Comica CVM-VS07 User manual

CVM-VS07
Mini Flexible Plug-In Omnidirectional Microphone
(For GOPRO,Camera,Phone,Stabilizer)
USER MANUAL

Foreword
Packing List
Thanks for purchasing COMICA CVM-VS07 Mini Flexible Plug-in Omnidirectional Microphone. This
item is universal for GoPro, DSLR Camera, Phone and Stabilizer , is a Omnidirectional Microphone with
3.5mm TRRS Plug, 90 Degree Adjustable Audio Recording Direction, Metal Housing Construction and
Excellent Shielding features, which is definetely the best assistant for your video recording;
To ensure bring you a good using experience, please read this manual book carefully before using
and correctly install and operate.
Microphone Windscreen User Manual Warranty Card
CVM-VS07
MiniFlexible Plug-In Omnidirectional Microphone
(ForGOPRO,Camera,Phone,Stabilizer)
USER MANUAL
1

Notice
For the Android system smartphone, the microphone works well in default audio mode,
but default video mode will happen with incompatibility trouble while working with some
smartphone;(Then we suggest you try the 3rd party’s video APP);
For the iOS system phone, the microphone works well in all default audio mode , video
mode, and 3rd party’s APP;
When used with a smartphone, please set it to flight mode to avoid interference;
Do not use this equipment near heat source or interference source, such as radiator,
oven, refrigerator, air conditioner or next to the WIFI AP;
Please use the windscreen while the sound distance is too closed or in outdoor to avoid
sound broken or wind noise;
Do not use the equipment in rain or in a damp environment to avoid short-circuit danger;
Please keep the product in a dry environment;
2

Main Features
. Plug-In Omnidirectional Mic
. 90 Degree Adjustable Recording Direction Construction
. Metal Housing for Excellent Shielding
. Built-in Shock-mount and Gold Plated Capsule
. Mini、Light and Flexibly Universal for GoPro,Camera,Phone,Stabilizer
90 Degree
Adjustment
Shock Absorption
Omnidirectional Metal Housing
for Better Shielding
Mini&Compact
3

Components Instruction
Capsule
Rotary Axis
3.5mm TRRS Plug
①
③
②
①②③
4

Product Installation and Use
1.Windscreen Installation
First Step: Put on the Windscreen Second Step: Normal use
5

2.Work with GoPro
First Step:
Insert microphone into 3.5mm socket
Second Step:
Adjust to right direction
Third Step:
Nomal use
6

3.Work with Camera
First Step:
Insert microphone into 3.5mm socket
Second Step:
Adjust to right direction
Third Step:
Nomal use
7

4.Work with Phone
First Step:
Insert microphone into 3.5mm socket
Second Step:
Adjust to right direction
Third Step:
Nomal use
8

Specification
1.Frequency Response 2.Polar Pattern
-2.0
-20.0
-10. 0
0.0
-2.0
-4.0
-6.0
-8.0
-10.0
-12.0
-14.0
-16.0
-18.0
-20.0
-22.0
-24.0 -25.0
dB rel. 1V/Pa
+5.0
Frequency:
500 Hz :
1000 Hz :
4000 Hz :
8000 Hz :
14000 Hz :
9

3.Technology Parameters
Polar Pattern
Sensitivity
Frequency Response
Signal to Noise Ratio
Maximum SPL
Output Socket
Maximum Rotate Degree
Working Temperature
Storage Temperature
Omnidirectional
-30±2dB
60Hz~18kHz
>75dB
>100dB
3.5mm TRRS Plug
90°
0℃~50℃
-20℃~60℃
10
