INSTALLATION &
OPERATION MANUAL
Infrared Electric Patio Heater
IRPH15SS
For Outdoor Use only
AITONS EQUIPMENT • Guelph, ON N1H 6H9 •1-888-744-2911 •www.aitons.com

Installation & Operation Manual Infrared Electric Patio Heater
2
WARNINGS
This electric appliance produces infrared heat and failure to follow warnings and
READ AND SAVE THESE INSTRUCTIONS!
WARNING
FIRE OR EXPLOSION HAZARD
•Failure to follow safety warnings exactly could
result in serious injury or property damage.
•vapors or liquids in the vicinity of this appliance.
•materials on, or allow them to come in contact
with, the unit: rags, fabrics ,spray or aerosol cans,
cleaning compounds, plastics or plastic containers,
•Do not install the heater close to furniture, curtains
•Do not cover or otherwise obstruct the heater.
WARNING
PERSONAL INJURY HAZARD
•Do not touch the heater during operation. Burn or
scald injury could result.
•Keep children away from the heater. Never leave
an unsupervised child near the heater.
•Because of injury risk, the heater should be
operated only by individuals knowledgeable about
the operation and familiar with the warnings and
cautions listed in this manual.
•Because of injury risk, this heater is not intended
for use by persons with reduced physical, sensory
or mental capabilities.
WARNING
PERSONAL INJURY HAZARD–SERVICE
•To avoid property damage, personal injury or death
due to electrical shock, do not service the unit
and allowing adequate time for the unit to cool down.
•service technician.
•Do not use the heater if the power cord is
damaged. Contact an authorized servicer or
electrician to replace the cord prior to use.
WARNING
INSTALLATION & USE
To avoid property damage, personal injury or
death due to electrical shock, all instructions in this
Installation and Operation manual.
•All local, regional and national electric codes and
local construction codes must be observed in the
installation of the heater.
•The power outlet must be properly polarized and
grounded.
•Be sure the voltage listed on the heater’s
nameplate is the same as the voltage at the
installation site.
•Do not use the heater if the power cord is
electrician to replace the cord prior to use.
•Remove the plug from the power outlet and wait
CAUTION
•Never use with an extension cord or multi-socket.
•Use extreme caution whenever the heater is left
operating and unattended.
•Do not install the heater immediately below a wall
socket outlet.
•Do not use a timer or other device that
automatically turns on the unit.
•Do not use the heater with an external voltage
regulator such as a dimmer or speed controller.
AITONS EQUIPMENT

Infrared Electric Patio Heater Installation & Operation Manual
3
When using electrical appliances, basic precautions
electrical shock and injury to persons, including the
following:
1. Fully read through the operation and assembly
instructions before operating the heater. Be sure to
keep this manual in a safe place for future reference.
2. This heater is designed for outdoor use only.
3. rating plate of the heater corresponds to the local
voltage before you connect the heater. The power
supply to the heater should correspond to the relevant
regulations of the power supply companies and the
regional construction/building code regulations.
4. This heater is hot when in use. To avoid burns do
not let bare skin touch hot surfaces. If provided, use
handles when moving this heater. Keep combustible
materials, such as furniture, pillows, bedding, papers,
clothes and curtains at least 3 feet (1m) from the front
of the heater and keep them away from the sides and
rear of the unit.
5. Extreme caution is necessary when any heater is used
by or near children, and whenever the heater is left
operating and unattended.
6. Always unplug heater when not in use.
7. Do not operate any heater with a damaged cord or
plug or after the heater malfunctions, or has been
dropped or damaged in any manner. Return heater to
authorized service facility for examination, electrical or
mechanical adjustment, or repair.
8. This heater is designed for outdoor use. It is not
intended for use in bathrooms, laundry areas and
similar indoor locations. Never locate heater where it
may fall into a bathtub, pool or other water container.
9. Do not run cord under carpeting. Do not cover cord
with throw rugs, runners or similar coverings. Locate
a tripping hazard. Do not let the cord hang over the
edge of a table or counter, or touch hot surfaces.
10. To disconnect the heater, press the red switch on the
side of the unit to the OFF (O) position, then remove
the plug from outlet.
11. To clean, remove the plug from the power outlet and
12. Connect to properly grounded outlets only.
13. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause an
14. exhaust in any manner. Do not use on soft surfaces,
such as a bed or other furnishings, where openings
may become blocked.
15. Do not use it in areas where gasoline, paint or
16. Use this heater only as described in this manual. Any
other use not recommended by the manufacturer may
17 Always plug the heater into a wall outlet/receptacle.
Never use with an extension cord or re-locatable
power tab (outlet/power strip).
18. This heater is for use with 120 volt power supply. The
cord has a plug as shown at A in Figure 1. An adaptor
as shown in Figure 1 is available for connecting three-
blade grounding type plugs to two-slot receptacles.
The green grounding lug extending from the adaptor
must be connected to a permanent ground such as
a properly grounded outlet box. The adaptor should
not be used if a three-slot grounded receptacle is
available.
Figure 1
Grounding Methods
SAVE THESE INSTRUCTIONS!
AITONS EQUIPMENT

1. Thread the 6 leveling feet into
the holes around the bottom
of the base. (Figure 1)
2. to the base with (4) M8
bolts, using the supplied hex
wrench. (Figure 1)
3. Mount the lamp to the terminal
box with M6 screw and nut.
(Figure 2)
4. Connect the terminal box to
the upper column with (4)
M5 bolts. Be sure to feed the
attached power cord into the
upper column. (Figure 3)
5. Connect the center column to
the upper column by screwing
clockwise. Do not over-
tighten.
6. Plug the power cord into the
supplied power cord extender,
and feed the cord through
the lower column and out the
bottom of the base. Connect
the center column to the lower
column byscrewing clockwise.
Do not over- tighten. (Figure 4)
7. Pull gently on the power cord at the bottom of the base
to keep it taut. Fix the cable to the base with the cable
clamp and (2) M4 screws.
(Figure 5)
ASSEMBLING THE UNIT (Follow diagrams below)
SPECIFICATIONS
MOUNTING AND OPERATING INSTRUCTIONS
Model: IRPH15SS
Voltage: 120V AC
Emitter (Lamp): IRRL15120
(Medium wave infrared)
Power : MAX 1500W
Height: 82 inches (2100mm)
Width: 24 inch base (600mm)
Installation & Operation Manual Infrared Electric Patio Heater
4
Congratulations on your purchase of the Comfort-Aire®
Electric Portable Infrared Patio Heater. This heater utilizes
medium-wave technology that heats people and objects,
not the air, and is unaffected by wind. For best results
and your safety, follow the instructions carefully. DO NOT
modify this product in any way as the manufacturer will not
accept liability for improper use.
AITONS EQUIPMENT

CLEANING AND STORAGE
1. Your heater is a robust aluminum unit with a strong mast and base, and requires
only minimal maintenance. There are no user serviceable parts inside.
2. Before cleaning, turn the unit OFF and remove the plug from the power outlet.
Wait until the heater has cooled down completely.
3. Clean with a lint-free cloth or a soft brush.
4. Never use abrasive cleaners, scrubbing brushes or chemical cleaners on the
heater, column or base.
5. To protect against electric shock and danger of death, do not immerse cord, plug,
or any part of the heater in water or other liquid.
6. Store the heater in a dry location when not in use. Take special care to ensure
that the plug is not subjected to damp or wet conditions during storage.
Infrared Electric Patio Heater Installation & Operation Manual
5
OPERATION
1. Plug the power cord into a GFCI protected outlet
2. Turn ON the heater by pressing the red switch mounted on the side
of the heater to the ON (I) position–it will illuminate red when the heater is ON.
3. To turn OFF the heater, press the red switch on the side of the heater to the OFF
(O) position. The switch will no longer be illuminated.
4. Remove the plug from the power outlet whenever the heater is not being used.
Coil the power cord when the heater is not being used, so that it is not a safety
hazard.
5. Allow the heater to cool down after use.
6. The heater should be stored in a dry location when not in use. Particular care
should be taken to ensure that the plug is not subjected to water or damp
conditions–electric shock could result.
WARNING
PERSONAL INJURY HAZARD
AITONS EQUIPMENT

1. Repairs must be carried out by authorized specialists to ensure electrical safety.
needed.
2. For heating element replacement, contact the manufacturer, its service agent or a
3. Improper repairs could result in death or personal injury to users. USERS
SHOULD NOTATTEMPT TO MAKE REPAIRS.
Owner’s Manual Electric Patio Heater
MAINTENANCE & SERVICE
and methylated spirits or alcohol. Finger marks will burn into quartz causing
premature lamp failure. Outer casing can reach high temperatures.
6
WARNING
PERSONAL INJURY HAZARD
CAUTION
AITONS EQUIPMENT

7
Limited Express Warranty
Comfort-Aire®Infrared Heaters
RESIDENTIAL INSTALLATION/USE:
LIMITED ONE (1) YEAR PARTS EXPRESS WARRANTY
Heat Controller warrants all parts of the Infrared Heaters to
be free from defects in workmanship and materials for normal
residential use and maintenance for one (1) year from the date
of purchase by the original consumer.
LIMITED THREE (3) YEAR EXPRESS WARRANTY ON BULB
Heat Controller warrants the heater bulb to be free from defects
in workmanship and materials for normal residential use and
maintenance for three (3) years from the date of purchase by
the original consumer.
COMMERCIAL INSTALLATION/USE:
LIMITED ONE (1) YEAR PARTS EXPRESS WARRANTY
Heat Controller warrants all parts of the Infrared Heaters to
be free from defects in workmanship and materials for normal
commercial use and maintenance for one (1) year from the date
of purchase by the original consumer.
The Express Limited Warranties described above apply only
when the Infrared Heater is installed and operated per Heat
Controller installation and operating instructions for normal use.
EXCEPTIONS
The Limited Express Warranty does not cover normal
maintenance—Heat Controller recommends that regular
inspection/maintenance be performed according to the
Installation and Operation Manual. Additionally, labor charges,
diagnosticcharges,transportationchargesforreplacementparts,
replacementofthebulb, or anyotherservicecalls/repairsarenot
covered by this Limited Warranty, and are the sole responsibility
of the user. It also does not cover any portion or component of
the system that is not supplied by Heat Controller, regardless of
the cause of failure of such portion or component.
CONDITIONS FOR WARRANTY COVERAGE
•Unit must be operated according to Heat Controller operating
instructions included with the unit and cannot have been
subjected to accident, alteration, improper repair, neglect or
•Installation must be according to Heat Controller installation
instructions
•Rating plate has not been altered or removed
•Unit is not operated in a corrosive environment
•Performance cannot be impaired by use of any product not
authorized by Heat Controller, or by any adjustments or
adaptations to components
•Damage has not been a result of inadequate wiring or
voltage conditions, use during brown-out conditions, or circuit
interruptions
DURATION OF WARRANTY & REGISTRATION
The warranty begins on the date of purchase by the original
consumer. The consumer must register at www.heatcontroller.
com within 90 days of purchase. The consumer must retain a
receipt or bill of sale as proof of warranty period. Without this
proof, the express warranty begins on the date of shipment from
the factory.
REMEDYPROVIDEDBYTHELIMITEDEXPRESSWARRANTY
The sole remedy under the Limited Warranty is replacement of
the defective part. If replacement parts are required within the
period of this warranty, Heat Controller replacement parts shall
beused; anywarranty onthe replacement part(s)shall notaffect
the applicable original unit warranty. Labor to diagnose and
replace the defective part is not covered by this Limited Express
Warranty, and is the responsibility of the user. If for any reason
the replacement part/product is no longer available during the
warranty period, Heat Controller shall have the right to allow a
credit in the amount of the current suggested retail price of the
part/product instead of providing repair or replacement.
LIMITATION OF LIABILITY
1. There are no other express or implied warranties. Heat
Controller makes no warranty of merchantability. We do not
warrant that the unit is suitable for any particular purpose or
can be used in buildings or rooms of any particular size or
and Operation document. There are no other warranties,
express or implied, which extend beyond the description in
this document.
2. All warranties implied by law are limited in duration to the
one-year term of the Parts Warranty. Your exclusive remedy
is limited to the replacement of defective parts. We will not
beliableforanyconsequentialorincidentaldamagescaused
by any defect in thisunit.
3. also have other rights which vary from state to state. Some
states do not allow limitation on how long an implied warranty
lasts or do not allow the exclusion or limitation of incidental or
consequentialdamages,sotheabovelimitationsor exclusions
may not apply to you.
4. No warranties are made for units sold outside the continental
provide a warranty on units sold outside these areas.
5. HeatControllerwillnotbeliablefordamagesifourperformance
regardingwarranty resolution isdelayed by eventsbeyond our
controlincluding accident,alteration,abuse, war,government
HOW TO OBTAIN WARRANTY SERVICE OR PARTS
If you have a warranty claim or service question, contact Heat
Controller at 517-787-2100. Have the model number and date
of purchase available for this call. Do not return your unit to the
store where it was purchased.
Owner responsibilities are set forth in the
instruction manual—read it carefully.

11/2014
subject to change without notice.
change and correction without notice and without incurring obligations. Determining
the application and suitability for use of any product is the responsibility of the installer.
Additionally, the installer is responsible for verifying dimensional data on the actual
product prior to beginning any installation preparations.
AITONS EQUIPMENT • Guelph, ON N1H 6H9 •1-888-744-2911 •www.aitons.com
