Comica CVM-VM10-K1 User manual

Mini & Flexible Smartphone Video Kit
CVM-VM10-K(1,2,3,4)
User Manual

Foreword
Thanks for purchasing Comica Multi-functional Smartphone Video Kit, it's designed in many
dierent combinations for your versatile use, and integrated into multi-functions like: 'Bluetooth
One-touch Control'、‘Exiquisite Smartphone Clamp’、'Extensible with Flexible Combinations'
etc., which can make your shooting more professional.
To ensure the safety of the product, please carefully read the user manual for correct
installation and operation.
Notice
1. Be careful to follow the assembly steps, otherwise, the parts cannot be paired, which will
aect the use.
2. This product has a variety of assembly methods, please assemble correctly according to the
needs of users.
3. Bluetooth remote control is an electronic component. Do not use it in rain or humid environ-
ment.
4. This product has many small parts, please do not swallow it to avoid life-threatening
5. Do not throw away used batteries, so as to avoid environmental pollution.
6. This Bluetooth remote control is small in size, so please do not place it at will, causing loss and
aecting use.
7. Please read the user manual carefully before using.
1

Main Features
. Detachable Electronic Bluetooth Remote Control for One-touch Video Shooting;
. Compatible with both IOS and Android System;
. Exquisite Smartphone Clamp, Easy to Install;
. Extensible with Flexible Combination;
. Fit for External Accessories like Microphones, LED lights, etc;
. All Metal Material with CNC Processing, Solid and Durable;
One-touch
control Support
IOS and Android
Flexible
combination CNC processing
Detachable Bluetooth
remote control Easy to install
2

Mini & Flexible Smartphone Video Kit
CVM-VM10-K(1,2,3,4)
User Manual
CVM-VM10-K1 Package Contents :
Package Contents
1. Microphone
2. Flexible Smartphone Clamp
3. Ordinary Handle Grip (1/4 screw)
4. TRS-TRRS Audio Output Cable for Smartphone
5. WindMu
6. User Manual
7. Warranty Card
1
54 6 7
2 3
3

Mini & Flexible Smartphone Video Kit
CVM-VM10-K(1,2,3,4)
User Manual
1
54 6 7
2 3
CVM-VM10-K2 Package Contents :
1. Microphone
2. Flexible Smartphone Clamp
3. Tripod
4. TRS-TRRS Audio Output Cable for Smartphone
5. WindMu
6. User Manual
7. Warranty Card
4

Mini & Flexible Smartphone Video Kit
CVM-VM10-K(1,2,3,4)
User Manual
1
765 8
2 3 4
CVM-VM10-K3 Package Contents :
1. Microphone
2. Flexible Smartphone Clamp
3. Electronic Handle Grip
4. Handle Grip Screw
5. TRS-TRRS Audio Output Cable for Smartphone
6. WindMu
7. User Manual
8. Warranty Card
5

Mini & Flexible Smartphone Video Kit
CVM-VM10-K(1,2,3,4)
User Manual
1 2 3 4
5
98 10 11
6 7
CVM-VM10-K4 Package Contents :
1. Microphone
2. Flexible Smartphone Clamp
3. Ordinary Handle Grip(3/8 Screw Hole)
4. Handle Grip Screw
5. Connecting Rod
6. Cold Shoe
7. Connecting Screw
8. TRS-TRRS Audio Output Cable for Smartphone
9. Windmu
10. User Manual
11. Warranty Card
6

Installation Instructions
Flexible Smartphone Clamp:
1. Install your smartphone onto the flexible smartphone clamp
7

2. Connect the microphone to the Smartphone clamp
8

1. Please note that you should connect Cable's TRS end to the
microphone, and Cable's TRRS end to the smartphone.
Otherwise it'll not work.
2. While you work with the smartphone with Lightning or Type-C
interface, you should buy(3.5mm-Lightning, 3.5mm-Type-C) and
connect the cable adapter separately.
3. Connect the microphone to your smartphone with TRS-TRRS audio output cable
9

CVM-VM10-K1 Kits :
Install the flexible smartphone clamp to the ordinary handle Grip (with 1/4 Screw ),
then fixing them through smartphone clamp locking screw.
Handle Grip
Smartphone Clamp Locking Screw
10

CVM-VM10-K2 Kits :
Install the flexible smartphone clamp to the tripod, then fixing them through
smartphone clamp locking screw, and adjust to the suitable angle for shooting.
Smartphone Clamp Locking Screw
Tripod Adjusting
Screw
11

CVM-VM10-K3 Kits :
Install the smartphone clamp to the electronic handle grip, lock them through
smartphone locking screw.
Smartphone Clamp Locking Screw
12

CVM-VM10-K4 Kits :
1. Install the cold shoe, connecting thread screw,ordinary thread screw and
connecting rod to ordinary handle grip(with 3/8 Screw )
3/8 Screw
1/4 Screw
13

2. Install the flexible smartphone clamp to ordinary handle grip(with 3/8 Screw ),
then lock them through smartphone clamp screw
Smartphone Clamp Locking Screw
14

Bluetooth Remote control Instruction
First Step: Start the Bluetooth Remote Control
Press and hold for 2 seconds to start the Bluetooth remote control. When the
blue light flickers, find and connect the ViewFlex-H on the smartphone
Bluetooth device. If it is connected, the blue light will go out; if it is not connect-
ed, the blue light will flicker once every second
15

Second Step: Functional operation
Photo Mode:
1. (In the Bluetooth remote control state) When the phone is connected to the
ViewFlex-H Bluetooth device, adjust the smartphone to the photo mode. At this
time, the Bluetooth remote control button can replace the smartphone photo
button. Short press once, the green light will flicker 3 times and take a picture
16

Continuous shooting function is only used for rear camera
2. Press and hold the Bluetooth remote control button for three seconds, when the
green light is on, release the button, and the green light flickers 3 times, the
smartphone enters the automatic continuous shooting mode (The continuous
shooting time lasts for 3 seconds, and the number of photos is subject to the
smartphone)
17

Bluetooth Disconnection:
1. Automatic disconnect
After 10 minutes of no operation, Bluetooth remote
control automatically turns o.
2. Manual disconnect
Press and hold the Bluetooth remote control button
for 6 seconds. When the blue light is on and start
flickering once every second, the smartphone is
disconnected from the Bluetooth remote control, and
you can reconnect dierent smartphones
Video Mode:
Enter the smartphone video mode, short press the Bluetooth remote control
button, the smartphone starts recording, press the Bluetooth remote control
button again, then the green light flickers 3 times and the video recording ends
18

Specification
Microphone
Polar Pattern
Frequency Range
Sensitivity
Signal/Noise
Maximum SPL
Operating Voltage
Cardioid
100Hz~20kHz
-33dB ±2dB
>75dB
>105dB
1.0V~10V
Polar Pattern Frequency Response
0°
90°270°
180°
-2.0
-20.0
-10.0
125 Hz:
250 Hz:
500 Hz:
1000 Hz:
2000 Hz:
4000 Hz:
8000 Hz:
50
40
30
20
-20
-30
-40
-50
10 100 1000 10000
10
-10
0
1/3 Smoothed Frequency Response (Hz)19
