Command access MLRK1-HAG User manual

A. B. C.
D. E.
Kit Includes Tools Required
#2 Phillips head screwdriver
Motor Mount w/ MM4S series Module
2- 40389 Allen Screws w/ 40390 Washers
1- 50030 8’ Power Lead
1- 40389 3/32” Allen Wrench
1- 50944 MM4S Socket Lead
A.
B.
C.
D.
E.
MLRK1-HAG/LAW/LSDA1
INSERT Instructions
The Command Access MLRK1 is a field installable motorized latch-retraction kit for:
#20227_G
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
• MLRK1-LAW - Lawrence Hardware 8000 series devices
• MLRK1-PDQ - PDQ 6200 series devices
• MLRK1-HAG - Hager 4500 series devices
• MLRK1-SQ - Stanley QED 1000 & 2000 seires devices
• MLRK1-LSDA1 - IDN LSDA 9000
1

Technical Information
US customer support 1-888-622-2377 | www.commandaccess.com | CA customer support 1-855-823-3002
Average Latch Retraction Current: 2 Amp
Average Holding Current: 250 mA
High Torque Mode
Average Latch Retraction Current: 900 mA
Average Holding Current: 215 mA
Standard Torque Mode
SPECIFICATIONS
• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Direct wire run - no relays or access control
units in-between power supply & module
MM4S SWITCHES
2
STANDARD TORQUE
HIGH TORQUE
PTS PROGRAMMING OFF
PTS PROGRAMMING ON
1OFF
OFF
ON
ON
2 Beeps
3 Beeps
5 Beeps
6 Beeps
Beeps Explanation Solution
Over Voltage
Under Voltage
Retraction or dogging failure
PUSH TO SET
> 30V unit will shut down. Check voltage & adjust to 24 V.
< 20V unit will shut down. Check voltage & adjust to 24 V.
After 1st fail: 5 beeps then immediately attempts to retract again.
After 2nd fail: 5 beeps with pause in-between for 30 seconds then device
attempts to retract again.
After 3rd fail: 5 beeps every 7 minutes, device will not attempt to retract.
To Reset: Depress bar for 5 seconds at any time.
Device is recording it’s new position and power mode after the 6th beep.
Troubleshooting & Diagnostics
4 Beeps Failed Sensor Verify all 3 sensor wires are installed correctly. Replace sensor if problem
persists by contacting o󰀩ce.
Step 1 - Select your preferred torque mode (ships in standard torque). Press the
device push pad to the desired setting. (We recommend to fully depress
and release 5%, giving the device room for changing door conditions.)
Step 2 - While depressing the push pad, apply power. (i.e. presenting the credential
to the reader).
Step 3 - Continue to keep the pad depressed, the device will beep 6 times. After the
beeps have stopped, release the pad and the adjustment is now complete.
If not to your liking repeat the 3 steps.
Setting PTS
**Important Info**
Make sure to set PTS before finishing installation
2

3
Ceiling Tile
Legend
Standard Placement
Optional Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT
Recommended Power Supplies:
All Command Access exit devices & field installable kits have been thoroughly
cycle tested with Command Access power supplies at our factory.
Electrified Exit Device
Installation Example
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002

4
1
Remove head cover.
1. Remove filler plate.
2.
Remove (2) screws securing base rail to housing.
3. Slide off housing, exposing baserail and push pad.
4.
If your device has dogging, remove it with steps 6 & 7.
if your device doesn’t, please skip ahead 3 steps.
5.
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
Flip over the push pad and remove (2) phillips screws
securing dogging assembly to baserail.
6.
Installation Instructions

5
1
2
Remove dogging assembly and place aside.
7. Remove (2) screws from back of the push pad.
8.
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
Remove push pad end cap
9. Depress the push pad to extend dogging hole.
Slide motor mount attaching hook into
dogging hole.
10.
Release push pad and line up holes on baserail
with holes on motor mount underneath.
11.
12
Install the provided (2) screws and washers with the
allen wrench to secure the motor moun to the baserail.
12.
CONTINUED

6
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
1
2
Re-install the push pad end cap with (2) screws.
13. Slide housing back onto baserail, being cautious
not to pitch any wires
14.
While sliding housing back on, make sure the
motor bracket fits between the exsiting groves.
15. Confirm motor has seated properly by seeing if the
bottom bracket is sitting flush on the baserail.
16.
Attach to power and test to confirm
motor is functioning.
17.
1 2
Re-install (2) screws securing base rail to housing.
18.
CONTINUED

7
US CUSTOMER SUPPORT1-888-622-2377 | WWW.COMMANDACCESS.COM | CA CUSTOMER SUPPORT 1-855-823-3002
Re-install filler plate being cautious of wires.
19. Re-install the head cover.
20.
Hook up to power. Depress push pad & set PTS adjustment.
21.
CONTINUED
Setting PTS
Step 1- Select your preferred torque mode (ships in standard torque) Press the device push pad to the
desired setting. (Recommend to fully depress and release 5%, giving the device room for
changing door conditions.)
Step 2- While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3- Continue to keep pad depressed, the device will beep 6 times. After the beeps have
stopped, release the pad and now the adjustment is complete. If not to your liking repeat the
three steps.
Step 4- Once you found the correct location, ip the dip switches to o󰀨 to lock programming.
MM4S SWITCHES
2
STANDARD TORQUE
HIGH TORQUE
PTS PROGRAMMING OFF
PTS PROGRAMMING ON
1OFF
OFF
ON
ON
remembering to turn the Programming Switch to the off position when completed.
