CommScope LC User manual

The CommScope Secure LC and RJ45 patching solution provides a color-coded locking system that prevents unauthorized access or disconnection
of fiber and copper ports at the work outlet, patch panel, and switch. Visit us on the web at www.commscope.com
© 2017 CommScope, Inc.
All rights reserved
Duplex LC and RJ45 Port Blocker and Locking Patch Cord Instructions
1
1
2
2
3
34
4
Fully insert port blocker into
adapter
Fully insert port blocker into
adapter
Port is secure
Port is secure Insert key into port blocker to
release
Insert key into port blocker to
release
Remove port blocker and key
from port
Remove port blocker and key
from port
Instruction Sheet 860635155
Issue 1, May 2017
Unlock
Unlock
RJ45 Copper Port Blocker
Duplex LC Fiber Port Blocker
Lock
Lock
®
Page 1 of 2

1
1
2
2
3
34
4
Fully insert jumper into adapter
with lock in the unlocked position
Fully insert jumper into adapter
with lock in the inlocked position
Secure jumper by fully pressing
in the lock to the locked position
Port is secure
Secure jumper by fully pressing
in the lock to the locked position
Port is secure
Insert key into jumper to release lock
Insert key into jumper to release lock
Pull key and lock to the un-lock
position and remove key
Pull key and lock to the un-lock
position and remove key
Instruction Sheet 860635155
Issue 1, May 2017
Unlock
Unlock
RJ45 Copper Locking Patch Cord
Duplex LC Fiber Locking Patch Cord
Lock
Lock
Page 2 of 2
