Command access PD25-M-SVR User manual

PD25-M-SVR
Doc # 20207_B
1
INSTALLATION INSTRUCTIONS
Visit our website for more details
www.CommandAccess.com
U.S. Customer Support
1-888-622-2377
Canada Customer Support
1-855-823-3002
A.
PD25 Includes
A. 6’ 2-Pin Power Lead (not included with PD26
B. Top & Bottom Latch
C. PD25-M Device w/ MM module
D. Rod Guides
E. Strike
F. SVR Rods
G. End Cap
H. 4 - Screw Pack
Tools Required
• Cordless Drill
The PD25-M-SVR (PD26 Mechanical) is our architectural grade 1 exit device. Electried it comes equipped
with motorized latch retraction utilizing our PTS “Push to Set” technology.
B. D.
E.
F.
C.
G. H.

2
Visit our website for more details
www.CommandAccess.com
U.S. Customer Support
1-888-622-2377
Canada Customer Support
1-855-823-3002
TECHNICAL INFORMATION
MM4S S witcheS
2 Beeps
3 Beeps
5 Beeps
6 Beeps
B eepS e xplanation S olution
Over Voltage
Under Voltage
Retraction or Dogging
failure
Push to Set
> 30V unit will shut down. Check voltage & adjust to 24 V.
< 20V unit will shut down. Check voltage & adjust to 24 V.
Device physically binding during retraction or pulled from the dogged position.
Device is recording it’s new position and power mode after the 6th beep.
trouBleShooting & DiagnoSticS
4 Beeps Failed Sensor Verify all 3 sensor wires are installed correctly. Replace sensor if problem
persists by contacting oce.
Setting ptS Make sure to set PTS before nishing installation!
**Important Info**
• Input Voltage: 24VDC +/- 10%
• Wire gauge: Minimum 18 gauge
• Direct wire run - no relays or access control units
in-between power supply & module
• Average Latch Retraction Current: 2 Amp
• Average Holding Current: 250 mA
High Torque Mode
• Average Latch Retraction Current: 600 mA
• Average Holding Current: 150 mA
Low Torque Mode
1. After 1st fail: 5 beeps then immediately attempts to retract again.
2. After 2nd fail: 5 beeps with pause in-between for 30 seconds then device
attempts to retract again.
3. After 3rd fail: 5 beeps every 7 minutes, device will not attempt to retract.
To Reset: Depress bar for 5 seconds at any time.
ON
OFF
OFF
OFF
ON
OFF
Low Torque
Standard Torque
Programming locked
ON ON High Torque
1
S witch p rogram
2
• Average Latch Retraction Current: 900 mA
• Average Holding Current: 215 mA
Standard Torque Mode- S hipS S tandard
SpecificationS
Step 1-Select your preferred torque mode (ships in standard torque) Press the device push pad to the
desired setting. (Recommend to fully depress and release 5%, giving the device a little room
for changing door conditions.)
Step 2-While depressing the push pad, apply power. (i.e. presenting the credential to the reader).
Step 3-Continue to keep pad depressed, the device will beep 6 times. After the beeps have stopped,
release the pad and now the adjustment is complete. If not to your liking repeat the three steps.
That’s all there is to it.
Step 4-Once you found the right location, switch the dip switches to o to lock in programming.
rex S witch
Rating: .5A @24VAC
Conguration:
Green - Common (C)
Blue - normally open (no)
Gray - normally Closed (nC)
OPTIONAL

3
Module
Ceiling Tile
Legend
Optional Module
Placement
Standard Placement
Optional Placement
Module
GREEN
CHANNEL 1
LED
NORMALLY OPEN
DRY CONTACT FROM
ACCESS CONTROL
SYSTEM
NO VOLTAGE
LOCKING
HARDWARE
+
-
CAT
ElEctrifiEd Exit dEvicE
Installaon Example
RECOMMEND POWER SUPPLIES:
All Command Access exit devices & field installable kits have been thoroughly cycle tested with
Command Access power supplies at our factory.
• PS210
• PS220/220B
• PS440B
• PS480B
• PS1
• PS2/2B
• PS5-4
• PS5-6
For more informaon click here or go to our website

4
Electried Exit Device
Installation Example

5
Electried Exit Device
Installation Example

6
TemplaTe for SVr exiT deVice
DRILL (4) 15/32” THRU DOOR
6-15/16”
1” DIA.
THRU DOOR
2-1/8” DIA
THRU DOOR
1-25/64”
VERTICAL
CENTERLINE
EXIT DEVICE PUSH BAR 41” FROM
FINISHED FLOOR
TEMPLATE FOR RIM EXIT DEVICES
VERTICAL
CENTERLINE
FOR LOCATION OF 7700 & 7760V SERIES RIM & VERTICAL ROD DEVICE USING
PULL TRIM, OR ESC LEVER HANDLE TRIM
FOR THRU BOLTING - DRILL (2) 9/32” DIA. HOLES THRU DOOR
For Location of PD25/26 RIM & Vertical Rod Series using ET26NL or ET26
Lever trim

7
TemplaTe for SVr laTcheS
ALEX
ELACSNOITPIRCSED
NOISREVTINUISNA
1 : 1
IF PRINTED TO SIZE inches ver. 1.0 rev. 03/16
TEMPLATE FOR NON-FIRE RATED TOP AND BOTTOM
CHASSIS ASSEMBLY
APPLICABLE FOR 2200, 7700 & 9800 SERIES PAGE 1 OF 1
---
22901 La Palma Ave. Yorba Linda CA 92887 USA Tel: [phone] FAX: [phone] Website: ccommandaccess.com Email:[email protected]
FOLD ON D
OTTED LINE STRIKE 227
1-11/16”
BOTTOM CHASSIS
SHOWN WITH MOUNTING
SCREW HOLES
TOP CHASSIS
SHOWN WITH MOUNTING
SCREW HOLES
FOR
LOCATION ON
THE DOOR PLEASE REFER
TO PANIC BAR TEMPLATE
1-3/8”
1-3/8”
2”
2-1/8”
2”
1/4”
1/4”
2-1/4”
3-1/2”
4”
3-1/2”
4”
2-1/4”
11/16”
11/16”
COVER

8
2-1/2”
8”
6-15/16”
1-25/64”
3-15/32”
