Command access SLP-UL-M-KIT User manual

SLP-UL-M-KIT
Doc # 20094_E
INSTALLATION INSTRUCTIONS
Visit our website for more details
www.CommandAccess.com
U.S. Customer Support
1-888-622-2377
Canada Customer Support
1-855-823-3002
A.
Kit Includes
A. 1- Motor Mount Assembly w/ MM4S series module
B. 2 -Phillips Screws
C. 1 - Push & Go Connector
D. 1- MM4S switch program sticker
E. 1 - 5/64” Hex Wrench
F. 1 - 5/32” Drill Bit
G. 1 - 8’ Lead w/ VD Connector
Tools Required
• Power Drill
The Command Access SLP-UL-M-KIT is a eld installable motorized latch-pullback kit for the
Sargent 80 series.
B. C. D. E. E.
Scan or Click here
Installation Video
F. G.

Visit our website for more details
www.CommandAccess.com
U.S. Customer Support
1-888-622-2377
Canada Customer Support
1-855-823-3002
TECHNICAL INFORMATION
MM4 S witcheS
PTS Video
Click or Scan
2 Beeps
3 Beeps
5 Beeps
6 Beeps
B eepS e xplanation S olution
Over Voltage
Under Voltage
Retraction or Dogging
failure
Push to Set
> 30V unit will shut down. Check voltage & adjust to 24 V.
< 20V unit will shut down. Check voltage & adjust to 24 V.
Device physically binding during retraction or pulled from the dogged position.
Device is recording it’s new position and power mode after the 6th beep.
trouBleShooting & DiagnoSticS
4 Beeps Failed Sensor Verify all 3 sensor wires are installed correctly. Replace sensor if problem
persists by contacting oce.
Step 1 - Press the device push pad to the desired setting. (Recommend to fully depress and
release 5%, giving the device a little room for changing door conditions.)
Step 2 - While depressing the push pad, apply power. (i.e. presenting the credential to the
reader).
Step 3 - Continue to keep pad depressed, the device will beep 6 times. After the
beeps have stopped, release the pad and now the adjustment is complete.
If not to your liking repeat the three steps. That’s all there is to it.
Setting ptS
Make sure to set PTS before nishing installation!
**Important Info**
• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Average Latch Retraction Current: 2 Amp
• Average Holding Current: 250 mA
High Torque Mode
• Average Latch Retraction Current: 600 mA
• Average Holding Current: 150 mA
Low Torque Mode
1. After 1st fail: 5 beeps then immediately attempts to retract again.
2. After 2nd fail: 5 beeps with pause in-between for 30 seconds then device
attempts to retract again.
3. After 3rd fail: 5 beeps every 7 minutes, device will not attempt to retract.
To Reset: Depress bar for 5 seconds at any time.
ON
OFF
OFF
OFF
ON
OFF
Low Torque
Standard Torque
PTS programming locked
ON ON High Torque
1
S witch p rogram
2
• Average Latch Retraction Current: 900 mA
• Average Holding Current: 215 mA
Standard Torque Mode- S hipS S tandard
SpecificationS
Add MM4S Program
sticker

Ceiling Tile
Legend
Standard Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT
electrifieD exit Device
InstallatIon ExamplE
recommenDeD power SupplieS:
All Command Access exit devices & field installable kits have been thoroughly cycle tested with
Command Access power supplies at our factory.
For more information click here or go to our website

STEP 1 - Disassemble Exit Device
A. Remove End Cap & Filler Plate
B. Remove (4) screws from baserail
C. Partially slide push pad o approx. 2-3”
D. Using 5/32” drill bit. Open up the (2) back screw holes #3 & 4.

E. Continue sliding push pad half way out of the base rail so activating bracket is accessible. Next,
remove metal rod and AB mount can be put aside.
STEP 2 - Install Motor Mount
A. Attach the link assembly to the end of the activating bracket. Next, place activating
bracket into center of the motor mount.
C. Re-install metal rod securing activating bracket to motor mount.
B. Secure link assembly to activating bracket with Hex wrench provided.
Activating Bracket
Metal Rod
AB Mount
Link Assembly
Baserail

STEP 3 - Install MM3 & Reassemble Device
A. Slide push pad with motor kit back into the device. Also, the ller plate must be slid in at same time.
B. Make sure Latch retractor is pressed down so push pad slides over it.
C. Re-install original screws in holes 1 & 2. Install new screws provided in holes 3 & 4.
Step 1-Select your preferred torque mode (ships in standard torque) Press the
device push pad to the desired setting. (Recommend to fully depress and
release 5%, giving the device room for changing door conditions.)
Step 2-While depressing the push pad, apply power. (i.e. Presenting the
credential to the reader).
Step 3-Continue to keep pad depressed, the device will beep 6 times. After
the beeps have stopped, release the pad and now the adjustment is
complete. If not to your liking repeat the 3 steps.
Setting ptS
Step 4-Once you found the correct location, ip the dip switches to o to lock programming.
ON
OFF
OFF
OFF
ON
OFF
Low Torque
Standard Torque
PTS programming locked
ON ON High Torque
1
S witch p rogram
2
