Comica CVM-WS50 User manual

FOR SMARTPHONE
CVM-WS50
USER MANUAL
6-channels Smartphone Wireless Microphone

Foreword
Thank you for purchasing Comica WS50 6-channels smartphone wireless microphone.
WS50 is a creative wireless microphone for smartphone with built-in mobile phones
holders. With built-in lithium polymer batteries, it uses UHF wireless technology and
high-resolution LCD code screen, comes with six channels in total, stepless adjustable
volume at receiving end, and integrated into power monitoring, audio dynamic display
bar, real-time monitoring and other functions; the working distance is up to 60 meters
(30 meters in barrier area), it can assist your phone for video recording and achieve
professional sound effects.
To ensure the smooth use and safety of the products, please read this user manual
carefully before using and properly assemble and operate.
1

Main Features
. 6 Channels, Working Distance Up to 60m (In Open Area, 30m in Barrier Area) ；
. Built-in Metal Material Smartphone Holder；
. LCD Screen for Displaying Channels and Audio Status；
. Stepless Volume Adjustment；
. Real-time Audio Monitor；
. Extendable for Connection with LED Light, Grip, Tripod, Cold-shoe, etc；
. Built-in Rechargeable Lithium Batteries；
. Portable and Light；
WS50A Additional Features: Detachable Electronic Grip, Intelligent Video Operation;
WS50B Additional Features: Detachable Ordinary Grip
WS50C Additional Features: Can be used for live video on table for wireless audio
transmission
6 Channels Working Distance
Up to 60m
Built-in
Smartphone Holder
Stepless Volume
Adjustment
Real-time
Audio Monitor
Lithium Batteries LCD Screen
60M
2

. This product is compatible with both IOS and Android system, and when used with the
iphone 7 or above, you need to use the original adapter cable;
. For smart phones with IOS system (Iphones), this Mic works well either in Audio or
Video mode;
. For the smart phones with Android system, this Mic works well in audio mode, it may not
be compatible with partial smart phones in video mode (Then we suggest you to try the
3rd party APP);
. To avoid signal interference during usage, please set the phone to flight mode;
. The working distance will be affected by the surrounding environment. In the process,
please try to make sure the environment is barrier free and turn off the WIFI of your
smart phone;
. During usage, the receiver should not be close to other UHF transmitters, radio stations
and other devices which may cause interference;
. Please keep this product in dry environment;
. Do not expose the device in rain or humid environment, or there will be a danger of
short circuit;
Notice
3

Packing List
Main Body:
Accessories:
Transmitter Receiver Ordinary Grip
(Only for WS50B)
Electronic Grip
(Only for WS50A)
Tripod on Table
(Only for WS50C)
1. 3.5mm Audio Mic
2.TRRS Audio Output Cable
3. USB Charging Cable
4. Belt Clip
5. Wind Muff
6. Portable Case
7. User Manual
8. Warranty Card
1 2 3 4
5 6 7 8
4

Components
Transmitter
1.Set Button for Channel Selection
2.On-off/Muting Button
3.Working Status Indicator Light
4.Mic Audio Input Socket/ Reset Hole
5.Micro USB Charging Socket
6.Belt Clip Hole
7.1/4 Thread at the Back
Components and Instruction
2
1
3
4
5
7
6
The function of reset hole：When function
program of the product is disorganized and
unable to make normal adjustment or even
shutdown, you can use an appropriate
taper tool to insert the reset hole to realize
the function reset.
5

3
4
5
67
1
2
9
8
10
11
Receiver
1.Set Button for Channel Selection
2.Adjusting Screw
3.On/Off Button
4.Working Status Indicator Light
5.3.5mm Audio Output Socket/ Reset Hole
6.Micro USB Charging Socket
7.3.5mm Monitoring Socket
8.Smartphone Clamp
9.1/4 Thread at the bottom
10.1/4 Thread at the top
11.Volume Adjusting Button
External light and other equipment can be
used on 1/4 thread at the top; Grip can be
used for 1/4 thread at the bottom.
The function of reset hole：When function
program of the product is disorganized and
unable to make normal adjustment or even
shutdown, you can use an appropriate
taper tool to insert the reset hole to realize
the function reset.
6

1
2
Ordinary Grip
1. 1/4 Screw Thread
2. 1/4 Thread at the Bottom
7

Electronic Grip
1. 1/4 Screw Thread
2. Adjustable Screw
3. 1/4 Thread at the Bottom
4. Bluetooth Remote Controller
5. On-off/Function Button of the Remote Controller
1
2
3
4
5
The bluetooth remote controller can be taken down for remote control；
Bluetooth remote controller supports both IOS and Android system；
8

1
2
4
3
Tripod on Table
1. 1/4 Screw Thread
2. Adjustable Screw
3. Stretchable Tripods
4. Direction Control Switch
9

Screen Display Instruction
Receiver:
Transmitter:
Normal Recording
Muting Power Indication
Channel
Audio Dynamic Display Bar
Normal recording Power Indication
Channel
Audio Dynamic Display Bar
10

Function Button Instruction
Long Press for 2
Seconds
Long Press for 6
Seconds
10 minutes later
In photo mode, press for photo shooting; In
video recording mode, first press to start,
press again to finish
Continuous Capture for 3 Seconds
Reset to default, can be matched with
different smartphone
Auto Power-Off
Dial the wheel to
the left/ right
Long Press for 2
Seconds
Short Press
Volume Adjustment
Power On
Insert the Mic line /
Insert a small
object like a pin
Insert the Mic line /
Insert a small
object like a pin
Short Press
Channel Selection（0~5 Channel）
（Take effect when the screen is lighted up）
Power On/Off
Channel Selection（0~5 Channel）
(Take effect when the screen is lighted up)
Audio Output / Reset
Long Press
Audio Recording / Reset
Transmitter
On-off//Muting Button
Long Press
Short Press
Short Press
Power On/Off
Muting Mode (Take effect when the screen is
lighted up）
On-off Button
Set Button
Set Button
Mic Input /
Reset Hole
Audio Output /
Reset Hole
Volume Adjustment Wheel
On-off Button
Matched with the Smartphone
No Operation
Receiver
Electronic
Grip
11

Indicator Light Instruction
Transmitter
Green Light Keeps On
Receiver
Electronic Grip
Red Light Keeps On
Red Light Flickers
Green Light Flickers
Green Light Keeps On
Red Light Flickers
Blue Light Flickers
(After the grip turned on)
Green Light Flickers
Normal Working Status
Muting Mode
Low-power reminder
Channel doesn’t match with the transmitter
Channels matches
Low-power reminder
Grip doesn’t match with the smartphone
Taking pictures/Video Recording
12

1.Connect the belt clip to the connection hole
2.Long press the power button to turn on the transmitter
Installation and Usage
Transmitter:
Power button
13

Audio Dynamic Display Bar
3.Insert the 3.5mm audio input line into the “Mic”socket
4.Target the Mic to the audio source and check whether the transmitter is working
properly according to the audio display bar on the screen
“Mic”socket
14

Channel
5. Short press set button to select the channel
“set”button
15

1.Rotate the four clamps, then adjust the screw to appropriate height, install the phone
in the neutral position; connect one end (black) of the audio output line to OUTPUT
socket, the other end (gray TRRS) to mobile phone audio input socket; A 3.5mm
headset can be inserted in real-time monitoring socket according to the need.
Receiver:
16

When the receiver channel
matches the transmitter, the
green light keeps on.
Power Button
2.Long press the power button to turn on the receiver；
3.Short press set button to make channel consistent with the transmitter, and adjust the
volume to the optimal status through the volume adjusting wheel；
“set” Button
volume adjusting wheel
Receiver ChannelTransmitter Channel
17

5.Go for the normal audio recording;
4.Can be extendable for connection with LED light or other auxiliary equipment;
18
