CommScope SYSTIMAX VisiPatch CPC5562 User manual

Material ID 860 365 873
Issue 2, July 2007
Field Termination of VisiPatch®1-Pair Patch Cord
© 2007 CommScope, Inc.
All rights reserved
Printed in U.S.A.
Page 1
2 Pages
How to Contact Us
•To find out more about SYSTIMAX®Solutions, visit us on the web at http://www.systimax.com/
•For technical assistance regarding SYSTIMAX products:
−Within the United States, contact your local account representative or SYSTIMAX
technical support at 1-800-344-0223. Outside the United States, contact your local
account representative orAuthorized BusinessPartner.
−Within the United States, report any missing or damaged parts to SYSTIMAX Customer
Service in Omaha, NE, at 1-866-539-2795. Outside the United States, contact your local
account representative orAuthorized BusinessPartner.
Verify Parts
Verify contents of kit from parts shown below.
Top Cover Contact Base
A
nti-Sna
g
Cover Wire Guide
This product is covered by one or more of the following U.S. patents or their foreign equivalents:
6,106,329, 5,915,989, 5,911,594, 6,403,885, 6,379,194, 6,302,699, 6,276,972, 6,118,075, 6,242,698, 5,718,604, 6,302,728,
6,284,980, 6,227,886, 6,159,020, 5,915,992.

860 365 873
Instruction Sheet
Page 2
2 Pages
Assembly Instructions
Wire placed
in guide
Light blue
Dark blue
Dark blue Light blue
A
cceptable
Wire Placement Unacceptable
Wir
e
Pl
ace
m
e
n
t
Wires must
cross-over
Wires do not
cross-over
1. Remove approximately 2 inches (51 mm) of outer sheath from patch cord.
2. Insert cord into wire guide as shown. Conductors must cross before exiting wire guide (see example
of acceptable and unacceptable wire placement).
Anti-snag
cover
C
ontact base
Latch must fit int
o
slot in wire guide
IDCs must
insert into
grooves in
wire guide
Slot
Grooves
3. Position anti-snag cover and push down to seat on wire guide.
4. Insert contact base, being sure latch is seated in slot and IDCs are seated in grooves.
Trim wire ends using
small wire cutters
Opening for
front latch to
seat into Opening for
rear latch to
seat into
Front latch
Rear latch
Top cover
5. Trim ends of conductors back to wire guide approximately as shown.
6. Install top cover being sure that both front and rear latches engage in openings in wire guide.
