Conrad Electronic FS20 S4 User manual

Version 12/06
OPERATING INSTRUCTIONS

2-/4-channel hand-held
transmitter „FS20 S4“
Item no. 62 30 25

2
Introduction
Dear customer,
Thank you for purchasing this product.
This product meets the requirements of both current national and
European guidelines.
Please read the user manual completely and observe the safety and
operation instructions before using the product!
This user manual belongs to this product. It contains important
information specific to its operation and handling. Please bear
this in mind when passing on the product to a third party.
Therefore keep this user manual for future reference!
All company and product names contained herein are trademarks of
their respective owners. All rights reserved.
For more inquiries, contact or consult our technical service:
Germany: Tel. no.: +49 9604 / 40 88 80
Fax. no.: +49 9604 / 40 88 48
e-mail: [email protected]
Mon. to Thur. 8.00am to 4.30pm
Fri. 8.00am to 2.00pm


3
Table of contents
Page
1. Prescribed use ................................................................................. 4
2. Scope of delivery ............................................................................. 4
3. Explanation of icons ......................................................................... 4
4. Safety instructions ........................................................................... 5
5. Information on batteries/rechargeable batteries ............................ 6
6. Inserting the battery, replacing the battery .................................... 7
7. Control panel .................................................................................... 8
8. Operation .......................................................................................... 9
a) Basic functions (2-channel operation) ..................................... 9
b) Using several transmitters ...................................................... 10
c) Timer functions (2-channel operation) ................................... 10
d) Saving settings ........................................................................ 11
e) Restoring the factory settings ................................................. 12
9. Double number of channels (4-channel operation) ..................... 13
a) Switching between 2-channel and 4-channel operation ....... 13
b) Operation in the 4-channel mode ........................................... 14
c) Timer functions (4-channel operation) ................................... 15
10. FS20 address system basics ........................................................ 16
11. Programming the hand-held transmitter ....................................... 18
a) Setting the house code ............................................................ 18
b) Setting the addresses (2-channel operation) ........................ 19
c) Setting the addresses (4-channel operation) ........................ 21
12. Example of an address assignment ............................................. 22
13. Handling ......................................................................................... 24
14. Maintenance and cleaning ............................................................ 25
15. Disposal .......................................................................................... 26
16. Information on the range ............................................................... 27
17. Declaration of conformity (DOC) .................................................. 28
18. Technical specifications ................................................................ 28

4
1. Prescribed use
The sole purpose of the ‘FS20S4’ 2-/4-channel hand-held transmitter is to
remotely control the various components of the FS20 wireless control
system.
The components are remotely controllable on 2 channels (two buttons per
channel) or 4 channels (one button per channel).
Any use other than the one described above may damage the
product and cause other dangers.
Please read these operating instructions thoroughly and care-
fully, as they contain important information on operating and
handling the product.
2. Scope of delivery
• Hand-held transmitter
• User manual
3. Explanation of icons
The icon with an exclamation mark in a triangle points to
important instructions in this user manual that must be ob-
served.
The ‘hand’ symbol indicates special tips and information on
operation.

5
4. Safety instructions
The product’s guarantee becomes invalid if the product is
damaged as a result of failure to observe these operating
instructions.Wedonotassumeanyliabilityforanyresult-
ing damages!
Nor do we assume liability for damage to property or
personal injury caused by improper use or failure to ob-
serve the safety instructions. In such cases the product’s
guarantee becomes invalid!
• For safety and licensing (CE) reasons any unauthorised alterations to
and/or modification of the product are not permitted.
• Do not use this product in hospitals or medical institutions. Although the
product emits only relatively weak radio signals, these may cause life-
support systems to malfunction. This may also be the case in other
areas.
• Make sure that the product does not get damp or wet. Protect the
product against heat, cold, and direct sunlight while in storage or
operation.
• This product is not a toy. It should be kept out of the reach of children.
The product contains small parts, which may be swallowed (battery).
• Do not leave packaging material lying around. This may become a
dangerous plaything in the hands of children.
• Handle the product with care; knocks, blows or even a fall from a low
height can damage it.

6
5. Information on batteries/rechargeable batteries
• Keep batteries/rechargeable batteries out of the reach of children.
• Make sure that the polarity is correct when inserting the button cell (pay
attention to positive and negative pole).
• Do not leave batteries/rechargeable batteries lying around as they
could be swallowed by children or pets. In such case seek immediate
medical care.
• Leaking or damaged batteries/rechargeable batteries may cause acid
burns, if they come into contact with skin. Therefore, please make sure
you use suitable protective gloves.
• Make sure that batteries/rechargeable batteries are not short-circuited,
taken apart or thrown into fire. They might explode!
• Conventional batteries must not be recharged. They might explode!
• If the device is not used for a longer period of time (for example, when
stored), remove the battery to prevent it from leaking and causing
damage.

7
6. Inserting the battery, replacing the battery
• Open the battery compartment on the rear by turning the battery
compartment cover clockwise slightly using a coin (the arrows are in
the ‘open’ position).
• Insert a ‘CR2016’ lithium button battery, observing the correct polarity.
The plus (‘+’) pole has to point outwards towards you.
• Replace the battery compartment cover and close it by turning it
anticlockwise (position ‘closed’).
• If the LED on the front side of the hand-held transmitter does not light
up when you press the buttons or you find that the range of the hand-
held transmitter decreases, then you need to replace the old battery
with a new one.
Please also see section 8. d).

8
7. Control panel
AControl indicator/LED
1Channel 1, ‘off’ button, or ‘dim down’
2Channel 1, ‘on’ button, or ‘dim up’
3Channel 2, ‘off’ button, or ‘dim down’
4Channel 2, ‘on’ button, or ‘dim up’
The operation above describes the 2-channel operation of the
hand-held transmitter.
The buttons or functions are allocated differently for 4-channel
operation. This is described later on in the user manual.
12
34
A

9
8. Operation
Please note:
In the delivery state the components of the FS20 wireless
control system do not respond to remote control commands.
They must first be addressed according to the instructions
provided in the respective device’s user manual. The setting
of the basic functions is then possible.
a) Basic functions (2-channel operation)
Buttons are pressed quickly (to switch) or longer than 0.4 seconds (to dim).
Right button (2or 4):
Quick press: ‘On’
Long press (>0.4 sec): ‘Dim up’
Left button (1or 3):
Quick press: ‘Off’
Long press (>0.4 sec): ‘Dim down’
The control indicator/LED (A) briefly lights up to signal that a command has
been transmitted.
Now you can program and operate the basic functions of the
FS20 wireless control system components.
Also read the following subsections, if you require an ex-
tended system with several components or you wish to use the
additional functions.

10
b) Using several transmitters
In the delivery state each transmitter in the FS20 wireless control system
has its own, randomly set house code.
If you want to jointly control one or several receivers via different transmit-
ters, you first need to coordinate the transmitters’ house codes.
The same house code must be set for each transmitter, as
described in section 11.
This must be set before programming the receivers for the
first time, as the associated house code is also sent to the
receiver during this procedure.
The transmitters’ channels are already set to the same addresses and only
need to be changed, if required (see sections 5 and 6).
c) Timer functions (2-channel operation)
In order to program a receiver’s timer function you must simultaneously
press the button combination that has been assigned to the receiver for
between 1 and 5 seconds (1 sec to 5 sec) on the hand-held transmitter.
This button combination is used to start as well as to stop the
programming of the timer. For information on how to program
the timer, see the instructions in the receiver’s user manual.
