ContiPressureCheck™
The system for permanent tire pressure monitoring
GB
USA
User manual

2
1 General.................................................................................................................................6
1.1 Information on this user manual ................................................................................ 6
1.2 Liability disclaimer ............................................................................................................ 7
1.3 Copyright ............................................................................................................................... 7
1.4 Abbreviations....................................................................................................................... 8
1.5 Explanation of symbols................................................................................................... 8
1.6 Warnings ................................................................................................................................ 9
1.7 Manufacturer's address.................................................................................................10
1.8 After-sales service ...........................................................................................................10
2 Technical data display ...............................................................................................10
3 Safety.................................................................................................................................11
3.1 Intended use.......................................................................................................................11
3.2 General safety instructions .........................................................................................12
3.3 Particular hazards............................................................................................................13
4 Tool overview ................................................................................................................14
4.1 Operating keys ..................................................................................................................14
5 Mounting the display .................................................................................................15
5.1 Display holder with suction caps for attaching to the windscreen ..........16
5.2 Display holder for screwing to the dashboard...................................................16
5.3 Adjusting the display......................................................................................................17
6 Commissioning .............................................................................................................18
6.1 Start screen.........................................................................................................................18
6.2 Warnings ..............................................................................................................................18
6.3 Automatic Language Query........................................................................................19
6.3.1 Setting the language for automatic language query........................20
6.3.2 Activate/deactivate automatic language query..................................20
Table of Contents
ContiPressureCheckTM

3
7 Operation.........................................................................................................................21
7.1 Safety precautions...........................................................................................................21
7.2 Setup menu.........................................................................................................................22
7.2.1 Open the settings menu .................................................................................22
7.2.2 Navigating the settings menu......................................................................22
7.2.3 Day/night mode ..................................................................................................23
7.2.4 Switching the buzzer ON/OFF......................................................................24
7.2.5 Display brightness ............................................................................................25
7.2.6 Selecting the language....................................................................................26
7.2.7 Selecting units.....................................................................................................27
7.3 Switching between the vehicle view and
the settings menu ............................................................................................................28
7.4 Vehicle view: standard screen pressure/temperature monitor..................29
7.5 General operation without automatic trailer detection) ...............................30
7.5.1 General....................................................................................................................30
7.5.2 Start screen pressure/temperature monitoring..................................31
7.5.3 Switching between pressure, temperature and target
pressure indicator..............................................................................................32
7.5.4 Warning message overview..........................................................................33
7.5.5 Low-level warning messages .......................................................................35
7.5.5.1 Tire sensor defective.....................................................................35
7.5.5.2 No signal..............................................................................................36
7.5.5.3 Pressure dierence ........................................................................37
7.5.5.4 Temperature......................................................................................38
7.5.5.5 Low pressure.....................................................................................38
7.5.6 High-level warning messages ......................................................................39
7.5.6.1 Check sensor.....................................................................................39
7.5.6.2 Very low pressure ...........................................................................40
7.5.6.3 Fast pressure loss............................................................................41
7.5.7 Multiple warnings ..............................................................................................42
7.5.8 Special features when operating on special vehicles .......................44
7.5.9 Automatic Single Wheel Exchange (SWE*) ............................................45
Table of Contents

4
7.6 Operating with Automatic Trailer Learning (ATL*)...........................................46
7.6.1 General....................................................................................................................46
7.6.2 Automatic Trailer Learning with tire position.......................................48
7.6.3 Start screen for automatic trailer learning.............................................49
7.6.3.1 No trailers found with tire sensors..........................................51
7.6.3.2 Special cases with automatic trailer learning....................52
7.6.4 Warning messages in the case of automatic trailer detection .....57
7.6.5 Multiple warnings for trailer tires in the case of automatic trailer
detection................................................................................................................58
7.6.6 Multiple warnings for truck and trailer tires in the case of
automatic trailer detection............................................................................60
7.6.7 Automatic Trailer Learning with Surrounding Observer (SO*).....61
8 Error messages .............................................................................................................63
9 Pressure control indicator .......................................................................................65
9.1 Pressure control indicator operating states........................................................65
9.2 Readjusting the pressure control indicator.........................................................68
10 Cleaning the display ...................................................................................................69
11 Maintenance...................................................................................................................69
12 Disposal ...........................................................................................................................70
12.1 General instructions .......................................................................................................70
12.2 Tire sensor...........................................................................................................................70
12.3 Electrical/electronic components ............................................................................71
12.4 CPC collection point........................................................................................................71
Table of Contents

5
13 Declaration of Conformity .......................................................................................72
14 Certiications..................................................................................................................73
14.1 Radio permit.......................................................................................................................73
14.2 General Operating Permit............................................................................................73
14.3 ADR.........................................................................................................................................73
15 Index ..................................................................................................................................74
Table of Contents

6
General
1 General
1.1 Information on this user manual
The information listed here serves to become familiar with the display
and the ContiPressureCheckTM system and make full use of its functions.
NOTE
►This manual applies to the
ContiPressureCheckTM software package with irmware
(FW) 7.00 or higher.
The user can see this from the software status of the
display or the
Central Control Unit, (CCU).
The software status of the display is indicated by
simultaneously pressing the SET and OK buttons and
must be software (SW version) 03.40 or higher.
As an alternative to the display, the software status of
the CCU can be read using the hand-held tool in the
respective vehicle via the Diagnosis - SW Update menu
and must be software 1.27 or higher.
►If the software of the display or CCU is older, please
contact your CPC supplier or the authorized workshop
that installed the CPC system and have the system
updated
The user manual must always be in the immediate vicinity of the display.
It must be read and observed by everyone who is involved with
●Installation,
●startup and
●operation
of the display and of the ContiPressureCheckTM system.

7
General
1.2 Liability disclaimer
The manufacturer assumes no liability for damage and operational faults
resulting from:
■failure to observe this user manual,
■use for other than the intended purpose,
■faulty installation,
■technical changes and modiications.
1.3 Copyright
This user manual is copyrighted.
This user manual may not be duplicated either wholly or in part without
the express permission of Continental Reifen Deutschland GmbH.

8
General
1.4 Abbreviations
The following abbreviations are used in this user manual:
Abbrevia-
tion: Meaning
ATL* Auto Trailer Learning
CPC ContiPressureCheckTM
SO* Surrounding Observer
SWE* Single Wheel Exchange
HHT Hand-held tool
* Optional functions that are not activated for all CPC systems.
1.5 Explanation of symbols
Warnings in this user manual are also indicated by warning symbols.
The following warning symbols are used in this user manual:
Symbol Meaning
General warning
General instructions and useful suggestions on
handling
Note on observing environmental regulations for
disposal
Electric/electronic components with this symbol
may not be disposed of in the normal household
waste.

9
General
1.6 Warnings
In the current user manual, the following warnings are used:
WARNING
A warning of this hazard level indicates a hazardous
situation.
If the hazardous situation is not avoided, it can result in
serious injuries.
►Follow the instructions in this warning to avoid serious
injuries to persons.
ATTENTION
A warning of this category indicates potential danger to
property.
If the situation is not avoided, it may lead to damage to
property.
►Follow the instructions in this warning to avoid dam-
age to property.
NOTE
►A note contains additional information that is im-
portant for further processing or for simplifying the
procedure step explained.

10
Technical data display
1.7 Manufacturer's address
Continental Reifen Deutschland GmbH
Büttnerstraße 25
30165 Hannover
Germany
www.contipressurecheck.com
1.8 After-sales service
In the case of technical questions on the display, pressure control indica-
tor or the entire ContiPressureCheckTM system, please contact your CPC
supplier or the authorized garage that installed the CPC system.
2 Technical data display
Dimensions (L x W x H) 117 x 107 x 40
4.60 x 4.21 x 1.57
mm
inch
Weight 240
8.47
g
oz
Supply voltage 12/24 V
Number of plugging cycles, min.
Connecting plug diagnosis
Connection plug supply
100
10
cycles
cycles
Number of plugging cycles, min.
Connecting plate holder for the
display
5cycles
Operating temperature -40 to 85
-40 to 185
°C
°F
Readability of the LCD without
restrictions
-20 to 80
-4 to 176
°C
°F
