Mobile Internet PC Features Guide
1800 Series
Including:
• Model-SpecificFeatures
• Upgrade Information
The information in this guide is subject to change without notice.
COMPAQCOMPUTERCORPORATION SHALL NOT BE LIABLE FORTECHNICALOR
EDITORIALERRORSOROMISSIONSCONTAINED HEREIN; NOR FOR INCIDENTALOR
CONSEQUENTIALDAMAGESRESULTING FROMTHE FURNISHING, PERFORMANCE, OR
USEOFTHISMATERIAL.
This guide contains information protected by copyright. No part of this guide may be photocop-
ied or reproduced in any form without prior written consent from Compaq Computer Corporation.
© 1999 Compaq Computer Corporation.All rights reserved. Printed in the U.S.A., Brazil,
Canada, Japan, Korea, Singapore, Taiwan, and the U.K. Compaq and Presario are registered in the
U.S. Patent and Trademark Office.
Microsoft, MS-DOS, andWindows are registered trademarks of Microsoft Corporation.
The software described in this guide is furnished under a license agreement or nondisclosure
agreement. The software may be used or copied only in accordance with the terms of
the agreement.
Product names mentioned herein may be trademarks and/or registered trademarks of their respec-
tive companies.
120223-001
Purchase Date ___________________
Store Name _____________________
Computer Model No. ______________
Computer Serial No. _______________
Port1800.pm6 3/25/99, 4:34 PM1

Table of Contents i
Contents
CHAPTER 1
Using This Guide
Text Conventions...................................................................................................................1-1
Special Messages .................................................................................................................1-2
Locating Help........................................................................................................................1-2
Glossary ........................................................................................................................1-2
Index .............................................................................................................................1-2
Troubleshooting.............................................................................................................1-2
Understanding Your Service and Support Options ..........................................................1-3
Comments about this Guide ..................................................................................................1-3
CHAPTER 2
Introducing Your Mobile Internet PC
Checking Your Connections...................................................................................................2-1
Front of Your Mobile Internet PC............................................................................................2-2
Using Your Keyboard to Access the Internet...........................................................................2-5
Internet Zone Buttons ....................................................................................................2-5
Reprogramming Your Internet Zone Buttons ..........................................................................2-7
Disabling and Enabling the Internet Zone Buttons ..........................................................2-7
Left Panel of Your Mobile Internet PC ....................................................................................2-8
Right Panel of Your Mobile Internet PC ..................................................................................2-9
Back Panel of Your Mobile Internet PC.................................................................................2-10
Bottom of Your Mobile Internet PC.......................................................................................2-11

ii Table of Contents
Inserting the Battery ...........................................................................................................2-12
Removing the Battery ......................................................................................................... 2-13
Charging the Battery........................................................................................................... 2-13
Battery Charging Time................................................................................................. 2-13
Spare or Extra Batteries .............................................................................................. 2-13
Plugging In Your Computer to AC Power.............................................................................. 2-14
Unplugging the Computer from AC Power ........................................................................... 2-14
CHAPTER 3
Mobile Internet PC Features
Turning On Your Mobile Internet PC ...................................................................................... 3-1
Turning Off Your Mobile Internet PC Properly ........................................................................ 3-1
Standard Off Mode ........................................................................................................ 3-1
Full Off (Main Power Off) Mode...................................................................................... 3-2
Recovering from a Locked Program or System...................................................................... 3-2
Recovering from a Locked Program............................................................................... 3-2
Recovering from a Locked System ................................................................................ 3-3
Using the Numeric Keypad.................................................................................................... 3-4
Using the Scroll Button .........................................................................................................3-5
Understanding Your Computer Status Lights ......................................................................... 3-5
Understanding Your Status Display ....................................................................................... 3-6
Using the Function Keys ....................................................................................................... 3-7
User-Programmable Keys.............................................................................................. 3-8
Adjusting the Volume............................................................................................................3-9
Adjusting the Volume Using Windows............................................................................ 3-9

Table of Contents iii
Using Disqplay2.....................................................................................................................3-9
Playing Audio CDs Using Disqplay2...............................................................................3-11
Using Repeat Track......................................................................................................3-12
Using Repeat All ..........................................................................................................3-12
Setting Up Your TV-Out Connection .....................................................................................3-13
Connecting and Enabling TV-Out..................................................................................3-13
Setting Up Your Television Format ...............................................................................3-14
Adjusting the Television Screen ...................................................................................3-14
Switching Between Displays ........................................................................................3-15
Introducing Your SuperDisk Drive (available on select models) ............................................3-15
Features of Your SuperDisk Drive ........................................................................................3-15
Using Your SuperDisk Drive.................................................................................................3-16
Inserting a Diskette......................................................................................................3-16
Ejecting a Diskette.......................................................................................................3-16
Manually Ejecting a Diskette........................................................................................3-17
Creating a Startup SuperDisk Diskette .........................................................................3-18
Write-Protecting a Diskette..........................................................................................3-18
Formatting a SuperDisk Diskette..................................................................................3-19
SuperDisk Copy Disk ...................................................................................................3-20
SuperDisk Accelerator (available on select models)......................................................3-20
Handling and Storing Diskettes ....................................................................................3-21

iv Table of Contents
CHAPTER 4
Learning About Your Modem
Performance Features .......................................................................................................... 4-1
Identifying Your Modem........................................................................................................ 4-1
56K ITU V.90 Standard.......................................................................................................... 4-2
Understanding Point-to-Point Connections............................................................................ 4-2
CHAPTER 5
Connecting Your Mobile Internet PC to a Network
Setting Up a Network............................................................................................................5-1
Hardware Requirements................................................................................................ 5-1
Hardware Installation .................................................................................................... 5-1
Installing the Network Protocols .................................................................................... 5-2
Sharing Folders .................................................................................................................... 5-4
File Security .................................................................................................................. 5-4
Creating a Shared Folder............................................................................................... 5-4
Sharing a Folder............................................................................................................ 5-5
Sharing Printers.................................................................................................................... 5-5
Setting Up Printer Sharing ............................................................................................. 5-5
Connecting to a Shared Printer...................................................................................... 5-6
Disabling Printer Sharing............................................................................................... 5-6
Mapping a Network Drive ..................................................................................................... 5-7
CHAPTER 6
Upgrading Your Mobile Internet PC
Adding More Memory ........................................................................................................... 6-1
Installing Memory Expansion Modules........................................................................... 6-1
What Are PC Cards?..............................................................................................................6-3
PC Card Types ...................................................................................................................... 6-3
Inserting a PC Card............................................................................................................... 6-4

Table of Contents v
Removing a PC Card .............................................................................................................6-5
Compaq-Compatible PC Cards ..............................................................................................6-6
Using Network PC Cards .......................................................................................................6-6
PC Card Software..................................................................................................................6-7
Configuring PC Cards.....................................................................................................6-7
Vendor-Provided PC Card Software................................................................................6-8
Index

v
iTable of Contents

Using This Guide 1-1
Chapter 1
Using This Guide
Thank you for buying a Compaq Mobile Internet PC. This Features Guide will help
you to familiarize yourself with the features of your Internet PC, as well as
information on how to upgrade your computer.
Please take a moment to familiarize yourself with the special text and messages
used throughout this guide.
Text Conventions
The examples below explain the specially formatted text used in this guide.
•Keyboard key names appear in bold type: Home, End, Backspace, Tab
•Keyboard keys that must be pressed at the same time to perform a task appear
in bold type with a plus (+) between the key names: Ctrl+Home
•Drives appear as capital letters: drive C
•Folder names appear with initial capital letters: Favorites
•File names appear in italics with an initial capital letter: Setup.exe
•Command line statements appear in lower case bold type: a:\install
•Names of icons appear in bold type followed by a picture of the icon:
My Computer Gicon
•Menu items appear in bold type: Programs, Accessories

1
-2 Using This Guide
Special Messages
The following words and symbols have special meaning in this guide.
*HINT: Helpful hints that will make using your computer easier and faster.
+NOTE: Important information concerning the operation of your Internet PC.
`CAUTION: Failure to follow directions may result in equipment damage or loss of
data.
aWARNING: Failure to follow directions may result in bodily harm or loss of life.
Locating Help
Compaq provides you with several resources to help you learn about your Internet
PC. These resources include the following:
Glossary
Computer terms that may be unfamiliar to you are identified in the glossary.
Index
The index is a comprehensive list of the topics covered in this guide.
Troubleshooting
The Troubleshooting section shows how to fix many common computer-related
issues.

Using This Guide 1-3
Understanding Your Service and Support Options
Your Internet PC is equipped with several helpful programs that will aid you in
identifying and solving common computer problems.
If you need further technical support, visit the Compaq Web site at:
www.compaq.com
Compaq Technical Support telephone numbers are listed in the Limited Warranty
Statement.
+NOTE: Locate the model and serial numbers for your computer before you call
technical support. Write these numbers down for future use.
Comments about this Guide
Compaq Computer Corporation welcomes comments and suggestions you may
have concerning this guide. Send correspondence to the following address:
COMPAQ COMPUTER CORP
ATTN: DOCUMENTATION PROGRAM MANAGER
MAIL CODE 060504
20555 SH 249
HOUSTON TX 77070
+NOTE: This address is for comments and suggestions only. It is not for the purpose
of obtaining technical assistance.

1
-4 Using This Guide

Introducing Your Mobile Internet PC 2-1
Chapter 2
Introducing Your Mobile Internet PC
Checking Your Connections
Your Computer Connections
Connections
1AC Adapter 3Modem Cable
2Battery

2
-2 Introducing Your Mobile Internet PC
Front of Your Mobile Internet PC
The following buttons, lights, and controls are located on the front of your
computer:
Front of Your Computer
Front Components
1Display Release Latch 6Speakers
2Display 7Left TouchPad Button
3Power Button 8Scroll Up/Down Button
4Keyboard 9Right TouchPad Button
5TouchPad -Model Number

Introducing Your Mobile Internet PC 2-3
Internet Zone Buttons and Lights
Internet Zone Buttons and Lights
1AC Adapter Light 7Instant Search Button
2Caps Lock Light 8Online MarketPlace Button
3Instant Internet Access Button 9Retail Central Button
4Instant E-Mail Button -Num Lock Light
5My Presario Instant Access Button qScroll Lock Light
6Power Button

2
-4 Introducing Your Mobile Internet PC
Front of Your Computer
Front Components
1Previous Track Button 7Battery Gauge
2Next Track Button 8Disqplay2On/Off Button
3Sleep Status Icon 9Volume Down Button
4Power Status Icon -Volume Up Button
5Battery Charging Status Icon qPlay/Pause Button
6Disqplay2Status Icon wStop Button
Refer to the Understanding the Status Display section in this guide for more details
about the icons found on the display.

Introducing Your Mobile Internet PC 2-5
Using Your Keyboard to Access the Internet
The Compaq Internet Zone buttons provide quick, easy access to the Internet.
Internet Zone Buttons
The Internet Zone buttons, located at the top of the keyboard of your Mobile
Internet PC, automatically connect you to the Internet. Before using these buttons,
you must have access to the Internet. These buttons give you quick access to the
most frequently used Internet activities. These buttons are programmed to do the
following:
Internet Zone
Button United States All Other Countries Outside
the United States
3
Instant Internet Access provides your
daily start point to the Internet. It
connects you to a personalized Web
page filled with local weather, news,
sports, and financial information.
Instant Internet Access is your daily
start point to the Internet. It connects you
to a personalized Web page filled with
local weather, news, sports, and
financial information.
2Instant E-Mail provides one-touch
access for sending and reading your
e-mail.
Instant E-Mail opens the Microsoft
Outlook Express e-mail program. For
AOL subscribers, this button opens your
AOL e-mail account.
$
$$
$
My Presario is your instant connection
to Compaq for product information,
helpful hints, performance updates,
service, and more.
My Presario is your direct link to the
Compaq Help Web site for quick answers
to your computing questions.
©
©©
©Instant Search accesses a default Web
site that helps you locate information on
the Internet.
Instant Search opens a search engine
Web site that helps you locate
information on the Internet.

2
-6 Introducing Your Mobile Internet PC
Internet Zone
Button United States All Other Countries Outside
the United States
*
**
*
Online MarketPlace takes you to an
electronic shopping experience. Compaq
has partnered with several companies to
provide you with the convenience of
catalog shopping at the touch of a
button.
Instant Answer connects you to a Web
page that is a central location for solving
problems and answering questions.
°
°°
°Retail Central provides an instant
connection to your computer store and a
variety of leading consumer companies.
Instant E-Commerce takes you to an
electronic shopping experience. Compaq
has worked with several companies to
provide you with the convenience of
catalog shopping at the touch of a
button. In some regions, the Featured
Web site button replaces the Instant
E-Commerce button.

Introducing Your Mobile Internet PC 2-7
Reprogramming Your Internet Zone Buttons
You can reprogram the Internet Zone buttons to reflect your personal preferences.
The Easy Access Internet Zone ¸icon is located on the Windows Taskbar. It
can also be reached by clicking the Start button, then Programs and choosing
Reprogram Easy Access Buttons.
To reprogram your Internet Zone buttons, complete the following steps:
1. From the Status bar, right-click the Easy Access Internet Zone ¸icon and
choose Reprogram Easy Access Buttons.
2. From the Compaq Easy Access Button Settings window, click the button you
wish to change.
3. Follow the instructions provided.
Disabling and Enabling the Internet Zone Buttons
You may turn off all Internet Zone buttons from the Easy Access Button program.
When turned off, no Internet Zone buttons will operate. The Easy Access Internet
Zone ¸icon located on the Taskbar will appear with a red X on top. You can
still access the button functions if you click the Easy Access Internet Zone ¸
icon.
To disable the Internet Zone buttons, complete the following steps:
1. From the Windows Taskbar, right-click the Easy Access Internet Zone ¸
icon.
2. Click Disable Easy Access Buttons.
To enable the Internet Zone buttons, complete the following steps:
1. From the Windows Taskbar, right-click the Easy Access Internet Zone ¸
icon.
2. Click Enable Easy Access Buttons.

2
-8 Introducing Your Mobile Internet PC
Left Panel of Your Mobile Internet PC
The following components are located on the left panel of your computer:
Left Panel of Your Computer
Left Panel Components
1Security Slot 4CD or DVD Manual Eject Hole
2CD or DVD Drive 5Diskette Drive*
3CD or DVD Eject Button 6Diskette Eject Button*
* A SuperDisk drive is available on some models. Refer to the Mobile Internet PC Features section of this guide
for more information about the optional SuperDisk drive.

Introducing Your Mobile Internet PC 2-9
Right Panel of Your Mobile Internet PC
The following components are located on the right panel of your computer:
Right Panel of Your Computer
Right Panel Components
1Battery Compartment 5Microphone Jack
2PC Card Eject Button 6Modem Port*
3PC Card Slot 7Ethernet Port*
4Headphone Jack
* Available on select models.
