Comica CVM-WS60 COMBO User manual

User Manual
CVM-WS60 COMBO
UHF 1-Trigger-2 Flexible Mini Wireless Microphone

Foreword
Main Features
Thanks for purchasing COMICA WS60 COMBO UHF 1-Trigger-2 flexible mini
wireless microphone;
WS60 is a Flexible Mini wireless microphone with dual-transmitter triggered by
one receiver, which charged by three AAA batteries; It utilizes UHF wireless FM
technology and LCD high-resolution lattice screen, 10-level adjustable volume,
and is integrated into LCF（Low cut filter) ,Stereo / Mono switchable audio mode,
MIC/LINE IN Input Mode Automatically,Smartphone/Camera Mode Switch,Sound
pickup dynamic display and other functions; Meanwhile the high-quality
microphone comes with strong shielding anti-noise performance equals
broadcasting level.
To ensure the smooth use and safety of the product, please carefully read this
instruction before using and properly assemble and operate.
. 1-Trigger-2,Universal for Smartphone & Camera
. Built-in Smartphone Holder Design, Flexible and Convenient
. Mini and Compact, Working Distance Up to 60m
(Open Area 60m, 30m in area with obstacle)
. 12 Channels for Multiple Devices Work Together
. M/S Switch, 10-levels Gain Adjustment, Muting Functions
. Real-time Monitor
. AAA Batteries and support external power charging
. Volume Dynamic Monitor
. Lattice LCD Display, High Resolution
Muting Mode
Support
External Power
LCD Screen
1-Trigger-2 12 channels M/S SwitchUniversal for
Smartphone&Camera
Built-in
Smartphone Holder
10-Levels
Volume Adjustment
Real-time Monitor
60m Working
Distance
60M
1

Notice
Package Contents
Transmitter should be used more than 20cm from Receiver, when the distance is
less than 20cm, Receiver’s wireless signal receiving part will take protect action to
shut down wireless signal receiving, then audio may be intermittent, which is
normal;
In the case of stereo/mono mode switch, please preset the mode before using to
avoid the transient interference caused by switching during usage;
The product utilizes TRRS-TRRS output cable, different with most TRS-TRS , or
TRS-TRRS output cables in the marketplace, cannot use it universally;
The working distance will be affected by the surrounding environment. Please try
to keep the environment open without interference during usage;
For Smartphone users, please cut off your phone’s WIFI function and set to‘Filght
Mode’ during the usage to avoid incoming call interference.
(It does not support the partial original recording of android systems, the third-party
APP is recommended to be used in this case);
Please keep this product in dry environment;
Do not expose the device in rain or humid environment, otherwise there will be a
danger of short circuit;
Main Parts:
Lavalier Transmitter（TX）Hand-held Transmitter （HTX）Receiver（RX）
2

3.5mm Mic Audio Input Cable
3.5mm-3.5mm Audio Output Cable
Belt Clip
Wind Muff
Carrying Case
Ball Head
Tabletop Tripod
Micro USB Charging Cable
User Manual
Warranty Card
Accessories:
1
1
2
2
3
3
4
4
5
5
6
6
910
7
7
8
8
9
10
用户使用手册
CVM-WS60 COMBO
UHF 一拖二无线多功能迷你麦克风
3

Components and Instruction
Components
Lavalier Transmitter (TX)
1/4 Connecting Hole
AAA Battery Tray
Belt Clip Connection Hole
LCD Screen
Channel Selection Switch
On-off/Muting Button
Matching / Muting Status Light Indicator
Type-C External Power Interface
MIC/ LINE IN Input Jack
Group Switching Button
LCF (Low Cut Filter) Switch
1
2
3
4
5
6
7
8
9
10
11
2
10 11
3
8
9
7
65
1
4
4

Hand-held Transmitter (HTX)
1
2
3
4
5
Microphone
LCD Display
On-off/ RF Adjustment Button
Group Switching Button
AA Battery Tray
1
2
3
5
4
A B
AB
5

Receiver (RX)
1/4 Connecting Hole
Locking Screw
Smartphone Clamp
AAA Battery Tray
1/4 Connecting Hole
Group A Channel Selection Switch
Group B Channel Selection Switch
On-off Button
Group A Working Status Light Indicator
Group B Working Status Light Indicator
Group A Volume Adjustment Dial
Group B Volume Adjustment Dial
Type-C External Power Interface
3.5mm Audio Output Jack
3.5mm Monitoring Jack
Channel Switching Button
Smartphone/Camera Switching Button
Mono/Stereo Switching Button
LCD Display
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
4
6
11
12
13
14
15
78910
32
1
5
16 17 18 19
6

Lavalier
Transmitter
(TX)
On-off/Muting Button
Long Press
Short Press
Power On/OFF
Muting Mode
(The Mute Mode only works
after the screen lighted up)
Channel Selection Switch
Group Switching Button
LCF Switch
Short Press Channel Selection
Push
Push
Left is Group A
Right is Group B
Is Low Cut Mode
Normal Recording
Function Button Instruction
Hand-held
Transmitter
(HTX)
On-off/ Channel
Selection Button
Channel Selection Button
Long Press Power ON/OFF
Short Press Channel Selection
Push Left Group A
Push Right Group B
A B
low-cut function will filter out the low-frequency part of the audio source, such as the
chirping and crowd noise, and the main audio source will be more crisp. Low cut
divided into low cut in low range and low cut in high range, low range is to filter out
part of the noise, while high range of low cut filter out all noise. Turn off the low cut
to restore the true, the main source will be more vigorous, but it can be adjusted
according to actual needs.
7

Receiver
(RX)
On-Off Button Long
Press Power ON/OFF
Channel Selection Switch
Group Switching Button
Mono/Stereo Switch
Smartphone/Camera
Switching Button
Group Volume Adjustment
Short
Press
Press is to select Group A`s
Channel
Press is to select Group B`s
Channel
Push left to , Open Group A
only
Push
Push
Turn
Turn
Mono Mode
Stereo Mode
Smartphone Mode
Group A volume adjustment
Group B volume adjustment
Camera Mode
Push to middle , Open both
Group A and Group B
Push right to , Open Group B
only
At the limitation of external microphone input, Switch to the mono mode
automatically under smartphone mode ,No Stereo Function
8

10d B
A11 579.125MHz
Screen Display
Lavalier Transmitter
Antenna Icon
Normal Recording
Muting
Low Cut Filter
Normal Recording
Power Indication
Group A/B
Channel
Audio Dynamic Bar Frequency
Hand-held Transmitter
A
B
8 8
Normal Recording Power Indication
Group A/B
Channel
9

05
6
11
9
S
05
6
11
9
S
M
S
Receiver
Group A Signal Strength
Group A Group B
Channel A Channel B
Group A Volume
Group B VolumeGroup A Audio Receiving Dynamic Bar
Group B Audio Receiving Dynamic Bar
Group B Signal Strength Mono Sound：
Stereo Sound：
Smartphone Mode：
Camera Mode：
Power Indication
A/B Mode M/S Mode
Stereo Mode
Smartphone / Camera Mode
10

Indicator Light Instruction
Lavalier
Transmitter
(TX)
Receiver
(RX)
RF
A RF
B RF
A RF: Group A working status light indicator
B RF: Group B working status light indicator
Green Light Keeps on
Green Light Keeps on Normal working status after channel
matched successfully
Red Light Keeps on
Red Light Flickers
Red Light Flickers
Normal Recording Status
（The status works for transmitter only.
The receiver can pick up the sound
when channel matched successfully.）
Muting Mode
Low- power Reminder
Red Light Keeps on Group closed
Green Light Flickers
Channel matching is unsuccessful
Low-power Reminder
11

05
6
11
9
M
10d B
A05 573.125MHz
Switch to Group to “A” OR “B”
Switch the corresponding Group
with the Receiver
（Receiver）
（Receiver）
（Lavalier Transmitter）
Working Status Light Indicator of
Receiver keeps on in Green
Select the appropriate channel
Switch the corresponding
Channel with the Receiver
The matching steps of Receiver and Transmitter
1. Steps of matching single Lavalier Transmitter with
Receiver
1.1 Switch the Receiver’s Group to “A” OR “B”, and select the
appropriate channel
1.2 Switch the Group of lavalier transmitter to 'A' or 'B' and adjust the
channel of 'A' and 'B' corresponding to the receiver. After above
steps, it will be connected automatically
1.3 When the working status light indicator of Receiver keeps on in
GREEN, it matched successfully
12

05
6
11
9
M
A
0 5
Switch to Group "A" or "B"
Switch the corresponding Group
with the Receiver
（Receiver）
（Receiver）
（Hand-held Transmitter）
Working Status Light Indicator of
Receiver keeps on in Green
Select the appropriate channel
Switch the corresponding Channel
with the Receiver
2. Steps of matching single Hand-held Transmitter
with Receiver
2.1 Switch the Receiver’s Group to “A” OR “B”, and select the
channel Switch to Group to “A” OR “B”
2.2 Switch the Group of handheld transmitter to 'A' or 'B' and adjust
the channel of 'A' and 'B' corresponding to the receiver. After
above steps, it will be connected automatically
2.3 When the working status light indicator of Receiver keeps on in
GREEN, it matched successfully
13

05
6
11
9
S
10d B
A05 573.125MHz
10d B
B11 579.125MHz
Switch to Group to “A/B”
（Receiver）
Select Different Channel
3. Steps of matching two Lavalier Transmitters with one
Receiver
3.1 Switch the Receiver’s Group to “A/B” , and select different
channel for different Group
3.2 Switch the Group of each lavalier transmitter to 'A' or 'B' and
adjust the channel of 'A' and 'B' corresponding to the receiver.
After above steps, it will connected automatically
Switch the corresponding
Group with the Receiver
（Lavilier Transmitter A）
Switch the corresponding
Channel with the Receiver
Switch the corresponding
Group with the Receiver
（Lavalier Transmitter B）
Switch the corresponding
Channel with the Receiver
14

05
6
11
9
S
（Receiver）
Green Light Keeps on
Green Light Keeps on
3.3 When the two working status light indicators of Receiver
keeps on in GREEN, it matched successfully
Switch to Group to “A/B”
（Receiver）
Select Different Channel
4. Steps of matching one Lavalier Transmitter and one
Hand-held Transmitter with Receiver
4.1 Switch the Receiver’s Group to “A/B”, and select different
channel for different Group
15

10d B
A05 573.125MHz
B
1 1
Switch the corresponding Group
with the Receiver
（Hand-held Transmitter）
Switch the corresponding Channel
with the Receiver
4.3 When the two working status light indicators of Receiver keeps
on in GREEN, it matched successfully
4.2 Switch the Group of each transmitter to 'A' or 'B' and adjust the
channel of 'A' and 'B' corresponding to the receiver. After above
steps, it will be connected automatically
Switch the corresponding Group
with the Receiver
（Lavalier Transmitter）
Switch the corresponding Channel
with the Receiver
16

Installation and Usage
1.Install batteries into the Transmitter’s battery tray according to their
positive and negative electrode; You can also charge by external
power by inserting the Type-C plug into the Type-C Power Interface
Lavalier Transmitter (TX)
Type-C Plug
POWER 5V
17

2. Insert the 3.5mm audio input cable into the audio input jack.
3. Long press the On-off Button to open the transmitter.
18
