COMPX TYPE350 Guide

CB-35X
03/24/03
TYPE 350GLASS DOOR DEADBOLT LOCK
915 Sherwood Drive
Lake Bluff, IL 60044
DRAWING#
DATE
Phone: [phone]
Fax: [phone]
1.20
30.5
1.65
41.9
.50
12.7
.85
21.5 CAM IN LOCKED POSITION
.30
7.6
PART NUMBERS:
CB-351 NICKEL FINISH
CB-355 BRASS FINISH
CB-357 SATIN NICKEL FINISH
1.12
28.5
.41
10.4
SET SCREW
TIGHTENS LOCK
TO GLASS DOOR
LOCK SLIPS ON TO
EDGE OF GLASS DOOR
AT ANY LOCATION
NO BORING REQUIRED
