Comtrend Corporation WAP-EN900R User manual

Quick Installation Guide
WAP-EN900R| AC900 Outdoor Access Point
Quick Installation Guide
05-2016 / v1.0

2
Product Information
I-1. Package Contents
1. Access Point
2. Passive PoE Injector
3. Quick Installation Guide
4. Ethernet Cable
5. Wall Mount Screws Kits
6. Pole Mount Ties
7. Power Cord
8. Power Adapter
3
4
1
2
6
5
7
8
I

3
I-2. System Requirements
Existing Ethernet cable, Passive PoE Injector
Computer with web browser for access point configuration
I-3. Hardware Overview
A. LAN1 port with Power over Ethernet (Passive PoE-IN; 48V/1A).
B. LAN2 port with Power over Ethernet (Passive PoE-OUT).
C. SMA connector for optional external antenna.
D. Reset Button.
E. Switch the LAN2 (Passive PoE-OUT) On/Off.
(Default: Off, Push Right)
ALAN1 (PoE-IN)
BLAN2 (PoE-OUT)
EPoE-OUT On/Off
CSMA
CSMA
DReset Button

4
I-4. LED Status
LED Behavior
Power
Blue
The access point is on.
Off
The access point is off.
LAN 1 & 2
Blue
LAN port is connected.
Flashing
Activity (transferring and receiving)
Off
LAN port is unconnected.
Wireless
(Client
mode
only)
Blue
RSSI Signal Strength:
Excellent: 4 LEDs bright
Good: 3 LEDs bright
Medium: 2 LEDs bright
Bad: 1 LED bright
Off
Wireless client mode disabled.
I-5. Reset
If you experience problems with your access point, you can reset
the device back to its factory settings. This resets all settings back
to default.
1. Press and hold the reset button on the access point for at least
10 seconds. Then release the button.
You may need to use a pencil or similar sharp object to
push the reset button.
2. Wait for the access point to restart. The access point is ready for
setup when the LED is blue.

5
I-6. Mounting
The access point includes a mount for wall or pole which requires
some assembly.
Wall Mount
1. Attach the access point to a wall using the included screws and
plugs.
Ensure your access point is securely attached to the wall
mount bracket.
Pole Mount
1. Fix the access point to a pole using the
included stainless tie.

6
The AC900 Long Range 802.11ac Outdoor AP/CPE features a
range of powerful functions:
802.11ac high-speed wireless technology
16 SSIDs for management
SNMP v1/v2c/v3
Your access point can be up and running in just a few minutes. It
can function as a standalone access point (AP mode), as part of
an AP array (Managed AP mode), or as a client bridge for WISP
last-mile services (Client Bridge mode).
II-1. Initial Setup
Do not connect a non-PoE device to the access point’s
LAN2 (PoE-OUT) port. The LAN2 port outputs 48V and can
damage a non PoE device.
1. Connect the access point’s LAN1 (PoE-IN) port to the PoE
injector’s PoE port via Ethernet cable.
2. Connect the PoE injector to a power source using the included
power adapter (DC IN 48/0.4A). Wait a moment for the access
point to start up. The access point is ready when the Power LED
is blue.
3. Use an Ethernet cable to connect the PoE injector’s LAN port to
your network: router or switch. If it’s more convenient for initial
setup, you can connect a computer directly to the access
point’s LAN2 port instead.
II
Quick Setup

7
II-2. AP Mode
1. Enter the access point’s IP address into the URL bar of a web
browser. The default IP is 192.168.2.2. If the AP is connected to
a DHCP server, ensure you use the correct address.
2. You will be prompted for a user name and password. Enter the
default username “admin” and the default password “1234”.
3. You will arrive at the “System Information” screen shown below.

8
The next steps will help you to configure the following basic
settings of the access point:
LAN IP Address
5GHz SSID & Security
Administrator Name & Password
Time & Date
It is recommended you configure these settings before
using the access point.
1. To change the access point’s LAN IP address, go to “Network
Settings” > “LAN-side IP Address”and you will see the screen
below.
2. Enter the IP address settings you wish to use for your access
point. You can use a dynamic (DHCP) or static IP address,
depending on your network environment. Click “Apply” to save
the changes and wait a few moments for the access point to
reload.
When you change your access point’s IP address, you
need to use the new IP address to access the browser
based configuration interface instead of the default IP
192.168.2.2

9
3. To change the SSID of your access point’s 5GHz wireless
network(s), go to “Wireless Settings” > “5GHz 11ac” > “Basic”.
Enter the new SSID for your 5GHz wireless network in the “SSID1”
field and click “Apply”.
To utilize multiple 5GHz SSIDs, open the drop down menu
labelled “Enable SSID number” and select how many
SSIDs you require. Then enter a new SSID in the
corresponding numbered fields below, before clicking
“Apply”.

10
4. To configure the security of your access point’s 5GHz wireless
network(s), go to “Wireless Settings” > “5GHz 11ac 11an” >
“Security”. Select an “Authentication Method” and enter a
“Pre-shared Key” or “Encryption Key” depending on your
choice, then click “Apply”.
If using multiple SSIDs, specify which SSID to configure
using the “SSID” drop down menu.
5. To change the administrator name and password for the
browser based configuration interface, go to “Management” >
“Admin”.
6. Complete the “Administrator Name” and “Administrator
Password” fields and click “Apply”.

11
7. To set the correct time for your access point, go to
“Management” > “Date and Time Settings”.
8. Set the correct time and time zone for your access point using
the drop down menus. The access point also supports NTP
(Network Time Protocol) so alternatively you can enter the host
name or IP address of a time server. Click “Apply” when you are
finished.
You can use the “Acquire Current Time from your PC”
button if you wish to set the access point to the same
time as your PC.
9. The basic settings of your access point are now configured.

12
Browser Based Configuration Interface
The browser-based configuration interface enables you to
configure the access point’s advanced features. The access point
features a range of advanced functions such as MAC filtering,
MAC RADIUS authentication, VLAN configurations, up to 16 SSIDs
and many more. To access the browser based configuration
interface:
1. Connect a computer to your access point using an Ethernet
cable.
2. Enter your access point’s IP address in the URL bar of a web
browser. The access point’s default IP address is 192.168.2.2
(Default IP address applies if No DHCP Server is detected).
3. You will be prompted for a username and password. The
default username is “admin” and the default password is
“1234”, though it was recommended that you change the
password during setup.
If you cannot remember your password, reset the access
point back to its factory default settings. Refer to I-5.
Reset
III
V
v
s
d
s
d

13
4. You will arrive at the “System Information” screen shown
below.
5. Use the menu across the top and down the left side to
navigate.

14
6. Click “Apply” to save changes and reload the access point, or
“Cancel” to cancel changes.
Wait a few seconds for the access point to reload after you “Apply”
changes.

15
Your Device is Now Connected!
IV
III
V
v
s
d
s
d
FOR MORE HELP: For instructions on advanced features, FAQ, etc.,
please visit our online Product Webpage.
For more information:
YouTube: https://www.youtube.com/user/ComtrendConnection
Facebook: https://facebook.com/Comtrend
Website: http://us.comtrend.com/
Support: Visit our website or call 1-877-COMTREND (1-877-266-8736)
