Command access PD15 User manual

Installation Instructions
Read all instructions completely before beginning.
PD15 CVR Exit Device

Step #1
Prepare lock stile.
38-7/8 (987) From Bottom of
Door to Center Point.

Step #2
Install Rod & Case assembly into active stile.
Secure with 2 ea. 8-32 x 1/4 cap screws.
Active Stile
Install spacer per drawing.

Step #3
Install Top & Bottom Strikes.
Secure with 2 ea. 8-3/4(19) self tap screws.
Active Stile

Step #4
Install Trim and Cylinder.
Install one 8-32 pan head screw partially to suit nominal wall thickness of 1/8” or 3/16”
Install pad assembly and rotate clockwise until it locks into position. Install single
8-32 x 1-15/16” screw and tighten.
NOTE:
Use 8-32x5/16 pan head on 1/8” wall thickness
Use 8-32x5/3/8 pan head on 3/16” wall thickness
NOTE: If trim or cylinder are
not being used, skip this step.
Active Stile

Step #5
NOTE: or for heaver wall extrusion
use 8-32 x 1 3/8 SOC HD MS
Panic Attachment.
- Remove front and rear end base covers by releasing 6-32x3/16(5) & 12-24x1-1/4(32) fillister head
screw through chassis and one 8-32x1-1/4 head machine screw, secure inactive end with single
1/4-20x1/2(13) round head machine screw (phil.) with semsthrough inactive base plate.
- Using the wire access hole as a guide, drill a 3/8" hole into the inactive stile to allow for wire
access.
- Proceed by re-installing base cover on each end of panic base.

Step #6
Adjust Top & Bottom Bolts.
Adjust Top & Bottom Bolts allowing for 1/2”(13) of bolt to extend from vertical stile.
Install bolt guides top & bottom with (2) each #10x1/2(13) flat head self-tapping screws.
Depress push bar, top bolt should lock in the retracted (unlocked) position. If locking does not
occur readjust bolts in half turn increments until locking occurs. Verify operation by fully depressing
touch bar to achieve dogging or full retraction of bolts.
Top Bolt Adjustment:
Release top and bottom bolts by depressing trigger on top bolt guide assembly.
Position top bolt 1/2”(13) from top edge of active stile.
Bottom Bolt Adjustment:
Fully depress push bar, retracting top and bottom rods. Adjust bottom bolt per detail “B”
Manual Check:
With top and bottom bolts fully retracted, depress trigger release, rods will then extend to the locked position.
Install trip bracket and adjust set screw so that when door closes, top bolt guide trigger contacts set
screw and allows bolts to extend.
Active Stile
x
x
x
x

22901 La Palma Ave.
Installation Flow Chart
Yorba Linda, CA 92887
P: 888-6-ACCESS
F: 888-622-2302
www.commandaccess.com
[e-mail]
PWM202 HO Wiring Instructions
Specifications
Operating Voltage:
Input Wires to PWM202HO:
Output Wires from PWM202HO:
Power Supply:
26.5V +/- 15%
Red (+), Black (-)
Yellow (+), Green (-)
PS1N
Wire Run Guidelines:
For best results we recommend that your maximum wire run not exceed the following:
18ga.= 700’ 16ga. = 1000’ 14ga. = 1250’ 12ga. = 1500’.
Note: A longer wire run than the maximum distances listed may result in an increased delay time
and possible solenoid “drop out” due to voltage drop.
Hook up:
The unit comes with an easy plug-in connector that connects to the solenoid and an easy plug-in
connector for the red & black wires that connect to the positive and negative leads from the power
supply (see fig. 1).
Polarization note:
The unit is polarized. In the event the input leads (red & black) are reversed the PWM202HO will
not work. Simply reverse the leads and the unit should function correctly.
++
_
red
com
black
yellow
green
PWM202 HO Solenoid
PS1N
Power
Supply
Step #7
