Competition Electronics Turbo35-GFX User manual

Competition Electronics, Inc
3469 Precision Dr.
Rockford, IL 61109
1
Competition Electronics, Inc
Turbo35-GFX LiPo
User’s Manual Addendum

Introduction
This enhancement makes it possible to charge 1,2 and 3 cell LiPo battery packs ith the T35-GFX.
No you can have the accuracy and reliability of the T35-GFX for LiPo charging, as ell as
NimH/NiCd charging.
afety Considerations
WARNING Please read before using your Turbo35-GFX LiPo charger/discharger
IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS
• You must read these safety instructions and arnings before using the Turbo35-GFX LiPo battery charger.
• Lithium Polymer batteries are volatile. Failure to read and follo the belo instructions may result in fire,
personal injury and damage to property if charged or used improperly.
• Competition Electronics, Inc, its distributors or retailers assume no liability for failures to comply ith these
arnings and safety guidelines.
General Guidelines and Warnings
1) Use only the LiPo mode, never the NimH/NiCd mode, to charge and discharge LiPo batteries. Failure
to do so may a cause fire, hich may result in personal injury and property damage. Like ise, do not
attempt to ork ith NimH/NiCd packs in LiPo mode.
2) Never charge batteries unattended. When charging LiPo batteries you should al ays remain in constant
observation to monitor the charging process and react to potential problems that may occur.
3) If at any time you witness a battery starting to balloon or swell u , discontinue the charging rocess
immediately, disconnect the battery and observe it in a safe lace for a roximately 15 minutes. This
may cause the battery to leak, and the reaction ith air may cause the chemicals to ignite, resulting in
fire.
4) Since delayed chemical reaction can occur, it is best to observe the battery as a safety precaution. Battery
observation should occur in a safe area outside of any building or vehicle and a ay from any
combustible material.
5) Wire lead shorts can cause fire! If you accidentally short the ires, the battery must be placed in a safe
area for observation for approximately 15 minutes. Additionally, if a short occurs and contact is made
ith metal (such as rings on your hand), severe injuries may occur due to the LiPo pack's ability to
supply massive amperage.
6) A battery can still ignite even after 10 minutes.
7) In the event of a crash, avoid any charging or discharging of a LiPo battery until you have placed it in a
safe open area a ay from any combustible material and observed it for approximately 15 minutes.
8) Never store, charge or discharge battery pack inside your car in extreme temperatures, since extreme
temperature could ignite fire.
2

9) Monitor the condition of your LiPo packs and discontinue use hen performance degrades or
changes significantly.
10) OBSERVE PROPER POLARITIES BETWEEN CHARGER AND PACK WITHOUT FAIL.
Charging Process
1) Never charge batteries unattended.
2) Charge in an isolated area, away from other flammable materials.
3) Let battery cool do n to ambient temperature before charging.
4) Do not charge batteries acks in series. Charge each battery pack individually. Failure to do so may
result in incorrect battery recognition and charging functions. Overcharging may occur and fire may be
the result.
5) When selecting the cell count or voltage for charging purposes, select the cell count and voltage as it
appears on the battery label. As a safety precaution, please confirm the information printed on the
battery is correct.
6) Selecting a cell count other than the one printed on the battery (al ays confirm label is correct), can
cause fire.
7) You must check the ack voltage before charging. It is not advisable to attempt to charge any pack
if open voltage per cell is less than 3.3v. If you insist and the per cell voltage is greater than 2.3
volts, the Turbo35-GFX LiPo ill charge the pack at a reduced current for 2 minutes in an attempt
to reach at least 3V per cell. Ho ever, chances are the pack is damaged and ill need replacement.
8) CEI recommends charging at 1C rate or less (one times the mAHr ca acity of the battery), unless the
manufacturer s ecifically recommends otherwise.
Caring for Battery
1) Do not discharge battery to a level below 3V er cell under load. Deep discharge belo 3V per cell can
deteriorate battery performance.
2) Use caution to avoid puncture of the cell. Puncture of cells may cause a fire.
Operating Temperature
Typical Charge temperatures: 32 to 113 degrees F
Typical Discharge temperatures: 32 to 140 degrees F
2) Consult the specific manufacturer's data sheet before charging or discharging a LiPo battery.
2) Let battery cool do n to an ambient temperature before charging.
3) During discharge and handling of batteries, do not exceed 160 degrees F.
3

ignificant Changes in the Turbo-GFX LiPo Charger
In order to add the LiPo capability, the scrolling help message system in the Turbo35-GFX LiPo as
eliminated.
In addition, the number of storable setups for the NimH/NiCd function has been reduced to 5, in order
to free up 5 setups for the LiPo mode.
Ho ever, no other functionality as removed.
Navigating the LiPo screens is no different than navigating the original NimH/NiCd screens, ith this
exception: not all the calculated and measured data produced ith NimH/NiCd packs makes sense ith
LiPo packs, so certain data has been eliminated in the LiPo mode.
Connecting the Turbo35-GFX Lipo to a LiPo Pack
The hazards to both the battery and operator associated ith shorting out or reversing polarity to LiPo
packs make it essential that care is taken ith connections bet een the Turbo35-GFX LiPo and the
pack. Smaller packs, such as transmitter packs or packs used for airplanes often come ith a pin and
socket type connector, or a Dean's connector already assembled to the pack. If the connector ampacity
is sufficient for the discharge rate, it is suggested that you obtain a mating connector and afix it to the
GFX contacts in such a ay that no short or polarity reversal is possible.
Larger packs such as those intended for R/C cars, often have lo resistance, gold-plated barrel-type
connectors. In this case, CEI recommends obtaining the proper mating connectors and connecting them
to the Turbo35-GFX LiPo output leads in such a ay that shorting of the pack is not possible. In this
case, it is recommended that similar proper mating connectors be directly attached to the Turbo35-GFX
LiPo output leads.
For convenience, you can use suitable connectors, such as Dean's connectors, on the sense and po er
leads. Then, make plug-in harnesses for different pack types; terminate the NimH/NiCd harness ith
the usual large and small alligator clips. Terminate the LiPo harness ith a pair of high quality barrel
connectors specifically designed to mate ith the LiPo pack.
CEI DOES NOT recommend using alligator clips or any dissimilar connector to directly connect to the
LiPo pack's recessed terminals. In addition, avoid lots of floppy alligator-clipped connections ith
LiPo packsMake the connections as simple as possible, and as short as practical.
Sense Leads
ALWAYS USE THE SENSE LEADS WITH LiPo PACKS.
If your pack has high current barrel connectors such as those mentioned above, then it is best if you
mate the sense leads ith their respective polarity po er leads directly at the barrel connector. Crimp
or solder both po er and sense lead directly into the mating barrel connector. Soldering is the preferred
method.
In any case, al ays try to connect the sense leads as close to the actual cell contacts as possible, and try
to assure that current through the sense leads does not travel through any more connections than is
4

necessary. For example, if you have bare leads coming from your LiPo pack, make sure both the sense
and po er leads of the Turbo35-GFX LiPo charger connect DIRECTLY to the bare leads, and do not
simply clip or attach the sense lead clips to the po er lead's alligator clips.
Powering up the Turbo-GFX LiPo: electing Cell Type
The first thing you ill notice after the T35-GFX LiPo sho s the sign on screen is the Cell Type
selection screen. Here, you can use the rotary encoder dial to select either NimH/NiCd or LiPo
chemistry. The unit defaults to NimH/NiCd but if you select LiPo and then store the setup, the next
time it ill default to LiPo mode. A scrolling message ill appear at the bottom of the screen
indicating that the T35-GFX LiPo is in LiPo mode.
NimH/NiCd mode
The NimH/NiCd operation mode is unchanged from the previous version, except that there ill be a
scrolling message at the bottom indicating that the unit is in NimH/NiCd mode. Please consult the
original manual, found at .competitionelectronics.com under Turbo35-GFX if you have questions.
LiPo Mode
The Turbo35-GFX LiPo mode allo s charging of LiPo packs consisting of 1, 2 or 3 cells at up to
12000 mAHr rates.
LiPo packs require a constant current charge process hen the voltage is belo 4.2 volts per cell. After
the voltage threshold of 4.2V per cell is reached, the charge mode ill s itch into a constant voltage
mode and maintain the pack voltage at (4.2V times # of cells) until current drops to roughly 3% of the
mAHr setpoint. At this point the charge is terminated.
The Turbo35-GFX LiPo can discharge a LiPo pack at up to a 35 amp rate. The discharge is terminated
hen the pack voltage reaches (3V times # of cells) hile under load.
Charging with the Turbo-GFX LiPo
A charge display page has been added to the Turbo35-GFX LiPo hich is very much like the existing
charge page for NimH/NiCd packs. There are three significant settings for charging/discharging LiPo
battery packs, as follo s:
Max Charge Seconds
This is a user-settable safety time limit that ill shut off the charge and signal an error if the charge
time becomes equal to the setting. It is just another safety device hich may be useful in the event of a
malfunctioning LiPo pack. You should determine the typical charge time for a given LiPo pack at a
given mAHr rate, and then set this just a bit longer.
It is also useful as a ay to put a partial charge into a pack for the purpose of storage.
5

No of Cells
Al ays make sure the number of cells set into this setting agrees ith the number of cells specified on
the LiPo pack.
Charge mAHrs
Set this to the mAHr rating on your LiPo pack label. The Turbo35-GFX LiPo ill charge at the ampere
rate hich ill result in full mAHrs delivered in 1 hours time. For example if you have a 3200 mAHr
pack, set the mAHr setpoint for 3200 and the Turbo35-GFX ill charge at a rate of 3.2 amps.
Some manufacturers of LiPo packs specify the ability to charge at 2C, or even 3C rates. Check your
manufacturer's pack data to determine if this is acceptable to your pack. At the time of this riting it is
generally the case that charge rates higher than 1C can shorten the life of the LiPo pack.
NOTE Unless specifically allowed by the manufacturer of the LiPo pack in question, never
exceed a 1C charge rate.
Under and Overvoltage Considerations
LiPo charge ill be disabled and an error message displayed if the pack voltage exceeds 4.3V per cell
or if is is less than 2.3V per cell.
If the LiPo pack voltage is bet een 2.3V and 3V per cell, the Turbo35-GFX LiPo ill try to charge the
pack at approx. 10% of the mAHr rate setpoint for 2 minutes in an effort to restore the pack voltage to
3V per cell. If the pack does not return to this level after 2 minutes, the charge cycle is terminated and
an error message is displayed.
Discharging with the urbo-GFX LiPo
The Turbo35-GFX LiPo is capable of discharging continuously at up to 35 Amps. For some LiPo
packs, this ill cause the pack to exceed it's maximum safe temperature. Usually, this is around 140
deg F. Exceeding the maximum temperature can cause fire or explosion. Consult the manufacturer's
data sheet for details concerning the maximum temperature for your pack. Al ays observe maximum
discharge rates specified by the manufacturer, as ell. If in doubt contact them and ask them directly.
The Discharge display page contains three settable parameters:
Discharge Amps
Settable bet een .5 and 35 amps. Observe all precautions under “Discharging ith the Turbo35-GFX
LiPo, above.
No of Cells
Al ays make sure the number of cells set into this setting agrees ith the number of cells specified on
the LiPo pack.
6

AIR On/Off
For higher charge rates, the Turbo35-GFX LiPo ill measure actual internal resistance at 121 seconds
into the discharge cycle. AIR measurement is disabled for discharge rates of 10 amps and belo .
Under and Overvoltage Considerations
NOTE: As ith charging, there are under and over voltage checks built in hich ill terminate
discharge if it can be determined that there is an abnormality.
Cycling with the Turbo-GFX LiPo
Cycling in LiPo mode orks as you ould expect; it first runs the LiPo charge and then the LiPo
discharge functions.
toring and Retrieving Program etups
Storage and retrieval of setups orks the same ay as ith the original T35-GFX, ho ever, there are
only 5 setups available in NimH/NiCD mode and 5 setups available in LiPo mode. See the T35-GFX
manual for details.
Generic setups have been provided for both NimH/NiCd and LiPo packs as a starting point and a
convenience to the user. It is the responsibility of the user to understand, select and adjust these setups
to suit specific packs.
This manual and its contents ©2007 Competition Electronics, Inc.
