishwasher is operating, there is a risk of water
squirting out.
Do not place any heavy objects on or stand on the door when it is open. The
appliance could tip forward. When loading items to be washed:
1) Locate sharp items so that they are not likely to damage the door seal;
2) Warning: Knives and other utensils with sharp points must be loaded in the
.
Check that the detergent powder is empty after completion of the wash cycle.
Do not wash plastic items unless they are marked dishwasher safe or the
equivalent. For plastic items without mark, check the manufacturer's
recommendations.
Use only detergent additives designed for an automatic dishwasher.
Never use soap, laundry detergent, or hand washing detergent in your
dishwasher. Children should be supervised to ensure that they do not play with
the appliance. The door should not be left open, since this could increase the risk
of tripping.
If the supply cord is damaged, it must be replaced by the manufacturer or its
service agent or a similarly qualified person in order to avoid a hazard.
During installation, the power supply must not be excessively or dangerously bent
or flattened.
Do not tamper with controls.
The appliance is to be connected to the water mains using new hose sets and that
old hose-sets should not be reused.
The maximum number of place settings to be washed is 2 in AHAM test, 1 setting
in DOE test. The maximum permissible inlet water pressure is 1MPa.
The minimum permissible inlet water pressure is 0.04MPa.
basket with their points down or placed in a horizontal position.
-6-

For more detailed information about recycling of this product, please
contact your local city office and your household waste disposal service.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection
of such waste separately for special treatment is necessary.
For disposing of package and the appliance please go to a
recycling centre. Therefore cut off the power supply cable
and make the door closing device unusable.
Cardboard packaging is manufactured from recycled paper and
should be disposed in the waste paper collection for recycling.
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product.
Disposal
-7-

Handle
Control panel
Kick board
GETTING TO KNOW YOUR APPLIANCE
IMPORTANT:
Before using this dishwasher for the first time and to get the best performance,
read these instructions.
Dishwasher features
Water Tank Cap
Upper Spray Arm
Filter
Basket
Tableware Basket
Detergent Dispenser
5L Water Container
Lower Spray Arm
Fruit Rack
-8-

12 3 4 56 7 89
LOCK
Program Button: Press the button to select wash cycles
P1(STEAM ) -P2 (GLASS) -P 3(FRUIT).
STEAM: High temp for washing baby bottles etc.(Steam Adding).
GLASS: Suitable for washing delicate ware with light soiled.
FRUIT: Suitable for washing hard surface fruit.
DELAY The Delay Time feature allows you to program the dishwasher
to begin the selected wash cycle between 0 to 24H hours later.
3
5
LOCK
6Press and hold for 3 seconds to activate or cancel the control
Lock option
CANCEL
Press and hold START for 3 seconds to cancel a cycle
when the dishwasher is running.
Press this button to start the dishwasher, the process
pilot lamp will be blinking when starting.
Control panel
POWER
1
AIR REFRESH
To turn on and off.
Air Refresh function, help to improve the dry performance,
or prevent peculiar smelly. Default setting on, touch to close.
4
NORMAL
7
RAPID
8Suitable for lightly soiled or well-rinsed dish loads.
CYCLES
2
DISPLAY Display the program time, error code etc.
Suitable for washing normally soiled dishes.
Water Faucet Icon
If the" "indicator is lit, it means the water faucet is closed.
START/
9
CANCEL
START
slightly and wait a few seconds until the wash action stops.
PAUSE If you need to pause a cycle in process, open the door
-9-

USING YOUR DISHWASHER
Loading The Dishwasher
Recommendation
Consider buying utensils which are identified as dishwasher-proof.
Use a mild detergent that is described as 'kind to dishes'. If necessary, seek further
information from detergent manufacturers.
For particular items, select a program with lower temperatures.
To prevent damage, do not take glass and cutlery out of the dishwasher
immediately after the program has ended.
Not suitable for use:
Cutlery with wooden, horn, china or mother-
of-pearl handles
Plastic items that are not heat resistant Older
cutlery with glued parts that are
not temperature resistant
Bonded cutlery items or dishes
Pewter or copper items
Crystal glass
Steel items subject to rusting
Wooden items
Items made from synthetic fibres
Attention before or after loading the dishwasher baskets
(For the best performance of the dishwasher, follow these loading guidelines.
Features and appearance of baskets and cutlery baskets may vary from your model.)
Scrape off any large food particles. Soften remnants of burnt food in pans. It is not
necessary to rinse the dishes under running water. Place objects in the dishwasher in
following way:
Items such as cups, glasses, pots/pans, etc. load face downwards.
Curved items, or those with recesses, should be loaded at a slant so that water can
run off.
All utensils are stacked securely and can not tip over.
Limited suitability:
Some glasses can become dull
after a large number of washes.
Silver and aluminium have a
tendency to discolour during
washing.
Glazed patterns may fade if
washed frequently.
Items Not Recommended for Dishwasher Use
